snow chains PORSCHE CAYMAN 2006 1.G Owners Manual

Controls, Instruments
63
Examples of PSM control operations
– If the “front wheels of the vehicle drift” on a
bend, the rear wheel on the inside of the bend
is braked and the engine power is reduced if
necessary.
– If the rear of the vehicle swings out on a bend,
the front wheel on the outside of the bend is
braked.
PSM should always be switched on during
“normal” driving.
However, it may be advantageous to switch off
PSM temporarily in exceptional situations, for
example:
– On a loose surface or in deep snow,
– When “rocking the vehicle free”, or
– When using snow chains.
Switching off PSMfPress the PSM OFF button.
PSM is switched off after a short delay.
The light-emitting diode in the button is illumi-
nated.
When the PSM is switched off, the multifunc-
tional PSM light on the instrument panel is lit
and a message is shown by the on-board
computer.
An acoustic signal also sounds.The following functions stabilize the vehicle in
emergency situations, even with PSM switched
off:
– When PSM is off, the vehicle is stabilized as
soon as one of the two front wheels enters the
ABS control range.
– When PSM is off and Sport mode is on, the
vehicle is stabilized as soon as both front
wheels enter the ABS control range.
One-sided spinning of the wheels is reduced,
even with PSM switched off, to enable optimum
traction on all drive wheels.
Switching PSM back onfPress PSM OFF button.
PSM is switched on after a short delay.
The light-emitting diode in the button and the
multifunctional PSM light go out.
The on-board computer shows a message.

218
Practical Tips, Emergency Service
Snow chains
Caution!
Risk of damage to body, axle or brake com-
ponents.
fFit snow chains only to the rear wheels, and
only with the tire/rim combination listed in the
Technical Data.
To ensure adequate clearance between chain
and body, Porsche recommends only the use
of fine-link chains such as those approved by
Porsche.
fFollow instructions issued by the supplier of the chains.
Different states and countries have varying statu-
tory requirements regarding maximum speed.
Check with local authorities for possible restric-
tions.
Remove chains as soon as the roads are free of
ice and snow. Fitting snow chains
The use of snow chains is not permitted when
5 mm spacers are mounted.
Caution!
Risk of damage to the wheel housings if the
5 mm spacers are not removed before fitting
snow chains.
fTo permit the fitting of snow chains, have the 5 mm spacers removed on all 4 wheels.
fTo fit/remove the spacers:
Please consult an authorized Porsche dealer.
fPlease observe the chapter “SPACERS” on
Page 230.
Tire designations Due to new speed and load ratings for radial tires,
new designations have come into force for snow
tires for your Porsche.
The designation to be used for ZR tires is e.g.,
265/40 ZR 18 (Z = code letter for radial tires for
speeds above 150 mph / 240 km/h).

230
Practical Tips, Emergency Service
SpacersfUse the spacers only together with wheels and
fastening parts approved by Porsche.
Before having spacers fitted, find out about the
current authorization status.
Mounting an emergency spare wheel
If 5 mm spacers are fitted, these must not be
removed to mount an emergency spare wheel.
Fitting snow chains
The use of snow chains is not permitted when
5 mm spacers are mounted.
Caution!
Risk of damage to wheel housings if the
5 mm spacers are not removed before fitting
snow chains.
fIn order to enable the fitting of snow chains,
have the 5 mm spacers removed on all 4wheels.Note on operation
fTo fit/remove the spacers:
Please consult an authorized Porsche dealer.
Removing the spacersfPlease observe the chapter “CHANGING A
WHEEL” on Page 228.
1. Unscrew both countersunk screws (M6x16) on
the wheel hub.
2. Remove the spacer.
3. Fasten the brake disc with the short M6x12
countersunk screws, part No.
900.269.047.09.
Tightening torque 10 Nm (7.5 ftlb.).
4. For wheel mounting without a spacer, 5 mm
shorter wheel bolts (part No:
996.361.203.02) must be used.
Tightening torque 130 Nm (96 ftlb.).Required scope of parts if the spacers are
removed
Short countersunk screws (M6x12)
Part No: 900.269.047.09
1 set of short wheel bolts
Part No: 996.361.203.02
Short anti-theft protection devices
Part No: 996.361.057.01

268
Vehicle Identification, Technical Data
Tires, Rims, Tracks
Danger!
Installation of sizes not authorized by
Porsche may have a dangerous effect on
the driving stability and could result in
severe personal injury or death.
fBefore mounting new tires, check with yourPorsche dealer about the current release status. Tire Rim Rim offset Track
Summer tires
front 235/40 ZR 18 91Y 8 J x 18 H2
57 mm 58.5 in./1486 mm
rear 265/40 ZR 18 101Y XL9 J x 18 H2
43 mm 60.2 in./1528 mm
or front 235/35 ZR 19 87Y8 J x 19 H2
57 mm 58.5 in./1486 mm
rear 265/35 ZR 19 94Y9.5 J x 19 H2
46 mm 60.0 in./1522 mm
Snow tiresfront 235/40 R 18 91V M+S8 J x 18 H2
57 mm 58.5 in./1486 mm
rear * 255/40 R 18 95V M+S9 J x 18 H2
43 mm 60.2 in./1528 mm
The load capacity coefficient (e.g. “91”) and maximum speed code letter (e.g. “V”) are minimum requirements.
Please observe the chapter “TIRES/WHEELS” on Page 207.
Tire and rim sizes
Extensive tests are performed before specific tires and wheels are approved by Porsche. Your Porsche dealer has information
about approved tires and wheels and is happy to assist you. If aftermarket tires and/or wheels are installed which are not
approved by Porsche, the vehicle’s roadability and handling characteristics might be impaired. Since Porsche has no data on
such combinations, Porsche cannot stand behind the safety or durability of these aftermarket combinations.
* Snow chains Can be mounted only on the rear wheels; maximum speed 30 mph/50 km/h.
Use only Porsche authorized fine-link cross-type or edge chains.
Snow chain clearance can be guaranteed only with the tire + rim combination marked.
