PORSCHE 911 TARGA4 2013 6.G Information Manual

103102True to style | Technical data
911 Targa 4911 Targa 4S
Weights
Manual/PDK Manual/PDK
Unladen weight (DIN) 1,5 4 0 k g / 1,5 6 0 k g1,555 kg /1,575 kg
Unladen weight (EC)
1)1,615 k g / 1,6 35 k g 1,6 3 0 k g / 1,65 0 k g
Permissible gross weight 1,925 k g / 1,9 45 k g1,9 6 0 k g / 1,9 8 0 k g
PerformanceManual/PDKManual/PDK
Top speed 175 mph/173 mph183 mph/182 mph
0 – 62 mph 5.2 secs/5.0 secs4.8 secs/4.6 secs
Sport Chrono Package (in conjunction with PDK) 0 – 62 mph –/4.8 secs–/4.4 secs
0 –99 mph 11.2 secs/10.8 secs10.2 secs/9.8 secs
Sport Chrono Package (in conjunction with PDK) 0 –99 mph –/10.5 secs–/9.5 secs
Flexibilit y (49 –74 mph). 5th gear 7.0 secs/–6.5 secs/–
Overtaking acceleration (49–74 mph) –/3.1 secs–/2.7 secs
Fuel consumption/emissions 2)Manual/PDKManual/PDK
Urban in mpg 21.6/ 23.922.6/30.3
Extra urban in mpg 3 7. 7/ 4 0 . 936.7/39.8
Combined in mpg 2 9 . 7/ 3 2 . 528.2 / 3 0.7
CO
2 emissions in g / km 223/2042 3 7/ 2 14
Dimensions/aerodynamics
Length 4,491 m m4,491 m m
Width 1,8 52 m m1,8 52 m m
Height 1, 2 9 8 m m1, 2 91 m m
Wheelbase 2,450 mm2,450 mm
Luggage compartment volume (German Car Manufacturers’ Assoc.) 125 l i t re s125 l i t re s
Tank capacity (refill volume) 68 litres68 litres
Drag coefficient 0.300.30
911 Targa 4 911 Targa 4S
Engine
Cylinders 6 6
Displacement 3,436 cm
33,800 cm3
Max. power (DIN)
at rpm257 kW (350 hp)
7, 4 0 0 294 kW (400 hp)
7, 4 0 0
Max. torque
at rpm 390 Nm
5,600 440 Nm
5,600
Compression ratio 12.5 : 1 12.5 : 1
Transmission
LayoutAll-wheel drive All-wheel drive
Manual gearbox 7-speed 7-speed
PDK (optional) 7-speed 7-speed
Chassis
Front a xleMcPherson strut suspension McPherson strut suspension
Rear axle Multi-link suspension Multi-link suspension
Steering Variable steering ratio, power-assisted (electromechanical) Variable steering ratio, power-assisted (electromechanical)
Turning circle 11.1 m 11.1 m
Brakes Four-piston aluminium monobloc fixed calipers front and rear,
discs internally vented and cross-drilled Six-piston aluminium monobloc fixed brake calipers at front,

four-piston units at rear, discs internally vented and cross- drilled
Vehicle stability system Porsche Stability Management (PSM) including ABS
with additional brake functions
Porsche Stability Management (PSM) including ABS

with additional brake functions
Standard wheels Front: 8.5 J x 19 ET 54, Rear: 11 J x 19 ET 48 Front: 8.5 J x 20 ET 51, Rear: 11 J x 20 ET 52
Standard tyres Front: 235/40 ZR 19, Rear: 295/35 ZR 19 Front: 245/35 ZR 20, Rear: 305/30 ZR 20
1) Weight is calculated in accordance with the relevant EC Directives and is valid for vehicles with standard specification only. Optional equipment increases this figure. The figure given includes 68 kg for the driver and 7 kg for luggage.2) Data determined in the NEDC (New European Driving Cycle) in accordance with the Euro 6 (715/2007/ EC, 195/2013/ EC and ECE- R 101.1) measurement method. The figures do not refer to an individual vehicle nor do they constitute par t
of the of fer. They are intended solely as a means of comparing dif ferent t ypes of vehicle. Fuel consumption calculated for vehicles with standard specification only. Actual consumption and per formance may var y with items of optional
equipment. A vehicle’s fuel consumption and CO
2 emissions depend not only on its ef ficient use of fuel but also on driving st yle and other non -technical factors. The latest Porsche models with petrol engine are designed to operate on
fuels with an ethanol content of up to 10 %. You can obtain fur ther information about individual vehicles from your Porsche Centre.
3) Valid in the countries listed only.

105104
Index
A
Adaptive cruise control 68
Air conditioning 67
Airbags 52
Anti-theft protection 68
Audio interface, universal 70, 72
Auto start/stop function 35
B
Bi-Xenon headlights 54
Body 43
BOSE
® Surround Sound System 74
B r a ke s 51
Burmester
® High - End
Surround Sound System 74
C
Catalytic converter 56
CD/ DVD autochanger 70
Chassis 41
Coasting 39
Colours Exterior 78
Interior 80 Co m fo r t
61
Communication 89
Cruise control 68
D
Digital radio 70
Direct fuel injection (DFI) 35
Dynamic engine mounts 48
E
Electrical system recuperation 35
Emission control 56
Engine management, electronic 46
Engineered design 43
Engines 33
3.4-litre boxer engine 35
3.8-litre boxer engine 35
Environment 56
Exhaust system 35
Exterior mirrors and rear-view mirror 68
F
Front axle 40
Fuel 56
Fuel consumption 56
H
Headlight cleaning system 54
HomeLink
® (programmable
garage door opener) 67
Hood 16
I
I number 84
Instruments 61
L
Leather 80, 88
LED main headlights 54
Light design package 67
Lights 54
Logbook, electronic 70
Luggage compartment 69
M
Manual gearbox 37
Memory package 64
Mobile phone preparation 72
Models 20
O
On-board computer 61
Online services 72
P
Panorama 98
Park Assist 68
Park Assist (front and rear) 68
Parking brake, electric 52
Performance display 70
Personalisation 78
Porsche Active Suspension
Management (PASM) 43

Porsche Ceramic Composite Brake
(PCCB) 52
Porsche Communication
Management (PCM) 70
Porsche Doppelkupplung (PDK) 37

Porsche Dynamic Chassis Control
(PDCC) 44

Porsche Dynamic Light System
(PDLS) 54
Porsche Dynamic Light System Plus
(PDLS +
) 54 Porsche Entry & Drive
68

Porsche Side Impact Protection
System (POSIP) 52

Porsche Stabilit y Management (PSM) 48

Porsche Torque Vectoring (PT V) 48

Porsche Torque Vectoring Plus
(PT V Plus) 48

Porsche Traction Management (PTM) 40
Power steering 44
Power steering Plus 44
R
Rain sensor 68
Rear axle 40
Rear differential lock 48
Recycling 56
Roll-over protection 52
Roof concept 17
S
S a f e t y 51
Seat heating 65 Seat ventilation
65
Seats Adaptive Sports seats Plus 64
Child seats 88
Fully electric Sports seats 64
Rear seats 65
Sports bucket seats 65
Sports seats 64
Sports seats Plus 64
Speed limit display 72
SPORT but ton 46
Sport Chrono Package 46
SPORT PLUS but ton 46
Steering 44
Steering wheel heating 63
Steering wheels Multifunction steering wheel 63
SportDesign steering wheel 63
Sports steering wheel 63
Stereo Lambda control circuits 56
T
‘ targa’ logo 17
Technical data 102Telephone module
72
TFT display 61
Thermal management 56
Transmission 102
T V tuner 72
Tyre Pressure Monitoring (TPM) 63
V
VarioCam Plus system 33
Voice control system 72
W
‘Welcome Home’ lighting 68
Wheels 48
