technical data PORSCHE CAYNNE S 2005 1.G User Guide

Vehicle Identification, Technical Data
361
Tire Pressures, ColdThese tire filling pressures apply only to the tire makes and types approved by Porsche.
Please observe the chapter “TIRES/WHEELS” on Page 277.Partially loaded Cayenne S Cayenne
Tire size Front axle Rear axle Front axle Rear axle
235/65 R 17
38 psi (2.6 bar) 43 psi (2.9 bar) 38 psi (2.6 bar) 43 psi (2.9 bar) 235/60 R 18
255/55 R 18
275/45 R 19
275/40 R 20
Collapsible spare wheel 51 psi (3.5 bar) 51 psi (3.5 bar) 51 psi (3.5 bar) 51 psi (3.5 bar)
Fully loaded Cayenne S Cayenne
Tire size Front axle Rear axle Front axle Rear axle
235/65 R 17
38 psi (2.6 bar) 50 psi (3.4 bar) 38 psi (2.6 bar) 50 psi (3.4 bar) 235/60 R 18
255/55 R 18
275/45 R 19
275/40 R 20
Collapsible spare wheel 51 psi (3.5 bar) 51 psi (3.5 bar) 51 psi (3.5 bar) 51 psi (3.5 bar)

362
Vehicle Identification, Technical Data
CapacitiesUse only fluids and fuels authorized by Porsche. Your authorized Porsche dealer will be pleased to advise you.
Your Porsche has been designed so that it is not necessary to mix any additives with oils or fuels.1 Depending on equipment levelCayenne S CayenneEngine oil change quantity without oil filter
approx. 8.5 quarts (8.0 liters)
approx. 6.0 quarts (5.7 liters)
Engine oil change quantity with oil filter approx. 9.0 quarts (8.5 liters) approx. 6.7 quarts (6.3 liters)
Reference indication is the level on the oil dipstick.
Please observe the chapter “ENGINE OIL LEVEL” on Page 244.
Coolant
1)
approx. 4.8 – 5.5 U.S. gallons (18 – 21 liters)
approx. 3.4 – 4.8 U.S. gallons (13 – 18 liters)
Manual transmission with compensation approx.1.9 quarts (1.8 litres) approx.1.9 quarts (1.8 litres)
Automatic transmission with torque converter
approx. 10.6 quarts (10.0 liters)
approx. 10.6 quarts (10.0 liters)
Transfer box approx. 0.9 quarts (0.85 liter) approx. 0.9 quarts (0.85 liter)
Front-axle differential
approx. 1.1 quarts (1.0 liter)
approx. 1.1 quarts (1.0 liter)
Rear-axle differential approx. 1.5 quarts (1.4 liters) approx. 1.2 quarts (1.25 liters)
Locking rear differential
approx. 1.7 quarts (1.6 liters)
approx. 1.7 quarts (1.6 liters)
Fuel tank
approx. 26.4 U.S. gallons (100 liters),
including approx. 3 U.S. gallons (12 liters) reserve
approx. 26.4 U.S. gallons (100 liters),
including approx. 3 U.S. gallons (12 liters) reserve
Fuel quality
The engine is designed to provide optimum performance and fuel consumption if unleaded premium fuel with
98 RON/88 MON is used.
If unleaded premium fuels with octane numbers of at least 95 RON/85 MON are used, the engine's “Electronic
Oktane™ knock control“ automatically adapts the ignition timing.
Power steering
approx. 1.6 quarts (1.5 liters) Pentosin CHF 11 S
®approx. 1.6 quarts (1.5 liters) Pentosin CHF 11 S
®
Brake fluid
approx. 1.0 quart (0.95 liter)
approx. 1.0 quart (0.95 liter)
Use only Original Porsche brake fluid.
Use only Original Porsche brake fluid.
Window/headlight washer system approx. 7.9 quarts (7.5 liters) approx. 7.9 quarts (7.5 liters)

Vehicle Identification, Technical Data
363
Weights1)Empty weight includes 165 lbs. (75 kg) driver and baggage share.2)The maximum gross weight must not be exceeded.
Note: If additional equipment is installed, the useful load will be correspondingly less.3)Use only Original Porsche Roof Transport System. Cayenne
manual transmissionCayenne
Tiptronic SCayenne S
manual transmissionCayenne S
Tiptronic SEmpty weightEmpty weight (depending on equipment)per DIN 70020
4860 - 5670 lbs.
(2160 - 2520 Kg)
4784 -5578 lbs.
(2170 - 2530 kg)
5006 - 5850 lbs.
(2225-2600 kg)
4949 - 5776 lbs.
(2245 - 2620 kg)
per 70/156/EEC
1)
5029 - 5839 lbs.
(2235 - 2595 kg)5051 - 5861 lbs.
(2245 - 2605 kg)5175 - 6019 lbs.
(2300 - 2675 kg)5220 - 6064 lbs.
(2320 - 2695 kg)
Maximum axle load, front
2)
3053 lbs. (1385 kg)
3053 lbs. (1385 kg)
3208 lbs. (1455 kg)
3208 lbs. (1455 kg)
Maximum axle load, rear
2)
3637 lbs. (1650 kg) 3637 lbs. (1650 kg) 3704 lbs. (1680 kg) 3704 lbs. (1680 kg)
Maximum gross weight 6492 lbs. (2945 kg) 6492 lbs. (2945 kg) 6790 lbs. (3080 kg) 6790 lbs. (3080 kg)
Trailer operation Canada/USAMaximum gross weight 6713 lbs. (3045 kg) 6713 lbs. (3045 kg) 7155 lbs. (3180 kg) 6790 lbs. (3080 kg)Maximum axle load, front/rear axle
3053/3858 lbs.
(1385/1750 kg)
3053/3858 lbs.
(1385/1750 kg)
3208/3913 lbs.
(1455/1775 kg)
3208/3913 lbs.
(1455/1775 kg)
Roof load
Maximum roof load
3)
when roof rail is fitted
3)
225 lbs. (100 kg)
165 lbs. (75kg)
225 lbs. (100 kg)
165 lbs. (75 kg)
225 lbs. (100 kg)
165 lbs. (75 kg)
225 lbs. (100 kg)
165lbs. (75kg)
Towing capacity/vehicle + trailer weight
Maximum towing capacity, braked
(up to a max. 12% slope)
7716 lbs. (3500 kg)
7716 lbs. (3500 kg)
7716 lbs. (3500 kg)
7716 lbs. (3500 kg)
Maximum towing capacity, unbraked 1654 lbs. (750 kg) 1654 lbs. (750 kg) 1654 lbs. (750 kg) 1654 lbs. (750 kg)
Maximum vehicle + trailer weight
14209 lbs. (6445 kg)
14209 lbs. (6445 kg)
14209 lbs. (6580 kg)
14506 lbs. (6580 kg)
Maximum trailer hich load 308 lbs. (140 kg) 308 lbs. (140 kg) 308 lbs. (140 kg) 308 lbs. (140 kg)

364
Vehicle Identification, Technical Data
Driving PerformanceThe specifications refer to a vehicle at DIN empty weight and max. 441 lbs. (200 kg) load, without performance-inhibiting extra equipment (e.g. special tires)
Cayenne
manual transmissionCayenne
Tiptronic SCayenne S
manual transmissionCayenne S
Tiptronic STo p s p e e d
133 mph (214 km/h)
133 mph (214 km/h )
150 mph (242 km/h)
150 mph (242 km/h)
Acceleration 0 - 62 mph (100 km/h) 9.1 seconds 9.7 seconds 6.8 seconds 7.2 seconds
Maximum speed when driving with a trailer
50 mph (80 km/h)

Vehicle Identification, Technical Data
365
Dimensions1) Up to 21.9 in. (555 mm) for vehicles with air suspension at special terrain level.Cayenne S CayenneLength
188.3 in. (4782 mm)
188.3 in. (4782 mm)
Length with external spare wheel 197.6 in. (5018 mm) 197.6 in. (5018 mm)
Width
75.9 in. (1928 mm)
75.9 in. (1928 mm)
Height at DIN empty weight66.9 in. (1699 mm) 66.9 in. (1699 mm)
Height at DIN empty weight (rail)
68.5 in. (1741 mm)
68.5 in. (1741 mm)
Height at DIN empty weight (basic carrier of Roof Transport System) 70.4 in. (1789 mm) 70.4 in. (1789 mm)
Height at DIN empty weight with rear lid open
87.4 in. (2219 mm)
87.4 in. (2219 mm)
Max. wading depth 19.7 in. (500 mm)
1)
19.7 in. (500 mm)
1)
Tr a c k17" front65.2 in. (1655 mm)17" rear
65.8 in. (1670 mm)
18" front 64.8 in. (1647 mm) 64.8 in. (1647 mm)
18" rear
65.4 in. (1662 mm)
65.4 in. (1662 mm)
19" front 64.6 in. (1641 mm) 64.6 in. (1641 mm)
19" rear
65.2 in. (1656 mm)
65.2 in. (1656 mm)
20" front 64.6 in. (1641 mm) 64.6 in. (1641 mm)
20" rear
65.2 in. (1656 mm)
65.2 in. (1656 mm)
Wheelbase112.4 in. (2855 mm) 112.4 in. (2855 mm)
Overhang, front
36.4 in. (924 mm)
36.4 in. (924 mm)
rear 39.5 in. (1003 mm) 39.5 in. (1003 mm)
Tu r n i n g c i r c l e
461 in. (11.7 m)
461in. (11.7m)

366
Vehicle Identification, Technical Data
Ground Clearance
Cayenne S Cayenne
Steel suspensionRamp angle 20.4° 20.4°Overhang angle, front
29.1°
29.1°
Overhang angle, rear 25.7° 25.7°
Ground clearance (center of axles)
8.5 in. (217 mm)
8.5 in. (217 mm)
Air suspension – normal level
Ramp angle
20.4°
20.4°
Overhang angle, front 29.1° 29.1°
Overhang angle, rear
25.7°
25.7°
Ground clearance (center of axles) 8.5 in. (217 mm) 8.5 in. (217 mm)
Air suspension – low levelRamp angle 17.7° 17.7°Overhang angle, front
27.3°
27.3°
Overhang angle, rear 23.7° 23.7°
Ground clearance (center of axles)
7.5 in. (190 mm)
7.5 in. (190 mm)
Air suspension – loading level
Ramp angle
14.9°
14.9°
Overhang angle, front 24° 24°
Overhang angle, rear
21.7°
21.7°
Ground clearance (center of axles) 6.2 in. (157 mm) 6.2 in. (157 mm)
Air suspension – terrain levelRamp angle 22.2° 22.2°Overhang angle, front
30.7°
30.7°
Overhang angle, rear 26.6° 26.6°
Ground clearance (center of axles)
9.6 in. (243 mm)
9.6 in. (243 mm)

Vehicle Identification, Technical Data
367
Cayenne S Cayenne
Air suspension – special terrain levelRamp angle 24.7° 24.7°Overhang angle, front
32.4°
32.4°
Overhang angle, rear 28.3° 28.3°
Ground clearance (center of axles)
10.7 in. (273 mm)
10.7 in. (273 mm)
