Comfort, ergonomics and security.
Anti-theft protection.
The Cayenne models are all
equipped as standard with an
engine immobiliser and anti-theft
alarm featuring ultrasonic interior
surveillance.
The alarm circuit includes all four
doors, engine lid, tailgate, rear
screen, interior, ignition and trailer
(if fitted).
The immobiliser system works by
automatically communicating with
the vehicle key. If the key is ap-
proved, the engine can be started
as normal.
When the key is removed from the
ignition, the steering column is
automatically locked to provide
additional security.
Porsche Entry & Drive.
With this optional system, you can
reduce the inconvenience of a con-
ventional key.
The moment you touch the door
handle
, the system automatically
checks the encrypted access code
on the key in your pocket. If the
code is accepted, the doors are
unlocked. To start or stop the
engine, simply push the ignition
button.
To lock the car on leaving, all you
have to do is press a button on the
outside of the door handle. Porsche
Entry & Drive then secures the car
doors, arms the immobiliser and
locks the steering column.
Preparation for vehicle
tracking system.
This optional preparation available
for all Cayenne models enables
future installation of a vehicle
tracking system obtainable from
Porsche Tequipment. The system
can be used to locate a stolen
vehicle across much of Europe.
Includes special wiring loom,
higher capacity battery (depend-
ing on vehicle specification) and
tilt sensor for the alarm system.
Cruise control.
Standard on the Cayenne Turbo
and optional on all other models,
cruise control offers increased
comfort on long-distance journeys.
It can be used at speeds between
30 and 240 km / h (19 and 149 mph)
and is activated using a button on
one of the control stalks.
Slide /tilt sunroof.
Available as an option on all
Cayenne models, the slide/tilt
sunroof is made from tinted
single-pane safety glass and has
a manually adjustable sunscreen.
The roof position is easily adjusted
using a single illuminated rotary
control. The sunroof also has
an anti-jam facility, as do all the
electric windows.
Comfort lighting package.
One of the special features in this
optional package is the ‘Welcome
Home’ lighting function. When you
arrive at a destination after dark,
the headlights remain
illuminated
Comfort
for a user-defined period, lighting
your path from the car. Other
features include courtesy lights
on both exterior
mirrors, auto-
matic headlight activation and
automatically dimming interior
and exterior mirrors.
· 127 · · 126 ·

Explore the world.
In every direction.
Panoramic roof system.
The electrically operated
panoramic roof system is available
as an option on all Cayenne models.
Made from laminated safety glass,
it has a total surface area of
approximately 1.4 square metres –
almost four times larger than the
optional slide/tilt sunroof. Even
when closed, it provides a unique
‘open-top’ driving experience. The
panoramic view can be enjoyed
from all seat positions in every
type of weather.
A key advantage of the panoramic
roof system is its variability. The
roof consists of three movable
segments (1 – 3) and one fixedsegment (4). When the roof is
opened, the forward segment (1)
tilts upwards to act as a wind
deflector. Even at high speed
it helps reduce turbulence and
noise. The two middle segments
(2 and 3) can be opened
separately to provide a stream
of fresh air to the front or rear.For the ultimate open-top driving
experience, both central segments
can be fully retracted to the rear.
It is also possible to tilt segment
3 (above rear seats) to provide
additional ventilation. In all, there
are 15 roof settings to choose
from.
An electrically operated sunscreen
protects the interior against direct
sunlight.
The roof settings are
selected using a single illuminated
rotary control located on the roof
console. When the car is stationary,
it can also be operated using the
ignition key in the door lock.
Comfort
Panoramic roof system opened fullyPanoramic roof system closed
Panoramic roof system opened at rear
43 2 1
43 2 1
43 2 1
· 129 · · 128 ·

The Cayenne, Cayenne S and the
Cayenne GTS are equipped with
the CDR-30 CD radio as standard.
The Cayenne Turbo has Porsche
Communication Management
(PCM – see page 132) and the
BOSE
® Surround Sound System
(see page 136).
The new CDR-30 CD radio.
Standard equipment in the Cayenne,
Cayenne S and Cayenne GTS,
the new 2-DIN CDR-30 CD radio
combines excellent sound with
exceptional ease of use. The
package includes an MP3-compatible
CD drive, 12 loudspeakers and
4 x 25-Watt internal amplifiers. The
5-inch monochrome display offers
excellent visibility and a clear layout –
especially when operating a con-
nected Bluetooth
®mobile phone
(telephone preparation available
as option). Other options available
in conjunction with the CDR-30
include an integrated six-disc
CD autochanger (easily accessible
from either front seat) and an
Aux-In port in the lower storage
compartment in the centre console
for connecting an external audio
source. The CDR-30 can also be
combined with the BOSE®
Surround Sound System for the
ultimate in sound performance.
Mobile phone preparation.
With this optional preparation,
you can connect a Bluetooth
®
Hands-Free Profile (HFP)-compatible
mobile phone* and use PCM
or the CDR-30 CD radio as a
hands-free system. As a Bluetooth®-
based solution, you can connect
your handset without even taking
it from your pocket. The basic
phone functions are accessible via
the PCM/CDR-30 head unit, multi-
function steering
wheel or voice
control. Connection to the mobile
phone network is via
the handset
antenna.**
Only one thing compares to the sound of your Porsche.
The sound of your Porsche.
Porsche audio systems.
The new CDR-30 CD radio
Comfort
At Porsche, we appreciate the
importance of sound as an integral
part of the driving experience.
Which is why the interior acoustics
of each Cayenne model were
a key consideration during the
development process.
· 131 · · 130 ·
CD/DVD autochanger.
This optional integrated CD/DVD
autochanger replaces the standard
single-disc drive in the CDR-30
CD radio or PCM (DVDs playable
only in PCM). The front-loading
device holds up to six CDs/DVDs
and is easily accessible from
either front seat. Operated using
the standard head unit controls.
** For information on compatible phones, please consult your Porsche Centre or visit www.porsche.com.
** Mobile phone preparation: using a mobile phone inside the vehicle may expose occupants to heightened levels of electromagnetic radiation.
Vehicles with the mobile phone preparation can also be equipped with a cradle upgrade kit (handset-specific). When the handset is in the cradle,
all calls are connected via an external antenna, thereby reducing interior radiation. For information on upgrade kits for your mobile phone, please
consult your mobile phone accessory retailer. Using the telephone module for PCM avoids exposure to radiation as it also connects to the mobile
phone network via an external antenna.

The Cayenne Turbo is equipped
as standard with a totally new gen-
eration of Porsche Communication
Management (PCM). The central
control system for all audio,
navigation and communication
functions, the new PCM is more
powerful, more versatile and yet
easier to use than ever before.
Key features include a 6.5-inch
touchscreen display with intuitive
user interface. As before, you
can also operate PCM using
the right-hand rotary push-button
control. The menu layout is
extremely clear, with no more than
five entries per page enabling fast
and accurate operation. A help
function is included at the bottom
of the screen.
Navigation, communication, entertainment.
The new Porsche Communication Management (PCM).
Radio functions include 48 presets,
FM twin-tuner with RDS and the
latest generation of frequency
diversity which searches the air-
waves for the best possible signal
from the selected radio station.
In conjunction with the BOSE®
Surround Sound System, the
integrated CD/DVD drive plays
audio CDs as well as audio/video
DVDs in 5.1 discrete surround
format. An optional integrated
six-disc CD/DVD autochanger is
available for PCM.
Navigation module.
The navigation module for PCM
now has all map data on a
hard-disc drive and covers most
of the countries in Europe. The
upgraded system offers faster
route calculation with a choice
of three alternative routes.
The touchscreen display enables
faster destination input as well as
easy access to congestion reports
and places of interest by simply
tapping on the respective icons on
the map. Intermediate destinations,
e.g., next service station, can be
input quickly and easily during the
current route guidance.
Comfort
The map display offers a new
perspective view as well as
conventional 2D layout, both with
altitude profiles. During motorway
driving, the route guidance
instructions include visual turn
indicators. In split-screen mode,
you can view the current map
section together with a list of
icons for the next manoeuvre. The
system also supports automatic
navigation along a previouslyrecorded route (reverse route
navigation) as well as compass
and GPS-based navigation.
· 133 · · 132 ·The new PCM

· 135 · · 134 ·
TV tuner.
The optional TV tuner is compatible
with both analogue and digital
television services (DVB-T). For
safety reasons, the TV tuner is
automatically disabled whenever
the vehicle is in motion.
Voice control.
The latest generation of optional
voice control enables convenient
operation of virtually all PCM
functions. In general, each menu
item can be selected by voice
using the wording as it appears
on-screen. Telephone contacts and
radio stations can be selected
using normal spoken words.
Voice recognition for commands
and number sequences is
Telephone module.
This optional GSM telephone
module combines ease of use with
optimised sound quality. Simply
insert your mobilephone SIM card in
the
slotin PCM to make calls via
the hands-free facility or optional
Bluetooth
®handset. Alternatively,
you can use a Bluetooth®SIM
Access Profile (SAP)-compatible
handset* to connect wirelessly
and automatically to the telephone
module. Once connected, the
GSM antenna on the mobile phone
is disabled to prolong battery life
and the external vehicle antenna
is utilised instead. Depending on
phone model, you can access
contact details on the mobile
phone SIM card and internal
memory. All operations are
performed in PCM, which means
your phone can remain in your
pocket.
unit and/or multifunction steering
wheel. All other functions are
accessible on the external device.
Universal audio interface.
Can’t decide which music to
bring? Then why not bring it all.
On vehicles equipped with PCM,
this optional package provides
three audio input ports (iPod
®,
USB and Aux-In). Located in the
lower storage compartment in
the centre console, these can be
used to connect an iPod
®, USB
memory stick or other audio
device with Aux-In cable. The
iPod
®and memory stick can be
operated via PCM, multifunction
steering wheel and/or voice con-
trol. The USB port can also be
used to download data from the
optional electronic logbook. On
vehicles with the CDR-30 CD
radio, the package includes an
Aux-In port only. Volume is
adjustable via the CDR-30 head
voice-independent. The system
provides audio responses and
guidance through the various
functions. There is no voice learn-
ing process.
Electronic logbook.
This optional addition to PCM
enables you to automatically
record on every journey the
mileage, route distance, date and
time as well as starting location
and destination. Data can
be downloaded from PCM via
Bluetooth
®or a USB port and
processed on a PC using soft-
ware
included with the package.
The software complies with the
statutory requirements for
automatic logbooks as specified by
the German revenue authorities.
Universal audio interface with iPod®cable
* For information on compatible mobile phones, please consult your Porsche Centre or visit www.porsche.com.
Comfort

Comfort
Five discrete audio channels (front
left, front right, centre, surround
left and surround right) plus a low-
frequency effects channel provide
naturalistic sound with precise spatial
location of voices, instruments,
sound effects, etc., at the front
and rear of the car. A 360-degree
soundstage, its realistic 3D audio is comparable with a concert hall
or cinema.
Naturally, you can also play
conventional CDs, either in stereo
mode or as surround sound
generated by the patented BOSE®
Centerpoint®technology. The
new Centerpoint
®II algorithm
takes the standard stereo signal
and generates a more precise and
realistic surround sound output.
BOSE
®SurroundStage®signal
processing assigns each audio
channel to a combination of
speakers to achieve a more
balanced surround sound at all
seat positions.
Of course, there’s more to the
BOSE®Surround Sound System
than exceptional surround sound
a 410-Watt 10-channel digital
amplifier to produce a powerful
sound experience.
The system supports digital 5.1
surround sound on audio and video
DVDs to create a lifelike audio
environment.
The optional BOSE®Surround Sound
System (standard in the Cayenne
Turbo) was specially developed
to Porsche specifications and
custom-engineered for the Cayenne
models. A total of 14 loudspeakers
(including active subwoofer and
centre-fill speaker) combine with
The ultimate soundtrack for the ultimate drive.
BOSE
®Surround Sound System.
alone. All audio output is precisely
engineered for the specific interior
acoustics of the Cayenne models.
The dynamic loudness function
automatically enhances the lower
frequencies in low-volume sound
in order to compensate for the
reduced sensitivity of the human
ear at this end of the spectrum.
AudioPilot
®noise compensation
technology uses a microphone in
the cockpit to monitor ambient
sound. The system is then able
to provide real-time adjustment
of all audio output for a more
consistent sound experience.
· 137 · · 136 ·BOSE
®Surround Sound System in Cayenne Turbo

Transport Strength.
Endurance.
Versatility.
Three of the qualities that
define every Porsche.In the Cayenne models,
they form a new permutation.
And bring a new facet to the
concept of high performance.
· 139 · · 138 ·

The Cayenne models use power
and performance for more than
just driving pleasure. All four cars
have a large and variable rear
luggage compartment with power
closing tailgate as standard.
An automatic tailgate is available
as an option. The luggage
compartment has a total volume
of 540 litres (VDA), i.e., more than
enough space for up to four large
suitcases. The loadspace floor is
completely flat and the tailgate
sill is low. When the rear seats
are folded flat on vehicles with
sports seats (featuring comfort
memory package), the larger side
bolsters create a slope of approx.
15º relative to the loadspace floor.
Even when the car is fully laden
(see page 188), the self-levelling
air suspension (standard on
Cayenne Turbo; optional on other
models) maintains a constant
ground clearance at front and
rear.
The air suspension package
includes ride-height adjustment,
enabling the car to be lowered
by approximately 54 mm* below
the normal ride level for easier
loading of heavy items. When
moving off, the suspension
automatically reverts to the
standard ride-height setting
(Normal Level).
When the rear backrest is folded
forward, the loadspace expands
to as much as 1,770 litres**
(VDA). Items can be stored out
of view and protected from the
sun using a retractable cover in
a detachable storage cassette.
Two additional storage spaces
(one on vehicles with four-zone
air conditioning) are discreetly
concealed behind the side trim
panels in the luggage compart-
ment (volume may vary depending
on optional equipment).
Even when loaded to the
maximum weight, each Cayenne
model remains agile, responsive
and easy to control.
Transport
More wide open spaces to explore.
Luggage compartment.
** Cayenne GTS: 34 mm lower
than standard Normal Level.
** With sports seats: 1,749 litres (VDA).
· 141 · · 140 ·

Luggage compartment with
larger section of rear seat
backrest folded (40 %/60 %).Luggage compartment
with rear seat backrest
fully folded.
Loading option with rear seat
backrest raised and loadspace
cover retracted:
1 x Porsche Diesel pedal tractor
1 x Porsche pushchair Loading option:
4 x Carfit trolley case (XL)
2 x Carfit travel bag (M)Loading option:
3 x Carfit trolley case (XL)
3 x Carfit travel bag (XL)
2 x Carfit travel bag (M)
2 x Porsche golf-bag
Loading option with rear
seat backrest raised and
loadspace cover extended:
3 x PTS trolley case (XL)
Transport
· 143 · · 142 ·

The rear door on the Cayenne
models opens high for easy
access and loading. A power
closing function is also included
as standard. An automatic tailgate
is available as an option, with
easy operation via controls on
the driver’s door, tailgate and key
remote. The opening height is
user-programmable.
To load or retrieve smaller items,
the rear screen can be opened
independently using either the
key remote or a button on the
rear window.
Transport
Convenient access and loading.
Tailgate.It won’t make it any more spacious – it just feels that way.
Loadspace management system.
This optional facility enables you
to partition the luggage compartment
and secure individual objects
during transit. The partitions are
created using a special rail system
with sliding telescopic bar. Objects
can be secured using a fixing belt
and four variable lashing eyelets.
A reversible mat protects against
dirt while preventing movement
under braking, etc. The package
also includes a loadspace partition
net with two easily accessible
attachment points on the rooflining.
The partition net provides additional
safety when the car is fully laden.Loadspace management system and partition net
Button for automatic tailgateRear screen
· 145 · · 144 ·Telescopic bar Case secured with fixing belt
