{CAUTION:
Even though the passenger sensing
system is designed to turn off the
passenger’s frontal airbag if the system
detects a rear-facing child restraint, no
system is fail-safe, and no one can
guarantee that an airbag will not deploy
under some unusual circumstance, even
though it is turned off. We recommend
that rear-facing child restraints be
transported in vehicles with a rear seat
that will accommodate a rear-facing child
restraint, whenever possible.
If the word OFF or the off symbol is lit on the
airbag status indicator, it means that the
passenger sensing system has turned off the right
front passenger’s frontal airbag. SeePassenger
Sensing System on page 50for more on this,
including important safety information.If, after several seconds, all status indicator lights
remain on, or if there are no lights at all, there
may be a problem with the lights or the passenger
sensing system. See your dealer for service.
{CAUTION:
If the off indicator and the airbag
readiness light ever come on together, it
means that something may be wrong with
the airbag system. If this ever happens,
have the vehicle serviced promptly,
because an adult-size person sitting in the
right front passenger seat may not have
the protection of the frontal airbag. See
Airbag Readiness Light on page 131.
133

If the light stays on, turn the ignition off. If the
light comes on when you are driving, stop as
soon as possible and turn the ignition off. Then
start the engine again to reset the system. If the
light still stays on after driving at a speed of at least
13 mph (20 km/h), or comes on again while you are
driving, your vehicle needs service. If the regular
brake system warning light is not on, you still have
brakes, but you do not have anti-lock brakes. If the
regular brake system warning light is also on, you
do not have anti-lock brakes and there is a problem
with your regular brakes. SeeBrake System
Warning Light on page 134.
The ABS warning light will come on briey when
you turn the ignition key to RUN. This is normal.
If the light does not come on then, have it xed so
it will be ready to warn you if there is a problem.Electronic Stability Control (ESC)/
Traction Control System (TCS)
Indicator/Warning Light
(2.0L Engine Only)
This light is located in
the center of the
instrument panel cluster.
For vehicles that have the Electronic Stability
Control (ESC) system or the Traction Control
System (TCS), this warning light should come on
briey when the engine is started.
If the warning light does not come on then, have it
xed so it will be ready to warn you if there is a
problem. This light, along with the appropriate
Driver Information Center (DIC) messages,
indicates when the ESC system and the TCS are
working or are disabled.
136

Low Coolant Warning Light
This light comes on
briey when you turn
your ignition on.
If this light comes on and stays on, the coolant
level in your vehicle is low. If the light is on along
with an overheat warning, you may have a
serious overheating problem.
Notice:Driving with the low coolant warning
light on could cause your vehicle to overheat.
See “Engine Overheating” underEngine
Coolant on page 257. Your vehicle could be
damaged and the damages might not be
covered by your warranty.
SeeEngine Coolant on page 257for information
on what to do. Your vehicle should be serviced as
soon as possible.
Malfunction Indicator Lamp
Check Engine Light
Your vehicle has a
computer which
monitors operation of
the fuel, ignition,
and emission control
systems.
This system is called OBD II (On-Board
Diagnostics-Second Generation) and is intended
to assure that emissions are at acceptable
levels for the life of the vehicle, helping to produce
a cleaner environment. The check engine light
comes on to indicate that there is a problem and
service is required. Malfunctions often will be
indicated by the system before any problem is
apparent. This may prevent more serious damage
to your vehicle. This system is also designed to
assist your service technician in correctly
diagnosing any malfunction.
138

CHECK GAS CAP
This message displays if the fuel cap has not been
fully tightened. Recheck the fuel cap to make sure
that it is on properly. A few driving trips with the cap
properly installed should turn the message off.
COMPETITIVE MODE
If your vehicle has this feature, this message
displays when the Competitive Driving mode is
selected. The Traction Control System (TCS) will
not be operating while in the Competitive Driving
mode and the ESC/TCS light on the instrument
panel cluster will be on solid. Adjust your driving
accordingly. SeeElectronic Stability Control on
page 200andElectronic Stability Control (ESC)/
Traction Control System (TCS) Indicator/Warning
Light (2.0L Engine Only) on page 136for more
information.
CRUISE ENGAGED
This message displays when the cruise control
system is active. SeeCruise Control on page 115
for more information.
DOOR AJAR
This message displays if one or more of the
vehicle’s doors are not closed properly. When this
message displays, make sure that the door(s)
are closed completely.
ENGINE DISABLED
This message displays if the starting of the engine
is disabled. Have your vehicle serviced by your
dealer immediately.
ESC (Electronic Stability Control) ACTIVE
If your vehicle has Electronic Stability
Control (ESC), this message displays and the
ESC/TCS light on the instrument panel cluster
ashes when ESC is assisting you with directional
control of the vehicle. You may feel or hear the
system working and see this message displayed
in the DIC.
149

SERVICE AIR BAG
This message displays when there is a problem
with the airbag system. Have your vehicle serviced
by your dealer immediately.
SERVICE ESC (ELECTRONIC STABILITY
CONTROL)
If your vehicle has Electronic Stability
Control (ESC), this message displays and a chime
sounds if there has been a problem detected with
ESC. The ESC/TCS light also appears on the
instrument panel cluster. This light stays on solid as
long as the detected problem remains present.
When this message displays, the system is not
working. Adjust your driving accordingly. See
Electronic Stability Control on page 200and
Electronic Stability Control (ESC)/Traction Control
System (TCS) Indicator/Warning Light (2.0L Engine
Only) on page 136for more information.
If this message turns on while you are driving, pull
off the road as soon as possible and stop
carefully. Try resetting the system by turning the
ignition off and then back on. If this message
still stays on or turns back on again while you are
driving, your vehicle needs service. Have the
ESC inspected by your dealer as soon as possible.
SERVICE TRACTION
If your vehicle has the Traction Control
System (TCS), this message displays and a chime
sounds when the system is not functioning
properly. The ESC/TCS light also appears on the
instrument panel cluster. This light stays on
solid as long as the detected problem remains
present. When this message displays, the system
is not working. Adjust your driving accordingly.
SeeTraction Control System (TCS) on page 198
andElectronic Stability Control (ESC)/Traction
Control System (TCS) Indicator/Warning
Light (2.0L Engine Only) on page 136for more
information. Have the TCS serviced by your dealer
as soon as possible.
TRACTION OFF
If your vehicle has the Traction Control
System (TCS), this message displays and the
ESC/TCS light on the instrument panel cluster
comes on solid when the TCS is turned off. Adjust
your driving accordingly. SeeTraction Control
System (TCS) on page 198andElectronic Stability
Control (ESC)/Traction Control System (TCS)
Indicator/Warning Light (2.0L Engine Only)
on page 136for more information.
151

Traction Control System (TCS)
Your vehicle may have a Traction Control System
(TCS) that limits wheel spin. This is especially
useful in slippery road conditions. The system
operates only if it senses that the rear wheels are
spinning too much or are beginning to lose
traction. When this happens, the system works the
rear brakes and reduces engine power by
closing the throttle and managing engine spark to
limit wheel spin.
This light will ash
when your traction
control system is limiting
wheel spin.
You may feel or hear the system working, but this
is normal.
SeeElectronic Stability Control (ESC)/Traction
Control System (TCS) Indicator/Warning Light
(2.0L Engine Only) on page 136for more
information.If your vehicle is in cruise control when TCS
begins to limit wheel spin, the cruise control will
automatically disengage. When road conditions
allow you to safely use it again, you may
re-engage the cruise control. SeeTurn
Signal/Multifunction Lever on page 111.
When this light is on
solid and either the
SERVICE TRACTION
or TRACTION OFF
message is displayed,
the system will not
limit wheel spin.
Adjust your driving accordingly. SeeDIC Warnings
and Messages on page 148for more information.
The Traction Control System is automatically
enabled whenever you start your vehicle. To limit
wheel spin, especially in slippery road conditions,
you should always leave the system enabled.
You can turn TCS off if you ever need to.
198

This is normal and does not mean there is
a problem with your vehicle. The system
should initialize before the vehicle reaches
20 mph (32 km/h).
If the system fails to turn on or activate, the
ESC/TCS light will be on solid, and the ESC OFF
or SERVICE ESC message will be displayed.
For more information, seeDriver Information
Center (DIC) on page 145andElectronic Stability
Control (ESC)/Traction Control System (TCS)
Indicator/Warning Light (2.0L Engine Only)
on page 136.
This light will ash on
the instrument panel
cluster when the
ESC system is both
on and activated.
You may also feel or hear the system working;
this is normal.When the light is on solid and either the
SERVICE ESC or ESC OFF message is displayed,
the system will not assist the driver in maintaining
directional control of the vehicle. Adjust your
driving accordingly. SeeDIC Warnings and
Messages on page 148.
SeeElectronic Stability Control (ESC)/Traction
Control System (TCS) Indicator/Warning Light
(2.0L Engine Only) on page 136for more
information.
The Electronic Stability Control (ESC) system is
automatically enabled whenever you start
your vehicle. To assist the driver with vehicle
directional control, especially in slippery road
conditions, you should always leave the system
on. But, you can turn ESC off if you ever need to.
If the vehicle is in cruise control when the system
begins to assist the driver maintain directional
control of the vehicle, the ESC/TCS light will ash
and the cruise control will automatically disengage.
When road conditions allow you to use cruise
again, you may re-engage the cruise control.
SeeCruise Control on page 115.
201

Gasolines containing oxygenates, such as ethers
and ethanol, and reformulated gasolines may
be available in your area. General Motors
recommends that you use these gasolines if they
comply with the specications described earlier.
However, E85 (85% ethanol) and other fuels
containing more than 10% ethanol must not be
used in vehicles that were not designed for
those fuels.
Notice:Your vehicle was not designed for
fuel that contains methanol. Do not use
fuel containing methanol. It can corrode metal
parts in your fuel system and also damage
the plastic and rubber parts. That damage
would not be covered under your warranty.
Some gasolines that are not reformulated for low
emissions may contain an octane-enhancing
additive called methylcyclopentadienyl manganese
tricarbonyl (MMT); ask the attendant where you
buy gasoline whether the fuel contains MMT.General Motors recommends against the use of
such gasolines. Fuels containing MMT can reduce
the life of spark plugs and the performance of
the emission control system may be affected. The
malfunction indicator lamp may turn on. If this
occurs, return to your dealer for service.
Fuels in Foreign Countries
If you plan on driving in another country outside
the United States or Canada, the proper fuel may
be hard to nd. Never use leaded gasoline or
any other fuel not recommended in the previous
text on fuel. Costly repairs caused by use of
improper fuel would not be covered by your
warranty.
To check the fuel availability, ask an auto club, or
contact a major oil company that does business
in the country where you will be driving.
239

Brake Wear
Your vehicle has four-wheel disc brakes.
Front disc brake pads have built-in wear indicators
that make a high-pitched warning sound when
the brake pads are worn and new pads are
needed. The sound may come and go or be heard
all the time your vehicle is moving, except when
you are pushing on the brake pedal rmly.
{CAUTION:
The brake wear warning sound means that
soon the brakes will not work well. That
could lead to an accident. When you hear
the brake wear warning sound, have your
vehicle serviced.
Notice:Continuing to drive with worn-out
brake pads could result in costly brake repair.Some driving conditions or climates may cause a
brake squeal when the brakes are rst applied
or lightly applied. This does not mean something
is wrong with your brakes.
Properly torqued wheel nuts are necessary to help
prevent brake pulsation. When tires are rotated,
inspect brake pads for wear and evenly tighten
wheel nuts in the proper sequence to GM torque
specications.
Brake linings should always be replaced as
complete axle sets.
Brake Pedal Travel
See your dealer if the brake pedal does not return
to normal height, or if there is a rapid increase
in pedal travel. This could be a sign of brake
trouble.
Brake Adjustment
Every time you apply the brakes, with or without
the vehicle moving, your brakes adjust for wear.
272

Electronic Stability Control Indicator Light...... 136
Engine
Air Cleaner/Filter...................................... 254
Battery..................................................... 273
Check and Service Engine Soon Light..... 138
Coolant.................................................... 257
Coolant Temperature Warning Light.......... 137
Cooling System Inspection....................... 352
Drive Belt Routing.................................... 356
Engine Compartment Overview................ 244
Exhaust..................................................... 91
Oil ........................................................... 247
Oil Life System........................................ 252
Overheating............................................. 260
Reduced Power Light............................... 143
Starting...................................................... 80
Entry/Exit Lighting....................................... 120
Event Data Recorders (EDR)...................... 373
Extender, Safety Belt..................................... 26
F
Filter
Engine Air Cleaner................................... 254
Finish Damage............................................ 322
Fixed Mast Antenna.................................... 187Flashers, Hazard Warning........................... 110
Flash-to-Pass.............................................. 113
Flat Tire...................................................... 302
Fluid
Automatic Transmission............................ 256
Manual Transmission................................ 256
Power Steering........................................ 268
Windshield Washer.................................. 269
Fog Lamps.................................................. 120
Fuel............................................................ 237
Additives.................................................. 238
California Fuel.......................................... 238
Filling a Portable Fuel Container.............. 242
Filling Your Tank...................................... 240
Fuels in Foreign Countries....................... 239
Gage....................................................... 144
Gasoline Octane...................................... 237
Gasoline Specications............................ 237
Low Warning Light................................... 145
System Inspection.................................... 351
Fuses
Floor Console Fuse Block........................ 327
Fuses and Circuit Breakers...................... 326
Underhood Fuse Block............................. 329
387
