air conditioning PONTIAC GRAND AM 1999 Owners Manual

3-
yellowblue
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control System with Air
Conditioning
3
-3 Air Conditioning
3
-4 Heating
3
-4 Defogging and Defrosting Windows
3
-5 Rear Window Defogger
3
-6 Ventilation System
3
-7 Audio Systems
3
-7 Setting the Clock for AM-FM Stereo
3
-7 Setting the Clock for All Systems Except
AM
-FM Stereo
3
-7AM-FM Stereo3
-9AM-FM Stereo with Cassette Tape Player
(If Equipped)
3
-12 AM-FM Stereo with Compact Disc Player and
Equalizer (If Equipped)
3
-14 Remote Cassette Tape Player (If Equipped)
3
-16 Theft-Deterrent Feature (If Equipped)
3
-18 Audio Steering Wheel Controls (If Equipped)
3
-19 Understanding Radio Reception
3
-19 Tips About Your Audio System
3
-20 Care of Your Cassette Tape Player
3
-21 Care of Your Compact Discs
3
-21 Care of Your Compact Disc Player
3
-21 Fixed Mast Antenna

yellowblue
3-2
Comfort Controls
With this system, you can control the ventilation and
heating in your vehicle.
Your vehicle also has the flow
-through ventilation
system described later in this section.
Climate Control System with
Air Conditioning
Fan Knob
The left control knob sets the fan speed. To select the
force of air you want, turn the knob. The fan is always
running unless the fan knob is moved to OFF.Temperature Knob
The center control knob regulates the temperature of the
air coming through the system.
Mode Knob
The right control knob changes the functions of
your system.
MAX: Use for maximum cooling. This setting
recirculates much of the air inside your vehicle. It
maximizes your air conditioner's performance and your
vehicle's fuel economy. The air conditioning compressor
will run automatically in this position when it is needed
to help dry the air in the vehicle.
VENT: In this position most of the airflow comes
through the instrument panel outlets. A small amount of
air comes through the floor vents. Set the center control
knob to the temperature desired.
BI-LEVEL: In this position the airflow comes
through the instrument panel outlets and through the
floor outlets. Set the center control knob to the
temperature desired.

yellowblue
3-3
FLOOR: In this position most of the airflow
comes through the floor outlet. The rest of the air comes
through the windshield and side window vents. Set the
center control knob to the temperature desired.
DEFOG: This position divides the airflow
between the floor outlets and the windshield defroster
vent. The air conditioning compressor will run
automatically in this position when it is needed to help
dry the air in the vehicle.
FRONT DEFROSTER: This position directs
most of the airflow through the window defroster vent.
Some of the air goes to the floor outlets. The air
conditioning compressor will run automatically in this
position when it is needed to help dry the air in
the vehicle.Air Conditioning Compressor Button
Press A/C to operate the air conditioner compressor.
The indicator light will glow when the button is pressed
to indicate that the air conditioning system has been
turned on. The fan knob must be set to a speed.
Air Conditioning
The air conditioner and heater work best if you keep
your windows closed while using them. Your vehicle
also has the flow
-through ventilation system described
later in this section.
On very hot days, open the windows long enough to let hot
inside air escape. This reduces the time it takes for your
vehicle to cool down, which should help fuel economy.
On cool, but sunny days, the sun may warm your upper
body, but your lower body may not be warm enough.
You can use BI
-LEVEL with the temperature knob in
the middle and the A/C indicator light glowing. The
system will bring in outside air and direct slightly
warmer air to your lower body.
For normal cooling on hot days, use VENT with the
temperature knob in the blue area and the A/C indicator
light glowing. The system will bring in outside air and
cool it.

yellowblue
3-4 Heating
On cold days, use FLOOR with the temperature knob all
the way in the red area. The system will bring in outside
air, heat it and send it to the floor outlets.
Your vehicle has heat ducts that are directed toward the
rear seat. Keep the area under the front seats clear of
obstructions so that the heated air can reach the rear
seat passengers.
If your vehicle has an engine coolant heater, you can use
it to help your system provide warm air faster when it's
cold outside (0
F (
-18
C) or lower). An engine coolant
heater warms the coolant your engine and heating
system use to provide heat. See ªEngine Coolant
Heaterº in the Index.
Defogging and Defrosting Windows
Your system has two settings for clearing the front and
side windows. For each setting, adjust the temperature
control as desired.
To defrost the front window quickly, rotate the
temperature control knob all the way in the red area. Use
FRONT DEFROST and adjust the fan to the highest
speed. To warm passengers while keeping the front
window clean, use DEFOG.
Your vehicle is equipped with side window defogger
vents. The side window defogger vents are located on
the outside of the side instrument panel vents. To defrost
the side windows, rotate the temperature control knob
all the way in the red area. Use FLOOR and adjust the
fan to the highest speed. To control fogging of the
windows, rotate the temperature control knob all the
way in the red area. Use DEFOG and adjust the fan to
the highest speed.
To defog the side windows while using air conditioning,
use BI
-LEVEL and adjust the fan to the highest speed and
press the A/C button so that the indicator light is glowing.
For added airflow to the side windows aim the side vents
toward the windows and close the center vents.

yellowblue
3-6 Ventilation System
For mild outside temperatures when little heating or
cooling is needed, use VENT to direct outside air
through your vehicle. Your vehicle also has the
flow
-through ventilation system.
Your vehicle's flow
-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the air conditioning
fan is running.Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction, such as leaves. The heater and
defroster will work far better, reducing the chance of
fogging the inside of your windows.

When you enter a vehicle in cold weather, adjust the
mode knob to FLOOR and the fan to the highest
speed for a few moments before driving off. This
helps clear the intake ducts of snow and moisture
and reduces the chance of fogging the inside of
your windows.

Keep the air path under the front seats clear of
objects. This helps air circulate throughout
your vehicle.

6-
yellowblue
6-1
Section 6 Service and Appearance Care
Here you will find information about the care of your vehicle. This section begins with service and fuel information,
and then it shows how to check important fluid and lubricant levels. There is also technical information about your
vehicle, and a part devoted to its appearance care.
6
-2 Service
6
-3 Fuel
6
-5 Fuels in Foreign Countries
6
-5 Filling Your Tank
6
-7 Filling a Portable Fuel Container
6
-8 Checking Things Under the Hood
6
-12 Engine Oil
6
-18 Engine Air Cleaner/Filter
6
-19 Automatic Transaxle Fluid
6
-19 Thermostat
6
-20 Engine Coolant
6
-23 Power Steering Fluid
6
-24 Windshield Washer Fluid
6
-25 Brakes6
-29 Battery
6
-30 Bulb Replacement
6
-35 Tires
6
-45 Appearance Care
6
-46 Cleaning the Inside of Your Vehicle
6
-48 Care of Safety Belts
6
-49 Cleaning the Outside of Your Vehicle
6
-51 Finish Damage
6
-52 GM Vehicle Care/Appearance Materials
6
-53 Vehicle Identification Number (VIN)
6
-54 Electrical System
6
-60 Replacement Bulbs
6
-60 Capacities and Specifications
6
-61 Air Conditioning Refrigerants
6
-61 Normal Maintenance Replacement Parts

yellowblue
6-58
Fuse Usage
3) Left
- Hand Electrical Center-Stop
Lamps, Hazard Lamps, Body
Function Control Module, Cluster,
Climate Control System
4) Right
- Hand Electrical Center-Fog
Lamps, Radio, Body Function
Control Module, Interior Lamps
5) Ignition Switch
6) Not Used
7) Anti
-Lock Brakes
8) Cooling Fan
Mini
-Relays
9) Rear Defog
10) Not Used
11) Anti
-Lock Brakes
12) Cooling Fan
13) HVAC Blower (Climate Control)
14) Cooling Fan
15) Cooling FanFuse Usage
Micro
-Relays
16) Air Conditioning Compressor
17) Not Used
18) Fuel Pump
19) Automatic Light Control
20) Automatic Light Control
21) Horn
22) Daytime Running Lamps
Mini
-Fuses
23
- 32) Spare Fuse Holder
33) Rear Defog
34) Accessory Power Outlets,
Cigar Lighter
35) Anti
-Lock Brakes
36) Anti
-Lock Brakes,
Variable Effort Steering
37) Air Conditioning Compressor,
Body Function Control Module

yellowblue
6-60
Replacement Bulbs
Outside Lamps (Rear) Bulb
Back
-Up Lamps 3156. . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stop Lamp 912. . . . . . . . . . . .
Fascia Rear Cornering Lamps 912. . . . . . . . . . . . . . .
Turn Signal lamps 3156. . . . . . . . . . . . . . . . . . . . . . .
Stop/Taillamps 3157. . . . . . . . . . . . . . . . . . . . . . . . . .
Outside Lamps (Front) Bulb
Halogen Headlamps 9007. . . . . . . . . . . . . . . . . . . . . .
Parking/Turn Signal Lamps 3157NA. . . . . . . . . . . . . .
Side Marker Lamps 194NA. . . . . . . . . . . . . . . . . . . . .
Fog Lamps 880X. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Lamps Bulb
Dome (Base) 561. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome (Uplevel) 212
-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications
Engine Crankcase
2.4L L4 Engine 4.0 quarts (3.8 L). . . . . . . . . . . . . . .
3400 V6 Engine 4.5 quarts (4.3 L). . . . . . . . . . . . . . .
Cooling System
2.4L L4 Engine 11.3 quarts (10.7 L). . . . . . . . . . . . . .
3400 V6 Engine 13.6 quarts (12.9 L). . . . . . . . . . . . .
Refrigerant, Air ConditioningSee refrigerant . . . . .
charge label under the hood.
Fuel Tank15.0 gallons (56.8 L) . . . . . . . . . . . . . . . . .
Tire Pressures, SizesSee Tire
-Loading . . . . . . . . . . .
Information label on the rear driver's
side passenger door.
Wheel Nut Torque100 lb
-ft (140 N´m) . . . . . . . . . .
NOTE: All capacities are approximate. When adding, be
sure to fill to the appropriate level or as recommended in
this manual.
See ªRecommended Fluids and Lubricantsº in
the Index.

yellowblue
6-61 2.4L L4 Engine Specifications
VIN Engine Code T. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type L4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 2.4 Liters. . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-3-4-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 150. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 180F (82C) . . . . . . . . . . .
3400 V6 Engine Specifications
VIN Engine Code E. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 3.4 Liters. . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-6 . . . . . . . . . . . . . . . . . . . . . .
Horsepower
-SE model 170. . . . . . . . . . . . . . . . . . . . .
Horsepower
-GT model 175. . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195F (91C) . . . . . . . . . . .
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same.
If the air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used.
If you're not sure, ask your dealer.
Normal Maintenance
Replacement Parts
Air Cleaner Element
2.4L L4 AC Type A
-1279C . . . . . . . . . . . . . . . . . . . . .
3400 V6 AC Type A
-1279C . . . . . . . . . . . . . . . . . . . .
Engine Oil Filter
2.4L L4 AC Type PF
-44 . . . . . . . . . . . . . . . . . . . . . . . .
3400 V6 AC Type PF
-47 . . . . . . . . . . . . . . . . . . . . . . .
Spark Plugs
2.4L L4 AC Type
41
-963 . . . . . . . . . . . . . . . . . . . . . .
(Platinum Plug) Gap: 0.050 inch (1.27 mm)
3400 V6 AC Type
41
-940 . . . . . . . . . . . . . . . . . . . . .
(Platinum Plug) Gap: 0.060 inch (1.52 mm)
Windshield Wiper Blades (Shepherd's Hook Type)
Passenger's Side 17 inches (43 cm). . . . . . . . . . . . . . .
Driver's Side 22 inches (56 cm). . . . . . . . . . . . . . . . .
Vehicle Dimensions
Length 186.5 inches (474.2 cm). . . . . . . . . . . . . . . . .
Width 70.4 inches (178.7 cm). . . . . . . . . . . . . . . . . . .
Height 54.5 inches (138.4 cm). . . . . . . . . . . . . . . . . . .
Wheelbase 107.1 inches (271.9 cm). . . . . . . . . . . . . .
Front Tread 59.1 inches (150.1 cm). . . . . . . . . . . . . . .
Rear Tread 59.4 inches (150.7 cm). . . . . . . . . . . . . . .

yellowblue
7-17
Part C: Periodic Maintenance
Inspections
Listed in this part are inspections and services which
should be performed at least twice a year (for instance,
each spring and fall). You should let your dealer's
service department or other qualified service center do
these jobs. Make sure any necessary repairs are
completed at once.
Proper procedures to perform these services may be
found in a service manual. See ªService and Owner
Publicationsº in the Index.
Steering, Suspension and Front Drive Axle
Boot and Seal Inspection
Inspect the front and rear suspension and steering
system for damaged, loose or missing parts, signs of
wear or lack of lubrication. Inspect the power steering
lines and hoses for proper hook
-up, binding, leaks,
cracks, chafing, etc. Clean and then inspect the drive
axle boot seals for damage, tears or leakage. Replace
seals if necessary.
Exhaust System Inspection
Inspect the complete exhaust system. Inspect the body
near the exhaust system. Look for broken, damaged,
missing or out
-of-position parts as well as open seams,
holes, loose connections or other conditions which could
cause a heat build
-up in the floor pan or could let
exhaust fumes into the vehicle. See ªEngine Exhaustº
in the Index.
Engine Cooling System Inspection
Inspect the hoses and have them replaced if they are
cracked, swollen or deteriorated. Inspect all pipes,
fittings and clamps; replace as needed. Clean the outside
of the radiator and air conditioning condenser. To help
ensure proper operation, a pressure test of the cooling
system and pressure cap is recommended at least once
a year.
