Page 4 of 66

Porsche Doppelkupplung (PDK,
p. 48) is available as an option.
The key elements of PDK are its
seven gears, t wo half gearboxes
and t wo clutches. It features both
manual and automatic modes.
Gears are changed using the gear
selector for PDK, the switches
on the three-spoke sports steering
wheel or the new optional three-
spoke sports steering wheel with
gearshif t paddles with race track
control logic. The gear change
takes place in a mat ter of millisec -
onds without any interruption in
the flow of power. The advantage
over a fully manual transmission
is the considerably faster rate of
acceleration for the same rate of
fuel consumption. The advantage
over a fully automatic transmission
is the perceptible increase in
driving dynamics – with a similar
level of comfort, and a distinct
reduction in fuel consumption.
Two dif ferent characters. One
personalit y. Their drive for power
is impressive, their spirited nature
fascinating. Two sports coupés
that go beyond all conventions.
Two cars that draw their drivers
under their spell, forever.
The concept behind the Cayman
models is the ‘Le Mans Coupé’,
a sports coupé designed in 1953
specifically for this legendary
race and based on the 550
Spyder. Its mid- engine layout is
what made this car special. The
car’s low centre of gravit y gave it
tremendous agilit y and cornering
dynamics. From this one basic
idea came great success, and
with this success our experience
grew. The result? Two sophisticated
sportscars. The Cayman and the
Cayman S.
Their uncompromising perform -
ance is generated by t wo engine
developments, which stand
out above all for their light weight construction, power output
and ef ficiency. The Cayman has
a 2.9 -litre flat-six engine with a
power output of 195 kW (265 hp).
Even more impressive are the per -
formance values of the Cayman S
with direct fuel injection (DFI, p. 34).
The fuel/air mixture is prepared
entirely in the combustion chamber
af ter having been metered and
injected directly, with millisecond
precision. This means even more
power and torque. To express
this in figures, its 3.4-litre flat-
six engine unleashes a might y
235 kW (320 hp). Depending on
the model, it has been possible
to reduce fuel consumption by
up to 15 % and CO
2 emissions by
up to 16 %.
In either model, this tremendous
power is delivered to the road
by a precision six-speed manual
gearbox.
The primary target group:
your central nervous system.
The Cayman models.
Cayman | The concept
89
Page 29 of 66

Sport Chrono stopwatchSPORT and SPORT PLUS but tons
on the centre console
Three -spoke sports steering wheel with gearshif t switches
For maximum dexterit y, PSM
can be set to standby while the
car is still in ‘Sport ’ mode (p. 72).
For safet y, it is set to intervene
automatically only when ABS
assistance is required on both
front wheels.
A key component of the Sport
Chrono Package is the swivel-
mounted stopwatch in the centre
of the dashboard with analogue
and digital display.
In combination with Porsche
Doppelkupplung (PDK), the Sport
Chrono Package offers t wo addi -
tional functions that are activated
by the SPORT PLUS but ton.
First, ‘Launch Control’, which
ensures you achieve the fastest
possible rate of acceleration from
a standing start – on the racetrack,
for example. ‘Launch Control’ is
operated via the SPORT PLUS
but ton with the ‘D’ or ‘M’ drive
position selected. Whilst the driver
depresses the brake pedal
with the lef t foot, the right foot
depresses the accelerator pedal
to the floor. With the accelerator
in the kickdown position, the
delayed until the upper rev range.
The shif t times are shorter, the
gear changes sportier. At low
rates of deceleration, the system
initiates a swif ter, brake-induced
downshift. In manual mode,
gear changes are faster and more
dynamic. In ‘Sport ’ mode, the
PSM system (p. 72) intervenes
later for increased longitudinal and
lateral dynamics. PSM now af fords
greater manoeuvrabilit y under
braking and exit acceleration,
especially at low speeds.
Sport Chrono Package.
Do you think driving a Porsche
should be an even more involving
experience than it is already? Your
wish is our command. On request,
we can equip your vehicle with the
Sport Chrono Package, which is
available for both of the Cayman
models. Its functions enable even
sportier tuning of the engine and
chassis and guarantee even more
driving pleasure.
Selecting the SPORT but ton
on the centre console activates ‘Sport ’ mode, which makes
throt tle response significantly
more immediate, adjusts the
rev-limiter to a harder set ting,
and tunes the engine dynamics
for performance driving.
The optional Porsche Active
Suspension Management (PASM)
also switches to ‘Sport ’ mode,
which of fers harder damping
and more direct steering and,
therefore, bet ter road holding.
With the optional PDK in automatic
mode, gearshif t points are system detects the driver’s
request for Launch mode and revs
the engine to an optimum speed
of approximately 6,500 rpm.
Engine torque increases and the
clutch closes slightly. The message
‘Launch Control’ appears on
the display on the steering wheel
for PDK. The driver now quickly
releases the brake – and prepares
for maximum acceleration.
Second, the ‘motorsport- derived
gearshif t strategy’. Using this, PDK
is geared up for maximum shif t
speed, the shortest possible shif t
times and optimum shif t points
for maximum acceleration – for
uncompromising performance.
Sport Chrono Package Plus.
On request, the optional Porsche
Communication Management
(PCM, p. 92) can be combined
with the Sport Chrono Package
Plus. In addition to the functions
of the Sport Chrono Package,
it includes a personal memory
function, which can be controlled
using PCM, and a performance
display for evaluating lap times.
Throttle
response
in ‘Sport’
mode Throttle
response
in ‘Normal’
mode
Both sets of characteristics
are dependent on engine
speed
Pedal travel (%)
(%)
Torque
as percentage of maximum
Comparison of the ETC characteristic curve in ‘Normal’ mode and ‘Sport ’ mode
Cayman | Chassis
6263
Page 33 of 66

Cayman S with PCCB
corrosion and offer more favour-
able noise-damping properties.
Six-piston aluminium monobloc
fixed calipers on the front axle
and four-piston units at the
rear provide a high and constant
brake pressure. The pedal
response is fast and precise with
only moderate input required. of even the most durable brake
pads and discs. We recommend
that all brake components be
professionally inspected and
replaced where necessary af ter
every track event.Porsche Ceramic Composite
Brake (PCCB).
On request, we can equip your
Cayman S with a brake system
that has already had to cope
with the harshest requirements of
motorsport: the Porsche Ceramic
Composite Brake (PCCB). The
ceramic brake discs have a diam -
eter of 350 mm front and rear –
for extremely powerful braking. All the necessary ingredients are
there for a short braking distance,
even in the toughest conditions.
Moreover, safet y under braking
at high speeds is increased thanks
to the excellent fade resistance
of PCCB.
The key advantage of PCCB is that
the brake discs are approximately
50 % lighter than standard discs
of similar design and size. A factor
The brake discs are formed from
a specially treated carbon -fibre
compound that is silicated in a
high-vacuum process at approxi -
mately 1,700 °C. Not only are the
resulting discs much harder than
standard discs, they are more
resistant to heat. The low thermal
expansion of the brake discs
prevents deformation under heav y
braking. Furthermore, the ceramic
brake discs are totally resistant to that helps to reduce unsprung and
rotating masses on the vehicle.
The consequence of this is bet ter
road holding and increased
comfort, particularly on uneven
roads, as well as greater agilit y
and improved handling.
Please note that circuit racing,
trackday use and other forms
of performance driving can
significantly reduce the service life
Cayman | Safet y
7071
Page 35 of 66

Porsche Side Impact Protection (POSIP) Cayman
Other passive safet y features
include headrests integrated into
the seat backrests, an energy
absorbing steering column,
three-point seat belts, front seat-
belt pretensioners and force
limiters, energy-absorbing
elements in the dashboard
and flame-resistant materials
throughout the interior.
Child seats.1)
The child seat preparation
package, which includes ISOFIX
mounting points and a key switch
for deactivating the passenger
airbag, is available from Porsche
Tequipment. A full range of
child seats is also available from
Porsche Tequipment.
Passive safety: airbags.
Each of the full-size airbags is
inflated in t wo stages, depending
on the severit y of an accident.
In less serious accidents, the
airbags are only partially inflated,
thereby minimising discomfort
for the occupants. Also fit ted as
standard is Porsche Side Impact
Protection (POSIP). It comprises
Anti-theft protection.
Both models are equipped
with an immobiliser with in -key
transponder. In addition, the
Cayman S has an alarm system
with contact-sensitive exterior
protection as standard (optional
for the Cayman). It is activated
and deactivated by the remote
control integrated in the ignition
key, which is also used to lock and
unlock the doors. Radar-based
interior surveillance is available as
an option for both models.
side impact protection elements
in the doors and t wo airbags
on each side. An integral thorax
airbag is located in the seat back -
rests, while each door panel
contains a head airbag. With each
having a volume of approximately
8 litres, these airbags of fer
excellent protection in the event
of a side impact.
Vehicle tracking system.
In conjunction with the alarm
system, this optional preparation
enables future installation of a
vehicle tracking system available
from Porsche Tequipment.
It makes it possible to locate a
stolen vehicle across most of the
countries of Europe. The package
includes a special wiring loom
and a higher- capacit y bat tery.
A tilt sensor for the alarm system
is also included.
1) Child seats must not be used with
sports bucket seats.
Cayman | Safet y
7475
Page 38 of 66

Cayman S dashboard with optional equipment, including PCM, cordless handset, Tyre Pressure Monitoring (TPM), Sport Chrono Package Plus and PDK
Doppel
kupplung (PDK), as well as
the selected gear. The dial on the
left contains the analogue speed -
ometer with digital trip meter and
total distance display. The design
and legibilit y of the dials are also
enhanced by the white backlight
illumination. of this steering wheel is of fered
as an option. Also available as an
option is the three-spoke sports
steering wheel with gearshift
paddles (p. 52). For extra comfort
on those cold days, steering
wheel heating is also available
on
request for all steering wheels
(steering wheel heating available
only in conjunction with heated
seats).
Instruments.
Each black circular dial in the
instrument cluster – aluminium-
coloured in the Cayman S model
– provides important information
at a glance. In the centre is the
analogue rev counter with digital
speedometer and a customisable
display of key data from the
Steering wheels.
The Cayman models feature as
standard a three-spoke sports
steering wheel with full-size airbag.
The steering wheel is adjustable
for height and reach and the
rim is in smooth -finish leather.
As an option, you can specif y a
three-spoke multifunction steering
wheel in leather with integrated
but tons for the most essential
standard on -board computer.
Additional data, such as average
fuel consumption, fuel range
or the data of the optional TPM
can be shown as desired.
The right-hand dial displays a
range of information, including
the outside temperature and shif t
pat tern of the optional Porsche audio and, where applicable,
navigation and telephone functions.
Alternatively, the multifunction
steering wheel is available in
smooth -finish leather, Aluminium
Look, carbon or macassar wood.
Fit ted as standard in conjunction
with Porsche Doppelkupplung
(PDK) is the three-spoke sports
steering wheel with gearshift
switches. A multifunction version
Cayman | Comfort
8081
Page 39 of 66

Adaptive sports seat with driver memor y
Comfort seat with driver memor y Sports bucket seat Automatic climate control
fore/af t position is adjusted
manually, the backrest electrically.
Adaptive sports seats with
driver memory.
The optional adaptive sports
seats in leather combine excellent
comfort with first-rate track
performance.
Along with all the adjustment
features of the comfort seats, the
side bolsters on the seat surface
and backrest are individually
electrically adjustable, for
increased comfort on long journeys
and tailor-made lateral support
through bends or on the racetrack.
The memory function supports the
exterior mirrors and all driver’s
seat positions, apart from the side
bolsters.
Air conditioning.
Both Cayman models come
with a powerful and quiet air-
conditioning system as standard.
The optional climate control
system of fers even more uniform
and comfortable ventilation.
Cruise control.
This optional automatic speed
controller for the 30 to 240 km/ h
(19 –149 mph) speed range
is operated using a switch on a
separate control stalk on the
steering column.
Standard seats.
The standard seats with centre
upholstered in Alcantara offer a
high degree of comfort with good
lateral support and optimised
under-seat suspension. Through
bends, your seat gives you a
feeling of securit y without restric -
tion. The seats are equipped as
standard with manual height and
fore/aft adjustment and an electric
backrest adjustment, enabling
virtually every driver to find the
ideal seat position, regardless of
physical build.
Comfort seats with
driver memory.
Comfort seats with electric fore/
af t, height, backrest and lumbar
support adjustment are available
as an option. The tilt angle of the
Sports bucket seats.1)
For the ultimate sports experience,
you could opt for sports bucket
seats with a folding backrest,
integral thorax airbag and manual
fore/aft adjustment. The backrest
shell is made from glass-/carbon-
fibre-reinforced plastic and has a
st ylish carbon-weave finish. The
backrest pivots are positioned high
in the side bolsters to provide
lateral support to the pelvic region,
characteristic of a race seat. The
seat upholstery is offered in all
available leather t ypes and colours.
seat squab is also electrically
adjustable. The memory function
supports the exterior mirrors and
all seat positions on the driver’s
side. Using the control switches
in the door panel, it is possible to
restore one of t wo personalised
set tings. Additionally, you can
store a further seat position in
each of the ignition keys. As soon
as you unlock the door using
the key remote, the driver’s seat
and exterior mirrors resume their
stored position.
Sports seats.
The optional sports seats have
firmer leather upholstery than
the standard design. Higher side
bolsters on the seat squab and
backrest provide additional lateral
support. The seat height and
Seat heating and ventilation.
As an option, all compatible seats
– apart from sports bucket seats
– can be equipped with t wo -level
seat heating.
Seat ventilation for the standard
seats and comfort seats is also
available as an option (only in
conjunction with heated seats,
climate control and part or
full-leather interior). A slipstream
effect evaporates perspiration
moisture – for a comfortable
seating environment. Ventilation
intensit y can be set to one of
three levels.
Cayman | Comfort
1) Child seats must not be used with sports bucket seats.
82
83
Page 40 of 66

Rear screenCayman with Park Assist
Water-repellent side windows.
The surfaces of the side windows
are treated with a water-repellent
coating so that not only water
but also dirt runs away more
easily, thereby providing optimum
visibilit y even in poor weather.
Windscreen wipers.
The windscreen wipers with
an adjustable intermit tent wipe
speed are aerodynamic and
ParkAssist.
As soon as reverse gear is
engaged, the optional Park Assist
is activated automatically. If you
move too close to an obstacle,
a warning signal begins to sound,
becoming faster until the car
stops. The sensors of the optional
Park Assist are neatly concealed in
the rear bumper.
‘Welcome Home’ lighting.
When the vehicle is opened
or closed using the key remote,
the standard automatic locator
lighting automatically switches on
the fog lights and LED day time
running lights. This is particularly
convenient at night. In conjunction
with the optional PCM (p. 92) and
Sport Chrono Package Plus (p. 63),
the delayed lighting switch - of f
period can be adjusted as desired. inconspicuous. The windscreen
washer system has t wo heated
and filtered nozzles. An integrated
rain sensor is available as
an option (in conjunction with
auto-dimming mirrors).
Rear screen.
The rear screen is tinted and has
heating functionalit y. Its generous
size af fords excellent rearward
visibilit y. A detachable fabric
screen on the inside of the rear lid
HomeLink® (programmable
garage door opener).
The optional programmable
garage door opener is integrated
into the overhead console and
remotely controls up to three dif -
ferent garage doors, gates, home
lighting and/or alarm systems. provides additional privacy for
the main luggage area.
Rear wiper.
The Cayman models can be
equipped with an effective and
streamlined rear wiper on request.
It is st yled to blend seamlessly into
the overall design of the vehicle.
Cayman | Comfort
8485
Page 43 of 66

CDR-30 audio system
When you’re driving along with bells and whistles,
why not listen to some music, too?
Porsche audio and communication systems.
output stages. For an even more
impressive sound experience,
you could opt for the Sound
Package Plus or BOSE
® Surround
Sound System.
Controlling the CDR-30 could not
be more simple: the function keys
ensure that all the main functions
are directly at your fingertips,
and it is possible to conveniently
control all of the most important
functions using the but tons on
any of the optional multifunction
steering wheels.
Admit tedly, to outperform the
distinctively powerful Porsche
sound is a real challenge.
Nevertheless, we’ve tried and
have developed audio systems
that offer a genuine alternative.
CDR-30 audio system.
Both Cayman models are
equipped as standard with the
CDR-30 audio system with
a 5-inch display (monochrome)
and an MP3- compatible CD drive. An integrated six- disc CD/ DVD
autochanger is available as an
option.
The FM dual tuner with RDS
diversit y, a total of 30 memory
presets, dynamic autostore and
speed-sensitive volume control
are, as usual, all part of the
standard package. Just like the
high-qualit y sound, which is
delivered by t wo high -range
speakers in the dashboard, t wo
low/mid-range speakers in the
door trims and t wo 25-wat t
Cayman | Comfort
90 91
Page 60 of 66

Factory collection
Vehicle handover in Zuf fenhausenPorsche Museum
from outside Germany is to fly
to Stut tgart, Frankfurt am Main,
or Leipzig, and then continue
by train, taxi or hire car (which we
can return on your behalf).
Please note that there are a
number of formalities that must be
completed when you take delivery
of your new Porsche. For full
details, please consult your
Porsche Centre, who will also be
happy to assist when it comes to
planning your trip.
Everything about a Porsche
is more intense. Especially the
anticipation.
There’s no need to rush just yet.
Take your time and make the
You won’t be able to sleep
the night before.
The night after, you won’t
want to.
Many of our customers dream
of collecting their new Porsche
in person. They want to be there
when the car of their dreams
leaves the factory. This way,
they can be the first to take their
Porsche to its right ful place:
on the road.
Today, all Porsche engines are
constructed here in our main
factory in Zuf fenhausen, where
the legendary 356 was built.
You can collect your Boxster, factory tour one of the highlights
of your visit. See Porsche produc
-
tion processes in action for
yourself, from engine assembly
and the preparation of upholstery
to final installation. Experience
one of the key moments in
the construction of any car: the
‘marriage’ of engine/chassis and
body. The factory tour is one of
our oldest traditions and is always
conducted by a Porsche enthusiast
with extensive knowledge of the
marque.
If Zuf fenhausen is the destination
for your factory collection,
then why not also visit the Porsche
Museum? Here, you’ll find
an impressive range of exhibits,
including legendary Porsche
models that have made key contributions to the Porsche
success story. Awaiting you in
Leipzig are an impressive car
exhibition and an exciting film
presentation about the fascinating
world of Porsche. How does
a Porsche experience of the
culinary kind sound? As part of
your factory collection visit,
we will be delighted to of fer you
a three- course meal from our
gourmet menu.
If there’s still time, you can enjoy
some additional refreshments
in the customer lounge or simply
browse in the Porsche Design
Driver’s Selection Shop.
The moment you’ve been
waiting for.
The highlight of your visit will
undoubtedly be the delivery of
your Porsche – handed over by
specialists who know it inside and
out. They will take their time to
explain every thing you need to
know about your new car and all
its technical features.
Then you’ll finally experience what
it means to own a Porsche.
Cayman or 911 from here. If
you’ve chosen a Cayenne or
Panamera, this will be waiting for
you at their place of manufacture
– in Leipzig.
Where bet ter to experience
the passion of Porsche than in
the place where it all began?
A place characterised by a unique
blend of past and future. To take
advantage of this fascinating
opportunit y, please inform your
Porsche Centre that you would
like to collect your vehicle in
Zuf fenhausen. We will then make
all the necessary arrangements
to have your Porsche ready by the
agreed collection date.
Finding the factory is straight for -
ward. The easiest way to travel
128129
