wipers PONTIAC GRAND AM 1999 Owners Manual

yellowblue
2-15
Ignition Switch
CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons. A child or
others could be injured or even killed. They could
operate power windows or other controls or even
make the vehicle move. Don't leave the keys in
the vehicle with children.
With the ignition key in the ignition switch, you can turn
the switch to four positions.
OFF (A): Before you put the key into the ignition
switch, the switch is off. It is the only position from
which you can remove the key. This position locks your
ignition and transaxle. A warning chime will sound if
you open the driver's door when the ignition is off and
the key is in the ignition.
ACC (Accessory) (B): This position unlocks the
transaxle. It also lets you use things like the radio and
windshield wipers when the engine is not running. To
use ACC, turn the key clockwise. Use this position if
your vehicle must be pushed or towed, but never try to
push
-start your vehicle.
ON (C): This position is where the key returns after you
start your engine and release the switch. The switch
stays in ON when the engine is running. But even when
the engine is not running, you can use ON to operate
your electrical power accessories and to display some
instrument panel warning lights.
START (D): This position starts the engine. When the
engine starts, release the key. The ignition switch will
return to ON for normal driving.

yellowblue
2-32 Windshield Wipers
You control the windshield wipers by moving the stalk
with the wiper symbol on it up or down.
For a single wiper cycle, push the stalk down to MIST, then
release it. For more cycles, hold the stalk down longer.For steady wiping at low speed, move the stalk up to the
LO position. For high
-speed wiping, move the stalk up
further, to HI. To stop the wipers, move the stalk to OFF.
You can set the wiper speed for a long or short delay between
wipes. This can be very useful in light rain or snow.
Move the stalk to INT, then rotate the inner band,
labeled INT ADJ, and choose the delay you want.
Rotate the inner band up for shorter delay times between
wiper cycles. Rotate the band down for a longer delay
time between wiper cycles.
Remember that damaged wiper blades may prevent you
from seeing well enough to drive safely. To avoid
damage, be sure to clear ice and snow from the wiper
blades before using them. If they're frozen to the
windshield, carefully loosen or thaw them. If your blades
do become damaged, get new blades or blade inserts.
Heavy snow or ice can overload your wiper motor.
A circuit breaker will stop the motor until it cools.
Clear away snow or ice to prevent an overload.

yellowblue
2-33 Windshield Washer
To wash your windshield, push in the button at the end
of the stalk until the washers begin.
CAUTION:
In freezing weather, don't use your washer until
the windshield is warmed. Otherwise the washer
fluid can form ice on the windshield, blocking
your vision.
When you release the button, the washers will stop, but
the wipers will continue to wipe for about three times or
will resume the speed you were using before.

yellowblue
6-54
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle
unless you check with your dealer first. Some
electrical equipment can damage your vehicle
and the damage wouldn't be covered by your
warranty. Some add
-on electrical equipment
can keep other components from working as
they should.
Your vehicle has an air bag system. Before attempting to
add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Windshield Wipers
The windshield wiper motor is protected by a circuit
breaker and a fuse. If the motor overheats due to heavy
snow, etc., the wiper will stop until the motor cools. If
the overload is caused by some electrical problem, have
it fixed.
Power Windows
A circuit breaker in the fuse panel protects the power
windows. When the current load is too heavy, the circuit
breaker opens and closes, protecting the circuit until the
problem is fixed.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers
and fusible links. This greatly reduces the chance of
damage caused by electrical problems.
Look at the silver
-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure to
replace a bad fuse with a new one of the identical size
and rating.
There are three fuse blocks in your vehicle: two
instrument panel fuse blocks and the engine
compartment fuse block.
There are four spare fuses located in the left instrument
panel fuse block for your use.
Instrument Panel Fuse Blocks
There are two fuse panels for your vehicle. One is
located on the driver's side of the instrument panel and
the other is located on the passenger's side.

yellowblue
9-12
Warning Devices 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Lights, Gages and Indicators 2-50 . . . . . . . . . . . . . . .
Warranty Information 8-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washer Fluid, Windshield 6-24 . . . . . . . . . . . . . . . . . . . . . . . .
Washing Your Vehicle 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weatherstrips 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel
Alignment 6
-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nut Torque 5-24 , 6-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used Replacement 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrench 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auto-Down 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Windshield Washer 2
-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 2-33, 6-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Level Check 7-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wiper Blade Check 7-14 . . . . . . . . . . . . . . . . . . . .
Windshield Wipers 2-32, 6-54 . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Check 7-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Replacement 6-34, 6-61 . . . . . . . . . . . . . . . . . . . . . .
Winter Driving 4-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Blades, Cleaning 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrecker Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrench, Wheel 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
