3233For fuel consumption, CO2 emissions and efficiency class please refer to page 131.
converter to reach normal operating
temperature sooner after a cold start and
a higher maximum torque to be achieved.
DFI improves the internal cooling of the
combustion chamber by having the
mixture prepared directly in the cylinder.
This allows for a higher compression ratio,
which helps to deliver higher power output
at the same time as enhanced engine
efficiency. Injection is regulated by the
electronic engine management system
and emissions are monitored by the stereo
Lambda sensors.
Direct fuel injection (DFI).
Direct fuel injection (DFI) is featured
as standard in both Boxster models.
Multi-hole injectors deliver fuel directly
into the combustion chamber with milli -
second precision. The injection pattern
has been optimised for torque, power
output, fuel consumption and emissions.
With direct injection, the engine manage -
ment system regulates injection timing
individually for each cylinder, as well as
the injection rate for each cylinder bank.
This optimises the combustion process
and therefore fuel economy. Depending
on the engine operating conditions, multi -
ple fuel injections can take place on each
operating cycle. This allows the cataly tic
Resonance intake manifold.
The resonance effect, where the air mass
inside the intake manifold is caused to
oscillate, is used to optimise the induction
process at all engine speeds. The engine
in the Boxster S is additionally equipped
with a switchable resonance valve.
The results are high torque, a flat ter
torque curve and high power output.

The sound produced is characteristically
resonant and deep, as you would expect
of a Boxster.

42
4342
43Fo r w ar d t h r u s t |
Engine
For fuel consumption, CO2 emissions and efficiency class please refer to page 131.
Servicing.
In the Boxster models, the generator and
air conditioning system are driven by a
single self-adjusting belt. The drive chains
on the camshafts do not normally require
servicing. With the sole exception of the
spark plugs, the ignition system is also
maintenance-free in normal servicing. In
short, longer service intervals mean long er-
lasting driving pleasure.
initiation of targeted braking. During this

process, any braking by the driver is
boosted to achieve the maximum braking
force that the system is able to provide.
Electrical system recuperation.
For enhanced ef ficiency the Boxster
models are equipped with intelligent elec -
trical system recuperation. The vehicle
bat tery is recharged by the generator
predominantly under braking. Thanks to
this selective recharging, when you
request full driving power the maximum
possible output can be directed straight to
the road.
For increased safet y, the system also
readies the brakes whenever it detects
that the distance from the vehicle is

decreasing. However, the driver should
be prepared to intervene manually if
heavier braking is required. As soon as
the road ahead clears, your vehicle will
accelerate back up to the cruising speed
originally set.
Porsche Active Safe (PAS) issues an audi -
ble and a visual warning if the system
detects that your vehicle is approaching
the vehicle in front too quickly. This is
accompanied by a brief application of
brake force and, where necessary, the

3
2
1
56
57
PCCB enables shorter braking distances
in even the toughest road and race
conditions. Excellent fade resistance
ensures greater balance when slowing
from racetrack speeds.
1 Standard brake on the Boxster
2 Standard brake on the Boxster S
3 Porsche Ceramic Composite Brake (PCCB)
road. The optional Porsche Ceramic
Composite Brake (PCCB) is a fine exam-
ple. This brake system has already had
to cope with the harshest requirements
of motor racing and is fit ted in cars
that compete in demanding events such
as the Porsche Mobil 1 Supercup.
The cross- drilled PCCB ceramic brake

discs for the Boxster have a diameter of
350 mm front and rear for even more
formidable braking performance.
The use of six-piston aluminium mono -
bloc fixed brake calipers on the front axle
and four-piston units at the rear – all
finished in yellow – ensures extremely
high brake forces which, crucially, are
exceptionally consistent.
The dynamics of the Boxster and
Boxster S also demand appropriate brake
discs. All Boxster brake discs are intern -
ally vented and cross-drilled for improved
braking in wet conditions. With a diame -
ter of 330 mm, the front brake discs of
the Boxster S are 15 mm larger than
those of the Boxster. The diameter of
the rear brake discs is 299 mm on both
models. The brake calipers on the
Boxster and Boxster S are black and red,
respectively.

Porsche Ceramic Composite Brake
(PCCB).
From the start, Porsche has been syn -
onymous with motorsport. Ever since
1948, when we found our identit y on the
racetrack, we have taken the experience
we have gained and applied it to the

Brakes.
Porsche brakes set standards worldwide
for stopping power and stability. For the
Boxster models, braking per formance is
as essential as driving performance.
Both models are equipped with four-
piston aluminium monobloc fixed calipers
at the front and rear. This design means
that, not only are the brakes extremely
resistant to deformation, they are light -
weight for a particularly fast and sensitive
braking response.
Large brake calipers help to provide
excellent braking and component stability
even during continuous use. These t wo
characteristics have also been optimised
by the brake ventilation system with air
spoiler at the front and rear axles.

2 1Free space |
Interior and comfort
1 Air conditioning system
2 Two-zone automatic climate controlprotection with the hood closed, is availa -
ble on request. A combined alarm and
radar-based interior surveillance system
is available as an option for the Boxster.
Porsche Vehicle Tracking System
(PV TS).
Available as an option, this preparation
enables future installation of the Porsche
Vehicle Tracking System (PV TS) available
from Porsche Tequipment. The system
makes it possible to locate a stolen
vehicle across most of the countries of
Europe. The preparation package inclu -
des a special wiring loom and a tilt sen -
sor for the alarm system.
mented by a visual warning in the central
display of the CDR audio system, optional
CDR Plus or optional PCM, which shows a
graphical representation of the vehicle
from overhead.
HomeLink®

(programmable garage door opener).
The optional programmable garage door
opener is integrated into the overhead
console and remotely controls up to three
different garage doors, gates, home light -
ing and/or alarm systems.
Anti-theft protection.
Both Boxster models are equipped as
standard with an immobiliser with in-key
transponder. In addition, the Boxster S
has an alarm system with contact-sensitive
exterior protection. A radar-based interior
surveillance system, which en hances
option, electrically folding exterior mirrors
with door courtesy lighting on both sides
of the vehicle make it easier to find your
way in the dark. An auto-dimming function
for the exterior mirrors and rear-view mir -
ror with an integrated rain sensor for the
windscreen wipers, is available as an
option.
ParkAssist.
Optional Park Assist is activated the mo -
ment you select reverse gear. An audible
signal gives a warning if you reverse too
close to an obstacle.
An enhanced version of Park Assist also
provides monitoring of the area to the
front of the vehicle. Ultrasonic sensors
are neatly integrated into the front and
rear aprons. The audible alert is supple-
Light design package.
The optional light design package com -
prises dimmable LEDs in the overhead
console, in the area of the door handles,
in the door storage compartments and in
the foot wells. LED illumination of the
luggage compartments and in the vanit y
mirrors of the sun visors is also included
with the light design package.
‘Welcome Home’ lighting.
The ‘Welcome Home’ lighting function
automatically switches on the LED day -
time running lights for a user- defined
period whenever the vehicle is opened
or closed using the key remote.
Exterior mirrors and rear-view mirror.
The Boxster models are equipped as
standard with electrically adjustable and
heated exterior mirrors. Available as an
Wave goodbye to everyday life.
But embrace everyday practicality.
Additional comfort and convenience features.
Air conditioning system.
An air conditioning system with integrat -
ed active carbon filter is fit ted as stand -
ard. The filter traps particles, pollen and
odours. The ventilation pat tern is wide
and the air conditioning is quiet and
ef fective.
Two-zone automatic climate control.
Two-zone automatic climate control is
available as an option. It provides an
enhanced ventilation effect and has sepa -
rate temperature controls for the driver
and passenger. The available air condi -
tioning modes are gentle, normal and
strong. The automatic air-recirculation
function permanently monitors air quality,
reduces humidity and switches from
fresh to recirculated air when required.

132133
Index
C
CD/ DV D au tochanger 101
CDR audio system 96
CDR Plus audio system 96
Chassis 50
Child seats 88
Coasting 46
Colours 110
Exterior 110
Interior 112
Comfort 82
Cruise control 40
D
Design 12
Digital radio 101
Direct fuel injection (DFI) 33
Dr y-sump lubrication, integrated 34
Dynamic gearbox mounts 66
E
Electric parking brake 59
Electrical system recuperation 42
Engine management 38
Engineered body design 70Engines
28
2.7-litre engine 30
3.4 - litre engine 30
Environment 77
Exhaust emission control 77
Exhaust system 36
Exterior 12 , 110
Exterior mirrors and rear-view mirror 92
F
Factory collection 12 5
Floor mats 11 8
Fuel 79
Fuel consumption 78
G
Gearbox mounts, dynamic 66
H
Handset for telephone module,
cordless 99
HomeLink
® (programmable
garage door opener) 92
Hood, fully electric 94I
Instruments
84
Integrated dr y-sump lubrication 34
I nte r i o r 16 , 8 2, 112
ISOFIX child seat preparation 88
L
Leather package 8 4 , 112
Light design package 92
Lights 74
Logbook, electronic 98
Luggage compartments 91
M
Manual gearbox, 6-speed 45
Materials 78
Mobile phone preparation 101
N
Navigation module 96
O
Online services 101P
Panorama
12 6
Pa r k A ssist 92
Parking brake, electric 59
Personalisation 10 8
Porsche Active Suspension
Management (PASM) 50
Porsche Car Configurator 12 3

Porsche Ceramic Composite
Brake (PCCB) 57
Porsche Communication
Management (PCM) 96
Porsche Doppelkupplung (PDK) 45

Porsche Driving Experience 124

Porsche Dynamic Light System
(PDLS) 74
Porsche Exclusive 12 2
Porsche Side Impact Protection
System (POSIP) 73
Porsche Stabilit y Management (PSM) 60

Porsche Torque Vectoring (PTV) 62

Porsche Vehicle Tracking
System (PV TS) 93
Power steering 53Power steering Plus
53
Principle 12 8
R
Recycling 78
Resonance intake manifold 33
Roll - over protection 72
S
Safety 70
Seat heating 88
Seat ventilation 88
Seats 88
Adaptive Sports seats Plus 88
Child seats 88
Fully electric Sports seats 88
Sports bucket seats 88
Sports seats 88
Sports seats Plus 88
Servicing 42, 79
Smoking package 11 8
Sound Package Plus 102
SPORT button 38
Sport Chrono Package 65Sports exhaust system
36
Steering 52
Steering wheel heating 87
Steering wheels 87
Multifunction steering wheel 87
SportDesign steering wheel 87
Sports steering wheel 87
Storage options 90
T
Technical data 13 0
Telephone module 99
TF T screen 85
Thermal management 36
Tra n s m i ssi o n 45
T V tuner 98
Tyre Pressure Monitoring (TPM) 55
U
Universal audio interface 9 6 , 101
V
VarioCam Plus 34
Voice control system 98W
Water- repellent side windows
94
‘Welcome Home’ lighting 92
Wheels 54
Wind deflector 95
Index
A
Adaptive cruise control including
Porsche Active Safe (PAS) 41
Air conditioning system 92
Airbags 72
Alarm system 93
Anti-theft protection 93
Audio and communication 96
Audio interface, universal 96
Auto start/stop function 39
Automatic climate control, two-zone 92
Automatic headlight activation 75
B
Bi-Xenon headlights 74
BOSE
® Surround Sound System 102
Boxer engines 28
Boxster 22
Boxster concept 9
Boxster S 24
Brakes 57
Burmester
® High - End
Surround Sound System 10 4
