PONTIAC GRAND AM 2001 Owners Manual

3-2
Comfort Controls
With this system, you can control the ventilation and
heating in your vehicle.
Your vehicle also has the flow
-through ventilation
system described later in this section.
Climate Control System with
Air Conditioning
Fan Knob
The left knob regulates the fan speed. To select the force
of air you want, turn the knob. The fan is always running
unless the fan knob is moved to OFF.Temperature Knob
The center knob regulates the temperature of the air
coming through the system.
Mode Knob
The right knob changes the functions of your system.
MAX: Use for maximum cooling. This setting
recirculates much of the air inside your vehicle. It
maximizes your air conditioner's performance and your
vehicle's fuel economy. The air conditioning compressor
will run automatically in this position when it is needed
to help dry the air in the vehicle.
UPPER: In this position most of the airflow comes
through the instrument panel outlets. A small amount of
air comes through the floor vents. Set the center knob to
the desired temperature.
BI-LEVEL: In this position the airflow comes
through the instrument panel outlets and through the
floor outlets. Set the center knob to the desired
temperature.
FLOOR: In this position most of the airflow
comes through the floor outlet. The rest of the air comes
through the windshield and side window vents. Set the
center knob to the desired temperature.

3-3
DEFOG: This position divides the airflow
between the floor outlets and the windshield defroster
vent. The air conditioning compressor will run
automatically in this position when it is needed to help
dry the air in the vehicle.
FRONT DEFROSTER: This position directs
most of the airflow through the window defroster vent.
Some of the air goes to the floor outlets. The air
conditioning compressor will run automatically in
this position when it is needed to help dry the air in
the vehicle.
Mode Button
: Press A/C to operate the air conditioner
compressor. The indicator light will glow when the
button is pressed to indicate that the air conditioning
system has been turned on. The fan knob must be set
to a speed for the air conditioning to operate.
Air Conditioning
The air conditioner and heater work best if you keep
your windows closed while using them. Your vehicle
also has the flow
-through ventilation system described
later in this section.
For normal cooling on hot days, use UPPER with the
temperature knob in the blue area and the A/C indicator
light glowing. The system will bring in outside air and
cool it.
On very hot days, open the windows long enough to
let hot inside air escape. This reduces the time it takes
for your vehicle to cool down, which should help
fuel economy.
On cool, but sunny days, the sun may warm your upper
body, but your lower body may not be warm enough.
You can use BI
-LEVEL with the temperature knob in
the middle and the A/C indicator light glowing. The
system will bring in outside air and direct slightly
warmer air to your lower body.

3-4 Heating
On cold days, use FLOOR with the temperature knob all
the way in the red area. The system will bring in outside
air, heat it and send it to the floor outlets.
Your vehicle has heat ducts that are directed toward
the rear seat. Keep the area under the front seats clear
of objects so that the heated air can reach the rear
seat passengers.
If your vehicle has an engine coolant heater, you can use
it to help your system provide warm air faster when it's
cold outside (0
F (
-18
C) or lower). An engine coolant
heater warms the coolant your engine and heating
system use to provide heat. See ªEngine Coolant
Heaterº in the Index.
Defogging and Defrosting Windows
Your system has two settings for clearing the front and
side windows. For each setting, adjust the temperature
control as desired.
To defrost the front window quickly, turn the
temperature knob all the way in the red area. Use
FRONT DEFROSTER and adjust the fan to the highest
speed. To warm passengers while keeping the front
window clean, use DEFOG.
Your vehicle is equipped with side window defogger
vents. The side window defogger vents are located on
the outside of the side instrument panel vents. To defrost
the side windows, turn the temperature knob all the way
in the red area. Use FLOOR and adjust the fan to the
highest speed. To control fogging of the windows, turn
the temperature knob all the way in the red area. Use
DEFOG and adjust the fan to the highest speed.
To defog the side windows while using air conditioning,
use BI
-LEVEL and adjust the fan to the highest
speed and press the A/C button so that the indicator
light is glowing. For added airflow to the side windows
aim the side vents toward the windows and close the
center vents.

3-5 Rear Window Defogger
The rear window defogger
uses a warming grid to
remove fog from the
rear window.
Press the defogger button. The indicator light will glow.
The rear window defogger will turn itself off after about
ten minutes after the first time the button is pressed, and
after five minutes each additional time the button is
pressed. You can turn the defogger off by pressing the
button again or turning off the ignition.
Do not attach a temporary vehicle license across the
defogger grid on the rear window.NOTICE:
Don't use a razor blade or anything else sharp on
the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.
Ventilation System
For mild outside temperatures when little heating or
cooling is needed, use UPPER to direct outside air
through your vehicle. Your vehicle also has the
flow
-through ventilation system.
Your vehicle's flow
-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the air conditioning
fan is running. Recirculation of the air is automatic
in MAX A/C.

3-6
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction, such as leaves. The heater and
defroster will work far better, reducing the chance of
fogging the inside of your windows.

When you enter a vehicle in cold weather, adjust the
mode knob to FLOOR and the fan to the highest
speed for a few moments before driving off. This
helps clear the intake ducts of snow and moisture
and reduces the chance of fogging the inside of
your windows.

Keep the air path under the front seats clear
of objects. This helps air circulate throughout
your vehicle.
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all its controls, to be sure you're getting the
most out of the advanced engineering that went into it.Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is off. See ªRetained
Accessory Powerº in the Index.
Setting the Clock
Press and hold the HR or MIN arrow for two seconds.
Then press the HR arrow until the correct hour appears.
Press and hold the MIN arrow until the correct minute
appears. The clock may be set with the ignition on
or off.
Setting the Clock for Systems with Radio
Data System
Press and hold HR or MIN for two seconds. Then press
and hold HR until the correct hour appears. AM will
appear on the display. Press and hold MIN until the
correct minute appears. The clock may be set with the
ignition on or off.
To set the clock to the time of an FM station
broadcasting Radio Data System (RDS) information,
press and hold HR and MIN at the same time for two
seconds until UPDATED and the clock symbol appear
on the display. If the time is not available from the
station, NO UPDATE will appear on the display instead.

3-7 AM-FM Stereo with Cassette Tape Player
Playing the Radio
PWR VOL: Press this knob to turn the system on
and off. To increase volume, turn the knob clockwise.
Turn it counterclockwise to decrease volume.
RCL: Press this knob to recall the station being
played, to recall if the tape player is active, or to display
the clock.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.TUNE: Turn this knob to choose radio stations.
SEEK: Press the right arrow to tune to the next higher
station and the left arrow to tune to the next lower
station and stay there. The radio will seek to stations
with a strong signal only.
SCAN: Press and hold one of the SEEK arrows for
two seconds until you hear a beep. Use SCAN to listen
to stations for a few seconds. The radio will go to a
station, stop for a few seconds and flash the station
frequency, then go on to the next station. Press one of
the SEEK arrows again to stop scanning. The radio will
scan to stations with a strong signal only.
PRESET SCAN: Use PRESET SCAN to listen to each
of your preset stations for a few seconds. Press and hold
one of the SEEK arrows for more than four seconds
until you hear two beeps. The radio will go to the first
preset station stored on your pushbuttons, except
stations with weak reception, stop for a few seconds and
flash the station frequency, then go on to the next preset
station. PRESET SCAN will only scan the six presets
that are in the band selected. Press one of the SEEK
arrows again to stop scanning presets. The channel
number (P1 through P6) will appear momentarily just
before the frequency is displayed.

3-8
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2) by
performing the following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press and hold one of the six numbered buttons until
you hear a beep. Whenever you press that numbered
button, the station you set will return.
5. Repeat the steps for each pushbutton.
Setting the Tone
BASS: Press and release AUDIO until BAS appears on
the display. Then press and hold the up arrow to increase
bass. ªBº and a positive number will appear on the
display. Press and hold the down arrow to decrease bass.
B and a negative number will appear on the display.
B and a zero will appear on the display when the bass
level is set to the middle position. Release the up or
down arrow when you find the bass level you want or
when the maximum or minimum level is reached.TREBLE: Press and release AUDIO until TRE appears
on the display. Then press and hold the up arrow to
increase treble. ªTº and a positive number will appear
on the display. Press and hold the down arrow to
decrease treble. T and a negative number will appear on
the display. T and a zero will appear on the display when
the treble level is set to the middle position. Release the
up or down arrow when you find the treble level you
want or when the maximum or minimum level is
reached. If a station is weak or noisy, you may want to
decrease the treble.
To set BASS or TREBLE to the middle position, select
the desired tone control. Then press and hold AUDIO
for more than two seconds until you hear a beep. B and
a zero or T and a zero will appear on the display. To set
all of the tone controls and speaker controls to the
middle position, end out of audio mode. Then press and
hold AUDIO for more than two seconds until you hear a
beep. CEN will appear on the display.

3-9
Adjusting the Speakers
BALANCE: Press and release AUDIO until BAL
appears on the display. Then press and hold the up arrow
to move the sound to the right speakers or the down
arrow to move the sound to the left speakers. ªRº and a
number will appear on the display when the sound is
balanced toward the right speakers. ªLº and a number
will appear on the display when the sound is balanced
toward the left speakers. L and a zero will appear on the
display when the sound is balanced between the
speakers. Release the up or down arrow when you find
the speaker balance you want or when the maximum or
minimum level is reached.
FADE: Press and release AUDIO until FAD appears on
the display. Then press and hold the up arrow to move
the sound to the front speakers or the down arrow to
move the sound to the rear speakers. ªFº and a number
will appear on the display when the sound is balanced
toward the front speakers. ªRº and a number will appear
on the display when the sound is balanced toward the
rear speakers. F and a zero will appear on the display
when the sound is balanced between the speakers.
Release the up or down arrow when you find the speaker
balance you want or when the maximum or minimum
level is reached.To set BALANCE or FADE to the middle position,
select the desired speaker control. Then press and hold
AUDIO for more than two seconds until you hear a
beep. L and a zero or F and a zero will appear on the
display. To set all of the tone controls and speaker
controls to the middle position, end out of audio mode.
Then press and hold AUDIO for more than two seconds
until you hear a beep. CEN will appear on the display.
Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in this
player. The longer side with the tape visible should face
to the right. If the ignition is on, but the radio is off, the
tape can be inserted and will begin playing. If you hear
nothing but a garbled sound, the tape may not be in
squarely. Press the eject button to remove the tape and
start over.
While the tape is playing, use the VOL, FAD, BAL,
TRE, BAS and SEEK controls just as you do for the
radio. The radio will display UP or the up arrow symbol
if the top side of the tape is playing. DN or the down
arrow symbol will appear if the bottom side is playing.

3-10
If the player detects a tight or broken tape, ERR (error)
will appear on the display and the player will eject the
tape. The radio will go back to playing the last
station selected.
If you want to insert a tape when the ignition is off, first
press the eject button or the RCL knob.
PREV (1): Press this button or the left SEEK arrow to
go to the previous selection on the tape if the selection
has been playing for less than three seconds. If the
PREV button or the left SEEK arrow is pressed and
the current selection has been playing for more than
13 seconds, it will go to the beginning of the current
selection. If the PREV button or the left SEEK arrow
is pressed and the current selection has been playing
from 3 to 13 seconds, it will go to the beginning of
the previous selection or the beginning of the current
selection, depending on the position on the tape. PRE
will appear on the display while the cassette player is in
PREV mode. Your tape must have at least three seconds
of silence between each selection for PREV to work.
The sound will mute while seeking.NEXT (2): Press this button or the right SEEK arrow to
go to the next selection on the tape. NXT will appear on
the display while the cassette player is in NEXT mode.
Your tape must have at least three seconds of silence
between each selection for NEXT to work. The sound
will mute while seeking.
REV (3): Press this button to reverse the tape rapidly.
REV will appear on the display. Press it again to return
to playing speed. The radio will play the last selected
station while the tape reverses. You may select stations
during REV operation by using TUNE, SEEK, SCAN or
PRESET SCAN.
FWD (4): Press this button to advance quickly to
another part of the tape. FWD will appear on the display.
Press the button again to return to playing speed. The
radio will play the last selected station while the tape
advances. You may select stations during FWD
operation by using TUNE, SEEK, SCAN or
PRESET SCAN.
SIDE (5): Press this button to play the other side of
the tape.

3-11
RPT (6): Press this button once to hear a selection over
again. RPT will appear on the display. The current
selection will continue to repeat. RPT will flash on the
display while the cassette player is searching for the
start of the selection. Your tape must have at least
three seconds of silence between each selection for RPT
to work. Press this button again to turn off repeated play.
OFF will appear on the display.
AM FM: Press this button to play the radio when a
tape is in the player. The tape will stop but remain in
the player.
TAPE: With a cassette tape in the player and the radio
playing, press this button to play a cassette tape. CAS
will appear on the display. Press AM FM to return to the
radio when a cassette tape is playing. The inactive tape
will remain safely inside the radio for future listening.
In order to use a portable CD player adapter or a cassette
tape head cleaner you must disable the TIGHT/LOOSE
TAPE sensor. Press and hold the TAPE button for two
seconds with the radio off and the vehicle on. CAS will
flash on the display showing the TIGHT/LOOSE TAPE
sensor has been disabled. The feature will remain
disabled until the tape is ejected. (EJECT): Press the upward triangle button to
remove a tape. The radio will play. Eject may be
activated with the radio off. Cassette tapes may be
loaded with the radio and vehicle off if this button is
pressed first.
CLN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you clean
the player, press and hold the eject button for five
seconds to reset the CLN indicator. The radio display
will flash
--- to show the indicator was reset.
Radio Calibration
Your audio system has been calibrated for your vehicle
from the factory. If CAL appears on the display it means
that your radio has not been configured properly for
your vehicle and must be returned to the dealership
for service.
