sunroof PONTIAC GRAND AM 2002 Owners Manual

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-11 Remote Keyless Entry System (If Equipped)
2
-14 Trunk
2
-17 Theft
2
-18 Passlock

2-19 New Vehicle ªBreak-Inº
2
-19 Ignition Positions
2
-20 Starting Your Engine
2
-23 Engine Coolant Heater (Option)
2
-24 Automatic Transaxle Operation
2
-28 Manual Transaxle Operation
2
-30 Parking Brake
2
-31 Shifting Into PARK (P)
(Automatic Transaxle Only)
2
-33 Shifting Out of PARK (P) (Automatic
Transaxle Only)2
-33 Parking Your Vehicle/Key Removal (Manual
Transaxle Models Only)
2
-34 Parking Over Things That Burn
2
-34 Engine Exhaust
2
-35 Running Your Engine While You're Parked
(Automatic Transaxle)
2
-36 Tilt Wheel
2
-36 Turn Signal/Multifunction Lever
2
-43 Exterior Lamps
2
-46 Interior Lamps
2
-48 Mirrors
2
-50 Storage Compartments
2
-50 Ashtray and Cigarette Lighter
2
-51 Sun Visors
2
-51 Sunroof (Option)
2
-52 The Instrument Panel -- Your
Information System
2
-56 Warning Lights, Gages and Indicators

2-51
Sun Visors
To block out glare, you can swing down the visors. You
can also swing them to the side. The visors also have
extenders that you can pull out for added coverage.
Visor Vanity Mirror
Swing down the sun visor and lift the cover to expose
the vanity mirror.
Sunroof (Option)
If your vehicle has a sunroof, the switch is located on
the headliner between the sun visors. The sunroof will
only operate when the ignition is in ON.
The sunroof can be opened to a vent position or it can be
express
-opened all the way.
To open the sunroof to the vent position, you must first
open the sunshade by hand. Then push the switch back
and release it.To fully open the sunroof, push the switch back again
and release it.
In both the vent and fully open positions, the air flow
can be adjusted for driving comfort by pushing and
holding the switch forward until the sunroof moves to
the desired position.
To close the sunroof, push the switch forward and hold
it until the sunroof is closed. The sunroof will stop if the
switch is released during operation. Remember to close
the sunshade by hand.
The sunroof glass panel cannot be opened or closed if
your vehicle has an electrical failure.NOTICE:
Do not attempt to force the sunshade forward of
the sliding glass panel. Damage will occur and the
sunroof may not open or close properly.

6-60
Instrument Panel Fuse Block -- Passenger's SideFuse Usage
INST LPS Interior Lamp Dimming
CRUISE
SW LPSSteering Wheel Cruise Control
Switch Lamps
CRUISE SW Steering Wheel Cruise
Control Switches
HVAC
BLOWERHVAC Blower Motor
CRUISE Cruise Control
FOG LPS Fog Lamps
INT LPS Interior Courtesy Lamps
RADIO BATT Radio
SUNROOF Power Sunroof
Circuit Breaker Usage
PWR WNDW Power Windows
Relay Usage
FOG LPS Fog Lamps
