Temperament

| Chassis and body
PTV in conjunction with the manual gear -
box, or PT V Plus with Porsche Doppel-
kupplung (PDK), are available as options
for the 911 Carrera models and standard
in the 911 Carrera S models. Both systems
actively enhance vehicle dynamics and
stability. Operating in conjunction with a
mechanical (PT V) or electronic (PT V Plus)
rear differential lock, they work by
braking the rear wheels as the situation
demands.
As a function of steering angle and steering
speed, accelerator pedal position, yaw
rate and vehicle speed, PT V and PT V Plus are able to improve steering response
and steering precision by specific braking
of the right or left rear wheel.
To be more precise, this means that when
the car is driven assertively into a corner,
moderate brake pressure is applied to the
inside rear wheel. Consequently, a greater
amount of drive force is distributed to the
outside rear wheel, inducing an additional
rotational pulse (yaw movement) around
the vehicle’s vertical axis. This results in
a direct and sport y steering action as the
car enters the corner.
Attack the corners.

Maintain good posture.

Porsche Torque Vectoring (PTV) and
Porsche Torque Vectoring Plus (PTV Plus).At low and medium vehicle speeds, PT V
and PT V Plus significantly increase agilit y
and steering precision. At high speeds
and when accelerating out of corners,
the rear differential lock ensures greater
driving stability. With PTV, the differential
lock is regulated mechanically; with PT V Plus, it is regulated electronically and
the torque distribution is infinitely varia
-
ble. Whichever system is fit ted, it interacts
with Porsche Stabilit y Management (PSM)
to improve driving stabilit y on a range of
surface conditions, including the wet and
snow. For the driver, this means remarkable

stability, easier handling and outstanding
traction as well as greater agilit y at every
speed with precise steering and stable
load transfer characteristics. What else?
Unrivalled driving pleasure at every t wist
and turn.

dis
tenacious
precise
controlled
balanced
i
fore
uncompromisi
Composure

6667
Composure
| Safet y
Control, discipline, precision.

At Porsche, we take driving pleasure very seriously.

S a f e t y.
Brakes.
Another crucial piece of the Porsche
identit y is the brakes. We value them as
highly as we do our engines and chassis.
They set standards for deceleration and
stabilit y, and give the driver the reassur -
ance needed to push the car to the limits
of its performance.
The 911 Carrera and 911 Carrera Cabriolet
are fit ted front and rear with anodised
black four-piston aluminium monobloc
fixed calipers. All brake discs have a
diameter of 330 mm. On the 911 Carrera S models, we have
fit ted larger brakes and more brake pistons
to cope with the increased engine power
of these models. The new generation of
brakes features red six-piston monobloc
aluminium fixed brake calipers at the
front and four-piston aluminium monobloc
fixed calipers at the rear. The brake
disc diameter is 340 mm at the front and
330 mm at the rear. The results are
enhanced braking performance and a
reduction in stopping distance compared
with that of the previous model.
On all models, the brake calipers have
an enclosed monobloc construction.
This makes them tougher but lighter and enables a more rapid response and
release of the brake even under extreme
loads. The pedal travel is short and

the biting point precise. The brake discs
are cross-drilled for better performance
in the wet.
Other benefits of the standard braking
system include the anti-lock braking
system (ABS), designed to keep decelera -
tion constant. Pedal effort is reduced and
braking response improved by a newly
developed 8-/9-inch tandem vacuum
brake booster. In the S models, brake disc
cooling is further enhanced by modified
air spoilers.
Standard brake system on the 911 Carrera
Standard brake system on the 911 Carrera S

6869
From the start, Porsche has been
synonymous with motorsport. Ever since
1948, when we found our identit y on
the racetrack, we have taken the experi -
ence we have gained and applied it to
the road. The optional Porsche Ceramic
Composite Brake (PCCB) is a fine example.
This brake system has already had to
cope with the harshest requirements of
Composure | Safet y
motor racing and is fit ted in cars that
compete in demanding events such as
the Porsche Mobil 1 Supercup.
The cross-drilled PCCB ceramic brake
discs for the new 911 have a diameter
of 350 mm front and rear for even more
formidable braking performance.
The use of six-piston aluminium monobloc
brake calipers on the front axle and four-
piston units at the rear – all finished in
yellow – ensures extremely high brake
forces which, crucially, are exceptionally
consistent. What we’ve discovered from over 28,000 racing victories:
Brake later, finish sooner.

Porsche Ceramic Composite Brake (PCCB).PCCB enables shorter braking distances
in even the toughest road and race
conditions. Excellent fade resistance
ensures greater balance when slowing
from racetrack speeds.
The key advantage of PCCB is the
extremely low weight of the ceramic
brake discs, which are approximately
50 % lighter than standard discs of similar
design and size. As well as enhancing
performance and fuel economy, this
represents a major reduction in unsprung
and rotating masses. The consequence
of this is bet ter road holding and increased comfort, particularly on uneven
roads, as well as greater agilit y and
improved handling.
Please note that circuit racing, track

day use and other forms of performance
driving can significantly reduce the
service life of even the most durable
brake pads and discs.
As with conventional high-performance
braking systems, we recommend that
all brake components be professionally
inspected and replaced where necessary
after every track event.

7071
Composure
| Safet y
Electric parking brake.
The new electric parking brake, which
you can activate and deactivate manually,
releases automatically as you pull away.
With the hill-hold function, you can

pull away without ever rolling back.
The system automatically detects when
the vehicle has come to a halt on an
uphill gradient requiring intervention.
PSM then maintains the brake pressure
at all four wheels to prevent the vehicle
from moving in the opposite direction.
Airbags.
The new 911 models offer advanced
airbag technology in the form of full-size
driver and front passenger airbags, which
are inflated in t wo stages depending
on the severit y and t ype of accident (e.g.
frontal or offset frontal). In less serious
accidents, the airbags are only partially
inflated, thereby minimising discomfort to
the occupants. In addition to the central airbag control
unit on the transmission tunnel, a pair

of impact sensors are located near the
headlights. This allows a crash to be
detected and evaluated far sooner and
with considerably greater accuracy.
Porsche Side Impact Protection
System (POSIP).
Coupé or Cabriolet, the new 911 models
are equipped as standard with the
Porsche Side Impact Protection System
(POSIP). It comprises side impact protec -
tion elements in the doors and t wo air -bags on each side. An integral thorax

airbag is located in each seat side bolster,
while the door panels each contain an
upwards-inflating head airbag. Each
thorax airbag has a volume of 10 litres
and each head airbag 15 litres, ensuring
excellent protection in the event of a
side impact.
Cabriolet roll-over protection concept.
Despite their low weight, the 911 Carrera
Cabriolet models have exemplary torsional
rigidit y and flexural strength. Body flexing
is minimal, even on the most poorly sur -
faced roads.
Increased protection is provided by an
automatically deploying roll-over protec -
tion system if the car were to overturn.
Two spring-loaded roll-over bars are
neatly incorporated behind the rear
seats. The roll-over sensor continuously
monitors the car’s pitch and roll, contact
with the road, as well as lateral and
longitudinal forces. If the car were to
overturn, the roll-over bars would be
deployed instantly.

7273
Composure
| Safet y
The new 911 models are equipped as
standard with Bi-Xenon headlights

including a headlight cleaning system and
dynamic range control. With dipped or
main beam, the road ahead is illuminated
more uniformly.
The rest yled LED front light units
incorporate direction indicators, daytime -
running lights and position lights.
Automatic headlight activation is also
included as standard. The moment it gets
dark, the daytime running lights switch
off and the dipped beam headlights
switch on automatically. Cut ting edge LED technology is also used
for the taillights, the high-level third brake
light, the licence plate illumination, the
rear direction indicators and the rear fog
light. LEDs provide bet ter illumination and
respond more quickly to driver input.
In the event of sudden braking, the adaptive
LED brake lights begin to pulsate. If the
vehicle is braked to a halt, the hazard
warning lights will switch on automatically,
alerting following traf fic more quickly to

a critical situation.
The lighting system features an automatic
switch-off and the ‘Welcome Home’
function. It ’s good to know what ’s around
the next corner or on the way to your
front door.
Porsche Dynamic Light System (PDLS).
The Porsche Dynamic Light System
(PDLS) is available as an option.
Its dynamic cornering light function
swivels the headlights towards the inside
of a bend, based on steering angle and
road speed, in order to illuminate more of the road at tight bends and turns.

Put simply, the road ahead is illuminated
the moment you enter a bend.
The system also of fers speed -sensitive
headlight range control. With adaptive
light systems, it is possible for the maxi -
mum range of the dipped beams to be
increased as a function of the speed of
Taillights and high-level third brake light Porsche Dynamic Light System (PDLS) cornering lights
Porsche Dynamic Light System (PDLS) headlights
To see something coming, experience helps.
So does forward-looking technology.

Lights.the vehicle. PDLS takes care of this
automatically in t wo stages. Stage 1 is
the basic position for driving in cit y traffic,
for example. Stage 2 is designed for
driving at faster speeds, such as on the
motorway. Above 130 km/ h (80 mph),
the range is adapted again.
Another feature of PDLS is the adverse
weather function, activated whenever the
rear fog light is switched on. It reduces
the effect of reflection phenomena in
poor visibilit y conditions to avoid the risk
of the driver being dazzled.

7475
Our identity is found under the bonnet,
in the design and behind the steering wheel.

Comfort.
Driving a 911 is first and foremost about
the feel of the road in the original, unadul -
terated and direct sense. Is it possible,
then, to mention the 911 and comfort in
the same breath? To speak of systems
that make driving ‘more agreeable’, or of
materials that feel ‘pleasant ’ to the touch?
Good question.
In reality, however, should anyone really
be forced to choose one over the other?
Let ’s introduce ourselves to the concept
of sport y comfort – dynamic performance
that maintains composure even when
pushed to the extreme.
Interior.
Engineering and st yle – and Porsche
identit y on the inside, as demonstrated by
the new elevated centre console. In t ypical
Porsche fashion, the use of form follows
a basic principle: focus on the driver. This
is why the distance bet ween the gear lever
or selector and steering wheel is extremely
short and the operating logic, such as that
of the two-zone air conditioning system
or the suspension set tings, is clear and
uncomplicated. You shouldn’t have to
browse one submenu after another. You
should instead be able to concentrate
on what ’s important: the road.
Inside there is a range of high qualit y
materials used, including a full leather
interior as standard. Alcantara has
proven its worth in motorsport and is
used as standard for the rooflining of
the Coupé models.
In addition to the choice of Black, Plati -
num Grey, Luxor Beige and Yachting Blue
for the interior, there is a wide range of
other personalisation options available,
including two-tone colour combinations
or special colours and materials such as
carbon, aluminium or high quality wood.
Composure | Comfor t

7677
Composure
| Comfor t
Engineering that takes you forward:

Porsche Communication Management
(PCM) with navigation module and a
high-resolution 7-inch colour touchscreen
is fit ted as standard. PCM is your control
centre for audio, navigationand communi -
cation functions.Instruments.
Sporty not kitsch, practical not fanciful.
The five circular instruments have one
purpose above all: to provide information.
They do so efficiently and accurately.
Their st yling is t ypically Porsche with the
rev counter exactly where you would
expect it to be: in the middle.
Another element of the Porsche identit y

is
sound. The Sound Package Plus offer
outstanding performance with a total
output of 235 watts. Available as an option
is the BOSE
® Surround Sound System
with a total output of 445 wat ts. In short,
it delivers authentic audio playback com -
bined with an impressive spatial sound.
No system promises such high standards
in the 911, and fulfils them, as the optional High-End Surround Sound System from
Burmester
®, the bespoke manufacturer
based in Berlin and one of the most
respected premium audio manufacturers
worldwide. With a total output of 821 watts,
it ensures an incredible audio experience.
Our patented integral subwoofer enhances
the bass performance of both optional sound systems and also saves weight.
Typically Porsche.
Ergonomics, st yle and sound. Sports car
technology, intelligently combined.
The instrument cluster is new with a high-
resolution 4.6-inch TFT colour screen.

It provides you with a continuous stream
of data from the on-board computer,
such as speed, trip mileage, journey time
or current fuel consumption. It also dis -
plays the navigation system map, delivers
various warnings, including alerts from
the Tyre Pressure Monitoring (TPM) system, and reminds you of your selected
communication and audio settings.
TFT display
Instruments in the 911 Carrera S with aluminium - coloured rev counter

7879
Composure
| Comfor t
In the 911, there is a point at which all
forces come together. The steering wheel
is the most important inter face bet ween
the driver and the sports car. This is

why all available steering wheels feature
a high-grip steering wheel rim in smooth-
finish leather and offer outstanding
ergonomics. A full -size airbag is integrated
as st a n d a rd .SportDesign steering wheel.
As with the sports steering wheel, the
optional SportDesign steering wheel
is adjustable for both height and reach
and, thanks to its grip mouldings, it’s
in safe hands – even on the sportiest
of drives.
Sports steering wheel.
The sports steering wheel is fit ted as
standard and adjusts up to 40 mm for
height and up to 60 mm for reach.
The optional multifunction steering
wheel has four function but tons and t wo thumbwheels for convenient operation

of audio, telephone and navigation
functions, TFT display and on-board
computer. On request, the steering
wheel is available in smooth-finish leather,
carbon or mahogany. In conjunction with PDK, the steering
wheels are equipped with t wo ergonomic
gearshift switches enabling you to
change gear directly from the steering
wheel. With the optional Sport Chrono
Package, the steering wheel also features
a display above the airbag module to
inform you whether the SPORT, SPORT
PLUS and Launch Control functions have
been activated.
SportDesign steering wheel
In conjunction with PDK, the steering
wheel features t wo gearshif t paddles.
These are made from a strong alloy and
are ergonomically located behind the
lef t- and right- hand steering wheel
spokes. Pull the right-hand paddle and
PDK shifts up. Pull the left-hand paddle and PDK shifts down. When PDK has
been combined with the optional Sport
Chrono Package, the left- and right-hand
spokes additionally feature a display

that tells you whether the SPORT, SPORT
PLUS and Launch Control functions have
been activated. Steering wheel heating.
For increased comfort on cold days,
steering wheel heating is available as
an option for the sports steering wheel
and multifunction steering wheels
(only in conjunction with seat heating).
The heating is operated by a but ton
on the rear of the lower steering wheel
spoke.
Multifunction steering wheel in conjunction with PDK Spor tDesign steering wheel with gearshif t paddles
Sports steering wheel

8081
Composure
| Comfor t
Sports seats.
The Sports seats in full leather are
comfortable and provide support even
during performance driving. They are
equipped as standard with electric seat
height and backrest adjustment and
mechanical fore/aft adjustment.

Fully electric Sports seats.
If you don’t want to sacrifice sportiness
for comfort, the optional fully electric
Sports seats of fer fully electric adjustment
of seat height, backrest angle, squab angle,
sq ua b dept h, fore/a f t posi t io n, 4 - way
lumbar support and even the steering
column.
The integrated memor y package supports
the exterior mirrors and all seat positions
on the driver’s side as well as set tings
for the steering wheel, lights, wipers,
air conditioning, door locks, PCM, and
instrument cluster.

Sports seats Plus.
Available as an option are Sports seats
Plus in leather with electric seat height
and backrest adjustment as well as
mechanical fore/aft adjustment. The side
bolsters on the squab and backrest
have a firmer, sportier padding and offer
even bet ter lateral support. The backrest
shell is finished in Silver Grey.
Adaptive Sports seats Plus.
The optional adaptive Sports seats Plus
are the ideal combination of sport
and comfort. Finished in leather and
with side bolsters having a firm, sport y
padding, they also feature shoulder
supports for the best possible hold.
Of fering 18 -way electric adjustment,
the seats can be optimally adapted to
meet your needs in terms of seat height,
squab and backrest angle, squab length,
fore/aft adjustment and 4-way lumbar
support. The steering column is also
electrically adjustable.
Adaptive Sports seat Plus
In addition, the side bolsters on the seat
squab and backrest are independently
adjustable for added comfort on long
journeys and precision lateral support
on winding roads. Also included is the
personal memory for all seat positions
(apart from the side bolsters) and lumbar
support on the driver’s side as well as
the positions of the steering wheel and exterior mirrors. The memory function
also supports set tings for the steering
wheel, lights, wipers, air conditioning,
door locks, PCM, and instrument cluster.

The ideal basis for any relationship:

Support as well as freedom.

Seating.Seat heating and ventilation.
Seat heating is available as an option for
all seats. Seats are heated in the squab,
the backrest and, for the front seats, the
side bolsters.
In conjunction with seat heating, we can
equip the seats with seat ventilation on
request. A slipstream effect is produced
by active ventilation of the perforated
seat centre and backrest and by passive
aeration at the side bolsters. This evapo -
rates perspiration moisture and therefore
makes for a dry and pleasant seating
environment, even in hot weather.
Rear seats.
The rear seats are remarkably comfortable
for a sports car and the shelf behind
offers additional storage space. With the
backrests folded down, the luggage
compartment volume in the 911 Coupé
models increases to 205 litres and,
with a capacit y of 155 litres available,
the 911 Cabriolet models offer plent y of
space for luggage, too.
Child seats.
ISOFIX child seat preparation including
top tether is available on the rear seats
as standard. On request, we can equip
the front passenger seat with ISOFIX child
seat preparation and integrate an airbag
deactivation feature.
