Controls, Instruments
Temperature gauge (ignition on) USA: Display in °F
Canada: Display in °C
Pointer to the left – engine cold
fAvoid high engine speeds and heavy engine
loading. Pointer in the middle – normal operating tem-
perature
The pointer may move up to the red area when en-
gine is heavily loaded and outside temperature is
high, but should return to “normal” when engine
load is reduced.
Warning light “A” If the coolant temperature is too high, the warn-
ing light comes on.
Additionally, a warning is displayed in the on-board
computer.
fPull off the road, turn off the engine and allow
to cool.
fCheck radiator and air passages in front end of
car for obstructions.
fCheck coolant level.
If necessary, add coolant and have fault reme-
died at an authorized Porsche dealer.
Please observe the chapter “COOLANT LEVEL”
on Page 179.
Note
To prevent excessive temperatures, the cooling-
air passages must not be restricted by coverings
(e.g. films, “stone guards”). If the coolant level is too low, the warning light
flashes.
Additionally, a warning is displayed in the on-board
computer.
fSwitch engine off and allow to cool.
fAdd coolant.
fHave the cause of the fault remedied at an au-
thorized Porsche dealer.
Please observe the chapter “COOLANT LEVEL”
on Page 179.
Caution!
Risk of engine damage.
fIf the warning lights come on even though cool-
ant level is correct, do not continue driving.
fHave the fault remedied at the nearest authorized Porsche dealer.
Engine compartment blower fan In addition, this warning light flashes to indicate a
fault in the engine compartment blower fan.
fHave the cause of the fault remedied at an
authorized Porsche dealer.
Cooling System

88
Controls, Instruments With the engine warmed up and running at a speed
of 5000 rpm, the engine oil pressure should be
approx. 3.5 bar.If oil pressure drops abruptly and a message
is displayed on the on-board computer when
the engine is running on or when driving:
fStop immediately in a suitable place.
fSwitch off the engine.
fCheck oil level.
Please observe the chapter “OIL DISPLAY AND
MEASUREMENT OF THE ENGINE OIL LEVEL”
on Page 101.
Please observe the chapter “ENGINE OIL
LEVEL” on Page 181.
fAdd engine oil if necessary.
Caution!
Risk of engine damage.
fDo not continue driving if there is an obvious oil
leak.
fDo not continue driving if the warning lights
come on even though oil level is correct.
fHave the fault remedied at the nearest authorized Porsche dealer.If the battery voltage drops abruptly, a warning
message will be displayed by the on-board compu-
ter.
If the warning is displayed by the on-board
computer while the engine is running or while
driving:
fStop the car in a safe place and stop the
engine.
Possible causes
– Defect in the battery charging system.
– Broken drive belt.
Warning!
Risk of an accident and risk of engine dam-
age.
A broken drive belt means there is no power
assistance to the steering (more effort is re-
quired to steer) and coolant pump function
will stop.
fDo not continue driving.
fHave the fault remedied at the nearest author-ized Porsche dealer.
Engine Oil Pressure
Battery

Controls, Instruments
107
Fuel gauge war-
ning lightPlease observe range
on remaining fuelRefuel at next opportunity.
Check the oil level Start engine oil level measurement in the
on-board computer.
The vehicle must be horizontal and the ignition
must be switched on.
Oil pressure too low Stop immediately at a suitable place, measure
oil level with the on-board computer and, if ne-
cessary, add engine oil.
Warning light
Temperature gau-
geEngine temperature too high Switch engine off and let it cool.
Check coolant level and, if necessary,
add coolant.
Temperature gau-
ge warning light
flashesCheck coolant level Switch engine off and let it cool.
Check coolant level and, if necessary, add
coolant.
Engine diagnostics – workshop Consult your authorized Porsche dealer.
Reduced engine performance Consult your authorized Porsche dealer.
Temperature gau-
ge warning light
flashesFailure of
engine-compartment blowerConsult your authorized Porsche dealer.
Battery/generator warning Stop at a safe place and switch the engine off.
Do not continue driving.
Have the fault remedied at an authorized
Porsche dealer.
Oil pressure gauge faulty Have the fault remedied at an authorized
Porsche dealer.
Oil level display faulty Have the fault remedied at an authorized
Porsche dealer.Instrument
panelOn-board
computerText display on on-board
computerMeaning/measure

Maintenance, Car Care
177 Maintenance, Car Care
Exercise Extreme Caution
when Working on your Vehicle .................... 178
Coolant Level ............................................ 179
Engine Oil ................................................. 181
Engine Oil Level ........................................ 181
Engine Oil Recommendation ....................... 183
Brake Fluid Level ....................................... 185
Fuel Economy ........................................... 187
Operating Your Porsche in other Countries .. 187
Fuel Recommendations.............................. 189
Portable Fuel Containers ............................ 190
Emission Control System ........................... 191
How Emission Control Works ..................... 192
Fuel Evaporation Control ............................ 193
Washer Fluid ............................................. 193
Power Steering ......................................... 194
Air Filter ................................................... 195
Combination Filter ..................................... 195
Manual Transmission Oil ............................ 195
Automatic Transmission Fluid ..................... 195
Wiper Blades ............................................ 196
Car Care Instructions................................. 198

178
Maintenance, Car Care
Exercise Extreme Caution when
Working on your Vehicle
Danger!
Ignoring the following instructions may
cause serious personal injury or death.
fThe engine compartment of any motor vehicle
is a potentially hazardous area. If you are not
fully familiar with proper repair procedures, do
not attempt the adjustments described on the
following pages.
This caution also applies to the entire vehicle.
fO n l y w o r k o n y o u r v e h i c l e o u t d o o r s o r i n a w e l l
ventilated area.
fEnsure that there are no open flames in the
area of your vehicle at any time when fuel
fumes might be present. Be especially cau-
tious of such devices such as hot water heat-
ers which ignite a flame intermittently.
fBefore working on any part in the engine com-
partment, turn the engine off and let it cool
down sufficiently. Hot engine compartment
components can burn skin on contact.
fBe alert and cautious around engine at all
times while the engine is running.
If work has to be performed with the engine
running, always set the parking brake, and
make sure the shift lever is in neutral position
or the selector lever in position P.fIn particular, be very careful to ensure that
items of clothing (ties, shirt, sleeves etc.),
jewelry, long hair, hand or fingers cannot get
caught in the engine-compartment blower, fan,
belts or other moving parts.
The radiator and radiator fans are in the front
of the car.
The engine-compartment blower is mounted
on the engine-compartment lid.
The engine-compartment blower can start or
continue running as a function of temperature,
even with the engine switched off.
Carry out work in these areas only with the en-
gine off, the ignition switched off, and exercise
extreme caution.
fYour Porsche is equipped with an electronic ig-
nition system. When the ignition is on, high
voltage is present in all wires connected with
the ignition system; therefore, exercise ex-
treme caution when working on any part of the
engine while the ignition is on or the engine is
running.
fAlways support your car with safety stands if it
is necessary to work under the car.
fWhen working under the car without safety
stands but with the wheels on the ground,
make sure the car is on level ground, the
wheels are blocked, and that the engine
cannot be started.
Remove the ignition key. fDo not smoke or allow an open flame around
the battery or fuel.
Keep a fire extinguisher in close reach.
fIncomplete or improper servicing may cause
problems in the operation of the car. If in doubt
about any servicing, have it done by your
authorized Porsche dealer.
Improper maintenance during the warranty
period may affect your Porsche warranty cov-
erage.
fSupplies of fluids, e.g. engine oil, brake fluid or
coolant, are hazardous to your health.
Keep these fluids out of children’s reach and
dispose of them in accordance with the appro-
priate regulations.
fSome countries require additional tools and
special spare parts to be carried.
Please make enquiries before driving abroad.
Power measurements Power measurements on dynamometers are not
approved by Porsche.

Maintenance, Car Care
179
Coolant LevelfPlease observe the chapter “EXERCISE EXTRE-
ME CAUTION WHEN WORKING ON YOUR VE-
HICLE” on Page 178.
The cooling system is filled at the factory with a
permanent coolant.
It provides year-round protection from corrosion
and freezing down to –31°F/–35°C
.
fOnly use antifreeze authorized by Porsche.
Checking coolant level The expansion tank with its filler orifice is in the en-
gine compartment.
fCheck the coolant level regularly through the
transparent expansion tank.
When the engine is cold and the car is level the
fluid level must lie between the “MIN” and “MAX”
markings. Topping off coolant
Warning!
Danger of serious personal injury from scald-
ing. Coolant is hazardous to your health, and
may be fatal if swallowed.
fDo not open the cap of the expansion tank
while the engine is hot.
fAllow the engine to cool down before opening
the cap and protect your hands, arms and face
from any possible escape of hot coolant.
fKeep coolant out of children’s reach.
fAlso, keep coolant away from your pets.
They can be attracted to it should there be a
spill, or to used coolant left in an open contain-er. Coolant can be deadly to pets if consumed.1. Switch engine off and let it cool.
Please observe the chapter “COOLING SYS-
TEM” on Page 84.
2. Cover the expansion tank cap with a thick rag.
Open cap slowly and carefully and allow over-
pressure to escape.
Then unscrew cap completely.
3. Only add a mixture of antifreeze and water in
equal parts, and do not exceed the “MAX”
mark.
Antifreeze in coolant:
50% gives protection down to –31°F/–35°C
60% gives protection down to –58°F/–50°C
4. Screw cap firmly on.
If in an emergency pure water has been added, the
mix ratio must be corrected at an authorized
Porsche dealer.
Marked loss of coolant indicates leakage in the
cooling system.
The cause should immediately be remedied at an
authorized Porsche dealer.
f f f

Maintenance, Car Care
193
Fuel Evaporation Control Fuel tank venting The evaporation chamber and the carbon canister
prevent fuel from escaping to the atmosphere at
extreme high outside temperatures, when driving
abruptly around curves and when the car is parked
at an incline or in any other nonlevel position. Vapor control system and storage When the fuel tank is filled, vapors are collected in
the evaporation chamber by a vent line leading the
vapors to the carbon canister where they are
stored as long as the engine does not run. Purge system When the engine is running, the fuel vapors from
the canister will be mixed with fresh air from the
ambient air of the canister. This mixture will be
directed to the intake air housing by the tank vent
line, mixed with the intake air and burned during
normal combustion.
Washer FluidThe reservoir, with a blue screw cap, is in the lug-
gage compartment, to the rear left. Capacity – Without headlight cleaning system:
approximately 2.6 quarts (2.5 liters).
– With headlight cleaning system:
approximately 6.3 quarts (6.0 liters).
Topping off washer fluidClean water is generally not enough to clean the
windshield and headlights.
Depending on the season, mix the water with win-
ter cleaner giving antifreeze protection or a sum-
mer cleaner. Follow the instructions for the mixing
ratio.
fOnly use cleaner fluids authorized by Porsche.
1. Please note all the information on the refill con-
tainer of the cleaning agent.
2. Open cap of the washer-fluid reservoir.
3. Top up washer fluid and close cap properly.
fDo not use engine coolant anti-freeze or any
other solution that can damage the car’s paint,
in the washer reservoir.
If less than 0.52 quarts (0.5 liter) remains, a
warning message appears on the on-board
computer.
fAdd washer fluid.
Warning light

208
Practical Tips, Emergency Service
Exercise Extreme Caution when
Working on your Vehicle
Danger!
Ignoring the following instructions may
cause serious personal injury or death.
fThe engine compartment of any motor vehicle
is a potentially hazardous area. If you are not
fully familiar with proper repair procedures, do
not attempt the adjustments described on the
following pages.
This caution also applies to the entire vehicle.
fO n l y w o r k o n y o u r v e h i c l e o u t d o o r s o r i n a w e l l
ventilated area.
fEnsure that there are no open flames in the
area of your vehicle at any time when fuel
fumes might be present. Be especially cau-
tious of such devices such as hot water heat-
ers which ignite a flame intermittently.
fBefore working on any part in the engine com-
partment, turn the engine off and let it cool
down sufficiently. Hot engine compartment
components can burn skin on contact.
fBe alert and cautious around engine at all
times while the engine is running.
If work has to be performed with the engine
running, always set the parking brake, and
make sure the shift lever is in neutral position
or the selector lever in position P.fIn particular, be very careful to ensure that
items of clothing (ties, shirt, sleeves etc.), jew-
elry, long hair, hand or fingers cannot get
caught in the engine-compartment blower, fan,
belts or other moving parts.
The radiator and radiator fans are in the front
of the car.
The engine-compartment blower is mounted
on the engine-compartment lid.
The engine-compartment blower can start or
continue running as a function of temperature,
even with the engine switched off.
Carry out work in these areas only with the en-
gine off, the ignition switched off, and exercise
extreme caution.
fYour Porsche is equipped with an electronic ig-
nition system. When the ignition is on, high volt-
age is present in all wires connected with the
ignition system; therefore, exercise extreme
caution when working on any part of the engine
while the ignition is on or the engine is running.
fAlways support your car with safety stands if it
is necessary to work under the car.
fWhen working under the car without safety
stands but with the wheels on the ground,
make sure the car is on level ground, the
wheels are blocked, and that the engine
cannot be started.
Remove the ignition key.fDo not smoke or allow an open flame around
the battery or fuel.
Keep a fire extinguisher in close reach.
fIncomplete or improper servicing may cause
problems in the operation of the car. If in doubt
about any servicing, have it done by your au-
thorized Porsche dealer.
Improper maintenance during the warranty pe-
riod may affect your Porsche warranty cover-
age.
fSupplies of fluids, e.g. engine oil, brake fluid or
coolant, are hazardous to your health.
Keep these fluids out of children’s reach and
dispose of them in accordance with the appro-
priate regulations.
fSome countries require additional tools and
special spare parts to be carried.
Please make enquiries before driving abroad.

268
Technical Data
CapacitiesUse only fluids and fuels authorized by Porsche. Your authorized Porsche dealer will gladly advise you.
Your Porsche has been designed so that it is not necessary to mix any additives with oils or fuels.
Engine 911 Carrera: Oil change quantity without oil filter approx. 8.5 quarts / 8.0 liters
911 Carrera: Oil change quantity with oil filter approx. 8.7 quarts / 8.25 liters
911 Carrera S: Oil change quantity without oil filter approx. 8.7 quarts / 8.25 liters
911 Carrera S: Oil change quantity with oil filter approx. 9 quarts / 8.5 liters
Please observe the chapter “ENGINE OIL” on Page 181.
Coolantapprox. 8.45 U.S. gallons / 32 liters
Manual transmission
and differential
approx. 3.1 quarts / 2.9 liters transmission oil
Tiptronic Sapprox. 9.5 quarts / 9 liters ATF
Differential for Tiptronic Sapprox. 1.3 quarts / 1.2 liter
Fuel tank approx. 16.9 U.S. gallons / 64 liters
Fuel qualityYour engine is designed to provide optimum performance and fuel economy using
unleaded premium fuel with an octane rating of 98 RON (93 CLC or AKI).
Porsche therefore recommends the use of these fuels in your vehicle.
Porsche also recognizes that these fuels may not always be available. Be assured that your vehicle
will operate properly on unleaded premium fuels with octane numbers of at least 95 RON (90 CLC or AKI),
since the engine’s “Electronic Oktane™ knock control” will adapt the ignition timing, if necessary.
Power steeringapprox. 1.35 quarts / 1.27 liter hydraulic fluid Pentosin CHF 11 S
®
Brake fluid0.48 quarts / 0.45 liters; use only Original Porsche brake fluid.
Windshield washerapprox. 2.6 quarts/2,5 liters without headlight washer
approx. 6.3 quarts/6 liters with headlight washer

Index
279
Compact disc
Player and Changer ............................. 141
Storage.............................................. 129
Compartment monitoring............................... 26
Convertible top ........................................... 156
Care .................................................. 200
Coolant ................................................84
, 179
Level.................................................. 179
Temperature gauge.............................. 84
Warning light ........................................ 84
Cooling system .....................................84, 179
Cruise control .............................. 88
, 118
, 119
Cupholder .................................................. 126
DDashboard ................................................... 70
Data bank .................................................. 262
Defrosting windows ...............................33
, 121
Diagnostic socket .................................17, 234
Diagrams ................................................... 273
Dimensions ................................................ 272
Door ............................................................ 21
Guard lights ........................................ 255
Handles................................................ 21
Locks...........................................21, 201
Mirror .................................................. 32
Mirror heating ....................................... 33
Windows ....................... 21
, 28, 156
, 203
Driving hints ................................................. 14
Driving in winter .......................................... 150
Driving performance ................................... 271
Drop-center rim .......................................... 221
DVD Navigation...................................132, 139
EElectrical system.........................................232
Emergency flasher ......................................112
Emergency operation
Central locking ......................................23
Lids ...................................................235
Sliding roof .........................................154
Tank flap ............................................188
Emergency service......................................208
Emergency starting
with jumper cables............................. 242
, 243
Emission control system ........... 7
, 89, 191
, 192
Engine
Checking the oil level ...........................101
Exhaust ..................................................9
Number ..............................................263
Oil consumption........................... 16, 181
Oil level ..............................................181
Oil level indicator.................................101
Oil pressure ..........................................88
Oil temperature .....................................80
Oils ........................................... 181, 268
Speeds ....................................... 16, 271
Starting ................................................74
Stopping ..............................................75
Engine compartment
Blower .......................................... 75, 84
Lid ............................................ 130, 131
Lid warning light ..................................130
Light ..................................................255
Environment ...................................................6
FFilling pressure, tire................................ 5
, 267
Fire extinguisher......................................... 135
Floor mats ................................................. 205
Fluids and fuels .......................................... 268
Fog lights .................................................. 113
Footbrake .................................................... 59
Footwell lights ............................................ 255
Fresh air intake .......................................... 123
Front lid ..................................................... 131
Fuel................................................. 4
, 86, 188
Containers ..................................... 8, 190
Economy ........................................... 187
Evaporation control ............................ 193
Level gauge ......................................... 86
Level warning light................................ 86
Recommendation ....................... 189, 190
Tank.................................................. 189
Function keys ............................................... 40
Fuses ........................................................ 234
GGarage door opener................................... 136
Garage lift ................................................. 224
Glove compartment .................................... 129
Gong ....................................... 18
, 73, 92, 113
Ground clearance ........................................... 9
