Comfort and transport | Comfor t · 90
89 · Comfort and transport | Comfor t
The perfect place to be.
Not just for the driver.
Storage compartments.
Comfort also means having the import ant
things at your fingertips when you need
them. Which is why the Cayenne models
offer a wide range of storage options.
These include door storage compartments
with bot tle holders, storage pockets on
the front seat backrests, a glove com -
partment cooled by the air-conditioning
system, a storage compartment in the
centre console and a handy drawer
beneath both the driver’s and front

passenger’s seat.
Interior lighting.
The interior lighting concept with
delayed- off function is well thought- out
to provide the required level of light
whenever you need it. The generous
standard equipment includes footwell
illumination front and rear, ignition lock
illumination, a front light console with
reading lights as well as reading lights at
the rear. This is complemented by door
entry lights, front and rear, and red door
safet y lights. In addition, all Cayenne
models come with luggage compartment
illumination and a tailgate courtesy-light
function.
Porsche Rear Seat Entertainment.
Available as a factory-fit ted option from
Porsche Exclusive, the Porsche Rear
Seat Entertainment package includes two
display consoles, each with an integrated
media player and USB port, and t wo
wireless infrared headphones. The dis-
play consoles are trimmed in matching
interior
leather with decorative seams
and are located on the front seat back -
rests. Each one contains a high-resolution

7-inch W VGA TFT colour display. For greater
convenience, they are swivel-mounted
and feature touchscreen operation. Boast
ing built-in anti-shock protection,
the system is compatible with CDs and
DVDs and can even receive T V broad -
casts – in conjunction with the optional
T V tuner. It is also possible to connect
two separate and individually selectable
AV sources, such as a games console or
digital camera.
Designed to the highest standards of
safety and ergonomics, Porsche Rear
Seat Entertainment blends harmoniously
within the passenger compartment.
Optional for all Cayenne models.
Door storage compartment with bottle holder
Cupholders in the centre console Porsche Rear Seat Entertainment

1)
Suitable for receiving analogue and digital T V signals
(DVB -T in MPEG -2 standard) where available.
T V tuner
Comfort and transport | Comfor t ·
94
93 · Comfort and transport | Comfor t
TV tuner.
The optional T V tuner receives unen -
crypted analogue and digital television
signals.
1) For your safet y, these can only
be viewed via the PCM display when the
vehicle is stationary. In conjunction with
the Porsche Rear Seat Entertainment
package, T V broadcasts can be received
on the rear screens while the car is in
motion.
Optional for all Cayenne models.
Telephone module.
This optional quad-band GSM telephone
module combines ease of use with
optimised sound quality. Simply insert
your mobile phone SIM card in the slot
in PCM to make calls via the hands-free
facility or optional Bluetooth
® handset.
For even greater convenience, you can
use a Bluetooth
® SIM Access Profile
(SAP)-compatible handset. Once connect -
ed, the GSM antenna on the mobile
phone is disabled to prolong battery
life and the external vehicle antenna
is utilised instead. Depending on the
phone model, you can access contact
details on the mobile phone SIM card
and internal memory and perform all
operations via PCM, voice control or
the multifunction steering wheel, which
means your phone can remain in your
pocket. In addition, the telephone module
enables you to establish a Bluetooth
®
connection to a mobile phone that only
supports the Hands-Free Profile (HFP).
In this case, the GSM connection to
the mobile phone network is via the
handset antenna. PCM acts as a hands-
free system.
A cordless handset with keypad and
display is also available as an option.
This is stowed in the centre console.
However, the handset cannot be used
to establish a Bluetooth
® connection
using the Hands-Free Profile (HFP).

Optional for all Cayenne models.
Voice control.
Do you wish to get to the point – or your
required destination – more quickly? All
you have to do is say so. The optional
voice control system with whole-word
recognition is at your command – without
the tedious task of voice learning. This
means that the voice control system can
recognise the input of an entire address
for a navigational destination, telephone
book entries or radio station names.
Audio prompts make voice inputs even
simpler. You can also browse through
lists by voice command.

Optional for all Cayenne models.
Mobile phone preparation.
With this optional preparation, you can
establish a Bluetooth
® connection with
a mobile phone that only supports the
Hands-Free Profile (HFP) and use the
CDR or CDR Plus audio system, or PCM
as a hands-free system. As a Bluetooth
®-
based solution, you can connect your
handset without even taking it out of your
pocket. The basic phone functions are
accessible via the audio system head
unit. Connection to the mobile phone net -
work is via the handset antenna.
Optional for all Cayenne models.
Universal audio interface.
On vehicles with the CDR audio system,
this optional package located in the front
centre console provides an AUX-In port,
e.g. for a compatible MP3 player. On
vehicles equipped with PCM, the package
includes an AUX-In port and a USB port
which can be used to connect an iPod
®.
The iPod
® as well as other compatible
MP3 players or memory sticks connect -
ed via USB can be operated using PCM.
When listening to music, the system now
also displays the album cover (cover art).
Using the jukebox function, you can store
and play up to 5,000 MP3 files on the
40GB hard drive integral to PCM.
Optional for all Cayenne models.

Personalisation · 140
139 · Personalisation BOSE
® Surround Sound System Porsche Communication Management (PCM) with navigation module
Burmester
® High-End Surround Sound System
Universal audio interface
5) Mobile phone preparation or telephone module in HFP mode: using a mobile phone inside the vehicle may expose occupants to increased
levels of electromagnetic radiation. The use of the telephone module for PCM via Bluetooth® SAP connection or with inser ted SIM card
helps to prevent exposure to this radiation as only the car’s external aerial is used.
6) Requires one-time configuration of wireless internet access and your client device in accordance with the operating instructions. 7) Suitable for receiving analogue and digital T V signals (DVB -T in MPEG -2 standard) where available.
1) Reduced luggage compar tment volume due to subwoofer beneath loadspace floor. Cayenne S Hybrid:
no storage compar tment on lef t- hand side of luggage compar tment.
2) May be incompatible with some copy-protected CDs.3) For information on compatibility with the latest iPod® and iPhone® models, please contact your Porsche Centre.4) For information on compatible mobile phones, please visit www.porsche.com or contact your Porsche Centre.
– not available
extra-cost option• standard equipment■ no-cost option
For more information on the options featured in this catalogue, please refer to the price list.
OptionCayenne
Cayenne Diesel
Cayenne S
Cayenne S Hybrid
Cayenne GTS
Cayenne TurboI no. Page
Audio & communication.
CDR Plus audio system 2)••••• –PM1
Porsche Communication Management (PCM) with navigation module
2)••••• •7T1 90
Digital radio
••••••QU0 95
Universal audio interface
3)••••••UF1 93
CD/ DVD autochanger (6 - disc)
2)••••••7 D7 90
Mobile phone preparation (HFP)
4), 5)••••••9W5 93
Telephone module (SAP and HFP)
4), 5)••••••9W1
Telephone module with cordless keypad handset
4), 5)••••••9ZP92
Burmester
® High-End Surround Sound System1)••••••9VJ 96
BOSE
® Surround Sound System1)••••• •9VL 98
Electronic logbook
••••••9NY 95
OptionCayenne
Cayenne Diesel
Cayenne S
Cayenne S Hybrid
Cayenne GTS
Cayenne TurboI no.Page
Audio & communication.
Voice control••••••QH1 93
T V tuner
7)••••••QV1 92
Online services
••••••UN1 94
Wireless internet access
6)
Exclusive••••••AXZ
Porsche Rear Seat Entertainment
Exclusive••••••A EC88
Sport Chrono Package
••••••QR5 95
Compass display in instrument cluster
••••••QR1 80
Factory collection.
Factory collection Cayenne••••••S9Y/SZ8141

155 · IndexIndex · 155
Index
Drive systems 28
‘Coasting’ 21
Electric machine 28
Hybrid module 28
Parallel full hybrid 28
Performance 31–36
Engine technology 38
Air intake system 42
Auto start/stop function 38
Common-rail injection system 40
Cooling systems 40
Direct fuel injection (DFI) 40
Engine management (electronic) 42
E-power button 30
Exhaust system 43
High-voltage battery 30
Lubrication 41
Sports exhaust system 43
Supercharging system 42
Turbocharging systems 42
Variable Turbine Geometry (VTG) 42
Variable valve timing 39
VarioCam Plus 39
Transmission 44
All-wheel drive 47
Anti-slip regulation (ASR) 47
Automatic brake differential (ABD) 47
Downhill assistance 48
Manual gearbox 44
Porsche Traction Management (PTM) 47
Tiptronic S 44
Off-road capability 50
Chassis 52
Air suspension 54
Front axle 53
Porsche Active Suspension
Management (PASM) 57
Porsche Dynamic Chassis Control
(PDCC) 55
Porsche Torque Vectoring Plus
(PT V Plus) 56
Power steering Plus 53
Rear axle 53
Self-levelling 54
Steel-spring suspension 54
Steering 53
Tyre Pressure Monitoring (TPM) 58
Ty r e s 5 8
Weight reduction 53
Wheels 58
Safety 62
Active safet y 62
Airbags 70
Anti-lock braking (ABS) 68
Automatic headlight activation 62
Automatic hold function 65
Bodyshell 71
Braking systems 65
Ceramic brakes 66
Cornering lights 63
Day time running lights 63
Headlights 63
Interior safety features 70, 71
ISOFIX 71
Lighting 62
Parking brake (electric) 65
Passive Safet y 70
Porsche Active Safe (PAS) 110
Porsche Ceramic Composite Brake
(PCCB) 66
Porsche Dynamic Light System
(PDLS) 63
Porsche Dynamic Light System Plus
(PDLS Plus) 63
Porsche Side Impact Protection
(POSIP) 70
Porsche Stabilit y Management (PSM) 68
Recuperation 66
Seat belt system 70
Taillights 63
Environment 72
Exhaust emissions 74
Fuel economy 75
Fuel system 75
Lightweight construction 72
Materials 77
Noise 77
Recycling 77
Ser vicing 77
Comfort 80
Adaptive sports seats 84
Anti-theft protection 102
Audio systems 90
Bluetooth
® 92, 93
BOSE
® Surround Sound System 98
Burmester
® High-End Surround
Sound System 96
CD/ DVD autochanger 90
CDR/CDR Plus audio system 90
Child seats 87
Climate control 100
Comfort memory package 84
Comfort seats 84
Compass display 80
Digital radio 95
Driver memory package 84
Electronic logbook 95
GTS sports seats 84
Heat and noise-insulating glass 100
Heated windscreen 100
Interior 80
Interior lighting 88
Mobile phone preparation 93
MP3 90, 91, 93
Multifunction steering wheel 80Navigation system
90
On-board computer 80
Online services 94
Panoramic roof system 104
Porsche Communication
Management (PCM) 90
Porsche Entry & Drive 102
Porsche Rear Seat Entertainment 88
Porsche Vehicle Tracking System
( P V T S) 10 2
Privacy glass 100
Radio 90
Rain sensor 102
Rear seats 87
Seat ventilation 85
Seat/steering wheel heating 85
Seats 84
Sport Chrono Package 95
Storage compartments 88
S u n r o o f 10 4
S u n s c r e e n 10 2
Telephone module 92
Touchscreen display 90
T V tuner 88, 92
Universal audio interface 93
USB port 90, 93
Voice control 93
Driver assistance systems 106
Adaptive cruise control with PAS 110
Automatic headlight activation 62
Automatically dimming mirrors 106
Comfort lighting package 100
Cruise control 106
Lane Change Assist (LCA) 109
Lane Departure Warning (LDW) 108
P a r k A s s i s t 10 6
Reversing camera 106
Speed limit indicator 111
Tr a n s p o r t 112
Loading Level 113
Loading options 112
Loadspace management system 117
Luggage compartment 112
Roof rails 115
Roof transport system 115
Tailgate (automatic) 113
Towbar systems 117
Personalisation 118
C o l o u rs 120
Exterior 120
I n t e r i o r 122–127
Porsche Exclusive 140
Factory collection 141
Panorama 142
Technical data 146
