6-74
Diode Description
Air Conditioning Clutch Diode
Relay Description
9 Cooling Fan
10 Cooling Fan 2
11 Ignition Main
12 Cooling Fan 1
13 Air Conditioning Clutch
14 Fuel Pump
15 Spare
16 Horn
17 Fog Lamp
Replacement Bulbs
For any bulb not listed here, contact your dealer.
Lamps Bulb Number
Back
-Up 3057. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stop (CHMSL) 1141. . . . . . .
Front Parking/Turn Signal 3357A. . . . . . . . . . . . . . . .
Headlamps High/Low Beam 9007. . . . . . . . . . . . . . .
Tail/Stop Turn Signal 3057. . . . . . . . . . . . . . . . . . . . .
Sidemarker (Front and Rear) 194. . . . . . . . . . . . . . . .
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº
in the Index for more information.
Automatic Transaxle with Overdrive
Pan Removal and Replacement 7.4 quarts (7.0 L). . .
After Complete Overhaul 10.0 quarts (9.5 L). . . . . . .
When draining/replacing converter or auxiliary cooler,
more fluid may be needed.
Cooling System Including Reservoir
3100 V6 (Code J) 11.0 quarts (10.4 L). . . . . . . . . . . . .
3800 V6 (Code K) 11.2 quarts (10.6 L). . . . . . . . . . . .
3800 V6 Supercharged (Code 1) 11.2 quarts (10.6 L).
Engine Oil with Filter
3100 V6 (Code J) 4.3 quarts (4.1 L). . . . . . . . . . . . . .
3800 V6 (Code K) 4.3 quarts (4.1 L). . . . . . . . . . . . .
3800 V6 Supercharged (Code 1) 4.3 quarts (4.1 L). .
Fuel Tank17.5 U.S. gallons (66.2 L) . . . . . . . . . . . .
Wheel Nut Torque100 ft
-lb (140 N´m) . . . . . . . . . .
All capacities are approximate. When adding fluid, be
sure to fill to the appropriate level, as recommended in
this manual. Recheck fluid level after filling. See
ªRecommended Fluids and Lubricantsº in the Index
for more information.
