PORSCHE 911 CARRERA 2005 5.G Owners Manual

Mobile Roofs
171
11.Carefully remove both protection covers J to
the rear.
12.Fit both plastic covers C into the trim panel.
The marking point must point to the rear.
These covers are also used with the hardtop.
13.Close front locking lever.
Push on plastic cover of the front hardtop lock.
Putting on the hardtop
Caution!
Risk of damage to the windstop and hardtop.
fAlways remove the windstop before fitting the
hardtop.
Please observe the chapter “WINDSTOP” on Page 165.1. Open all four side windows and convertible
top.
2. Take unlocking handle D from the storage tray
between the front seats.
Position unlocking D on the point marking.
Carefully remove both plastic covers C on both
sides of the hardtop.
3. Carefully fit both protective covers J into the
trim panel from behind.
f f f

172
Mobile Roofs 4. Pull off plastic cover of the front hardtop lock. 5.Press red lock button of the front locking lever.
Fully open locking lever.

Controls, Instruments
173
6.Check whether the rear screw connections on
the hardtop are loosened (turn it 2 turns clock-
wise).
7. Together with a second person on the other
side, grasp the hardtop at points E and F.
8. Carefully lift the hardtop up and over the vehi-
cle from behind.
Warning!
Danger of pinching fingers or hands at the
points “F”.
fEvenly lower the hardtop at both sides.
9. First push the hardtop completely into the
guides on the windshield frame.
Then carefully lower the hardtop into the lock-
ing elements at the rear.
Caution!
Danger of damage due to inadvertent opera-
tion of the convertible top with the hardtop
fitted.
fMake sure that the front locking lever G is al-
ways correctly locked.This disables the convertible top drive.
f f f

174
Mobile Roofs 10.Swivel front locking lever G to the rear.
The latching hook H must engage in the wind-
shield frame (arrow).
The white marking line J on the red locking but-
ton must become visible when the hardtop is
locked properly.
11.Push on plastic cover of the front hardtop lock.12.Tighten the fastening screw by hand.
Then tighten the fastening screw with the un-
locking handle D (tightening torque 34 ftlb.
(46 Nm)).
13.Repeat procedure on the other side of the
hardtop. 14.Fit both plastic covers C into the trim panels of
the rear hardtop locking elements so that the
marking points are opposite each other.
15.Store unlocking handle in storage tray
between the front seats.

Mobile Roofs
175
Roof Transport System(Coupé only)
fPlease follow the separate instructions for fit-
ting the Roof Transport System.
fOnly use Roof Transport Systems from the
Porsche Tequipment product range or Roof
Transport Systems which have been tested
and approved for your car by Porsche.
Fitting normal commercially available luggage
racks is not possible.
The Porsche Roof Transport System allows you
to carry various sports and hobby equipment.
Your authorized Porsche dealer will be pleased to
tell you about the various different uses of the
Roof Transport System.
Safety notes!
fCompletely remove the Roof Transport System
before using an automatic car wash – risk of
damage to the vehicle!
fDo not exceed the maximum permitted pay-
load, the maximum permitted gross weight
and the maximum permitted axle loads.
Please observe the chapter “WEIGHTS COU-
PÉ” on Page 269.
fDistribute load evenly, with heavy items as low
as possible.
Items of luggage must not project beyond the
side of the load area.
fFix and secure every item to the basic carrier
with a rope or lashing strap (do not use elastic
rubber tensioners).
fBefore every journey, and at regular intervals
during long trips, check that Roof Transport
System and load are secure. Re-tighten if nec-
essary and secure additionally by locking.When the Roof Transport System is loaded, the
maximum speed depends on the nature, size and
weight of the load being carried.
Driving, braking and steering behavior change due
to the higher center of gravity and the greater
wind-resistant area. You should adapt your driving
style appropriately.
Since fuel consumption and noise are increased
with the Roof Transport System fitted, it should
not remain on the vehicle if not in use.

176
Mobile Roofs

Maintenance, Car Care
177 Maintenance, Car Care
Exercise Extreme Caution
when Working on your Vehicle .................... 178
Coolant Level ............................................ 179
Engine Oil ................................................. 181
Engine Oil Level ........................................ 181
Engine Oil Recommendation ....................... 183
Brake Fluid Level ....................................... 185
Fuel Economy ........................................... 187
Operating Your Porsche in other Countries .. 187
Fuel Recommendations.............................. 189
Portable Fuel Containers ............................ 190
Emission Control System ........................... 191
How Emission Control Works ..................... 192
Fuel Evaporation Control ............................ 193
Washer Fluid ............................................. 193
Power Steering ......................................... 194
Air Filter ................................................... 195
Combination Filter ..................................... 195
Manual Transmission Oil ............................ 195
Automatic Transmission Fluid ..................... 195
Wiper Blades ............................................ 196
Car Care Instructions................................. 198

178
Maintenance, Car Care
Exercise Extreme Caution when
Working on your Vehicle
Danger!
Ignoring the following instructions may
cause serious personal injury or death.
fThe engine compartment of any motor vehicle
is a potentially hazardous area. If you are not
fully familiar with proper repair procedures, do
not attempt the adjustments described on the
following pages.
This caution also applies to the entire vehicle.
fO n l y w o r k o n y o u r v e h i c l e o u t d o o r s o r i n a w e l l
ventilated area.
fEnsure that there are no open flames in the
area of your vehicle at any time when fuel
fumes might be present. Be especially cau-
tious of such devices such as hot water heat-
ers which ignite a flame intermittently.
fBefore working on any part in the engine com-
partment, turn the engine off and let it cool
down sufficiently. Hot engine compartment
components can burn skin on contact.
fBe alert and cautious around engine at all
times while the engine is running.
If work has to be performed with the engine
running, always set the parking brake, and
make sure the shift lever is in neutral position
or the selector lever in position P.fIn particular, be very careful to ensure that
items of clothing (ties, shirt, sleeves etc.),
jewelry, long hair, hand or fingers cannot get
caught in the engine-compartment blower, fan,
belts or other moving parts.
The radiator and radiator fans are in the front
of the car.
The engine-compartment blower is mounted
on the engine-compartment lid.
The engine-compartment blower can start or
continue running as a function of temperature,
even with the engine switched off.
Carry out work in these areas only with the en-
gine off, the ignition switched off, and exercise
extreme caution.
fYour Porsche is equipped with an electronic ig-
nition system. When the ignition is on, high
voltage is present in all wires connected with
the ignition system; therefore, exercise ex-
treme caution when working on any part of the
engine while the ignition is on or the engine is
running.
fAlways support your car with safety stands if it
is necessary to work under the car.
fWhen working under the car without safety
stands but with the wheels on the ground,
make sure the car is on level ground, the
wheels are blocked, and that the engine
cannot be started.
Remove the ignition key. fDo not smoke or allow an open flame around
the battery or fuel.
Keep a fire extinguisher in close reach.
fIncomplete or improper servicing may cause
problems in the operation of the car. If in doubt
about any servicing, have it done by your
authorized Porsche dealer.
Improper maintenance during the warranty
period may affect your Porsche warranty cov-
erage.
fSupplies of fluids, e.g. engine oil, brake fluid or
coolant, are hazardous to your health.
Keep these fluids out of children’s reach and
dispose of them in accordance with the appro-
priate regulations.
fSome countries require additional tools and
special spare parts to be carried.
Please make enquiries before driving abroad.
Power measurements Power measurements on dynamometers are not
approved by Porsche.

Maintenance, Car Care
179
Coolant LevelfPlease observe the chapter “EXERCISE EXTRE-
ME CAUTION WHEN WORKING ON YOUR VE-
HICLE” on Page 178.
The cooling system is filled at the factory with a
permanent coolant.
It provides year-round protection from corrosion
and freezing down to –31°F/–35°C
.
fOnly use antifreeze authorized by Porsche.
Checking coolant level The expansion tank with its filler orifice is in the en-
gine compartment.
fCheck the coolant level regularly through the
transparent expansion tank.
When the engine is cold and the car is level the
fluid level must lie between the “MIN” and “MAX”
markings. Topping off coolant
Warning!
Danger of serious personal injury from scald-
ing. Coolant is hazardous to your health, and
may be fatal if swallowed.
fDo not open the cap of the expansion tank
while the engine is hot.
fAllow the engine to cool down before opening
the cap and protect your hands, arms and face
from any possible escape of hot coolant.
fKeep coolant out of children’s reach.
fAlso, keep coolant away from your pets.
They can be attracted to it should there be a
spill, or to used coolant left in an open contain-er. Coolant can be deadly to pets if consumed.1. Switch engine off and let it cool.
Please observe the chapter “COOLING SYS-
TEM” on Page 84.
2. Cover the expansion tank cap with a thick rag.
Open cap slowly and carefully and allow over-
pressure to escape.
Then unscrew cap completely.
3. Only add a mixture of antifreeze and water in
equal parts, and do not exceed the “MAX”
mark.
Antifreeze in coolant:
50% gives protection down to –31°F/–35°C
60% gives protection down to –58°F/–50°C
4. Screw cap firmly on.
If in an emergency pure water has been added, the
mix ratio must be corrected at an authorized
Porsche dealer.
Marked loss of coolant indicates leakage in the
cooling system.
The cause should immediately be remedied at an
authorized Porsche dealer.
f f f

180
Maintenance, Car Care
Engine-compartment blower,
radiator fan The radiator and radiator fans are in the front of
the car.
The engine-compartment blower is mounted on
the engine compartment lid.
Warning!
Risk of injury.
After the engine is switched off, the engine-
compartment temperature is monitored for
approx. 30 minutes.
During this period, and depending on tem-
perature, the engine-compartment blower
may continue to run or start to run.
fCarry out work in these areas only with the en-
gine off, the ignition off, and exercise extreme
caution.
Risk of injury. The radiator fans in the front
end of the car may be operating or
unexpectedly start operating when the
engine is switched on.
fCarry out work in these areas only with the en-gine switched off.
