Maintenance and Car Care
273
Care of windshield wiper bladesWindshield wiper blades that are in perfect
condition are vital for a clear view.
fPlease see the chapter “WIPER BLADES” on
page 261.
f Have the wiper blades replaced twice per year
(before and after the cold season) or if wiper
performance deteriorates or the blades are
damaged.
f Clean the wiper blades with window cleaner at
regular intervals, especially after washing the
vehicle in a car wash.
We recommend Porsche window cleaner.
If wiper blades are very dirty (e.g. covered with
insect remains), they can be cleaned with
a sponge or cloth.
If the wiper blades rub or squeak, this may be due
to the following:
– If the vehicle is washed in an automatic car wash, wax residues may adhere to
the windshield. These wax residues can
be removed only by using window
cleaner concentrate.
f Please see the chapter “WASHER FLUID” on
page 259. Contact your authorized Porsche dealer for more
information.
– The wiper blades may be damaged or worn.
f
Have damaged wiper blades replaced
immediately.
UndercoatingThe underside of your car is durably protected
against chemical and mechanical influences.
As it is not possible to ex clude the risk of damage
to this protective coating in day to day driving, it
is advisable to have the underside of the car
inspected at certain intervals - preferably before
the start of winter and again in spring - and the
undercoating restored as necessary.
Your authorized Porsche dealer is familiar with the
bodyseal treatment procedures and has the
necessary equipment for applying factory
approved materials. We recommend that you
entrust them with such work and inspections.
Unlike conventional spray oils, undercoating and
rust-proofing compounds based on bitumen or
wax do not attack the sound-proofing materials
applied at the factory.
Warning!
Danger of fire resulting in serious personal
injury or death.
f Do not apply additional undercoating or rust-
proofing on or near the exhaust manifold,
exhaust pipes, catalytic converters or heat
shields. During driving the substance used for undercoating could overheat and ignite.
f Before applying fresh underseal, carefully
remove deposits or dirt and grease. Once it
has dried, the new undercoating compound
forms a tough protective coating which
provides efficient rust-proofing of the floor
panels and components.
f Always apply a fresh coating of suitable preser-
vative to unprotect areas after cleaning the
underside of the body, the transmission, the
engine or carrying out repairs to under-body,
engine or transmission components.
Effective rust-proofing is particularly important
during the cold weather season. If your car is
driven frequently in areas where salt has been
spread on the roads, the whole engine compart-
ment should be cleane d thoroughly after the
winter to prevent salt from causing any lasting
damage. A full under-body wash should also be
performed at the same time.

332
Index
Switching on and off .......................................... 170
Automatic (PDK transmission) Rocker switches on the st eering wheel .................. 61
Automatic brake differential (ABD) Functional description . ....................................... 204
Automatic driving light assistant Adaptive light system .. ......................................... 92
Automatic headlight levelling Functional description . ......................................... 94
Automatic speed control (cruise control) Accelerating ........ ...................................... ........ 177
Decelerating........................................... ........... 177
Functional description . ....................................... 176
Interrupting operation.. ....................................... 177
Storing speed.. .................................................. 176
Switching off .................. ................................... 178
Switching on .................. ................................... 176
Automatic transmission...... .......................................... 193
AUX interface, installation position ................................ 192
Auxiliary high-beam headlight Changing bulb ................ ................................... 311
Installing headlights..... ....................................... 309
Removing headlights ....... ................................... 309
BBaby seat
Installing with LATCH sy stem ................................ 56
LATCH restraint system .. ..................................... 56
Prescribed installation direction (depending on
weight of child) ........... ......................................... 53
Battery ........................................ ............................... 191
Care ................... ...................................... ........ 304
Changing in car key .... ....................................... 307
Charge state ... .................................................. 303
Charging ............. ...................................... ........ 307
General information..... ....................................... 303
Jump-lead starting .......... ................................... 306
Location.............. ...................................... ........ 303
Procedure after connectio n ................................ 305
Replacing .................................................. ........ 305
Vehicle electrical system voltage indication .......... 113
Winter driving ..................... ............................... 304
Before driving off .............. .............................................. 4
Belt tensioner Functional description . ......................................... 45 Belts...................
.......................................... ................ 44
Adjusting belt height .......................... ................... 47
Belt tensioner functional description ...................... 45
Care instructions........... ..................................... 276
Fastening ..................... ....................................... 46
Opening ............ ...................................... ............ 46
Warning light on the tach ometer ............................ 45
Bi-Xenon headlight Changing bulb for auxiliary high-beam headlight .... 311
Installing headlights ....... ..................................... 309
Removing headlights ......... ................................. 309
Brake booster ........................ ..................................... 174
Brake fluid Changing .............. ............................................. 259
Warning light on speedometer
............................. 259
Brake pads Breaking in new brake pa ds .................................... 6
Warning message, brakes . ................................. 174
Brake pedal............. .................................................... 173
Brake wear Warning message ............. ................................. 174
Brakes Applying/releasing parkin g brake ........................ 171
Brake pad warning messag e ............................... 174
Brake pedal ...................... ................................. 173
Brake wear warning mess age ............................. 174
Break in new brake pads ........................................ 6
Footbrake.......... ................................................ 172
Test stand ......... ................................................ 253
Break in hints ..................... ............................................. 6
Breaking in Engine ................. ................................................. 6
Engine oil and fuel consumption during break-in
period ...................................... ............................. 6
Hints .................... ................................................. 6
New brake pads and brake discs ............................ 6
New tires .......... .................................................... 6
Brief overview Air conditioning, front co ntrol panel ....................... 68
Air conditioning, rear co ntrol panel ........................ 69
Opening and locking the ve hicle from outside ......... 21
Windshield wipers ............. ................................. 101
Bulbs Changing bulb for auxiliary high-beam headlight .... 311
Changing bulb for licence plate light .................... 313
Changing bulb for side ma rker light ..................... 313 Changing bulb for
side turn signal light................ 312
CCar care
Air bags.............. .............................................. 276
Alcantara ............ .............................................. 276
Alloy wheels .................... .................................. 274
Cleaning the engine comp artment....................... 272
Fabric linings............... ...................................... 276
Headlights, plastic componen ts, adhesive foils .... 274
Laying up your Porsche ..................................... 276
Leather............... .............................................. 275
Paint .................. .............................................. 271
Seals.................. .............................................. 275
Seat belts ....... .................................................. 276
Undercoating ......................................... ........... 273
Use of high-pressure cleaning equipment ............ 270
Washing the vehicle, inst ructions ........................ 270
Wheel bolts ..................... .................................. 293
Windows ............. .............................................. 272
Car key (remote control) Emergency operation of key in ignition lock ......... 166
Locking vehicle door ....... .................................... 24
Unlocking vehicle door . ........................................ 23
Car Telephone ...................... ...................................... 190
Care instructions Air bags.............. .............................................. 276
Alcantara ............ .............................................. 276
Alloy wheels .................... .................................. 274
Car washing .................... .................................. 270
Carpet ................ .............................................. 275
Cleaning the engine comp artment....................... 272
Fabric linings............... ...................................... 276
Headlights, plastic componen ts, adhesive foils .... 274
Laying up your Porsche ..................................... 276
Leather............... .............................................. 275
Mats................... .............................................. 275
Paint .................. .............................................. 271
Radar sensor ......................................... ...........
274
Reversing camera ........... .................................. 274
Seals.................. .............................................. 275
Seat belts ....... .................................................. 276
Ultrasound sensors, Park Assist .......................... 274
Undercoating ......................................... ........... 273
Use of high-pressure cleaning equipment ............ 270
