Page 176 of 314
A-OpeningfrontluggagecompartmentlidB-Openingrearluggagecompartmentlid
FrontLuggageCompartmentlid
Generalinformation
Note
Ifthevehiclebatteryisdischarged,thefrontlidcanbeopenedonlybyconnectinganexternalelectricalpowersource.
Pleaseobservethechapter”EMERGENCYUNLOCKINGOFTHEFRONTLUGGAGECOMPARTMENTLID”onpage260.
Pleaseobservethedescriptioninsidethefuseboxlid.
Warningmessage
Awarningmessageintheon-boardcomputercomesonifthelidsarenotcompletelyclosed.
Fullyclosethelid.
Unlockingthelid
Operatepull-buttonAnexttothedriver’sseatorcorrespondingbuttonoftheremotecontrol.Whenthelidisopen,theluggagecompartmentislit.
Pleaseobservethechapter”LOADSWITCH-OFFAFTER2HOURSOR7DAYS”onpage259.
Pleaseobservethechapter”KEYWITHRADIOREMOTECONTROL”onpage23.
Openingfrontluggagecompartmentlid
Caution!
Riskofdamagetoluggagecompartmentlidorwindshieldwipers.
Makesurethatthewindshieldwipersarenotfoldedoutforwardswhenopeningthelid.
Raiselidslightlyandunlatchthesafetycatchwiththelever(arrow).
174Controls,Instruments
Page 261 of 314
ElectricalSystem
Generalinformation
Inordertoavoiddamageandfaultsinelectricalorelectronicsystems,electricalaccessoriesshouldbeinstalledatyourauthorizedPorschedealer.
OnlyuseaccessoriesauthorizedbyPorsche.
Danger!
Riskofshortcircuitandre,resultinginseriouspersonalinjuryordeath.Replacingfusesorrelayswiththeenginerunningortheignitiononcouldcauseelectricalshock.
Disconnectedthebatteryduringallworkontheelectricalsystem.
Pleaseobservethechapter”BATTERY”onpage262.
Relays
Defectiverelaysshouldbechangedonlybyanauthorizedworkshop.
Alarmsystem,centrallocking
Thestatusofthecentrallockingandalarmsystemisnotchangedbydisconnectingthebattery.Whenthebatteryisdisconnected,thealarmsystemceasestofunction.
Overloadprotection
Ifthecentrallockingsystemisoperatedmorethantentimeswithinaminute,furtheroperationisblockedfor30seconds.
Loadswitch-offafter2hoursor7days
Iftheignitionkeyisremoved,loadswhichareswitchedonorareinstandbymode(suchastheluggagecompartmentlight,interiorlightandradio)areautomaticallyswitchedoffafterapprox.2hours.
Ifthevehicleisnotstartedorunlockedwiththeremotecontrolwithin7days,theremotecontrolstandbyfunctionisswitchedoff(tosavethevehiclebattery).
1.Inthiscase,unlockthedriver’sdoorwiththekeyatthedoorlock.Leavethedoorclosedinordertopreventthealarmsystemfrombeingtriggered.
2.Pressbutton1ontheremotecontrol.
Theremotecontrolisnowactivatedagain.
A-Diagnosticsocket
Replacingfuses
Inordertopreventdamagetotheelectricalsystemduetoshortcircuitsandoverloads,theindividualcircuitsareprotectedbyfuses.Thefuseboxislocatedinthedriver’sfootwell.
PracticalTips,EmergencyService259
Page 262 of 314
A-PlasticgripperB-Sparefuses
1.Switchofftheloadwiththedefectivefuse.
2.Pulloffplasticcoveratthefingerhole(arrow).Thefuseplanandinstructionsforemer-gencyunlockingoftheluggagecompart-mentlidcanbefoundontheinnersideofthecover.
3.RemovethecorrespondingfusefromitsslotusingtheplasticgripperAinordertocheckit.Ablownfusecanbeidentifiedbythemeltedmetalstrip.
4.Replaceonlywithfusesofthesamerating.
Note
Ifafuseblowsrepeatedlyconsultanauthor-izedPorschedealer.
Nevertryto“repair”fuses:youmaycauseseriousdamagetootherpartsoftheelectricalsystem.
Emergencyunlockingofthefrontluggage
compartmentlid
Ifthebatteryisdischarged,thelidcanbeopenedonlywiththeaidofadonorbattery.
Unlockinglid
1.Usethekeytounlockthevehicleatthedoorlock.
2.Removeplasticcoveroverthefusebox.
3.PulloutpositiveterminalAinthefusebox.
4.UseajumpercabletoconnectthepositiveterminalofthedonorbatterywithpositiveterminalAinthefusebox.
Note
Ifthevehiclewaslocked,thealarmhornwillsoundwhenthenegativecableisconnected.
5.UsethesecondjumpercabletoconnectthenegativeterminalofthedonorbatterywithlatchstrikerB.
6.Unlockthefrontluggagecompartmentlidwiththeremotecontrol.Thealarmsystemisswitchedoff.
260PracticalTips,EmergencyService
Page 263 of 314
7.Disconnectthenegativecablefirst,thenthepositivecable.
8.PushthepositiveterminalAintothefuseboxandpushontheplasticfuseboxcover.
Note
Theenginecannotbestartedwiththismethod.
Pleaseobservethechapter”EMERGENCYSTARTINGWITHJUMPERCABLES”onpage267.
PracticalTips,EmergencyService261
