navigation system PORSCHE CAYNNE TURBO 2006 1.G Owners Manual

90
Controls, Safety, Instruments
Multi-Purpose Display
Warning!
There is a danger of accident if you set or
operate the on-board computer, radio, navi-
gation system, telephone or other equipment
when driving.
This could distract you from the traffic and
cause you to lose control of the vehicle.
fOperate the components while driving only if
the traffic situation allows you to do so safely.
fCarry out any complicated operating or setting procedures only with the vehicle stationary.
It is not possible to describe all details of the
functions in this Owner's Manual.
The examples clearly demonstrate the functional
principle and clarify the menu structure.
As a rule, you can use the menu items:
MAIN MENU > SETTINGS > FACTORY SETTINGS
to return to the basic factory settings.
fPlease observe the chapter “FACTORY SET-
TINGS” on Page 121.
Readiness for operation– Ignition is on.Operation, controlsThe multi-purpose display is operated with the
rocker switch at the end of the wiper stalk and the
RESET switch at the bottom of the wiper stalk.
To move up in the menu
fPress rocker switch up.
To move down in the menu
fPress rocker switch down.To call selected menu line
fPress RESET switch.
To scroll in the menu
Arrows at the top and bottom of the menu indicate
additional entries.
fPress rocker switch up or down.
In the COMFORT menu, the menu scrolls
automatically as you approach the end of the list.
Note on operation
Depending on the equipment of your vehicle,
some information or functions may not be availa-
ble on the multi-purpose display (e.g. navigation,
audio system, compass or tire pressure).
Various menus can only be called up when the ve-
hicle is stationary.

186
Controls, Safety, Instruments
Porsche Communication
Management (PCM)
Warning!
There is a danger of accident if you set or
operate the on-board computer, radio, navi-
gation system, telephone or other equipment
when driving.
This could distract you from the traffic and
cause you to lose control of the vehicle re-
sulting in serious personal injury or death.
fOperate the components while driving only if
the traffic situation allows you to do so safely.
fCarry out any complicated operating or setting
procedures only with the vehicle stationary.
fIf it is necessary to operate these components
while the vehicle is in motion, use the function keys on the multi-functional steering wheel.
fRefer to the separate operating instructions
before putting the PCM into operation.When put into operation for the first time, a dis-
tance of approx. 3 miles (5 km) must be driven in
order for the navigation system to complete the
process of fine calibration. The same applies
when the tires are changed (e.g. summer/winter
tires) or new tires fitted.
Full location accuracy is not yet achieved during
the fine-calibration process.
If the vehicle has been transported (e.g. ferry, car
train), the system may take a few minutes after be-
ing switched on before it determines the current
location.
Serious tire slip (e.g. spinning wheels on snow)
may result in temporarily inaccurate navigation.
When the battery has been disconnected, it may
take up to 15 minutes before the navigation
system is operational once more.
Satellite radioYou must have the satellite radio activated before
you can put it into operation. You will need a con-
tract with a provider in order to use this radio.
fRefer to the separate radio operating instruc-
tions before putting into operation.

328
Practical Tips, Minor Repairs
Fuse assignment – fuse box in right side of dashboard
No. Designation Rating in A1
Towing attachment
15
2 ParkAssist5
3
Towing attachment
15
4 Telephone/telematics control unit5
5
Towing attachment
15
6 Porsche Stability Management (PSM)30
7
Transfer box (center differential lock), telephone preparation
5
8 Additional high beam, vehicle electrical system control unit 20
9
CD changer, DVD navigation
5
10 TV tuner, satellite receiver5
11
Radio or Porsche Communication System (PCM)
10
12 Radio booster30
1314 Tail light, left; central locking system, power windows, mirrors 1515
Power window, rear right
25
16
17
Low beam, right; high beam, right; vehicle electrical system control unit
15
18 Heated rear window relay30
19
Brake booster, towing attachment
30/25
20
21
Hood open switch, spare wheel release
10

382
Index Platform ............................................. 300
Light
Flasher............................................... 133
Switch................................................ 130
Light alloy wheels ....................................... 279
Inscription .......................................... 298
Light segments........................................... 175
Lighter
front .................................................. 182
rear ................................................... 182
Lights ............................................... 210
, 279
Changing............................................ 348
Chart ................................................. 347
Limit speed
Off-road shifting......................... 223, 226
Load .......................................................... 209
Compartment cover............................ 188
Full .................................................... 106
Partial ................................................ 106
Safety net .......................................... 188
Securing (ski bag)............................... 204
Stowing.............................................. 209
Load fastening points.................................. 197
Loading level ............................ 245
, 246
, 375
Loadspace ........................................ 197, 209
Loadspace floor ......................................... 197
Locking the steering column
With Porsche Entry & Drive .................... 71
Without Porsche Entry & Drive ............... 71
Locking, keyless ........................................... 22
Immobilizer........................................... 23
Switching off readiness for operation...... 23
Unlocking vehicle doors......................... 22
Locks .......................................................... 99Low beam ......................................... 130
, 162
Switch ................................................ 130
Low level .................................................... 244
Low Range ............... 99
, 217
, 219
, 223
, 226
Indicator light ...................................... 223
Off-road driving program...................... 222
Luggage
Compartment cover ............................ 188
Safety net........................................... 188
Luggage compartment ................................ 197
Luggage compartment cover ..... 188
, 198
, 199
Luggage compartment lid................... 194, 195
Locking ................................................ 22
Opening ............................................... 22
Luggage net ...................................... 197, 209
Luggage safety net............................ 201, 202
Bracket .............................................. 201
MMain menu.................................................... 92
Make-up mirror ........................................... 158
Manual headlight beam adjustment ............... 123
Memory ................................................ 37
, 38
Minor paint damage .................................... 276
Minor repairs .............................................. 285
Mirrors ....................................................... 210
Door mirrors......................................... 67
Interior mirror ....................................... 66
Moving off ................................ 214
, 216
, 217
MSR........................................................... 231
Multi-functional steering wheel ........................ 64
Function keys................................. 64, 65
With telephone function.......................... 65
Multi-purpose display ............................ 90
, 200Basic screens .......................................91
Clock .................................................114
Collapsible spare wheel .......................105
Comfort..............................................116
Compass ............................................115
Factory settings ..................................121
Language ...........................................120
Level ....................................................98
Lighting ..............................................119
Load ..................................................106
Locks/reduction ....................................99
Main menu ............................................92
Operation, controls................................90
Settings..............................................114
Spare wheel........................................105
System...............................................107
Telephone.............................................93
Tire pressure .............................100
, 102
Tire sealant/sealing set .......................106
Tire type .............................................103
Units ..................................................120
Vehicle info ...........................................97
Warnings ..............................................98
NNavigation system .......................................186
Normal level ...............................................244OOctane ratings ............................................269
Odometer .....................................................87
Off delay ...........................................119
, 162
Off-road ABS ......................................234, 239
