Temperament
|
Engines
Engine cross section: 3.8-litre boxer engine
911 Carrera S models: 440 Nm at 5,600 rpm, 294 kW (400 hp) at 7,400 rpm
1. High - pressure pump
2. High-pressure injector
3. Ignition rod module
4. Camshaft controller
5. Valve lif t adjustment switch valve
6. Switch tappet with integrated valve clearance
compensation
7. Intake camshaf t
8. Intake valves
9. Valve spring
10. Combustion chamber with Alusil cylinder liner
surface
11. Forged aluminium piston
12. Forged connecting rod
13. Crankshaft
14. Water pump
15. Air-conditioning compressor
16. Power steering pump (in conjunction with PDCC)
17. Vibration damper
18. Alternator pulley with freewheel
19. Hydraulic belt tensioner
20. Resonance valve
21. Resonance distributor
22. Resonance valve actuator
23. Intake manifold with integrated sound chamber
24. Electronically controlled throttle valve
25. Oil filter
26. Electronic map-controlled thermostat
27. Vacuum pump
28. Coolant jacket
29. Crankcase breather
30. Timing chain
31. S t a r t e r
911 Carrera models: 390 Nm at 5,600 rpm, 257 kW (350 hp) at 7,400 rpm
The new 3.4-litre engine.
The 911 Carrera and the 911 Carrera
Cabriolet are equipped with a 3.4-litre
boxer engine with direct fuel injection
(DFI) and VarioCam Plus. It develops

257 kW (350 hp) at 7,400 rpm and the
maximum torque is 390 Nm at
5,600 rpm.
For the 911 Carrera with 7-speed manual
gearbox, this means acceleration from
0 to 100 km/ h (0 to 62 mph) in 4.8 sec -
onds and a top speed of 289 km/ h
(179 mph). The figures
achieved by the
911 Carrera Cabriolet
are 5.0 seconds
and 286 km/ h (177 mph). With the
optional Porsche Doppelkupplung (PDK),

it means figures of 0 to 100 km/ h
(0 to 62 mph) in just 4.6 seconds and
a top speed of 287 km/ h (178 mph)
for the 911 Carrera and 4.8 seconds
and 284 km/ h (176 mph) for the
911 Carrera Cabriolet.
The new 3.8-litre engine.
The 911 Carrera S and the 911 Carrera S
Cabriolet are powered by a 3.8-litre boxer
engine with direct fuel injection (DFI)
and VarioCam Plus. It produces 294 kW
(400 hp) at 7,400 rpm and the maximum
torque of 440 Nm is achieved at
5,600 rpm.
As a result, the new 911 Carrera S
with 7-speed manual gearbox completes
the sprint from 0 to 100 km/ h (0 to
62 mph) in
4.5 seconds and reaches
a top speed of 304 km/ h (188 mph). The
911 Carrera S Cabriolet
achieves 4.7 sec -
onds and 301 km/ h (187 mph). With
the
optional Porsche Doppelkupplung (PDK),
the figures are 0 to 100 km/ h (0 to
62 mph) in 4.3 seconds and a top speed
of
302 km/ h (187 mph) for the Coupé and
4.5 seconds
and 299 km/ h (185 mph) for
the Cabriolet.
For fuel consumption and CO
2 emissions please refer to page 129.
40 60 80
100
120 140 160 180 200 220 240 260
1500 75008000
2000 2500300035004000450050005500600065007000
1000
294 kW (400 hp)440 Nm
300
280
Power (kW)
T orque (Nm)
Engine speed (rpm)
200
280 300 320 340 360 380 400 420
220 240 260
460
440
40
60 80
100 120 140 160 180 200 220 240 260
1500 75008000
2000 2500300035004000450050005500600065007000
1000
300
280
Power (kW)
T orque (Nm)
Engine speed (rpm)
200
280 300 320 340 360 380
400 420
220 240 260
460
440
257 kW (350 hp)
390 Nm

3435
A widely held belief about motorsport is
that power is the only thing that mat ters.
From experience, we know bet ter. Extra
horsepower alone has never been enough
to win a single race. Much more important
to us are ideas – ideas that inspire more
intelligent vehicle concepts and more ef fi-
cient drive systems. The same applies on
the road. It ’s about get ting the most out
of what you’ve got. select neutral and release the clutch
pedal. In cars with Porsche Doppel
kupplung
(PDK), the engine switches off whenever
you stop and leave your foot on the
brake pedal.
All audio and communication systems
remain switched on and the climate con -
trol continues to maintain your selected
temperature. The only differences you
will notice are the silence at the rear and
the fuel saving. As soon as you operate
the clutch or release the brake, the
engine will restart swiftly and smoothly.
The auto start/stop function may remain
inactive under particular circumstances,
extreme outside temperatures, when the
SPORT but ton is selected or if bat tery
charge is low. It is also possible to deacti -
vate the function manually using a
separate but ton on the centre console.
Thermal management.
The new thermal management system
regulates the temperature in the engine
and gearbox through the intelligent
manipulation of heat flow.
In this way, the engine and gearbox reach
their optimum operating temperature
sooner. As a result, fuel consumption is
reduced through increased combustion
efficiency and lubrication performance.

Electrical system recuperation.
The new 911 models are also equipped
as standard with fuel-saving electrical
system recuperation technology.
The vehicle bat tery is recharged by the
alternator, predominantly under braking.
Under acceleration, on the other hand,
the power draw of the alternator is limit -
ed to increase the engine output availa -
ble for driving. The electrical systems
are supplied by the electrical energy
stored during the recharging process.
Temperament | Engines
Auto start/stop function.
The auto start/stop function is standard
in the new 911 models.
In cars with the manual gearbox, the
engine switches off automatically when,
for example, you stop at traffic lights,
Not as thirsty as you might think.

Efficiency- enhancing measures.
For fuel consumption and CO2 emissions please refer to page 129.
