The new 911 Turbo is also
available with an optional high-
performance braking system:
the Porsche Ceramic Composite
Brake (PCCB). Successfully
tested in the toughest endurance
racing, this unique technology
has been further refined for even
greater road performance.The key components in PCCB
are the moulded ceramic discs
(front/rear diameter: 380 mm/
350 mm). The larger front discs
provide greater leverage and
therefore better brake performance.
Thediscsaremadefrom a
specially treated carbon-fibre
compound that is silicated in a
high-vacuum process at 1,700 ºC.
The resulting material is not
only much harder than metal, it
is also more resistant to heat.
Even at high temperatures, the
thermal resistance of the PCCB
disc ensures excellent dimensional
stability. The ceramic material is
totally resistant to corrosion and
offers excellent acoustic damping
properties.The pads are mounted in six-
piston monobloc aluminium
fixed calipers at the front, with
four-piston units at the rear.
The resulting brake forces are
not only extremely high, they are
also exceptionally consistent.
The pedal response is fast andprecise, with only moderate input
required.
The key advantage of PCCB is the
total weight saving over comparable
metal discs of approximately 50 %.
As well as enhancing performance
and fuel economy, this represents
a major reduction in both the
unsprung and rotating masses.
This, of course, produces
additional benefits in terms of
comfort and road-holding on
uneven road surfaces as well as
general handling and agility.
For more information, see thelatest PCCB brochure available
from your Porsche Centre.
· 70 ·· 71 ·The new 911 Turbo |
Safety
PCCB
Porsche Ceramic Composite Brake (PCCB).
When it comes to developing new brake technology,
nothing holds us back.

Porsche Communication
Management (PCM). This
comprehensive system features
satellite navigation with a
separate DVD drive in the
luggage compartment for
the single navigation disc.
The one-touch switches on the
centre console are logically
positioned for optimum ease of
use. All instruments are perfectly
placed within the driver’s field of
vision. The air-conditioning system
is fully automatic and features a
highly effective active carbon filter.
This added convenience gives
you greater freedom to enjoy the
driving experience.
The tinted front glass and generous
rear screen offer excellent fore-
and-aft visibility. The front side
windows have a water-repellent
finish, which automatically
disperses moisture and dirt.
The result: optimum visibility in
poor weather conditions.
Instruments.
The classic arrangement of five
round instruments provides a
clear overview of all key information.
The digital display in the centre-left
dial (speedometer) provides main
and trip odometer readings. The
central rev counter, featuring the
‘turbo’ logo, includes the standard
on-board computer display.
This multi-purpose field contains a
permanent digital speedometer
as well as the following optional
information: boost pressure,
average speed, average fuel
consumption, tyre pressure,
current radio station, navigation
instructions and remaining range
till empty. When ‘Sport’ mode
is selected on the optional Sport
Chrono Package Turbo, the
temporary increase in torque is
clearly indicated using an arrow
symbol in the boost pressure
display. The third display, in the
centre-right dial, contains a
clock and external temperature.
The dot-matrix technology used in
each of these displays provides
a high resolution for icons and
text. Design and legibility are
further enhanced with brilliant
white backlight illumination.
· 78 ·· 79 ·The new 911 Turbo |
Comfort
Interior.
For the pure enjoyment of performance.
The passenger compartment in the
new 911 Turbo is another example
of uncompromising design. As you
would expect, it offers the highest
standards of ergonomics, comfort
and quality. The seats, dashboard,
doors and rear side panels are
finished in leather as standard. Atthe centre of the cockpit is a new
gear lever design that’s exclusive
to the new 911 Turbo.
Other standard features include
a three-spoke sports steering
wheel offering 40 mm of
adjustment for both height and
reach. A three-spoke multi-function
steering wheel – available as
optional equipment – provides
direct access to audio, navigation
and (if fitted) telephone functions.
The standard audio package
is the latest evolution of

Storage compartments.
The new 911 Turbo is not only
a powerful performer, it is also
highly versatile. Added to the
comfort and ergonomics of the
interior are a range of practical
features.
The storage compartments in the
doors and centre console feature
matching upholstered lids. These
are positioned at precisely the
same height to form comfortable
armrests on longer journeys.
Beneath the front passenger
airbag, behind a fold-down trim,
are two cupholders for driver and
front passenger. Beneath the
cupholders is a lockable glove
compartment featuring integral
CD storage.
Two 12 V sockets (including the
cigar lighter) provide power for
electrical equipment. An optional
fire extinguisher is also available,
installing neatly out of sight but
always within reach directly ahead
of the driver’s seat.
‘Welcome Home’ lighting.
This standard function provides
generous illumination via the
foglight units when the key remote
is used to lock or unlock the
car. As the name suggests, it is
particularly convenient when
returning home after dark. On
vehicles equipped with the optional
Sport Chrono Package Turbo, the
timing delay can be programmed
via the Porsche Communication
Management (PCM) terminal.
ParkAssist.
This optional parking aid is auto-
matically enabled whenever you
select reverse gear. Move too
close to a stationary object and
a warning signal is emitted.
Continue to reverse and the tone
increases in frequency. The
ultrasonic sensors are neatly
concealed within the rear apron
moulding.
Cruise control.
This optional system is available
from 30 to 240 km / h
(20 – 149 mph) and can even be
used in first gear. The system is
operated using a separate control
stalk on the steering column.
HomeLink®.
This optional garage-door opener
is integral to the car and offers
full remote control for up to three
garage doors. It can also be used
with gate, home lighting and alarm
systems. Compatible with virtually
all garage and gate systems.
Rear wiper.
Also available as an option, the
rear wiper system includes a flat
and streamlined ‘aero’ blade which
blends with the exterior of the car.
Interior and exterior mirrors.
All three rear-view mirrors on the
new 911 Turbo feature auto-
dimming glass as standard. The
interior mirror also includes an
integral rain sensor for the front
wiper system.
Slide /tilt sunroof.
This electrically operated and
steplessly adjustable slide/tilt
sunroof is also available as an
option. In the tilted position,
it offers comfortable ventilation
of the passenger compartment,
even when travelling at high speed.
· 82 ·· 83 ·The new 911 Turbo |
Comfort
Glove compartment
Slide/tilt sunroof

· 85 ·The new 911 Turbo |
Comfort
Luggage compartment.
In addition to the loadspace in the
rear seat area, the new 911 Turbo
has a 105-litre front luggage
compartment. The bulkhead
panelling conceals the standard
audio amplifier for the BOSE
®
Surround Sound System, as well
as the DVD drive for the
navigation module. The optional
CD autochanger is installed on the
right-hand side of the compartment
(looking forwards). The entire
compartment is lined with high-
quality, scratch-resistant
materials.
Roof transport system.
The optional roof transport
system is made from lightweight
aluminium, making it extremely
easy to fit. It is also styled to
match the exterior design as well
as the car’s aerodynamics. The
basic load-carrying bars can
be
combined with a range of
attachments from Porsche
Tequipment, including a roof box
and carriers for bikes, snowboards
and skis. Maximum roof load is
75 kg.
Anti-theft protection.
Standard anti-theft equipment
on the new 911 Turbo includes
an engine immobiliser with in-key
transponder. The comprehensive
alarm system features contact-
sensitive exterior protection and
radar-based interior surveillance.
Vehicle tracking system.
Optional protection includes a
factory-fitted preparation enabling
future installation of a vehicle
tracking system from Porsche
Tequipment. In the event of theft,
the system enables remote
tracking of the stolen vehicle
across most European countries.
Also requires special wiring
loom and higher capacity battery.
· 84 ·Luggage compartment
Roof transport system

Antenna diversity.
The PCM package includes four
separate antennae which are
discreetly incorporated within the
windscreen glass. This simple
solution enables the twin-tuner
radio system to find the strongest
possible signal, thereby enhancing
FM reception.
On-board computer.
The PCM computer offers a wide
range of information, including
average fuel consumption, average
speed, range till empty, journey
time and external temperature.
It can also be used to view data
from the optional Tyre PressureMonitoring (TPM). The computer
is operated using a separate
control stalk, displaying key infor-
mation in the central instrument
dial. The same control stalk
is used to operate the timing
functions in the optional Sport
Chrono Package Turbo.
Electronic logbook.
This optional addition to PCM
enables automatic logging on
every journey of mileage, route
distance, date and time as well as
starting location and destination.
Data can be downloaded from
PCM via an infrared port and
processed on a computer using
software included with the
package. This easy-to-use option
fulfils all the requirements for
automatic logbooks as specified
by the German revenue authorities.
Telephone module.
The optional GSM telephone has
a 12-digit keypad and a hands-
free facility offering excellent callquality. The hands-free microphone
is located next to the steering
column and is ideally positioned
for the driver. The telephone
system supports SMS (text)
messaging as well as card-free
calls to emergency services. An
optional passive (keyless) handset
with leather-trimmed console
enables clearer communication
as well as greater privacy when
making a call.
CDC-4 CD autochanger.
This optional CD autochanger has
a total capacity of six audio
CDs and installs beneath a panel
in the luggage compartment.
An autochanger preparation is
included as standard.
· 88 ·· 89 ·The new 911 Turbo |
Comfort
Passive (keyless) handset

Servicing.
Longer service intervals are not
only easier on resources, they
also reduce ownership costs. The
new 911 Turbo has very modest
servicing requirements of 18,000
miles or every two years (standard
service) and 36,000 miles or
every four years (major service).
The replacement intervals for
parts and fluids have also been
significantly extended: engine
oil and filter every 18,000 miles,
air filter every 36,000 miles,
spark plugs every 36,000 miles
or four years, and fuel filter every
56,000 miles.
Noise.
The new 911 Turbo complies with
all noise regulations worldwide.
Instead of resorting to engineencapsulation, we’ve eliminated
noise at source: engine com-
ponents are more rigid, moving
parts are lighter, and tolerances
have been reduced to a minimum.
High-efficiency silencers in durable
stainless steel help to minimise
noise throughout the life of the
car. All that remains, both inside
and out, is the famous Porsche
sound.
Fuel system.
Key developments in the fuel
supply system include a further
reduction in the evaporation of
hydrocarbons. This is achieved
through a combination of active
carbon filter and specially coated
fuel tank. All fuel lines are made
from robust aluminium, while
those carrying vapours use multi-
layer plastic.
· 96 ·· 97 ·The new 911 Turbo |
Environment

Porsche Crest embossed on head restraint Passive (keyless) handset
· 114 ·· 115 ·
OptionI no. Page
• Extended trim package (doors) in leather•
•XTV
•
Sports seat backrests in leather• •XSB
• Porsche Crest embossed on head restraints
• •XSC 114
•
Passive handset in leather• •XEA 114
• Rear centre console in leather
• •XMZ 112
• Rooflining in leather
• •XMA
• Sun visors in leather
• •XMP
•
Interior light surround in leather• •XZD
• Inner door-sill guards in leather
• •XTG
Interior: leather.
Interior with macassar trim and other optional equipment
OptionI no. Page
• Macassar interior package•
•801 115
• Extended trim package (dashboard) in macassar
• •EAB 115
• Three-spoke multifunction steering wheel in macassar
• •451 115
•
Extended trim package (doors) in macassar• •XTT 115
• Rear centre console in macassar
• •XJT 115
Interior: macassar (dark satin wood).
•
•extra-cost option W no-cost option
For more information on optional equipment, please refer to the 911 Turbo price list.

· 120 ·· 121 ·
Factory
collection 911
From our hands to yours.
Where better to experience the
first moments with your Porsche
than at the home of Porsche
engineering.
Almost 60 years ago, our first
large-scale production models
were crafted by hand in a modest
red-brick building, here in
Zuffenhausen. From those humble
beginnings, the factory has
evolved into one of the most
advanced production facilities in
the world. Today, it’s home to anew generation of legends: the
911, the Boxster, the Cayman S
and, of course, your Porsche.
Our factory collection programme
offers a unique insight into
the origins and making of your
Porsche. Like your car, a visit to
Zuffenhausen is an absorbing mix
of past and future, history and
innovation, heritage and creativity.
To take advantage of this exclusive
opportunity, please inform your
Porsche Centre when you place
your specification. A collection
date can then be arranged when
final information regarding the
build of your car has been
confirmed. Your Porsche can be
Make the most of your journey.
And discover more about your
Porsche.
Our factory tour offers a detailed
insight into the latest production
processes. These range from
engine assembly and the prep-
aration of upholstery, to the
‘marriage’ of powertrain and body.
The factory tour is one of our
oldest traditions, and is usually
conducted by a retired member
of staff. Each of our guides is
a genuine Porsche enthusiast
with a genuine passion for the
marque. On average, the tour
takes around one-and-a-half
hours to complete, and follows
delivery of your Porsche. The keys
will be presented by a member
of the Factory Collection Team
who will explain everything you
need to know about the car.
You can now take your place
behind the wheel, and experience
what it means to drive your
own Porsche. For the perfect
introduction to the pleasure
of Porsche ownership,* you may
wish to combine your visit with
one of the exclusive offerings
from the Porsche Travel Club.
Each one offers a fascinating
blend of culture, adventure and
first-class hospitality.
every stage in the building of
a Porsche.
Next, you can visit the Porsche
Museum, where you’ll find a
fascinating cross-section of
legendary Porsche models from
every era of our history.
If there’s time, you can relax with
a refreshment in the customer
lounge or browse in the Porsche
Design Driver’s Selection shop.
You can also enjoy a three-course
lunch at our exclusive guest
restaurant.
The highlight of your visit,
however, will undoubtedly be
the moment when you finally take
Porsche factory in ZuffenhausenPorsche Design Driver’s Selection shopPorsche Museum
collected on any working day*
(Monday to Friday) at a time that
suits your requirements.
The easiest way to travel from
outside Germany is to fly to either
Stuttgart or Frankfurt and then
continue by train, taxi or hire car.
Please note that there are a
number of formalities that must be
completed when you take delivery
of your car. For full details, please
consult your Porsche Centre, who
will also be happy to assist when it
comes to planning your trip.
* Please note that collection is not possible
during the factory shutdown periods.* Depending on insurance regulations
for your market.
