relay PORSCHE CAYMAN 2009 1.G Owners Manual

Practical Tips, Emergency Service
235
Electrical System In order to avoid damage and faults in electrical or
electronic systems, electrical accessories should
be installed at your authorized Porsche dealer.
fOnly use accessories authorized by Porsche.
Warning!
Risk of short circuit and fire, resulting in
serious personal injury or death.
Replacing fuses or relays with the engine
running or the ignition on could cause elec-
trical shock.
f Disconnect the negative terminal on the
battery during all work on the electrical
system.
Please see the chapter “BATTERY” on Page 239.
RelaysDefective relays should be changed only by an
authorized workshop.
In storage tray between the front seats
(not on vehicles with iPod, USB, AUX interfaces)SocketsElectrical accessories should preferably be
connected to the 12 V sockets.
f Please observe the maximum power
consumption.
Note on operation
The tire filling compressor must be connected to
the cigarette lighter.
In the passenger’s footwellNote on operation
The sockets and thus the connected electrical
accessories function even if the ignition is
switched off or the igni tion key is withdrawn.
If the engine is not running and the accessories
are switched on, the vehicle battery will be dis-
charged.
Do not operate additional accessories for more
than 5 minutes when engine is off. Continuing to
do so may drain the batte ry such that it may go
completely dead.
Maximum power consumpti on for both sock-
ets together: 70 W.

Index
279
PPaintCare .......................... ................ 203, 205
Data............... ......................... ........... 265
ParkAssistant ...................................... ......... 70
Parking
PDK transmission.... ............................ 183
Parking aids ............... ............................ 70, 71
Parking brake ............. .................................. 55
Warning light .......... .............................. 56
Parking light ............... ...................... 78, 80, 81
Particle filter ........... .................................... 201
Passenger compartment monitoring............... 25
PDK transmission ....... ................................ 178
Drive-Off Assistant... ............................ 177
Driving in winter .. ................................ 183
Faults................................................. 179
Kickdown ................... ........................ 181
Launch Control ....... ............................ 181
Manual selection mode ........................ 182
Reduced driving program .................... 184
Selector lever emerge ncy release ........ 259
Selector lever positi ons ....................... 180
Shifting gears on the steering wheel ..... 181
Sport mode ................ ........................ 180
Transmission fluid ............................... 201
Warning messages.. ............................ 184
Pen holder.................. .................................. 92
Plastic parts ............................................... 208 Care .................................................. 208
Platform lift ................ ................................ 232
Porsche Active Suspension Management
(PASM) ................................................ ......... 66
Sport mode ................ .......................... 66 Porsche Ceramic Composite Brake (PCCB) .......4
Porsche Communication Management (PCM).101
Porsche Doppelkupplung
(PDK) ....................178
Drive-Off Assistant . ..............................177
Driving in winter .... ..............................183
Faults ....................... ..........................179
Kickdown.................. ..........................182
Launch Control.......... ..........................178
Manual selection mo de ........................182
Reduced driving program.....................184
Selector lever emergency release ........259
Selector lever position .................178, 180
Shifting gears on the steering wheel .....181
Sport mode .............. ..........................180
Transmission fluid ...............................201
Porsche Stability Manage ment (PSM) ..............63
Information light .... ................................65
Power steering fluid le vel .....................201, 271
Power windows ............. ................................18
Practical tips ............ ..................................2
12
Putting vehicle into op eration

.......................241RRadiator fan..........................................76, 188
Radio reception ........ ..................................101
Rain sensor .............. ....................................82
Range on remaining fuel ......................135, 164
Rear fender
Retractable ........... ................................67
Rear lid ........................ ..........................94, 95
Unlocking ................. ............................16
Rear luggage compartm ent ...........................96
Rear spoiler .................. ..........................67, 68
Rear view mirrors...... ..............................29, 30 Rear window defogger
.......................... 31, 117
Rear window heating .................................. 117
Recirculating-air butt on ............................... 114
Refuelling ........................................ .......... 196
Relays ......................... .............................. 235
Remote control ............ ................................ 16
Readiness ................ ............................ 17
Replacing battery ..................... .......... 244
Standby funktion .. ................................ 17
Synchronization.... ................................ 17
Replacement key.......... ................................ 15
Replacing bulbs....... ................................... 247
Replacing wiper blades ............................... 202
Retractable spoiler .. ..................................... 67
Rims Diameter ................. .......................... 223
Rim width................. .......................... 223
TPM sensors............ .......................... 219
Roof transport system ................................ 105
Running in.................... ................................ 10
SSafety belts ............ ..................................... 42
Cleaning ............................................ 209
Tensioner ............................................ 42
Warning light ............ ............................ 43
Safety compliance sticker ........................... 264
Sealing set .................. .............................. 230
Seals .......................... .............................. 208
Care ........................ .......................... 208
Seat Adaptive sports se at............................. 33
Adjustment .......................................... 32
Comfort seat ........... ............................ 33
