Technical data
Technical data · 131
130 · Technical data
Cayenne Cayenne Diesel
Engine/electric motor
Cylinders 6 6
Displacement 3,598 cm
32,967 cm3
Max. power (DIN)
at rpm220 kW (300 hp)
6,300 176 kW (240 hp)
4,000–4,400
Max. torque
at rpm 400 Nm
3,000 550 Nm
2,000 –2,250
Compression ratio 11.7:1 16 . 8 :1
Max. power (electric motor)
at rpm –
–
Max. torque (electric motor)
at rpm –
–
Max. power (parallel full hybrid)
at rpm –
–
Max. torque (parallel full hybrid)
at rpm –
–
Transmission
Layout Porsche Traction Management (PTM):
active all­wheel drive with elec­
tronically variable, map ­controlled
multi ­plate clutch, automatic
brake dif ferential (ABD) and anti ­slip
regulation (ASR) Porsche Traction Management (PTM):
permanent all
­wheel drive with self ­
locking centre dif ferential, automatic
brake dif ferential (ABD) and anti ­slip
regulation (ASR)
6 ­speed manual gearbox Standard –
8 ­speed Tiptronic S Optional Standard
Chassis
Front axle Extra­large format double wishbone
suspension, fully independent Extra
­large format double wishbone
suspension, fully independent
Rear axle Multi­link suspension,
fully independent Multi
­link suspension,
fully independent
Steering Power­assisted, hydraulic Power­assisted, hydraulic
Cayenne S Cayenne S Hybrid Cayenne Turbo
8 6 8
4,806 cm
32,995 cm34,806 cm3
294 kW (400 hp)
6,500 245 kW (333 hp)
5,500 – 6,500 368 kW (500 hp)
6,000
500 Nm
3,500 440 Nm
3,000 –5,250 700 Nm
2,250 – 4,500
12.5:1 10. 5:1 10. 5:1
– 34 kW (47 hp)
> 1,15 0 –
– 300 Nm
< 1,15 0 –
– 279 kW (380 hp)
5,500 –
– 580 Nm
1,000 –
Porsche Traction Management (PTM):
active all ­wheel drive with elec­
tronically variable, map ­controlled
multi ­plate clutch, automatic
brake dif ferential (ABD) and anti ­slip
regulation (ASR) Porsche Traction Management (PTM):
permanent all
­wheel drive with self ­
locking centre dif ferential, automatic
brake dif ferential (ABD) and anti ­slip
regulation (ASR) Porsche Traction Management (PTM):
active all
­wheel drive with elec­
tronically variable, map ­controlled
multi ­plate clutch, automatic brake
dif ferential (ABD) and anti ­slip
regulation (ASR)
– – –
Standard Standard Standard
Extra ­large format double wishbone
suspension, fully independent Extra
­large format double wishbone
suspension, fully independent Extra
­large format double wishbone
suspension, fully independent
Multi ­link suspension,
fully independent Multi
­link suspension,
fully independent Multi
­link suspension,
fully independent
Power ­assisted, hydraulic Power­assisted, hydraulic Power­assisted, hydraulic
Provisional data only. Of ficial data unavailable at the time of publication. Some of the vehicles featured in this catalogue are fit ted with optional
equipment available at extra cost. All information in respect of features, design, per formance, dimensions, weight, fuel consumption and running
costs is correct at the time of publication. Porsche reser ves the right to alter specifications and other product information without prior notice.

132 · Technical dataTechnical data · 133
CayenneCayenne Diesel
Chassis
Brakes 6­piston monobloc aluminium fixed
calipers at front, 4 ­piston monobloc
aluminium brakes at rear, ABS 6
­piston monobloc aluminium fixed
calipers at front, 4 ­piston monobloc
aluminium brakes at rear, ABS
Wheels 8.0J x 18 8.0J x 18
Ty r e s 255/55 R 18 255/55 R 18
Unladen weight Manual gearbox/ Tiptronic STiptronic S
DIN 1,995 kg /2,030 kg 2,10 0 k g
EC
1) 2,070 kg /2,105 kg 2 ,17 5 k g
Permissible gross weight 2,765 kg /2,800 kg 2,860 kg
Maximum payload 770 kg / 770 kg 760 k g
Performance Manual gearbox/ Tiptronic STiptronic S
Top speed 230 km/ h (143 mph)/
230 km/ h (143 mph) 218 km/ h (135 mph)
0 –100 km/ h (0 – 62 mph) 7.5 secs/7.8 secs 7.8 secs
Flexibility (manual gearbox) in
second highest (5th) gear,
80 –120 km/ h (50 –75 mph) 9.6 secs
–
Over taking acceleration (automatic
transmission) 80 –120 km/ h
(5 0 –75 m p h) 5.4 secs
5.3 secs
Fuel consumption/emissions2)Manual gearbox/ Tiptronic STiptronic S
Fuel grade
3)Super Plus Diesel
Urban in l/100 km (mpg) 15.9 (17.8)/13.2 (21.4) 8.7 (32.5)
Extra urban in l/100 km (mpg) 8.4 (33.6)/8.0 (35.3) 6.6 (42.8)
Combined in l/100 km (mpg) 11.2 (25.2)/9.9 (28.5) 7.4 (38.2)
CO
2 emission in g/km 263/236 195
Emissions standard
3)EU5 EU5
Cayenne SCayenne S Hybrid Cayenne Turbo
6­piston monobloc aluminium fixed
calipers at front, 4 ­piston monobloc
aluminium brakes at rear, ABS 6
­piston monobloc aluminium fixed
calipers at front, 4 ­piston monobloc
aluminium brakes at rear, ABS 6
­piston monobloc aluminium fixed
calipers at front, 4 ­piston monobloc
aluminium brakes at rear, ABS
8.0J x 18 8.0J x 18 8.5J x 19
255/55 R 18 255/55 R 18 265/50 R 19
Tiptronic S Tiptronic S Tiptronic S
2,065 kg 2,240 k g 2 ,17 0 k g
2 ,14 0 k g 2,315 k g 2,245 k g
2,840 kg 2,910 k g 2,880 kg
775 kg 670 kg 710 k g
Tiptronic S Tiptronic S Tiptronic S
258 km/ h (160 mph) 242 km/ h (150 mph) 278 km/ h (173 mph)
5.9 secs 6.5 secs 4.7 s e c s
– – –
4.0 secs 4.6 secs 3.1 secs
Tiptronic S Tiptronic S Tiptronic S
Super Plus Super Super Plus
14.5 (19.5) 8.7 (32.5) 16.2 (17.4)
8.2 (34.4) 7.9 (35.8) 8.8 (32.1)
10.5 (26.9) 8.2 (34.4) 11.5 (24.6)
245 193 270
EU5 EU5 EU5
1) The unladen weight (EC) complies with the relevant EC Directives and is valid for standard specification vehicles only. Some items of
optional equipment can increase this weight. The figure specified above includes 68 kg representing the driver and 7 kg for luggage.
2) Fuel consumption was recorded on vehicles with standard specification. Optional equipment may af fect fuel consumption and vehicle
per formance. The data presented here was recorded using the Euro 5 test procedure (715/2007/ EC and 692/2008/ EC) and the NEDC
(New European Driving Cycle). The respective figures were not recorded on individual vehicles and do not constitute par t of the of fer.
This data is provided solely for the purposes of comparison bet ween the respective models. Provisional data only. Of ficial data unavailable
at the time of publication. Please contact your Porsche Centre for the final and of ficially cer tified values.
3) The petrol­engined models are designed to operate on fuels with an ethanol content of up to 10%.
The diesel engine is compatible with a biodiesel blend of max. 7%.

134 · Technical dataTechnical data · 135
CayenneCayenne Diesel
Dimensions
Length 4,846 mm 4,846 mm
Width (incl. mirrors) 1,939 mm (2,155 mm) 1,939 mm (2,155 mm)
Height 1,705 mm 1,705 mm
Wheelbase 2,895 mm 2,895 mm
Luggage compar tment volume
(VDA), with rear seats folded 670 litres/1,780 litres
670 litres/1,780 litres
Tank capacit y/reser ve 85 litres/15 litres 85 litres/13 litres
Off-road capability
Wading depth 500 mm 500 mm
Approach angle
1)26°
(steel ­sprung suspension) 26°
(steel
­sprung suspension)
Departure angle
1)24.5°
(steel ­sprung suspension) 24.5°

(steel ­sprung suspension)
Ramp breakover angle
1)20.5°
(steel ­sprung suspension) 20.5°
(steel
­sprung suspension)
Lockable differentials (standard) Electronically variable,
map­controlled multi ­plate clutch Self
­locking centre differential
Max. ground clearance
1)
High Level II
High Level I
Normal Level
Low Level I
Low Level II
Loading Level 215 mm
215 mm
Cayenne SCayenne S Hybrid Cayenne Turbo
4,846 mm 4,846 mm 4,846 mm
1,939 mm (2,155 mm) 1,939 mm (2,155 mm) 1,939 mm (2,155 mm)
1,705 mm 1,705 mm 1,702 mm
2,895 mm 2,895 mm 2,895 mm
670 litres/1,780 litres 580 litres/1,690 litres 670 litres/1,705 litres
85 litres/15 litres 85 litres/13 litres 100 litres/15 litres
500 mm 500 mm 500 mm
26°
(steel ­sprung suspension) 26°
(steel
­sprung suspension) 26°
(air suspension)
24.5°
(steel ­sprung suspension) 24.5°
(steel
­sprung suspension) 24.5°
(air suspension)
20.5°
(steel ­sprung suspension) 20.5°
(steel
­sprung suspension) 20°
(air suspension)
Electronically variable,
map ­controlled multi ­plate clutch Self
­locking centre differential Electronically variable,
map­controlled multi ­plate clutch
215 mm 215 mm 273 mm
243 mm
215 mm
193 mm
183 mm
163 mm
1) At DIN unladen weight, ground clearance at axle centre, Cayenne Turbo with air suspension. All information in respect of features,
design, per formance, dimensions, weight, fuel consumption and running costs is correct at the time of publication.
Porsche reser ves the right to alter specifications and other product information without prior notice.

Index
A
Adaptive cruise control 104
Air intake system 40
Air suspension 52
Airbags 68
All ­wheel drive 44
Anti ­slip regulation (ASR) 44
Anti ­theft protection 99
Audio systems 88, 92, 94
Auto start /stop function 36
Automatic headlight
activation 60
Automatic hold function 63
Automatically dimming
mirrors 103
B
Bluetooth® 90
BOSE
® Surround
Sound System 92
Brake differential (ABD) 44
Brakes 62
Burmester
® High ­End
Surround Sound System 94
C
CD/ DVD autochanger 88
Ceramic brakes 64
Chassis 50
Child seats 84
Climate control 96
‘Coasting’ 23
C o l o u r s 112
Comfort lighting package 102
Comfort memory package 82
Common ­rail injection
system 38
Compass display 79
Cooling systems 38
Cornering lights 61
Cruise control 103
D
Day time running lights 61
Direct fuel injection (DFI) 38
Downhill assistance
(Porsche Hill Control – PHC) 47
Driver memory package 82

E
Electric machine 23, 28
Electronic logbook 90
Engine management
(electronic) 41
Engines 28
Environment 70
Exhaust emissions 72
Exhaust system 41
E x t e r i o r 112 , 116
F
Factory collection 125
Fuel economy 73
Fuel system 73
H
Headlights 60
Heat and noise ­insulating
glass 97
Heated windscreen 97
Hybrid module 28
I
Ignition system 74
Interior 79, 114, 120
Interior lighting 86
Interior safet y features 68
L
Lane Change Assist (LCA) 105
Lighting 60
Lightweight construction 70
Loading options 107
Loadspace management
system 108
Lubrication 39
Luggage compartment 106
M
Manual gearbox 42
Materials 75
Mobile phone preparation 90
MP3 89, 91
Multifunction
steering wheel 79, 91

N
Navigation system 88
O
Off­road capabilit y 48
On ­board computer 79
P
Panoramic roof system 100
Parallel full hybrid 28
Park Assist 102
Parking brake (electric) 63
Performance 28
Personalisation 110
Porsche Active Suspension
Management (PASM) 51
Porsche Ceramic Composite
Brake (PCCB) 64
Porsche Communication
Management (PCM) 88
Porsche Dynamic Chassis
Control (PDCC) 53
Porsche Dynamic Light
System (PDLS) 61
Porsche Entry & Drive 98Porsche Rear Seat

Entertainment 87
Porsche Side Impact
Protection (POSIP) 68
Porsche Stabilit y
Management (PSM) 66
Porsche Torque Vectoring
Plus (PT V Plus) 50
Porsche Traction
Management (PTM) 44
Privacy glass 97

R
Radio 88
Rain sensor 98
Recuperation 64
Recycling 75
Reversing camera
1

02
Roof transport system 108

S
Safety 58
Seat belt system 69
Seats 82
Self ­levelling 52, 106
S e rv i c i n g 74
Servotronic 55
Sports exhaust system 41
Steering 55
Storage compartments 86
S u n r o o f 10 0
Sunscreen 98
Supercharging system 40

T
Tailgate (automatic) 106
Taillights 61
Technical data 130
Telephone module 90
Tiptronic S 42
Touchscreen 88
Towbar systems 109
Tra n s m i s si o n 42
Turbocharging systems 40
T V tuner 91
Tyre Pressure Monitoring
( T PM) 57
U
Universal audio interface 91
USB port 91
V
Variable Turbine Geometry
(V TG) 40
Variable valve timing 37
VarioCam Plus 37
Vehicle tracking system 99
Voice control 90
W
Water­repellent side
windows 97
Weight reduction 54
Wheels 56
Index · 137
136 · Index

The models featured in this publica­
tion are approved for road use in
Germany. Some items of equipment
are available as extra ­cost options
only. The availabilit y of models and
options may vary from market to
market due to local restrictions
and regulations. For information on
standard and optional equipment,
please consult your Porsche
Centre. All information in respect
of construction, features, design,
performance, dimensions, weight,
fuel consumption and running costs
is correct at the time of publication.
Porsche reserves the right to alter
specifications and other product
information without prior notice.
Colours may differ from those illus ­
trated. Errors and omissions ex ­
cepted.
© Dr. Ing. h.c. F. Porsche AG, 2010
All text, images and other informa ­
tion in this publication are copyright
Dr. Ing. h.c. F. Porsche AG. No part of this publication may
be reproduced or transmit ted,

in any form or by any means,
without prior permission in writing
from Dr. Ing. h.c. F. Porsche AG.
Dr. Ing. h.c. F. Porsche AG
supports the use of paper from
sustainable forestry. The paper
in this publication is certified in
accordance with the stringent
requirements of the PEFC
(Programme for the Endorsement
of Forest Certification).
Porsche, the Porsche Crest,
Cayenne, PCCB, PCM, PSM,
Tequipment and Tiptronic are
registered trademarks of
Dr. Ing. h.c. F. Porsche AG.
Dr. Ing. h.c. F. Porsche AG
Porscheplatz 1
70435 Stut tgart
Germany
www.porsche.com
Edition: 03/10
Printed in Germany
W S L E11010 0 012 0 G B/ W W
