Beforedrivingoff...
Checkthefollowingitemsrst
Turntheengineoffbeforeyouattemptanychecksorrepairsonthevehicle.
Besurethetiresareinflatedcorrectly.Checktiresfordamageandtirewear.
Seethatwheelboltsareproperlytightenedandnotlooseormissing.
Checkengineoillevel,addifnecessary.Makeitahabittohaveengineoilcheckedwitheveryrefueling.
Checkallfluidlevelssuchaswindshieldwasherandbrakefluidlevels.
Besurethevehiclebatteryiswellchargedandcrankstheengineproperly.
Checkalldoorsandlidsforproperoperationandlatchthemproperly.
Checkandifnecessaryreplacewornorcrackedwiperblades.
Seethatallwindowsareclearandunobstruct-ed.
Checkairintakeslotsandareabetweenfrontlidandwindshield.Ensurethattheseareasarefreeofsnowandice,sotheheaterandthewindshieldwipersworkproperly.
Ifachildwillberidinginthevehicle,checkchildseat/childseatrestraintsystemtoensurethatrestraintsareproperlyadjusted.
Checkallexteriorandinteriorlightsforoperationandthatthelensesareclean.
Checktheheadlightsforproperaim,andifnecessary,havethemadjusted.
Checkunderthevehicleforleaks.
Besureallluggageisstowedsecurely.
Emergencyequipment
Itisgoodpracticetocarryemergencyequipmentinyourvehicle.Someoftheitemsyoushouldhaveare:windowscraper,snowbrush,containerorbagofsandorsalt,emergencylight,smallshovel,first-aidkit,etc.
16Controls,Instruments
Page 141 of 314
InstrumentpanelOn-boardcomputerTextdisplayonon-boardcomputerMeaning/measure
ParkinglightonLeft/rightparkinglighton.
Checkleft/rightdippedbeam(lowbeam)alsoappliesto:frontsidelights,directionindicator,highbeam,foglights,sideindicatorlight,brakelight,taillight,rearfoglight,reversinglight,raisedbrakelight,sidemarker
Thereportedlightisfaulty.Checkbulb.HavethefaultremediedatanauthorizedPorschedealer.
DaytimedrivinglightsoffDaytimedrivinglightsswitchoffwhentheengineisshutoff.Switchonlightsifnecessary.
HeadlightbeamadjustmentfaultyHavethefaultremediedatanauthorizedPorschedealer.
FrontlidnotclosedCloseluggagecompartmentlidproperly.
RearlidnotclosedCloseenginecompartmentlidproperly.
RainsensorfaultyHavethefaultremediedatanauthorizedPorschedealer.
Refillwasherfluid
Controls,Instruments139
Page 152 of 314
WindshieldWiper/WasherLever
Generalinformationtothewindshield
wipers
Warning!
Dangerofinjurywhenthewindshieldwipersoperateunintentionally.Riskofdamagetothewindshieldandwipersystem.
Avoidrunningthewiperbladesoveradrywindshieldtopreventscratchingtheglass.Spraywasherfluidonthewindshieldfirst.Ascratchedwindshieldwillreducevisibility.
Alwaysloosenwiperbladesfromfrozenglassbeforeoperatingwiperstopreventdamagetothewipermotororblades.
Alwaysswitchoffwindshieldwipersincarwashtopreventthemwipingunintentionally(intermittentorsensoroperation).
Alwaysswitchoffwindshieldwipersbeforecleaningthewindshieldtoavoidunintentionaloperation(intermittentorsensoroperation).
Donotoperatetheheadlightwasherincarwashes.
Donotoperateheadlightwasherwhenitisfrozen.
Frontwindshieldwipersandheadlight
washersystem
0–Windshieldwipersoff
1–Intermittent/rainsensoroperationforfrontwindshieldwipers
Movewiperleverupwardstothefirstclick.
Pleaseobservethechapter”RAINSENSOR”onpage151.
2–Windshieldwipersslow
Movewiperleverupwardstothesecondclick.
3–Windshieldwipersfast
Movewiperleverupwardstothethirdclick.
4–Frontwindshieldwiper-one-touchopera-tion:
Movewiperleverdownwards.Thewindshieldwiperswipeonce.
5–Windshieldwipersandwashersystem:
Pullwiperlevertowardsthesteeringwheel.Thewashersystemspraysandwipeswhiletheleverispulledtowardsthesteeringwheel.Whenthewiperleverisreleased,afewdryingwipesareexecuted.
A-Headlightwasher(Vehicleswith
Bi-Xenonheadlights):
Thewasherspraysonlywhilelowbeamorhighbeamisswitchedon.
BrieflypushbuttonAtooperateheadlightwashersystem.
Ifheavilysoiled,repeatwash.
Theheadlightwashersystemautomaticallyspraysonceforeverytentimesthefrontwindshieldwashersystemisoperated.
Note
Thewindshieldwashernozzlesareheatedwhentheignitionison,asaprecautionagainstfreezing.
150Controls,Instruments
Page 153 of 314
Wipeintervalcontrol
Function
Onvehicleswithoutarainsensor,thewipingintervalscanbeadjustedinfoursteps.
Decreasingintervals
AdjustswitchAupwards.Thesettingisconfirmedbyonewipeofthewindshield.
Increasingintervals
AdjustswitchAdownwards.
Rainsensor
Invehicleswitharainsensortheamountofrainfall(snowfalltoo)whichhassettledonthewindshieldismeasured.Wiperspeedisautomaticallyadjustedaccordingly.
Switchingon
Movewiperleverupwardstothefirstclick.
Switchingoff
Movewiperlevertoposition0.
Therainsensorremainsswitchedoffifthewiperleverisalreadyinposition1whentheignitionisswitchedon.
Toswitchtherainsensoronagain:
Movewiperlevertoposition0andthentoposition1or
Operatewindshieldwashersystem5or
Changethesensitivityoftherainsensorwithfour-stageswitchA.
Switch-onisconfirmedbyonewipeofthewind-shield.
OnvehicleswiththeSportChronoPlusPackage,furtherrainsensorfunctionscanbeselectedviathePCM.
Pleaseobservethechapter“IndividualMemory”intheseparatePCMoperatinginstructions.
Changingthesensitivityoftherainsensor
SensitivitycanbesetwithswitchAin4stages:
AdjustswitchAupwards-highsensitivity.Thesettingisconfirmedbyonewipeofthewindshield.
AdjustswitchAdownwards-lowsensitivity.
Maintenancenote
Periodicallycleanthewiperbladeswithawin-dowcleaner,especiallyafterthevehiclehasbeenwashedinacarwash.WerecommendPorschewindowcleaner.Iftheyareverydirty(e.g.withinsectremains),theycanbecleanedwithaspongeorcloth.
Ifthewiperbladesruborsqueak,thismaybeasaresultofthefollowing:
Ifthevehicleiswashedinanautomaticcarwash,waxresiduesmaybeadheringtothewindshield.Thesewaxresiduescanberemovedusingawindowcleanerconcentrate.
Pleaseobservethechapter”WASHERFLUID”onpage223.
PleasecontactyourauthorizedPorschedealerforfurtherinformation.
Thewiperbladesmaybedamaged.
Replacedamagedwiperbladesassoonaspossible.
Controls,Instruments151
Page 203 of 314
Maintenance,CarCare
ExerciseExtremeCautionwhenWorkingonyourVehicle.......................................................202WiperBlades..............................................203CoolantLevel..............................................205EngineOil...................................................207EngineOilLevel...........................................208EngineOilRecommendation.........................210BrakeFluidLevel.........................................212FuelEconomy.............................................214OperatingyourPorscheinotherCountries.....215Fuel...........................................................216Portablefuelcontainers...............................218FuelRecommendations................................219EmissionControlSystem.............................220HowEmissionControlWorks........................221FuelEvaporationControl..............................222WasherFluid...............................................223PowerSteering...........................................224Filter..........................................................225AutomaticTransmissionFluid........................226ManualTransmissionOil...............................227CarCareInstructions...................................228
Maintenance,CarCare201
Page 205 of 314
WiperBlades
Generalinformationtothewiperblades
Whenwiperperformancedeteriorates,replacethewipers.
Pleaseobservethechapter”CARCAREINSTRUCTIONS”onpage228.
Caution!
Riskofdamageifthewiperarmaccidentallyfallsbackontothewindow.
Alwaysholdthewiperarmsecurelywhenreplacingthewiperblade.
Caution!
Riskofdamageifwiperbladesthatarefrozeninplaceareloosenedimproperly.
Thawthewiperbladesbeforelooseningthem.
Maintenancenote
Ifthewiperbladesruborsqueak,thiscanbeasaresultofthefollowing:
Ifthevehicleiswashedinanautomaticcarwash,waxresiduesmayadheretothewindshield.Thesewaxresiduescanberemovedbyusingwindowcleanerconcentrate.
Pleaseobservethechapter”WASHERFLUID”onpage223.
PleasecontactyourauthorizedPorschedealerforfurtherinformation.
Thewiperbladesmaybedamaged.
Replacedamagedwiperbladesassoonaspossible.
Changingwindshieldwiperblades
Caution!
Riskofdamage.Ifawiperbladeisnotchangedproperly,itcancomeloosewhenthecarismoving.
Checkwhetherthewiperbladeisseatedsecurely.Thewiperblademustengagethewiperarmproperly.
1.Applythehandbrake.
2.Switchthewipersoff(position0)andremovetheignitionkey.
3.Foldwindshieldwiperarmawayfromthewindshield.
A-Passenger’sside,curvedwiperbladeB-Driver’sside,wiperbladewithspoiler
4.Presstogethertheplasticspringofthewiperblade(rightarrow).Pullwiperbladeoutofwiperarm.
5.Insertnewwiperbladeuntilyoufeelitengage.Ensurethatthenewwiperbladeisinsertedintothewiperarminthesameposition:
–directionofthespoileronthedriverside,
–curvatureonthepassengerside.
6.Carefullyfoldwiperarmbackontothewind-shield.
Maintenance,CarCare203
Page 225 of 314
WasherFluid
Capacity
–Withoutheadlightcleaningsystem:approxi-mately2.6quarts(2.5liters).
–Withheadlightcleaningsystem:approximately6.3quarts(6liters).
Washeruid
Thereservoir,withabluescrewcap,isinthefrontluggagecompartment,totherearleft.
Cleanwaterisgenerallynotenoughtocleanthewindshieldandheadlights.Dependingontheseason,mixthewaterwiththeappropriateadditives.Followtheinstructionsforthemixtureratio.
Onlyusewindowcleanerconcentratewhichmeetsthefollowingrequirements.
–Dilutability1:100
–Phosphate-free
–Suitableforplasticheadlightlenses.
WerecommendwindowcleanerconcentratesapprovedbyPorsche.YourauthorizedPorschedealerwillbepleasedtoadviseyou.
Summerlling
Water+windowcleanerconcentrateatthemixingratioindicatedonthecontainer.
Winterlling
Water+antifreezeprotection+windowcleanerconcentrateatthemixingratioindicatedonthecontainer.
Pleasenotealltheinformationonthecontain-ersofthewindowcleanerconcentrateortheantifreezeprotection.
Addingwasheruid
1.Pleasenotealltheinformationontherefillcontainerofthecleaningagent.
2.Opencapofthewasher-fluidreservoir(arrow).
3.Addwasherfluidandclosecapproperly.
Donotuseenginecoolantanti-freezeoranyothersolutionthatcandamagethecar’spaint,inthewasherreservoir.
Warninglight
Iflessthan0.52quarts(0.5liter)remains,awarningmessageappearsontheon-boardcomputer.
Addwasherfluid.
Maintenance,CarCare223
Page 303 of 314
Capacities
UseonlyfluidsandfuelsauthorizedbyPorsche.YourauthorizedPorschedealerwillgladlyadviseyou.
YourPorschehasbeendesignedsothatitisnotnecessarytomixanyadditiveswithoilsorfuels.
EngineOilchangequantitywithoutoilfilterapprox.1.98U.S.gallons/7.5litersOilchangequantitywithoilfilterapprox.2.05U.S.gallons/7.75litersPleaseobservethechapter”ENGINEOILRECOMMENDATION”onpage210.
CoolantCayman:Manualtransmissionapprox.5.81U.S.gallons/22liters;TiptronicS:approx.5.92U.S.gal-lons/22.4litersCaymanS:Manualtransmissionapprox.5.89U.S.gallons/22.3liters;TiptronicS:approx.6.42U.S.gal-lons/24.3liters
Manualtransmissionanddifferential5-speed:approx.2.4quarts/2.25liters;6-speed:approx.3quarts/2.8liters
TiptronicSapprox.2.5U.S.gallons/9.5liters
DifferentialwithTiptronicSapprox.0.21U.S.gallons/0.8liters
Powersteeringapprox.1.1quarts/1literhydraulicfluidPentosinCHF11S®orPentosinCHF202®
Brakeuidapprox.0.4quarts/0.39liters;useonlyOriginalPorschebrakefluid
Windshieldwasherapprox.0.66U.S.gallons/2.5literswithoutheadlightwasherapprox.1.58U.S.gallons/6literswithheadlightwasher
FueltankRefillvolumeapprox.16.9U.S.gallons/64liters,includingapprox.2.6U.S.gallons/10litersreserve.
FuelqualityYourengineisdesignedtoprovideoptimumperformanceandfueleconomyusingunleadedpremiumfuelwithanoctaneratingof98RON(93CLCorAKI).Porschethereforerecommendstheuseofthesefuelsinyourvehicle.Porschealsorecognizesthatthesefuelsmaynotalwaysbeavailable.Beassuredthatyourvehiclewilloperateproperlyonunleadedpremiumfuelswithoctanenumbersofatleast95RON(90CLCorAKI),sincetheengine’s“ElectronicOctane™knockcontrol”willadapttheignitiontiming,ifnecessary.
VehicleIdentification,TechnicalData301
Page 314 of 314
