height PONTIAC GRAND AM 1999 Owners Manual

yellowblue
1-3 Power Lift Seat-Forward/Rearward
Controls (If Equipped)
Move the control lever under the front of the seat to
unlock it. Slide the seat to where you want it. Then
release the lever and try to move the seat with your
body, to make sure the seat is locked into place.
Power Lift Seat-Height Controls
(If Equipped)
The power seat switch is located on the lower, left side
of the driver's seat. Raise the seat by holding the switch
up. Lower the seat by holding the switch down.

yellowblue
1-16
Shoulder Belt Height Adjuster (4-Door Models)
Before you begin to drive, move the shoulder belt
adjuster to the height that is right for you.To move it down, squeeze the release button and move
the height adjuster to the desired position. You can move
the adjuster up just by pushing on the shoulder belt
guide. After you move the adjuster to where you want it,
try to move it down without squeezing the release button
to make sure it has locked into position.
Adjust the height so that the shoulder portion of the belt is
centered on your shoulder. The belt should be away from
your face and neck, but not falling off your shoulder.

yellowblue
1-41
A forward-facing child restraint (C-E) positions a
child upright to face forward in the vehicle. These
forward
-facing restraints are designed to help
protect children who are from 20 to 40 lbs.
(9 to 18 kg) and about 26 to 40 inches (66 to
102 cm) in height, or up to around four years of
age. One type, a convertible restraint, is designed to
be used either as a rear
-facing infant seat or a
forward
-facing child seat.

yellowblue
2-42 Trunk Lamp
The trunk lamp comes on when you open your trunk.
Battery Saver
Your vehicle is equipped with a battery saver feature
designed to protect your vehicle's battery.
When any interior lamp (trunk, mirror reading lamps,
footwell, dome lamp or glove box) is left on when the
ignition is turned off, the battery saver system will
automatically shut the lamp off after 20 minutes.
This will avoid draining the battery.
To reactivate the interior lamps, either:

Lift the driver's door handle, or

Open any door, or

Press any keyless entry transmitter button
(if equipped), or

Press the power door lock switch, or

Press the remote trunk release, or

Switch the dome lamp from OFF to ON.
Mirrors
Inside Day/Night Rearview Mirror
This mirror can be adjusted two ways. First, to adjust
the angle of the mirror, move the mirror to a position
that allows you see to out the back window. To adjust
the height of the mirror, adjust the arm that connects the
mirror to the windshield.
To reduce glare from lights behind you, move the lever
toward you to the night position.

yellowblue
6-28 Brake Wear
The GT Series has four-wheel disc brakes and the
SE Series has front disc brakes and rear drum brakes.
Disc brake pads have built
-in wear indicators that make
a high
-pitched warning sound when the brake pads are
worn and new pads are needed. The sound may come and
go or be heard all the time your vehicle is moving (except
when you are pushing on the brake pedal firmly).
CAUTION:
The brake wear warning sound means that soon
your brakes won't work well. That could lead to
an accident. When you hear the brake wear
warning sound, have your vehicle serviced.
NOTICE:
Continuing to drive with worn-out brake pads
could result in costly brake repair.
Some driving conditions or climates may cause a brake
squeal when the brakes are first applied or lightly
applied. This does not mean something is wrong with
your brakes.
Properly torqued wheel nuts are necessary to help
prevent brake pulsation. When tires are rotated, inspect
brake pads for wear and evenly torque wheel nuts in the
proper sequence to GM specifications.
If you have rear drum brakes, they don't have wear
indicators, but if you ever hear a rear brake rubbing
noise, have the rear brake linings inspected immediately.
Also, the rear brake drums should be removed and
inspected each time the tires are removed for rotation or
changing. When you have the front brake pads replaced,
have the rear brakes inspected, too.
Brake linings should always be replaced as complete
axle sets.
See ªBrake System Inspectionº in Section 7 of this
manual under Part C ªPeriodic Maintenance
Inspections.º
Brake Pedal Travel
See your dealer if the brake pedal does not return to
normal height, or if there is a rapid increase in pedal
travel. This could be a sign of brake trouble.

yellowblue
6-44
NOTICE:
The wrong wheel can also cause problems with
bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper
height, vehicle ground clearance and tire or tire
chain clearance to the body and chassis.
See ªChanging a Flat Tireº in the Index for
more information.
Used Replacement Wheels
CAUTION:
Putting a used wheel on your vehicle is
dangerous. You can't know how it's been used or
how far it's been driven. It could fail suddenly
and cause an accident. If you have to replace a
wheel, use a new GM original equipment wheel.
Tire Chains
NOTICE:
If your vehicle has P225/50R16 size tires, don't
use tire chains. They can damage your vehicle
because there's not enough clearance.
Use another type of traction device only if its
manufacturer recommends it for use on your
vehicle and tire size combination and road
conditions. Follow that manufacturer's
instructions. To help avoid damage to your
vehicle, drive slowly, readjust or remove the
device if it's contacting your vehicle, and don't
spin your wheels.
NOTICE: (Continued)

yellowblue
6-61 2.4L L4 Engine Specifications
VIN Engine Code T. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type L4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 2.4 Liters. . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-3-4-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 150. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 180F (82C) . . . . . . . . . . .
3400 V6 Engine Specifications
VIN Engine Code E. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 3.4 Liters. . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-6 . . . . . . . . . . . . . . . . . . . . . .
Horsepower
-SE model 170. . . . . . . . . . . . . . . . . . . . .
Horsepower
-GT model 175. . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195F (91C) . . . . . . . . . . .
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same.
If the air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used.
If you're not sure, ask your dealer.
Normal Maintenance
Replacement Parts
Air Cleaner Element
2.4L L4 AC Type A
-1279C . . . . . . . . . . . . . . . . . . . . .
3400 V6 AC Type A
-1279C . . . . . . . . . . . . . . . . . . . .
Engine Oil Filter
2.4L L4 AC Type PF
-44 . . . . . . . . . . . . . . . . . . . . . . . .
3400 V6 AC Type PF
-47 . . . . . . . . . . . . . . . . . . . . . . .
Spark Plugs
2.4L L4 AC Type
41
-963 . . . . . . . . . . . . . . . . . . . . . .
(Platinum Plug) Gap: 0.050 inch (1.27 mm)
3400 V6 AC Type
41
-940 . . . . . . . . . . . . . . . . . . . . .
(Platinum Plug) Gap: 0.060 inch (1.52 mm)
Windshield Wiper Blades (Shepherd's Hook Type)
Passenger's Side 17 inches (43 cm). . . . . . . . . . . . . . .
Driver's Side 22 inches (56 cm). . . . . . . . . . . . . . . . .
Vehicle Dimensions
Length 186.5 inches (474.2 cm). . . . . . . . . . . . . . . . .
Width 70.4 inches (178.7 cm). . . . . . . . . . . . . . . . . . .
Height 54.5 inches (138.4 cm). . . . . . . . . . . . . . . . . . .
Wheelbase 107.1 inches (271.9 cm). . . . . . . . . . . . . .
Front Tread 59.1 inches (150.1 cm). . . . . . . . . . . . . . .
Rear Tread 59.4 inches (150.7 cm). . . . . . . . . . . . . . .

yellowblue
9-9
Lap Belt 1-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lap-Shoulder 1-13, 1-29 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Larger Children 1-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Passenger Position 1-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Questions and Answers 1-12 . . . . . . . . . . . . . . . . . . . . . . . .
Rear Comfort Guides 1-32 . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Seat Outside Passenger Positions 1-29 . . . . . . . . . . . .
Rear Seat Passengers 1-29 . . . . . . . . . . . . . . . . . . . . . . . . . .
Reminder Light 1-8, 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing After a Crash 1-54 . . . . . . . . . . . . . . . . . . . . . . . .
Right Front Passenger Position 1-22 . . . . . . . . . . . . . . . . . .
Shoulder Belt Height Adjuster 1-16 . . . . . . . . . . . . . . . . . . .
Smaller Children and Babies 1-36 . . . . . . . . . . . . . . . . . . . .
Use During Pregnancy 1-21 . . . . . . . . . . . . . . . . . . . . . . . . .
Why They Work 1-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Chains 4-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Defects, Reporting 8-12 . . . . . . . . . . . . . . . . . . . . . . . .
Safety Warnings and Symbols iii. . . . . . . . . . . . . . . . . . . . . . .
Scheduled Maintenance 7
-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Scheduled Maintenance Services 7-4 . . . . . . . . . . . . . . . . . . . .
Seat Adjustment 1-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seatback
Latches 1
-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining Front 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seats
Easy Entry 1
-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Front 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Lumbar Support 1-4 . . . . . . . . . . . . . . . . . . . . . . . .
Rear 1-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Restraint Systems 1
-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat Controls 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing a Child Restraint 1-45, 1-47, 1-48 . . . . . . . . . . . .
Second Gear, Automatic Transaxle 2-22 . . . . . . . . . . . . . . . . .
Security Light 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Security System 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service 6-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulletins, Ordering 8-13, 8-14 . . . . . . . . . . . . . . . . . . . . . . .
Manuals, Ordering 8-13, 8-14 . . . . . . . . . . . . . . . . . . . . . . .
Parts Identification Label 6-53 . . . . . . . . . . . . . . . . . . . . . . .
Work, Doing Your Own 6-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Service and Appearance Care 6-1 . . . . . . . . . . . . . . . . . . . . . .
Service and Owner Publications 8-13, 8-14 . . . . . . . . . . . . . .
Ordering in Canada 8-13 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon Light 2-59 . . . . . . . . . . . . . . . . . . . . . . .
Service Publications 8-13, 8-14 . . . . . . . . . . . . . . . . . . . . . . . .
Service Vehicle Soon Light 2-62 . . . . . . . . . . . . . . . . . . . . . . .
Servicing Your Air Bag-Equipped Vehicle 1-28 . . . . . . . . . . .
Sheet Metal Damage 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift Lever 2-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shifting
Automatic Transaxle 2
-20 . . . . . . . . . . . . . . . . . . . . . . . . . .
Into Park (P) 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Out of Park (P) 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shoulder Belt Height Adjuster 1-16 . . . . . . . . . . . . . . . . . . . . .
Signaling Turns 2-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Skidding 4-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound Equipment, Adding 3-19 . . . . . . . . . . . . . . . . . . . . . . . .
Spare Tire, Compact 5-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
