198
Practical Tips, Emergency Service
Changing a WheelfHave the wheel changed at your authorized
Porsche dealer.Note
The tools required for changing a wheel (e.g. jack,
torque wrench, assembly aids) are not supplied as
standard with the vehicle. Your authorized
Porsche dealer will be pleased to advise you.
If a wheel has to be changed, the procedure
described below must be adhered to exactly,
as otherwise the wheel may become loosened,
resulting in damage. In such an event Porsche
will not be held liable.
For application of the required high tightening
torques of the central bolt, a suitable, commer-
cially-available 370 ftlb./500 Nm torque wrench
may be used. Alternatively, a corresponding tool
with torque multiplier (part no. 997.450.323.90)
is available from Porsche Motorsport. When the
torque multiplier is used, the torque should be
reduced in accordance with the tool operating
instructions.
Warning!
Risk of serious personal injury or death. The
car may slip off the jack.
fDue to the high assembly forces, there is a risk
of the car rolling away when using a jack.
Always use a lifting platform if there is one
available.
Risk of damage.
fDo not use an impact wrench.1. Fully apply the handbrake, engage 1st gear
and withdraw the ignition key.
2. Carefully secure the car against rolling away
in both directions, e.g. by placing wedges
under the wheels on the opposite side.
This is particularly important on slopes.
3. Raise the car until the wheel lifts off the
ground. Lift vehicle only at the specified
jacking points.
fPlease see the chapter “LIFTING THE VEHICLE
WITH A LIFTING PLATFORM OR GARAGE LIFT”
on Page 206.
10_GT3_21.book Seite 198 Donnerstag, 4. Juni 2009 12:48 12

206
Practical Tips, Emergency Service
Lifting the Vehicle with a Lifting
Platform or Garage Lift The car must be raised only at the illustrated
jacking points.
Caution!
Serious personal injury or death and/or
serious damage to the engine or the vehicle
may occur, if you lift the vehicle improperly.
fNever lift the vehicle at any other place than
the jacking points.
fNever lift the vehicle by the engine, transmis-
sion or axles.
fDo not damage any sensitive components in the vicinity of the jacking points.
Platform lift Before the car is driven on to a lifting platform, it
must be ensured that there is enough space
between the lifting platform and the vehicle. Garage lift A garage lift must be used only at the illustrated
jacking points.
