Whatever the terrain, the passenger
compartment provides a comfort-
able environment for up to five adult
occupants. The partial-leather seats
have 12-way electric adjustment
for the driver and front passenger.
Other standard features include
air conditioning and the CDR-30
CD radio with two-tuner frequency
diversity and 12 loudspeakers.
The optional automatic air condi-
tioning has separate temperature
adjustment for the driver and front
passenger. Alternatively, there’s a
four-zone air-conditioning system
with additional controls for the
rear seat occupants.
The luggage compartment offers
540 litres of loadspace. With the
rear seats folded, this is increased
to as much as 1,770 litres*.
For easier loading, there’s an
optional automatic tailgate (see
page 144). Other load-carrying
solutions include a roof transport
system and a choice of towbars
(manually detachable or electrically
retractable). Both can be used
with braked trailer loads up to
3,500 kg.
The passive safety concept
offers excellent protection for
all occupants. The concept is
based on a sophisticated body
structure featuring multi-phase
steels, energy-absorbing areas
and side-impact protection.
This is augmented by a compre-
hensive airbag system featuring
full-size front airbags for driver
and front passenger, integratedroof-mounted curtain airbags
covering both rows of seats,
and thorax airbags in the front
seat backrests.The Cayenne. Performance,
practicality, Porsche.
Model range
· 25 · · 24 ·* Sports seats: 1,749 litres (VDA).
Page 12 of 95

The Porsche ‘S’ has long been
a mark of heightened sports
performance. On the Cayenne S –
as on many cars before – it means
power, athleticism, more efficient
dynamics – even greater driving
pleasure.
To experience its effects, simply
drop down a gear on the six-speed
manual gearbox (option: six-speed
Tiptronic S) and open up the
throttle on the 4.8-litre V8 engine.
Thanks to direct fuel injection (DFI),
the effect is immediate with drive
transmitted to a set of 18-inch
Cayenne S II wheels. The car is
propelled to 100 km / h (62 mph) in
as little as 6.6 seconds. Maximum
speed is 252 km / h (157 mph).
The naturally aspirated V8 develops
283 kW (385 hp) at 6,200 rpm.
Maximum torque is 500 Nm
from 3,500 rpm. This exceptional
performance is, in part, achieved
with the aid of variable valve
timing and two-stage valve lift
(VarioCam Plus). This system is
also responsible for the smooth
running characteristics, significantly
improved fuel economy and lower
exhaust emissions.
The engine sound is typically
Porsche – even more so with the
optional sports exhaust system
(available in conjunction with
Tiptronic S). As well as enhancing
the acoustics of the car, it features
twin chrome-plated stainless
steel tailpipes. The sports exhaust
has a ‘Sport’ sound setting that
is automatically enabled when the
general ‘Sport’ mode is selected.
Reaches places that others can only dream of.
Like the heights of driving pleasure.
The Cayenne S.
The handling characteristics and
driving properties are exemplary
for a car of such versatility. Equally
impressive are the standard safety
systems, including larger brakes
with distinctive silver-finish calipers.
Porsche Stability Management (PSM)
is standard on all Cayenne models
and provides a further reduction in
braking distances (see page 98).
The Porsche Ceramic Composite
Brake (PCCB) is available as optional
equipment on the Cayenne S,
Cayenne GTS and Cayenne Turbo.
The driving dynamics can be
further enhanced with the optional
air suspension featuring Porsche
Active Suspension Management
(PASM – see page 76).
Model range
· 27 · · 26 ·
Page 13 of 95

The heightened performance
of the Cayenne S is reflected
throughout the interior.Special features include door-sill
guards in stainless steel plus
partial-leather seats with a genuine
leather finish on the centres,
inner side bolsters and head
restraint centres. Both front seats
have 12-way electric adjustment.The optional sports seats provide
additional lateral support and
have a comfort memory package.
Instruments (Cayenne S) Centre console (Cayenne S)
The familiar arrangement of five
round
instruments includes a
large 3-inch display in the centre
dial. This is used for a wide range
of information, including Tiptronic S
gear display, ‘Sport’ mode
confirmation or readings from
the optional Tyre Pressure
Monitoring (TPM).
Stylish features include an
Aluminium Look finish on the
instrument rings and a gear
lever surround in satin-fin
ish
aluminium.In addition, the Cayenne S offers
greater comfort, including a
grained leather finish on the
centre armrest. The automatic
air conditioning has separate
controls for the driver and front
passenger as standard.
The Cayenne S. It’s amazing how
much difference one letter can
make.
Model range
· 29 · · 28 ·
Page 14 of 95

Breaking new ground.
On the road.
The Cayenne GTS.
Drive is transmitted through a
high-performance six-speed manual
gearbox or optional six-speed
Tiptronic S. The GTS model has
a shorter final-drive ratio than
the Cayenne S, which increases
acceleration. The benchmark sprint
to 100 km / h (62 mph) requires
just 6.1 seconds (with standard
manual gearbox). Maximum
speed is 253 km / h (157 mph).
The engine sound is specially
enhanced by the standard sports
exhaust system.
Developing the Cayenne GTS was
an exercise in what we do best:
more performance, more agility,
a more immediate driving experi-
ence. In short: more sport – both
visually and technically – designed
exclusively for the road.
The 4.8-litre naturally aspirated
V8 features direct fuel injection
(DFI). It also includes a range
of performance enhancements
compared with the Cayenne S.
The revised intake manifold and
engine management system
enable greater power and
efficiency. The results: 298 kW
(405 hp) at 6,500 rpm and
500 Nm of torque at 3,500 rpm.
Another special feature on the
Cayenne GTS is the combination
of steel-sprung sports suspension
and Porsche Active Suspension
Management (PASM) as standard
(air suspension available as an
option). The ride height has been
lowered by 24 mm (20 mm
on optional air suspension) to
improve handling and high-speed
stability. The car’s cornering
potential is immediately apparent
from the standard 21-inch
Cayenne Sport wheels.
Model range
· 31 · · 30 ·
Page 15 of 95

non-slip Alcantara, as are the
rooflining, manual gear-lever boot
and parts of the door panel trim.
The rear seats have a two-seater
look but are in fact designed
f
or up to three adult occupants.
The ‘Sport’ aluminium package
uses aluminium trim on the
dashboard and doors to enhance
the car’s sporting style.
GTS. A thrilling blend of two
legendary designations: the
uncompromising character of Engine power is more than
matched by the red-caliper brakes
with internally vented discs
measuring 350 mm in diameter
at the front. The Porsche Ceramic
Composite Brake (PCCB) is
available as optional equipment.
The performance capability of
the Cayenne GTS is expressed
throughout the exterior design.
The front and rear sections are
identical to those on the Cayenne
Turbo. The colour-coded lower
mouldings (front, side and rear)
enhance the car’s powerful looks.
An elongated roof spoiler with
fixed bi-plane profile is available
as a no-cost option. The side
window surrounds, door handles
and door-sill trim strips have a
stylish black finish. Another feature
unique to the GTS model is the
pair of dual-tube chrome tailpipes
on the sports exhaust system.
The interior shares the same
sporting style – from the stainless
steel door-sill guards with
‘Cayenne GTS’ logo to the high-grip
padded leather steering wheel.
The standard leather interior
incorporates a range of surfaces
on the dashboard, centre console
and door panels. The electrically
adjustable sports seats combine
luxury driving with high lateral
support and include a comfort
memory package. The front and
rear seat centres are finished in
Model range
Extended roof spoiler with fixed bi-plane profile (no-cost option)
the Porsche GT plus the sporting
capability of the Porsche S.
The Cayenne GTS continues
these traditions with power,
practicality and driving pleasure.
The sports seat package with comfort memory includes a three-seater rear bench featuring two-seater styling
· 33 · · 32 ·
Page 16 of 95

Model range
More agility. More efficiency. More safety.
So far, it all makes perfect sense.
The Cayenne Turbo.
This enormous potential is trans-
mitted to the road through the stand-
ard six-speed Tiptronic S.Running
on 19-inch Cayenne Design
wheels,
the benchmark sprint to
100 km / h
(62 mph) is completed in just
5.1 seconds. At 210 km / h (131 mph),
the standard air suspen
sion is
automatically lowered to
increase
stability and aerodynamic
efficiency.
Maximum speed is 275 km / h
(171 mph).
Porsche Active Suspension
Management (PASM) continuously
modifies the damping force on
each wheel based on changing
road conditions and driving style.
The optional Porsche Dynamic
Chassis Control (PDCC) helps to
minimise body-roll when cornering.
This not only enhances occupant
comfort, it also improves contact
with the road. Pulse rate climbing. Shiver down
the spine. Both natural reactions
in a turbocharged Porsche.
The Cayenne Turbo is one of the
most remarkable examples of
the Porsche performance principle.
Blending power with comfort,
it does so in style without ever
compromising on either.
Start the ignition, and immediately
you sense the energy latent in
the 4.8-litre twin-turbo V8.
Featuring direct fuel injection (DFI),
it develops 368 kW (500 hp) at
6,000 rpm. Maximum torque
of 700 Nm is available between
2,250 and 4,500 rpm.Press the ‘Sport’ button on the
centre console and the throttle
becomes more responsive,
the engine more dynamic and
Tiptronic S more direct. At
the same time, Porsche Active
Suspension Management (PASM)
is also switching to ‘Sport’ mode.
The air suspension is automatically
lowered to the more streamlined
Low Level I.
· 35 · · 34 ·
Page 17 of 95

Another impressive feature is the
new braking system. The larger-
diameter discs provide extremely
high standards of active safety
in all driving scenarios. As a result,
the Cayenne Turbo achieves bench-
mark performance in decelerationand stability under load. The new
calipers are larger in size with
a distinctive red paint finish. The
Porsche Ceramic Composite
Brake (PCCB) is available as an
option.
Externally, the Cayenne Turbo is
instantly recognisable by the
‘power domes’ on the engine lid.
Other standard features include
Bi-Xenon headlights with static and
dynamic cornering lights. Together
with the elongated lights in the
front air intakes, they lend additional
presence and character to the car.
The interior is a blend of sporting
style and exclusivity: comfort
seats with a comfort memory
package and leather upholstery
as standard. Sports seats are
offered as a no-cost option, also
with a comfort memory package.
The standard BOSE®Surround
Sound System delivers perfect
sound at every seat position.
Other standard features include
Porsche Communication
Management (PCM) with satellite
navigation (see page 132).
The cluster of five round instru-
ments in the Cayenne Turbo has
a 5-inch colour display in the
central dial. This provides infor-
mation from a range of systems,
including the on-board computer.
The far right-hand dial contains
the boost pressure gauge.
All interior trim elements in the
Cayenne Turbo have an elegant
satin aluminium finish.
The Cayenne Turbo. Uncom-
promising in performance, a
technological benchmark, yet
practical in everyday use. Virtually
unlimited on or off road – but
always in comfort and safety.
Model range
5-inch colour display
· 37 · · 36 ·
Page 18 of 95

Drive More drive.
More power.
More efficiency.More of the things that make
the Cayenne a Porsche.
· 39 · · 38 ·
Page 19 of 95

1. Air intake system
2. High-pressure pump
3. VarioCam Plus
(rotary-vane adjuster)
4. Duplex timing chain
5. High-pressure fuel rail
6. Injector (obscured)
7.
VarioCam Plus (switchable
tappet with hydraulic valve
clearance adjustment)
8. Inlet camshaft
9. Exhaust camshaft
10. Valve
11. Piston
12. Spark plug
13. Exhaust manifold
14. Turbocharger
15. Oil filter
16. Oil /coolant heat exchanger
17.
Air-conditioning compressor
18. Oil pump pick-up pipe
19. Water pump (obscured)
20. Ancillary drive belt
21. Throttle-valve tract
(electronic throttle)
Cayenne Turbo engine
1011
12
13
14
15
16
17
18
19
20
21
1
2
3
4
56
78
9
· 41 · · 40 ·
Drive
Page 20 of 95

100 300 350
400
450
500 550 600
6500 30
60 90 120150
180 210 240 270
300
3301500
7500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000
150 200
250
1000
Power (kW)Torque (Nm)
Engine speed (rpm)
360700
283 kW (385 hp)
500 Nm
100 300 350
400
450
500 550 600
6500 30
60 90 120150
180 210 240 270
300
3301500
7500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000
150 200
250
1000
Power (kW)Torque (Nm)
Engine speed (rpm)
360700
213 kW (290 hp)
385 Nm
Cayenne: 385 Nm at 3,000 rpm, 213 kW (290 hp) at 6,200 rpm Cayenne S: 500 Nm at 3,500 rpm, 283 kW (385 hp) at 6,200 rpm
The engine is the heart of every
Porsche. It is the origin of its power,
presence and sound, its unique
Porsche character and performance.
On all four Cayenne engines, we
have used direct fuel injection (DFI)
to achieve a significant increase in
specific power and torque as well
as better fuel economy and lower
emissions. All four units are relatively
compact in spite of their large
displacement. The engine cooling
system is extremely effective,
coping easily with heavy trailer loads.
The Cayenne has a naturally
aspirated 3.6-litre V6 with direct
fuel injection and variable valve
timing.
Maximum power output is 213 kW
(290 hp) at 6,200 rpm with
maximum torque of 385 Nm at
3,000 rpm. The results: 0 to
100 km / h (62 mph) in 8.1 seconds
(with manual gearbox) and a max-
imum speed of 227 km / h (141 mph).
The Cayenne S has a naturally
aspirated 4.8-litre V8 with direct
fuel injection and VarioCam Plus.
Maximum outputs are 283 kW
(385 hp) at 6,200 rpm and
500 Nm of torque at 3,500 rpm.
Top speed is 252 km / h (157 mph)
with a manual gearbox and
250 km / h (155 mph) with
Tiptronic S. The standard sprint
to 100 km / h (62 mph) requires
6.6 seconds (manual) or
6.8 seconds (Tiptronic S).
Cayenne S engine
Drive
Taking a little. Giving a lot.
The heart of the Porsche Cayenne.
Cayenne engine
· 43 · · 42 ·
