78
Controls, Safety, Instruments
Multi-Purpose Display
Warning!
There is a danger of accident if you set or
operate the on-board computer, radio, navi-
gation system, telephone or other equipment
when driving.
This could distract you from the traffic and
cause you to lose control of the vehicle.
fOperate the components while driving only if
the traffic situation allows you to do so safely.
fCarry out any complicated operating or setting procedures only with the vehicle stationary.
It is not possible to describe all details of the
functions in this Owner's Manual.
The examples clearly demonstrate the functional
principle and clarify the menu structure.
As a rule, you can use the menu items:
MAIN MENU > SETTINGS > FACTORY SETTINGS
to return to the basic factory settings.
fPlease observe the chapter “FACTORY SET-
TINGS” on Page 105.
Readiness for operation– Ignition is on.
Operation, controlsThe multi-purpose display is operated with the
rocker switch at the end of the wiper stalk and the
RESET switch at the bottom of the wiper stalk.
To move up in the menu
fPress rocker switch up.
To move down in the menu
fPress rocker switch down.
To call selected menu line
fPress RESET switch.
To scroll in the menu
Arrows at the top and bottom of the menu indicate
additional entries.
fPress rocker switch up or down.
In the COMFORT menu, the menu scrolls
automatically as you approach the end of the list.
Note on operation
Depending on the equipment of your vehicle,
some information or functions may not be avail-
able on the multi-purpose display (e.g. telephone,
navigation, audio system, compass or tire pres-
sure).

170
Controls, Safety, Instruments
Porsche Communication
Management (PCM)
Warning!
There is a danger of accident if you set or
operate the on-board computer, radio, navi-
gation system, telephone or other equipment
when driving.
This could distract you from the traffic and
cause you to lose control of the vehicle re-
sulting in serious personal injury or death.
fOperate the components while driving only if
the traffic situation allows you to do so safely.
fCarry out any complicated operating or setting
procedures only with the vehicle stationary
fIf it is necessary to operate these components
while the vehicle is in motion, use the function keys on the multi-functional steering wheel.
fRefer to the separate operating instructions
before putting the PCM into operation.When put into operation for the first time, a dis-
tance of approx. 3 miles (5 km) must be driven in
order for the navigation system to complete the
process of fine calibration. The same applies
when the tires are changed (e.g. summer/winter
tires) or new tires fitted.
Full location accuracy is not yet achieved during
the fine-calibration process.
If the vehicle has been transported (e.g. ferry, car
train), the system may take a few minutes after
being switched on before it determines the current
location.
Serious tire slip (e.g. spinning wheels on snow)
may result in temporarily inaccurate navigation.
When the battery has been disconnected, it may
take up to 15 minutes before the navigation
system is operational once more.
Satellite radioYou must have the satellite radio activated before
you can put it into operation. You will need a con-
tract with a provider in order to use this radio.
fRefer to the separate radio operating instruc-
tions before putting into operation.

308
Practical Tips, Minor Repairs
Fuse assignment – fuse box in left side of dashboard
No. Designation Rating in A1
Socket for towing attachment
15
2 ParkAssist5
3
Towing attachment control unit
15
4 Telephone/telematics control unit5
5
Towing attachment control unit
15
6 Porsche Stability Management (PSM)30
7
Center differential lock
5
8 Additional high beam20
9
CD changer, DVD navigation
5
10 TV tuner, satellite receiver5
11
Radio
10
12 Radio booster30
13
Seat heating
5
14 Tail light, left15
15
Power window, rear right
25
16 Rear guard lights, luggage compartment lights, entry light, rear lid 10
17
Low beam, right; high beam, right
15
18 Heated rear window30
19
Towing attachment motor
30/25
20 Electric seat height adjustment30
21
Alarm system, spare wheel release
10

Index
363
NNavigation system ...................................... 170
Normal level ............................................... 228OOctane ratings ............................................ 252
Odometer .................................................... 75
Off delay ........................................... 104
,146
Off-road ABS ..................................... 218,223
Off-road driving ........................................... 220
Recommendation ................................ 221
Off-road shifting
Limit speed ............................... 207,210
Oil ............................................................. 235
Change .............................................. 239
Consumption ........................................ 14
Dipstick .............................................. 237
Filler opening ...................................... 237
Performance class .............................. 239
Temperature gauge .............................. 72
Topping up ......................................... 237
Viscosity ............................................ 239
Oil level
Checking ............................................ 236
On-board computer .............................. 78,181
Basic Screens ...................................... 79
Clock ................................................... 99
Collapsible spare wheel ......................... 90
Comfort ............................................. 101
Factory settings .................................. 105
Language ........................................... 105
Level.................................................... 83
Lighting .............................................. 104Load ....................................................91
Locks/reduction....................................84
Main menu ............................................80
Operation, controls ...............................78
Settings ...............................................99
Spare wheel..........................................90
System.................................................92
Tire pressure .................................85
,87
Tire sealant/sealing set .........................91
Tire type...............................................88
Tyre type ..............................................88
Units ..................................................104
Vehicle info ...........................................82
Warnings ..............................................83
Operating in other countries.........................249
Oxygen sensor ...........................................255
PPaint ..........................................................259
Panic button .................................................17
Panorama roof system ................................151
ParkAssist ................................157
,159
,195
Parking ......................................................204
Parking aid ..........................................34,157
Parking brake ...............................................62
Test stand ..........................................219
Warning light................................63,110
Parking heater ............................................137
Activating the memory .........................140
Faults .................................................141
Programming.............................138,139
Switching on and off ............................138
Parking light ...............................................117
Particle filter ...............................................245PASM ............................................... 211
,231
Display .............................................. 231
Indicator light ..................................... 110
Warning light ...................................... 231
Passenger compartment ............................ 193
Passenger compartment monitoring
system ............................ 21
,23,27,28,30
Passenger-seat drawer ...................... 172
,175
PCM .......................................................... 170
Person buttons ............................................ 33
Plastic parts .............................................. 262
Polishing.................................................... 259
Porsche Active Suspension
Management..................................... 211,231
Display .............................................. 231
Indicator light ..................................... 110
Warning light ...................................... 231
Porsche Communication Management ......... 170
Porsche Down-Hill Assistant ........................ 219
Porsche Entry & Drive .................. 24
,25,178
Immobilizer .......................................... 25
Opening/locking rear window ................ 24
Opening/locking spare wheel bracket .... 24
Porsche Stability
Management............................ 211
,214
,294
Deactivating ....................................... 216
Indicator light ..................................... 110
Information light ................................. 216
Off road ............................................. 215
Switching on ...................................... 216
Warning light ............... 68
,70,110
,216
Porsche Traction Management ........... 211,212
Power measurement .................................. 234
Power steering .......................................... 244
