PONTIAC GRAND PRIX 2000 Owners Manual

6-64
Fuse Description
BLANK Blank
BLANK Blank
MALL PGM Mall Module
-- Program
MALL Mall Module
WIPER Wipers
STR WHL
ILLUMSteering Wheel Illumination
BLANK Blank
STR WHL
CTRLSteering Wheel Control
SUNROOF Sunroof
RADIO Radio, Antenna
BLANK Blank
RADIO AMP Bose Amplifier
PWR LOCK Mall Module
-- Power Locks
HSEAT/LUM Heated Seats, Power LumbarFuse Description
R DEFOG Rear Defog
PASSKEY III PASS
-Key
III Security System
RAP Retained Accessory Power
HAZARD Hazard Flashers
PWR MIR Power Mirrors
HVAC HI HVAC Blower
-- Hi
CIG LTR Cigarette Lighter, ALDL, Floor
Console Accessory Outlet
INT LAMP Mall Module
-- Interior lamps
STOP LAMP Stoplamp
AUX/CNSL Accessory Power,
Overhead Console
CD CHG CD Changer
ECM Electronic Control Module
CRUISE Cruise Control

6-65
Fuse Description
I/P
-IGN Chime/Mall Module, Cluster,
Trip Computer, Head
-Up Display,
Automatic Transaxle Shift
Lock Control
SIR Supplemental Inflatable Restraint
(Air Bag)
TURN Turn Signal
BLANK Blank
BLANK Blank
BLANK Blank
BLANK Blank
BTSI Automatic Transaxle Shift
Lock Control
BLANK BlankFuse Description
BLANK Blank
BLANK Blank
HVAC CTRL Blower Control, HVAC
DIC/HVAC Rear Defog, HVAC, Driver
Information Center, Daytime
Running Lamps, Heated Seats
BLANK Blank
BLANK Blank
PWR DROP Power Drop Ignition
CANISTER
VENTCanister Vent Solenoid
DRL Daytime Running Lamps

6-66 Underhood Electrical
Center -- Passenger's Side
Some fuses are in a fuse
block on the passenger's
side of the engine
compartment. Pull off the
cover labeled FUSES to
expose the fuses.
Fuse Description
1 Cooling Fan 2
2 Spare
3 Headlamps
4 Battery Main 2
5 Ignition Main 1
6 Cooling Fan 1
7 Battery Main 1
8 Ignition Main 2
18 Fuel Injections

6-67
Fuse Description
19 Spare
20 Spare
21 Mass Air Flow (MAF), Heated Sensors,
Canister Purge, Boost Solenoid
22 Spare
23 Spare
24 Spare
25 Ignition Module
26 Spare
27 Trunk Release, Back
-Up Lamps
28 AC Clutch, ABS Ignition
29 Remote Keyless Entry, Theft
-Deterrent,
Shock Sensor, Trip Computer, HVAC
Module, Security LED
30 Alt Sense
31 Torque Converter Clutch (TCC)
32 Fuel Pump
33 Electronic Control Module/Powertrain
Control Module
34 SpareFuse Description
35 Fog Lamps
36 Horn
37 Chime/Mall Module, Taillamps,
Parking Lamps, Sidemarker Lamps,
Dimmable Lamps
38 Spare Fuse
39 Air Pump
40 Spare
Diode Description

Air Conditioning Clutch Diode
Relay Description
9 Cooling Fan
10 Cooling Fan 2
11 Ignition Main
12 Cooling Fan 1
13 Air Conditioning Clutch
14 Fuel Pump
15 Fuel Pump Speed Cont
16 Horn
17 Fog Lamp

6-68
Replacement Bulbs
Exterior Lamps Bulb Number. . . . . . . . . . . . . . . . .
Back
-Up 3156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stop 1141. . . . . . . . . . . . . . . .
Fog Lamp 880L. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Parking/Turn Signal 3357 NAK. . . . . . . . . . . . .
Headlamps High/Low Beam 9007. . . . . . . . . . . . . . .
License Plate Lamp 194. . . . . . . . . . . . . . . . . . . . . . .
Stop/Tail/Turn Signal 3057. . . . . . . . . . . . . . . . . . . . .
Front and Rear Sidemarker 194. . . . . . . . . . . . . . . . .
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº
in the Index for more information.
Automatic Transaxle with Overdrive
Pan Removal and Replacement 7.4 quarts (7.0 L). . .
After Complete Overhaul 10.0 quarts (9.5 L). . . . . . .
*When draining/replacing converter or auxiliary
cooler, more fluid may be needed.Cooling System Including Reservoir
3100 V6 (Code J) 11.0 quarts (10.42 L). . . . . . . . . . . .
3800 V6 (Code K) 12.3 quarts (11.65 L). . . . . . . . . . .
3800 V6 Supercharged (Code 1) 12.3 quarts (11.65 L)
Engine Crankcase (Oil Change with Filter Change)
3100 V6 (Code J) 4.5 quarts (4.3 L). . . . . . . . . . . . . .
3800 V6 (Code K) 4.5 quarts (4.3 L). . . . . . . . . . . . .
3800 V6 Supercharged (Code 1) 4.5 quarts (4.3 L). .
Fuel Tank17 gallons (64 L) . . . . . . . . . . . . . . . . . . . .
A/C Refrigerant1.9 lbs. (0.85 kg) . . . . . . . . . . . . . . .
Note: All capacities are approximate. When adding
fluid, be sure to fill to the appropriate level, as
recommended in this manual. Recheck fluid level after
filling. See ªRecommended Fluids and Lubricantsº in
the Index for more information.

6-69 3100 V6 (Code J) Engine Specifications
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 191 CID (3.1L LG8). . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-6 . . . . . . . . . . . . . . . . . . . . . .
Horsepower 175. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3800 V6 (Code K) Engine Specifications
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 231 CID (3.8L L36). . . . . . . . . . . . . . .
Firing Order 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . .
Horsepower 200. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3800 V6 Supercharged (Code 1)
Engine Specifications
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 231 CID (3.8L L67). . . . . . . . . . . . . . .
Firing Order 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . .
Horsepower 240. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Normal Maintenance
Replacement Parts
Engine Air Cleaner/Filter
3100 V6 (Code J) GM Part No. 24508572
-A1614C . .
3800 V6 (Code K) GM Part No. 24509632. . . . . . . . .
3800 V6 Supercharged
(Code 1) GM Part No. 24509632. . . . . . . . . . . . . . .
Battery
3100 V6 (Code J) 600 CCA. . . . . . . . . . . . . . . . . . . . .
3800 V6 (Code K) 690 CCA. . . . . . . . . . . . . . . . . . . .
3800 V6 Supercharged (Code 1) 770 CCA. . . . . . . . .
Engine Oil Filter
3100 V6 Engine (Code J) AC Type PF47. . . . . . . . . .
3800 V6 (Code K) GM Part No. 25010792. . . . . . . . .
3800 V6 Supercharged
(Code 1) GM Part No. 25010792. . . . . . . . . . . . . . .
PCV Valve
3100 V6 (Code J) CV892C. . . . . . . . . . . . . . . . . . . . .
3800 V6 (Code K) GM Part No. 25043843. . . . . . . . .
3800 V6 Supercharged
(Code 1) GM Part No. 25043843. . . . . . . . . . . . . . .

6-70
Radiator Cap
3100 V6 (Code J) AC Type RC27. . . . . . . . . . . . . . . .
3800 V6 (Code K) GM Part No. 10409635. . . . . . . . .
3800 V6 Supercharged (Code 1) GM Part . . . . . . . . .
No. 10409635
Spark Plugs
3100 V6 (Code J) AC Type 41
-940 . . . . . . . . . . . . . . .
Gap: 0.060 inches (.15 mm)
3800 V6 (Code K) AC Type 41
-921 . . . . . . . . . . . . . .
Gap: 0.060 inches (.15 mm)
3800 V6 Supercharged (Code 1) AC Type 41
-921 or
NGK Type PTR4B
-15
Gap: 0.060 inches (.15 mm)
Wiper Blades
Type Hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 22 inches (55.9 cm). . . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Wheelbase 110.5 inches (280.7 cm). . . . . . . . . . . . . .
Tread Width
Front 62.0 inches (157.5 cm). . . . . . . . . . . . . . . . . .
Rear 61.5 inches (156.1 cm). . . . . . . . . . . . . . . . . . .
Length 196.5 inches (499.1 cm). . . . . . . . . . . . . . . . .
Width 72.7 inches (184.5 cm). . . . . . . . . . . . . . . . . . .
Height 54.7 inches (139.0 cm). . . . . . . . . . . . . . . . . . .

7-
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-3 How This Section is Organized
7
-4 Part A: Scheduled Maintenance Services
7
-5 Scheduled Maintenance7
-15 Part B: Owner Checks and Services
7
-19 Part C: Periodic Maintenance Inspections
7
-21 Part D: Recommended Fluids and Lubricants
7
-23 Part E: Maintenance Record

7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet, or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
Maintenance Requirements
Maintenance intervals, checks, inspections and
recommended fluids and lubricants as prescribed in this
manual are necessary to keep your vehicle in good
working condition. Any damage caused by failure to
follow recommended maintenance may not be covered
by warranty.

7-3 How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you want to get the service information, see ªService
and Owner Publicationsº in the Index.ªPart B: Owner Checks and Servicesº tells you
what should be checked and when. It also explains
what you can easily do to help keep your vehicle in
good condition.
ªPart C: Periodic Maintenance Inspectionsº explains
important inspections that your dealer's service
department or another qualified service center
should perform.
ªPart D: Recommended Fluids and Lubricantsº lists
some recommended products necessary to help keep
your vehicle properly maintained. These products, or
their equivalents, should be used whether you do the
work yourself or have it done.
ªPart E: Maintenance Recordº is a place for you
to record and keep track of the maintenance performed
on your vehicle. Keep your maintenance receipts.
They may be needed to qualify your vehicle for
warranty repairs.
