PORSCHE CAYNNE TURBO 2005 1.G Owners Manual

Practical Tips, Minor Repairs
341
Pulling vehicle onto flat bed1. Position wooden ramps at the base of the flat
bed to reduce the angle of the pull.
2. Reel in the hoist cable and check the underside
of the vehicle for any interference.
Tieing down vehicle on flat bed1. Carefully feed towing straps through the open-
ing in the rear wheels.
Make sure metal parts of straps do not dam-
age rim. Make sure the strap is flat over the
rim bead.
Make sure brake backing plate is not dam-
aged.
2. Secure straps to rear of flat bed.
3. Reel in hoist cable only far enough to tension
tie-down straps.4. Carefully feed towing straps through the open-
ing in the front wheels.
Make sure metal parts of straps do not dam-
age rim.
Make sure the strap is flat over the rim bead.
Make sure brake backing plate is not dam-
aged.
5. Secure straps to front of flat bed.
6. Release tension on hoist cable, but do not dis-
connect. Use hoist cable as a safety cable.
Recovering the vehicleDepending on the vehicle equipment, the spare-
wheel well contains one or two towing lugs.
fWhen recovering the vehicle, always use two
towing lugs if possible.
Screw in the towing lugs only at the front or re-
ar.
Never screw them in so that one towing lug is
at the front and one is at the back.

342
Practical Tips, Minor Repairs

Vehicle Identification, Technical Data
343 Vehicle Identification, Technical Data
Vehicle Identification ................................... 344
Engine Data ............................................... 346
Transmission ............................................. 347
Tires, Rims, Tracks .................................... 348
Tire Pressures, Cold ................................... 350
Capacities ................................................. 351
Weights ..................................................... 352
Driving Performance ................................... 353
Dimensions ................................................ 354
Ground Clearance ...................................... 355

344
Vehicle Identification, Technical Data
Vehicle IdentificationWhen ordering spare parts or making inquiries,
please always quote the vehicle identification num-
ber.Data bankThe data bank is located in the passenger com-
partment below the steering wheel. It contains all
important data about your car.This label contains the following information:
1. Vehicle Identification No.
2. Type/Type description
3. Engine code/Transmission code
4. Paint No./Interior
5. Optional equipment
A duplicate of this label is in your Maintenance
Booklet.
Note
The data bank cannot be reordered when lost or
damaged.
Vehicle identification numberIn accordance with Federal Safety Regulations,
the vehicle identification number of your car is lo-
cated at the bottom left of the windshield frame
and can be seen from the outside and in the lug-
gage compartment on the right in front of the tool
box.

Vehicle Identification, Technical Data
345
Safety compliance stickerThe safety compliance sticker is your assurance
that your new Porsche complies with all applicable
Federal Motor Vehicle Safety Standards which
were in effect at the time the vehicle was manufac-
tured.
The sticker also shows the month and year of pro-
duction and the vehicle identification number of
your car (perforations) as well as the Gross Vehi-
cleWeight Rating and the Gross AxleWeightRat-
ing.
Tire pressure plateThe tire pressure plate is fitted to the driver's
door.

346
Vehicle Identification, Technical Data
Engine DataTy p e
Four-cycle spark-ignition
engine
Number of cylinders 8
Bore
3.66 in. (93 mm)
Stroke 3.27 in. (83 mm)
Displacement
275 cu. in. (4511 cm
3)
Compression ratio 9.5 : 1
Net-horsepower, SAE J 1349
450 HP (331 kw)
at engine speed 6000 rpm
Net. torque, SAE J 1349
460 ftlb. (620 NM)
at engine speed 2250 - 4750 rpm
Maximum permitted engine speed
6500 rpm

Vehicle Identification, Technical Data
347
TransmissionTransmission ratio1st gear
4.15 : 1
2nd gear 2.37 : 1
3rd gear
1.56 : 1
4th gear 1.16 : 1
5th gear
0.86 : 1
6th gear 0.69 : 1
Reduction gear
2.70 : 1
Reverse gear 3.39 : 1
Final drive ratio
3.70 : 1

348
Vehicle Identification, Technical Data
Tires, Rims, Tracks
Tires Wheel Rim offset Track
front/rear front/rear front rear
Summer tires
255/55 R 18 109 Y XL
1)
8 J x 18
57 mm
64.8 in. (1647 mm)
65.4 in. (1662 mm)
275/45 R 19 108 Y XL 9 J x 19 60 mm 64.6 in. (1641 mm) 65.2 in. (1656 mm)
275/40 R 20 106 Y XL
9 J x 20
60 mm
64.6 in. (1641 mm)
65.2 in. (1656 mm)
275/40 R 20 106 Y XL 9 J x 19/10 J x 20 60 mm / 55 mm 64.6 in. (1641 mm) 65.6 in. (1666 mm)
Winter tires
235/60 R 18 107 H XL
1)
8 J x 18
57 mm
64.8 in. (1647 mm)
64.8 in. (1662 mm)
255/55 R18 109 V XL
1)
8 J x 18 57 mm 64.8 in. (1647 mm) 65.4 in. (1662 mm)
255/50 R19 107 V XL
1)
9 J x 19
60 mm
64.6 in. (1641 mm)
65.2 in. (1656 mm)
All-Season
255/55 R 18 109 V XL
1)
8 J x 18
57 mm
64.8 in. (1647 mm)
65.4 in. (1662 mm)
All-Terrain
235/60 R 18 107 T XL
1)
8 J x 18
57 mm
64.8 in. (1647 mm)
65.4 in. (1662 mm)
The load capacity coefficient (e.g. “106”) and maximum speed code letter (e.g. “T”) for permitted top speed are
minimum requirements.
When fitting new tires or changing tires: Please observe the chapter “TIRES/WHEELS” on Page 269.
Tire and rim sizes
The authorization of tire and rim sizes is determined on the basis of extensive testing.
Your authorized Porsche dealer will be pleased to advise you about the current authorization status.
Refitting with sizes not authorized by Porsche may have a dangerous effect on driving stability.

Vehicle Identification, Technical Data
349
1)Snow chainsSnow chain clearance can be guaranteed only with the tire + rim combination marked
1).
The best possible handling characteristics are achieved when snow chains are fitted on all four wheels of the
vehicle. However, it is also possible to fit snow chains on only one axle (preferably the rear axle).
For safety reasons, vehicles with snow chains must not be driven faster than 30 mph (50 km/h).
fObserve the respective road traffic regulations.
fUse only Porsche-authorized fine-link cross-type or edge chains.
Collapsible spare wheel
195/75 18
6.5 J x 18
Tires Wheel Rim offset Track
front/rear front/rear front rear

350
Vehicle Identification, Technical Data
Tire Pressures, ColdThese tire filling pressures apply only to the tire makes and types approved by Porsche.
Please observe the chapter “TIRES/WHEELS” on Page 269.Partially loaded
Tire size Front axle Rear axle
235/60 R 18
38 psi (2.6 bar) 43 psi (2.9 bar) 255/55 R 18
275/45 R 19
275/40 R 20
195/75 - 18 collapsible spare wheel 51 psi (3.5 bar) 51 psi (3.5 bar)
Fully loaded
Tire size Front axle Rear axle
235/60 R 18
38 psi (2.6 bar) 50 psi (3.4 bar) 255/55 R 18
275/45 R 19
275/40 R 20
195/75 - 18 collapsible spare wheel 51 psi (3.5 bar) 51 psi (3.5 bar)
