Design. Precision. Sportiness.
Safet y. These are all at tributes of
the 911, and the wheel options
from Porsche Tequipment are no
exception. They add to the car’s
appeal in terms of looks, dynamics
and safet y. St yled with confidence,
tested without compromise. For
a result beyond compare. There is
simply no substitute.
finish and are complemented
by high-sheen rims. Originally,
the wheel was reserved for the
911 Sport Classic and the
911 Speedster only, but is now
available to order exclusively
from
Porsche Tequipment for
all 911 models.
19-inch 911 Turbo II wheels with
summer or winter tyres
These forged alloy wheels with a
choice of summer or winter t yres
are both imposing and dynamic-
looking. The reduction in unsprung
masses makes an important con-
tribution to driving stability.
19-inch Sport Classic wheels
with summer tyres
Alloy wheel design with the tradi -
tional st yling of a Fuchs wheel.
Wide dimensions at front and rear
(8.5 and 11.5 inches, respectively)
create a larger contact patch for
increased safet y and enhanced
dynamic performance. The centre
spokes feature a black high -gloss
Wheels
19-inch Sport Classic wheels with summer tyres
19-inch 911 Turbo II wheels with summer or winter tyres

· 18 ·· 19 ·
19-inch Carrera Sport wheels with summer tyres
19-inch Carrera Sport wheels
with summer tyres
Classic 10 -spoke alloy design. Wide
dimensions at front and rear (8.5
and 11.5 inches, respectively) create
a larger contact patch. As well
as enhancing the car’s presence on
the road, this improves driving
dynamics. The visual effect is
further augmented by the centre
spokes in GT Silver Metallic and
the high -gloss polished outer rim. clear view of the Porsche brake
system.
18-inch Carrera IV wheels with
winter tyres
This five-spoke 18-inch Carrera IV
wheel will charm you instantly, just
like your Porsche. These wheels

impress with their functional design
and sporting elegance. With winter
t yres they provide bet ter traction
at low temperatures. For further product information
and part numbers, please refer to
the Tequipment 911 price list.
See pages 20 to 25 for wheel and
tyre specifications.
19-inch Carrera S II wheels with
summer or winter tyres
The design of the 19-inch Carrera S II
wheel is as sport y as it is powerful.
It speaks a language which suits
your Porsche completely.
19-inch Carrera Classic wheels
with summer tyres
Elegantly sculpted alloy wheel with
classic Porsche five-spoke design.
The large wheel openings provide a
19-inch Carrera S II wheels with summer or winter tyres
19 - inch Carrera Classic wheels with summer t yres 18 - inch Carrera IV wheels with winter t yres

· 26 ·· 27 ·
Central wheel locking device
retrofit kit
The central locking device was
engineered to facilitate fast wheel
changes on the racetrack. It also
reduces rotational masses on the
vehicle and improves steering and
turning responses. The locking
component is made from a high-
quality forged aluminium alloy, while
the central bolt has an anodised
titanium-coloured finish and features
a wheel centre cap with full- colour
Porsche Crest.
Required for the 19 -inch RS Spyder
wheel. For 911 Turbo models.
Crested valve caps
Silver- coloured valve caps with
embossed Porsche Crest.
Spacers
Wheel spacers can be used to
widen the track (5-mm spacers)
or compensate for wheel of fsets
(17-mm spacers).
Not compatible with snow chains.
Please refer to the wheel specifi -
cation tables on pages 20 to 25
for further information.
Wheel centre
Wheel bolts in black
Crested valve caps for vehicles with TPM
Spacers
Snow chains
Specially designed for Porsche
models and featuring ultra-fine
links for minimal adhesion of ice
and snow.
Not compatible with wheel spacers.
Wheel centres
Set of wheel centre caps with full-
colour Porsche Crest. The perfect
finishing touch for the wheels of
y o u r 9 11 . For 19 -inch Sport Classic wheel
and 19 -inch SportDesign wheel in
a black high-gloss finish.
For 19 -inch 911 Turbo II wheel in
a titanium - coloured paint finish.
For 19 -inch 911 Turbo wheel with
monochrome Porsche Crest.
For 19 -inch Carrera Sport wheel in
a GT Silver Metallic finish.
Wheel bolts in black
Set of 20 wheel bolts, including four
with highly secure locking system.
Available in t wo dif ferent versions
for vehicles with and without 5-mm
spacers.
Anti-theft wheel protection
(not shown)
Set of four steel bolts or t wo
aluminium nuts for alloy wheels
with highly secure locking system.
Snow chains
19 - inch RS Spyder wheel with
central locking device

· 30 ·· 31 ·
Carrera S Powerkit
The only alternative to power? Even
more power. This Powerkit for the
911 Carrera S, 911 Carrera 4S
and 911 Targa 4S with direct fuel
injection (DFI) features an exten -
sive redesign of the intake tract
from air filter to intake valve to
further enhance performance and
torque. The variable resonance
intake system with six switchable
valves is what makes a decisive contribution to this performance im
-
provement.
This intake system is
able to switch between power and
torque-opt imised
geometries for
all six intake
tracts, thanks to its
vacuum-controlled
switch valves.
As a result, the torque in the mid-
rev
range is increased, thereby en -
hancing mid-range acceleration.
The improved
combustion process
provided by DFI is also supported
by a flow-optimised
intake tract. Additional cooling
measures ensure
improved cooling. The finishing
touch is the air filter with its
twin-funnel air intakes and carbon-
fibre air filter housing upper section.
The result of all this development is
a responsive torque curve combined
with maximum engine power of
300 kW (408 hp). Additionally,
acceleration figures from
0 to
100 km/ h are reduced, for
Carrera S Powerkit
example, from 4.7 to 4.6 seconds
in the case of the 911 Carrera S
with a manual gearbox. For the
911 Carrera S with PDK
1 and
SPORT PLUS but ton, they are
down
to an impressive 4.2 sec -
onds with the top speed increas -
ing by 5 km/ h to 307 km/ h
.
Also included in the Powerkit is a
sports exhaust system with specially
designed t win tailpipes engineered
for
optimum throughput. And the
sound of your 911 can be changed
at the touch of a button.
Benefits for the driver include in -
creased power over the entire
engine speed range. The car is
more responsive with a more
exhilarating sound. In other words:
even more driving pleasure.
Some models may require addi -
tional components (see fit ting and
conversion instructions).
1 7-speed Porsche Doppelkupplung
(PDK).
911 Carrera S Coupé models with manual gearbox/PDK
Performance 911 Carrera S 911 Carrera 4S
Top speed 307 km/ h/305 km/ h 302 km/ h/300 km/ h
Acceleration
0–100 km/h 4.6 secs/4.4 secs 4.6 secs/4.4 secs
0–100 km/h –/4.2 secs –/4.2 secs
with SPORT PLUS but ton
Flexibility 5.6 secs/2.6 secs 5.7 secs/2.7 secs
(80 –120 km/ h) 5th gear/– 5th gear/–
911 Carrera S Cabriolet models/911 Targa 4S with manual gearbox/PDK
Performance 911 Carrera S 911 Carrera 4S Cabriolet/
Cabriolet 911 Targa 4S
Top speed 307 km/ h/305 km/ h 302 km/ h/300 km/ h
Acceleration
0–100 km/h 4.8 secs/4.6 secs 4.8 secs/4.6 secs
0 –100 km/ h –/4.4 secs –/4.4 secs
with SPORT PLUS but ton
Flexibility 5.9 secs/2.8 secs 6.0 secs/2.9 secs
(80 –120 km/ h) 5th gear/– 5th gear/–
Carrera S Powerkit
911 Carrera S model/911 Targa 4S with Powerkit
911 Carrera S model/911 Targa 4S with standard engine
Engine speed (rpm)
T orque (Nm)
Power (kW)
320
400 420 440
460
480
250 260
270 280
290 300
310
1000
7000
1500 20002500 3000350040004500 5000550060006500 340
360
3808000
7500 500 520
540
200 210 220 230 240
911 Carrera S/911 Carrera S Cabriolet /911 Carrera 4S/911 Carrera 4S Cabriolet /911 Targa 4S:
fuel consumption (in l/100 km) · urban 16.8–15.3 · extra urban 8.0 –7.2 · combined 11.2–10.2;
CO
2 emissions 263–240 g / km

· 32 ·· 33 ·
Porsche Ceramic Composite
Brake (PCCB)
PCCB discs are made from a
carbon-fibre reinforced ceramic
compound. Considerably harder
than standard brake discs, they
also of fer higher temperature
resistance.
With six-piston monobloc aluminium
calipers at the front and four-piston
units at the rear, PCCB provides
extremely high and consistent levels of friction under braking. The deci
-
sive advantage of PCCB is its total
weight saving over comparable
standard brake discs of approxi -
mately
50 %.
As well as enhancing performance
and fuel economy, this huge reduc -
tion in both unsprung and rotational
masses of fers major benefits in
terms of comfort and road-holding,
especially on poor road surfaces.
Only for 911 Carrera S,
911 Carrera GTS, 911 Carrera 4S,
911 Targa 4S and 911 Turbo
models.
Sports exhaust system
The t ypical Porsche sound –
power ful, robust, sport y. Bet ter
still, it can be further enhanced
using this sports exhaust system.
The sound varies with driving
behaviour, ranging from a robust
output during normal road driving
Porsche Ceramic Composite Brake (PCCB)
to a distinctively more aggressive
tone during performance use.
The package also includes
specially designed tailpipes as
st a n d a rd .
Some models may require addi -
tional components (see fit ting
and conversion instructions).
Sports tailpipes
These stainless steel, nanocoated
tailpipes give the rear of your 911
a more powerful look. The nano -
coating makes them easier to clean
and provides a striking effect.
Short shifter
This short-throw mechanism pro -
vides a faster, sportier gearshif t
action and a more dynamic sports -
car experience. Compatible with
all gear lever options.
Gear lever with short shifter
Gear lever without short shifter Sports exhaust system
Sports tailpipe

· 54 ·· 55 ·
irrespective of the speaker. It gives
audible feedback and guides you
through the functions. Without
needing to ‘train’ the system, phone
book entries can be retrieved, a
radio station selected or the navi -
gation destination entered directly
by speaking whole words rather
than dictating just one let ter at a
time.
Electronic logbook1
The optional electronic logbook
enables automatic recording of
mileage, route distance, date and
time, starting point and
destina -
tion as part of every journey. Once

you have downloaded the logbooks
from the PCM via Bluetooth®
or the optional USB interface, you
can evaluate the data on your
home PC using the software
supplied.
1 Only in conjunction with PCM
including navigation module.Navigation update 2011
(not shown)
Map update (Model Year 2011) for
your navigation system.
Please consult your Porsche
Centre for information on the data
version of your PCM.
Universal audio interface
For vehicles with PCM, the storage
compartment in the centre console
will contain three connections: one for an iPod
®, one for a USB stick/
MP3-player and one as an AUX

interface for any chosen compatible
audio source. The iPod
® or USB
stick can be operated conveniently
and safely via PCM, the multi -
function steering wheel or the voice
control system.
For vehicles with the CDR-30 audio
system, the centre console storage
compartment will contain an AUX
interface for connecting a compatible
audio source. The volume is
adjusted using the controls on
the CDR-30 audio system, other
functions are operated using the
controls on the external audio
source itself.
Voice control system
(not shown)
1
Almost all of the functions of the
PCM can be activated by voice
control. The system recognises
commands or figure sequences
Electronic logbook
Universal audio interface

Porsche strongly recommends the
u s e o f ge n u i n e Po rsc h e p a rt s a n d
accessories. Porsche cannot accept
l i a b i l i t y f o r d a m ages res u l t i n g f r o m
t h e u s e o f t h i rd p a rt y p r o d u c t s.
Po rsc h e res e rv es t h e r i g h t t o a l te r
specifications and other product
information without notice. Colours
a n d m a te r i a l s m a y d i f f e r f r o m t h o s e
illustrated.
E r r o r s a n d o m i s s i o n s e xc e p t e d .
Subject
to change without notice. Products may vary from market to
market due to local restrictions and
regulations. The models illustrated
may feature optional equipment

that is not included in the respective
Tequipment package.

For fur ther information on selected
Tequipment products, see our online
shop at www.porsche.com.
Po rsc h e, t h e Po rsc h e C rest ,
911, Ca r rera, Ta rga, Spyd er,
PCM,
PCCB, PDK and Tequipment
are
registered trademarks of
D r. I n g. h .c. F. Po rsc h e AG
Porscheplatz 1
70 435 S t u t t ga rt , G e r m a n y
www.porsche.com
©
D r. I n g. h .c. F. Po rsc h e AG , 2011
E d i t i o n : 0 7/ 11
Printed in Germany
WS L712010 01720 G B/ W W
