The Cayenne | Model range · 12
11 · The Cayenne | Model range
Those who develop talent reap the reward.
Sometimes in more ways than one.
The Cayenne models.
When we launched the first Cayenne in
2002, it was met with great scepticism.
Can it still be considered a Porsche at
all? Our reply: never before in the history
of the company, had a model gone
from 0 to 100,000 sold units so quickly.
The second-generation Cayenne too has
firmly established itself in the SUV
market, demonstrating that exceptional
sports car performance is not just
restricted to the road, while the first
Cayenne Diesel proved once more
that we are not afraid to follow uncon -
ventional paths.
The success story continued to gather
momentum in 2010 – with the sum of the
ideas inherent in every Porsche. Innovative drive systems have led to
greater efficiency: fuel consumption has
been reduced by up to 23
% and CO
2
emissions by up to 26 %. This was
achieved thanks to the Cayenne models
being considerably lighter, with each
one weighing up to 185 kg less than the
respective previous model. They also
feature a host of advanced technologies
such as the auto start/stop function
(p. 38). All this has made our vehicles
more dynamic, practical and comfortable
than ever before.
For increased comfort and safet y there’s
a range of driver assistance systems
including the optional adaptive cruise
control (p. 110) with Porsche Active Safe
(PAS). Ensuring a phenomenal sound
experience in every seat position is the
optional Burmester
® High-End Surround
Sound System (p. 96). The most innovative – and therefore in
keeping with the rest of the Porsche
family – is the Cayenne S Hybrid. Its par
-
allel full hybrid system (p. 28) harnesses
the power of an electric machine (motor/
generator) and an internal combustion
engine. This provides several clear
benefits for the driver: outstanding
sports car performance combined with
excellent fuel economy. Once again,
typically Porsche.
The Cayenne Diesel is no exception.
The drive system is based on the tried-
and-tested Porsche principle. We’ve
just refined the concept, making it even
lighter and more powerful.
The Cayenne and Cayenne S offer
increased power and efficiency, while
also delivering exceptional capability
off road. The result: greater driving pleasure with reduced fuel consumption
and CO
2 emissions. On and off road.

This has also been achieved through the
use of advanced technologies such as
direct fuel injection (DFI, p. 40), eight-
speed Tiptronic S (p. 44) and VarioCam
Plus (p. 39). The interaction bet ween
all components has also been optimised.
The Cayenne GTS: an SUV descended
from a thoroughbred sports car. The
purist among Cayenne models, it is
extremely close to the road. With excep -
tional performance, a reduction in ride
height and an engine note t ypical of the
GTS, it offers one thing above all else:
pure sporting prowess.
Another of our principles: high per -
formance should never come at the
expense of comfort or safet y, and

this is something we have kept to. Even
with a car offering the phenomenal out -
put of the Cayenne Turbo. Its 4.8-litre V8
powerplant develops 368 kW (500 hp),
which is guaranteed to set pulse rates
climbing and send a shiver down the
spine – both natural reactions in a turbo -
charged Porsche.
Standard active safety features include
Bi-Xenon main headlights with the
Porsche Dynamic Light System (PDLS,
p. 63). For greater comfort and perform -
ance, the car is equipped as standard
with eight-speed Tiptronic S (p. 44), while
Porsche Torque Vectoring Plus (PTV Plus,
p. 56) enhances driving dynamics and
stability.
As always, we’ve focused on what ’s really
important. To the point: the Cayenne
models.
For fuel consumption, CO
2 emissions and efficiency class data, please refer to pages 150/151.

The Cayenne | Cayenne · 16
15 · The Cayenne | Cayenne
Everything has changed.
Apart from the concept.
Cayenne.
At Porsche, we are continually changing.
Looking for a new and different approach.
Without ever losing sight of where we’ve
come from. That ’s how we remain true to
ourselves.
The basic Cayenne concept is therefore
the same. We’ve just continued to
improve it: the Cayenne is now lighter –
up to 165 kg
1) depending on the specifi -
cation – and also more dynamic, more
comfortable, and closer to the road than
ever before. Without detracting from the
qualities required for off-road driving or
towing heav y loads.
Its naturally aspirated 3.6-litre V6 engine
features direct fuel injection (DFI, p. 40),
variable valve timing on both inlet and
exhaust, and a variable resonance intake manifold – for a generous output and
excellent fuel economy. In other words:
we have enhanced the performance,
while significantly lowering the weight,
fuel consumption and CO
2 emissions. The
figures speak for themselves: maximum
torque of 400 Nm, 220 kW (300 hp),
a top speed of 230 km/ h and the abilit y
to accelerate from 0 to 100 km/ h in
7.5 seconds. With both fuel consumption
and CO
2 emissions reduced by 20 %.1)
Delivering this power to the road effi -
ciently, Porsche Traction Management
(PTM, p. 47) combines active all-wheel
drive with an electronically variable multi-
plate clutch, automatic brake differential
(ABD, p. 47) and anti-slip regulation (ASR,
p. 47). Together they enable the perfect
distri bution of drive torque to all four wheels, whether on long straights,
through tight corners or on surfaces with
different
friction coefficients – for dynamic
handling
and increased traction. Drive is
trans mitted through a high-performance


six-speed manual gearbox (p. 44), which
ensures optimum progression through
the gears.
In addition to the standard 18-inch
Cayenne wheels and larger brakes, the
Cayenne can be fit ted with the optional
Porsche Ceramic Composite Brake
(PCCB, p. 66) – for even more outstand -
ing brake performance.
Another key advantage: a total weight
saving of approximately 50 % compared
with equivalent cast-iron discs. The generous standard equipment
includes partial-leather seats, climate
control, the CDR audio system with
touchscreen, cruise control and auto
-
matic headlight activation. For added
comfort, there’s also a ‘Welcome Home’
lighting function. When you arrive at a
destination after dark, the headlights
remain illuminated for a user-defined
period, lighting your path from the car.
So, a unique blend of the great sports
performance and unrestricted everyday
practicalit y that is t ypical of Porsche.
Let ’s be honest, would you have expected
anything else?
For fuel consumption, CO
2 emissions and efficiency class data, please refer to pages 150/151.1) Compared to previous model.

Safety and environment | Safet y · 70
69 · Safety and environment | Safet y
Porsche Stability Management (PSM).
Porsche Stabilit y Management (PSM) is
an electronic control system that uses a
range of functions – including anti-lock
braking (ABS) – to help stabilise the
vehicle (and trailer, if fit ted) in hazardous
road scenarios. Throughout each journey,
sensors monitor the direction, speed,
yaw velocit y and lateral acceleration of
the car. Using this information, it is pos-
sible to calculate the actual direction of
travel at any given moment. If the car
begins to oversteer or understeer, PSM
applies selective braking on individual
wheels to restore stabilit y. If necessary,
PSM can also intervene in the engine
management system to temporarily
modify the amount of drive transmitted
to the wheels. PSM has three additional functions that
help reduce braking distances. If the
throt tle pedal is released suddenly, PSM
automatically readies the braking sys
-
tem. The pressure in the brake lines
is marginally increased, bringing each
of the pads into light contact with the
corresponding disc. If the driver goes on
to apply the brakes, the calipers respond
more quickly and the braking distance is
reduced.
In an emergency stop – i.e. when the
pressure on the brake pedal exceeds
a certain threshold – the brake assist
function uses the PSM hydraulics to
apply maximum braking force at all
four wheels.
Preparing for the road ahead.
With a little help from PSM.
For added safet y, the system also read -
ies the brakes whenever a decreasing
distance to the vehicle in front is detect -
ed. The optional adaptive cruise control
and PSM interact to prefill the brakes.
Even if adaptive cruise control is inactive,
the system registers the speed of the
vehicle in front and automatically readies
the braking system. In addition, the sys -
tem alerts the driver to the decreasing
distance by briefly tugging on the
brakes.
PSM also features a trailer stabilisation
function – for a significant contribution
to car and trailer safet y. Within the laws
of physics, it compensates for load
transfer caused by throt tle and brake inputs up to the maximum degree of
lateral acceleration. It also enhances the
car’s driving dynamics and directional
stability when accelerating on inconsis
-
tent road surfaces.
Other features include a special control
strategy in the ABS for braking on loose
surfaces. By briefly locking the wheels,
a wedge is formed ahead of each t yre
which provides additional purchase to
help slow the car, e.g. on gravel or snow.
For a more involving driving experience,
PSM can also be disabled, but remains
active in the background.
Standard on all Cayenne models.

Comfort and transport | Comfor t · 82
81 · Comfort and transport | Comfor t Cayenne Turbo with t wo -tone leather interior in Umber/Cream and walnut interior package (wood)Cayenne GTS with leather interior in Black and GTS interior package in Carmine Red
As on every Porsche, the interior of the
Cayenne is designed around the driver,
combining sporting st yle with the very
highest standards of ergonomics, com
-
fort and quality.
Particularly striking features include the
way the centre console rises to meet
the dashboard – clearly inspired by the
Carrera GT. This immediately enhances
the interior structure, a continuation of
the car’s dynamic exterior lines. The seat
position and sports steering wheel offer
exceptional support and contact – for an
even sportier ride.
Our benchmark for exceptional driver comfort?
An out-and-out sports car.
Comfort.
A t ypical Porsche feature: the five round
instruments form the familiar cluster and
are slightly raised from the dashboard as
a visual unit. The high-resolution 4.8-inch
TFT colour screen displays information
from the on-board computer or, in con -
junction with PCM including navigation
module, map data from the navigation
system. It also shows the set tings of the
optional adaptive cruise control (p. 110)
or gives various warnings, such as alerts
from Tyre Pressure Monitoring (TPM,
p. 58), which is also available as an option.
On the Cayenne S Hybrid, the display also
provides information about the energy
management. Oil pressure, oil and coolant temperature
as well as the fuel level are displayed
using analogue gauges, while the boost
pressure gauge on the Cayenne Turbo is
digital. A compass display in the instrument
cluster is available as an
option in conjunc-
tion with PCM. This shows the four cardinal
and four ordinal directions with degree
increments as well as your current altitude.
The steering column offers manual height
and reach adjustment (electrically adjust -
able on the Cayenne Turbo). The steering
wheel rim is in smooth-finish leather. As is the optional SportDesign steering
wheel with gearshift paddles (standard on
the Cayenne GTS) – for genuine race-
st yle gearshift action. Also available as
an option, the multifunction steering
wheel enables easy access to a range of
functions including audio and telephone.

Comfort and transport | Driver assistance systems · 108
107 · Comfort and transport | Driver assistance systems
Seeing and being seen.
It’s all about having the right technology.
Driver assistance systems.
ParkAssist.
This parking aid uses an acoustic signal
and front /rear displays to alert the
driver of any obstacles at the front or
rear of the car. Its sensors are neatly
concealed in the front and rear aprons.
The acoustic signal is supplemented
by a visual warning in the centre console
display which provides a graphical r ep-
resentation of the vehicle’s proximit y to
obstacles.
Standard on the Cayenne Turbo.
Optional for all other Cayenne models.
Reversing camera.
The reversing camera facilitates reverse
parking and manoeuvring and also
assists with hitching a trailer. Help is
provided in the form of a high-contrast
colour image with dynamic guidelines
on the PCM screen, which show the pre -
dicted course of the vehicle based on the
current position of the steering wheel.
The ParkAssist visual proximity indicator
is also shown in the central display.
Optional for all Cayenne models.
Automatically dimming mirrors.
Another comfort-oriented feature:
automatically dimming exterior and
interior mirrors.
Standard on the Cayenne Turbo.
Optional for all other Cayenne models.
Cruise control.
Cruise control automatically regulates
the speed of your vehicle for added
driver comfort on longer journeys. It
can be used at speeds bet ween 30
and 240 km/ h and is operated using a
button on one of the control stalks.
Standard on all Cayenne models.
Reversing camera Reversing camera display in PCM

Comfort and transport | Driver assistance systems · 112
111 · Comfort and transport | Driver assistance systems
Speed limit indicator.
The speed limit indicator informs the
driver about speed restrictions, restric -
tions on overtaking and when these
no longer apply, which is recorded using
a camera.
Information is shown on the colour TFT
display in the instrument cluster and
via PCM. If the driver misses a traffic
sign – e.g. due to heav y rainfall or
darkness – the speed limit stored in
the navigation module is automatically
displayed.
This leaves the driver free to focus on
the road ahead.
Optional for all Cayenne models.
Speed limit indicator
Adaptive cruise control with
Porsche Active Safe (PAS).
Optional on all Cayenne models, adaptive
cruise control regulates the speed of your
vehicle in line with that of the ve hicle in
front. To do that, the system uses a radar
sensor in the central air intake to monitor
the road up to 200 m ahead.
If you approach another vehicle that is
travelling slower than your selected
cruising speed, the system slows the
engine or gently applies the brakes.

This continues until the distance that
you have preset is maintained. If heavier
braking is required, the driver has to

actively intervene. Your vehicle will
now follow the one in front at a reduced
speed.
If the other vehicle decelerates further,
adaptive cruise control will continue to
reduce your speed – even down to a halt.
When the road ahead is free once more,
the car automatically returns to your
selected cruising speed between 30 and
210 km/ h. To pull away after an auto -
matic stop, simply use the control lever
or depress the accelerator pedal.
If selected by the driver, the integrated
Stop & Go function automatically applies
the brakes and then drives off again in
congested traf fic.
For added safet y, the system also
features integrated Porsche Active Safe
(PAS). The system visually and audibly
alerts the driver in the event of a sudden
decrease in distance and briefly tugs
on the brakes. It can also intervene in
the braking process and apply increased
braking pressure through to all- out emer -
gency braking, if required.
Optional for all Cayenne models.
Adaptive cruise control

Electric sunscreen for rear side windowsPersonalisation ·
136
135 · Personalisation Porsche Crest embossed on head restraints (front and outer rear seats)
Spor tDesign steering wheel with gearshif t paddles
Comfort lighting package
1) Includes electric adjustment of lumbar support, squab length, side cushions on backrest/squab and steering column
(Cayenne Turbo: comfor t memor y package as no - cost option); comfor t memor y package (driver’s side: seat, steering column,
exterior mirror set tings; front passenger’s side: seat set tings) and other additional functions.
2) Includes electric adjustment of lumbar suppor t, squab length and steering column, a comfor t memor y package
(driver’s side: seat, steering column, exterior mirror set tings; front passenger’s side: seat set tings) and other additional functions.
3) ‘Cayenne’ for Cayenne and Cayenne Diesel, ‘Cayenne S’ for Cayenne S and Cayenne S Hybrid, ‘Cayenne GTS’ for Cayenne GTS and ‘Cayenne turbo’ for Cayenne Turbo.– not available extra-cost option• standard equipment■ no-cost option
For more information on the options featured in this catalogue, please refer to the price list.
OptionCayenne
Cayenne Diesel
Cayenne S
Cayenne S Hybrid
Cayenne GTS
Cayenne TurboI no. Page
Interior.
Adaptive cruise control with Porsche Active Safe (PAS)••••••8T3110
Speed limit indicator
••••••9Q6 111
Lane Change Assist (LCA)
••••••7Y1 10 9
Lane Departure Warning (LDW)
••••••7Y6/7Y7 10 8
Preparation for Porsche Vehicle Tracking System (PV TS)
••••••7G5 10 2
HomeLink
® (garage-door opener)••••••VC1
Loadspace management system
••••••3GN 116
Ski bag
••••••3X1 112 , 113
Smoker package
■■■■■■9JB
Fire extinguisher
••••••6A7
OptionCayenne
Cayenne Diesel
Cayenne S
Cayenne S Hybrid
Cayenne GTS
Cayenne TurboI no. Page
Interior.
SportDesign steering wheel with gearshif t paddles••••••1M L 80
Adaptive sports seats with comfort memory package (18-way)
1)••••• •PE6 84
Comfort memory package (14-way)
2)•••••■PE5/Q2J 84
Driver memory package
••••• –3L4
84
Rooflining in Alcantara
•••• ••6NN
Porsche Crest embossed on head restraints (front)
Exclusive ••••••3J7
Porsche Crest embossed on head restraints (front and outer rear seats)
Exclusive••••••5ZF112 , 13 5
Door-sill guards in stainless steel with model logo (front)
3)•• ••••7M1
Electric sunscreen for rear side windows
••••••3Y8 10 2
Floor mats
••••••0TD
Comfort lighting package
••••••PP5/PP6 10 0
Extended LED comfort lighting package
Exclusive••••••AEH
4-zone climate control
••• –••9AH
10 0
Auxiliary heating system
••• –••9M9
Side airbags (rear)
••••••4X4 70

155 · IndexIndex · 155
Index
Drive systems 28
‘Coasting’ 21
Electric machine 28
Hybrid module 28
Parallel full hybrid 28
Performance 31–36
Engine technology 38
Air intake system 42
Auto start/stop function 38
Common-rail injection system 40
Cooling systems 40
Direct fuel injection (DFI) 40
Engine management (electronic) 42
E-power button 30
Exhaust system 43
High-voltage battery 30
Lubrication 41
Sports exhaust system 43
Supercharging system 42
Turbocharging systems 42
Variable Turbine Geometry (VTG) 42
Variable valve timing 39
VarioCam Plus 39
Transmission 44
All-wheel drive 47
Anti-slip regulation (ASR) 47
Automatic brake differential (ABD) 47
Downhill assistance 48
Manual gearbox 44
Porsche Traction Management (PTM) 47
Tiptronic S 44
Off-road capability 50
Chassis 52
Air suspension 54
Front axle 53
Porsche Active Suspension
Management (PASM) 57
Porsche Dynamic Chassis Control
(PDCC) 55
Porsche Torque Vectoring Plus
(PT V Plus) 56
Power steering Plus 53
Rear axle 53
Self-levelling 54
Steel-spring suspension 54
Steering 53
Tyre Pressure Monitoring (TPM) 58
Ty r e s 5 8
Weight reduction 53
Wheels 58
Safety 62
Active safet y 62
Airbags 70
Anti-lock braking (ABS) 68
Automatic headlight activation 62
Automatic hold function 65
Bodyshell 71
Braking systems 65
Ceramic brakes 66
Cornering lights 63
Day time running lights 63
Headlights 63
Interior safety features 70, 71
ISOFIX 71
Lighting 62
Parking brake (electric) 65
Passive Safet y 70
Porsche Active Safe (PAS) 110
Porsche Ceramic Composite Brake
(PCCB) 66
Porsche Dynamic Light System
(PDLS) 63
Porsche Dynamic Light System Plus
(PDLS Plus) 63
Porsche Side Impact Protection
(POSIP) 70
Porsche Stabilit y Management (PSM) 68
Recuperation 66
Seat belt system 70
Taillights 63
Environment 72
Exhaust emissions 74
Fuel economy 75
Fuel system 75
Lightweight construction 72
Materials 77
Noise 77
Recycling 77
Ser vicing 77
Comfort 80
Adaptive sports seats 84
Anti-theft protection 102
Audio systems 90
Bluetooth
® 92, 93
BOSE
® Surround Sound System 98
Burmester
® High-End Surround
Sound System 96
CD/ DVD autochanger 90
CDR/CDR Plus audio system 90
Child seats 87
Climate control 100
Comfort memory package 84
Comfort seats 84
Compass display 80
Digital radio 95
Driver memory package 84
Electronic logbook 95
GTS sports seats 84
Heat and noise-insulating glass 100
Heated windscreen 100
Interior 80
Interior lighting 88
Mobile phone preparation 93
MP3 90, 91, 93
Multifunction steering wheel 80Navigation system
90
On-board computer 80
Online services 94
Panoramic roof system 104
Porsche Communication
Management (PCM) 90
Porsche Entry & Drive 102
Porsche Rear Seat Entertainment 88
Porsche Vehicle Tracking System
( P V T S) 10 2
Privacy glass 100
Radio 90
Rain sensor 102
Rear seats 87
Seat ventilation 85
Seat/steering wheel heating 85
Seats 84
Sport Chrono Package 95
Storage compartments 88
S u n r o o f 10 4
S u n s c r e e n 10 2
Telephone module 92
Touchscreen display 90
T V tuner 88, 92
Universal audio interface 93
USB port 90, 93
Voice control 93
Driver assistance systems 106
Adaptive cruise control with PAS 110
Automatic headlight activation 62
Automatically dimming mirrors 106
Comfort lighting package 100
Cruise control 106
Lane Change Assist (LCA) 109
Lane Departure Warning (LDW) 108
P a r k A s s i s t 10 6
Reversing camera 106
Speed limit indicator 111
Tr a n s p o r t 112
Loading Level 113
Loading options 112
Loadspace management system 117
Luggage compartment 112
Roof rails 115
Roof transport system 115
Tailgate (automatic) 113
Towbar systems 117
Personalisation 118
C o l o u rs 120
Exterior 120
I n t e r i o r 122–127
Porsche Exclusive 140
Factory collection 141
Panorama 142
Technical data 146
