Engine Ram 1500 2018 Owner's Manual

Chassis
ComponentFluid, Lubricant, or Genuine Part
Automatic Transmission – Eight-Speed Automatic Use only Mopar ZF 8&9 Speed ATF Automatic Transmis- sion Fluid, or equivalent. Failure to use the correct fluid
may affect the function or performance of your transmis-
sion.
Automatic Transmission – Six-Speed Automatic with Gaso-
line Engine (For Diesel Engine see Diesel Supplement) Use only ATF+4 Automatic Transmission Fluid. Failure to
use ATF+4 fluid may affect the function or performance of
your transmission. We recommend Mopar ATF+4 fluid.
Transfer Case We recommend you use Mopar BW44–44 Transfer Case
Fluid.
Front Axle – 1500 Four-Wheel Drive Models We recommend you use Mopar GL-5 Synthetic Axle Lubri-
cant SAE 75W-85.
Rear Axle – 1500 Models We recommend you use Mopar Synthetic Gear Lubricant
SAE 75W-140 (MS-8985). Limited-Slip Rear Axles require
the addition of 5 oz. (148 ml) Mopar Limited Slip Additive
(MS-10111).
9
TECHNICAL SPECIFICATIONS 607

Customer Programmable Features — Uconnect 3
Personal Settings
Push the MORE or SETTINGS button on the faceplate, then
press the “Settings” button on the touchscreen (if
equipped) to display the settings menu screen. In thismode the Uconnect system allows you to access program-
mable features that may be equipped such as Display,
Units, Voice, Clock, Safety & Driving Assistance, Lights,
Doors & Locks, Auto-On Comfort (if equipped), Engine Off
Options, Suspension, Trailer Brake, Audio, Compass Set-
tings, Phone/Bluetooth, SiriusXM Setup (if equipped),
Restore Settings, Clear Personal Data and System Informa-
tion.
NOTE:
Only one category may be selected at a time.
When making a selection, press the button on the touch-
screen to enter the desired mode. Once in the desired
mode, press and release the preferred setting until the
button is highlighted. Once the setting is complete, either
press the back arrow or the “Done” button on the touch-
screen or the Back button on the faceplate to return to the
previous menu. Pressing the Up or Down Arrow buttons
on the touchscreen on the right side of the screen will allow
you to toggle up or down through the list of available
settings.
NOTE: All settings should be changed with the ignition in
the RUN position.
Uconnect 3 With 5–inch Display Buttons On The
Touchscreen And Buttons On The Faceplate
1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate
10
MULTIMEDIA 615

Engine Off Options
After pressing the “Engine Off Options” button on the
touchscreen, the following settings will be available:
Setting NameSelectable Options
Easy Exit Seats — If Equipped
Headlight Off Delay 0 sec30 sec 60 sec 90 sec
Engine Off Power Delay 0 sec
45 sec 5 min10 min
Setting Name Selectable Options
Auto Entry/Exit — If Equipped OnOff
Suspension — If Equipped
After pressing the “Suspension” button on the touchscreen,
the following settings will be available:
Setting Name Selectable Options
Sound Horn With Lower OnOff
Flash Lights With Lower OnOff
624 MULTIMEDIA

Customer Programmable Features — Uconnect
4C/4C NAV Personal Settings
Press the “Apps” button on the touchscreen then press the
“Settings” button on the touchscreen to display the settings
menu screen. In this mode the Uconnect system allows youto access programmable features that may be equipped
such as Display, Voice, Clock, Safety & Driving Assistance,
Lights, Doors & Locks, Auto-On Comfort (if equipped),
Engine Off Options, Suspension, Trailer Brake, Audio,
Phone/Bluetooth, SiriusXM Setup (if equipped), Restore
Settings, Clear Personal Data and System Information.
NOTE:
Only one category may be selected at a time.
When making a selection, press the button on the touch-
screen to enter the desired mode. Once in the desired
mode, press and release the preferred setting until a
check-mark appears next to the setting, showing that
setting has been selected. Once the setting is complete,
either press the back arrow button on the touchscreen or
the Back button on the faceplate to return to the previous
menu or press the “X” button on the touchscreen to close
out of the settings screen. Pressing the Up or Down Arrow
buttons on the touchscreen on the right side of the screen
will allow you to toggle up or down through the list of
available settings.
NOTE: All settings should be changed with the ignition in
the RUN position.
Uconnect 4C/4C NAV With 8.4–inch Display Buttons On
The Touchscreen And Buttons On The Faceplate
1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate
10
MULTIMEDIA 633

Auto Comfort Systems — If Equipped
After pressing the “Auto-On Comfort” button on the
touchscreen, the following settings will be available:
Setting NameSelectable Options
Auto-On Driver Heated/
Ventilated Seat & Steering Wheel With Vehicle Start — If Equipped Off
Remote Start All Starts
NOTE:
When the “Auto-On Driver Heated/Ventilated Seat & Steering Wheel With Vehicle Start” feature is selected the driv-
er’s heated seat and heated steering wheel will automatically turn on when temperatures are below 40° F (4.4° C).
When temperatures are above 80° F (26.7° C), the driver vented seat will turn on.
Engine Off Options
After pressing the “Engine Off Options” button on the
touchscreen, the following settings will be available:
Setting Name Selectable Options
Easy Exit Seat — If Equipped
NOTE:
When the “Easy Exit Seat” feature is selected, the Driver ’s seat will automatically move rearward once the engine is shut off.
644 MULTIMEDIA

Setting NameSelectable Options
Engine Off Power Delay +–
NOTE:
When the “Engine Off Power Delay” feature is selected, the power window switches, radio, Uconnect phone system
(if equipped), power sunroof (if equipped), and power outlets will remain active for up to ten minutes after the igni-
tion is cycled to OFF. Opening either front door will cancel this feature. Headlight Off Delay +–
NOTE:
When the “Headlight Off Delay” feature is selected, the driver can choose to have the headlights remain on for 0, 30,
60, or 90 seconds when exiting the vehicle.
Air Suspension — If Equipped
After pressing the “Suspension” button on the touchscreen,
the following settings will be available:
Setting Name Selectable Options
Sound Horn With Lower
NOTE:
When the “Sound Horn With Lower” feature is selected, a short horn sound will occur when the key fob remote
lower button is pushed.
10
MULTIMEDIA 645

to a TDD or a conventional teletypewriter (TTY) in the
United States, can communicate with the manufacturer by
dialing 1-800-380-CHRY.
Canadian residents with hearing difficulties that require
assistance can use the special needs relay service offered by
Bell Canada. For TTY teletypewriter users, dial 711 and for
Voice callers, dial 1-800-855-0511 to connect with a Bell
Relay Service operator.
Service Contract
You may have purchased a service contract for a vehicle to
help protect you from the high cost of unexpected repairs
after the manufacturer’s New Vehicle Limited Warranty
expires. The manufacturer stands behind only the manu-
facturer’s service contracts. If you purchased a manufac-
turer’s service contract, you will receive Plan Provisions
and an Owner Identification Card in the mail within three
weeks of the vehicle delivery date. If you have any
questions about the service contract, call the manufactur-
er’s Service Contract National Customer Hotline at 1-800-
521-9922 (Canadian residents, call (800) 465-2001 English /
(800) 387-9983 French).
The manufacturer will not stand behind any service contract
that is not the manufacturer’s service contract. It is notresponsible for any service contract other than the manufac-
turer’s service contract. If you purchased a service contract
that is not a manufacturer’s service contract, and you require
service after the manufacturer’s New Vehicle Limited War-
ranty expires, please refer to the contract documents, and
contact the person listed in those documents.
We appreciate that you have made a major investment
when you purchased the vehicle. An authorized dealer has
also made a major investment in facilities, tools, and
training to assure that you are absolutely delighted with
the ownership experience. You will be pleased with their
sincere efforts to resolve any warranty issues or related
concerns.
WARNING!
Engine exhaust (internal combustion engines only),
some of its constituents, and certain vehicle compo-
nents contain, or emit, chemicals known to the State of
California to cause cancer and birth defects, or other
reproductive harm. In addition, certain fluids con-
tained in vehicles and certain products of component
wear contain, or emit, chemicals known to the State of
California to cause cancer and birth defects, or other
reproductive harm.
678 CUSTOMER ASSISTANCE

Service Manuals
These comprehensive Service Manuals provide the infor-
mation that students and professional technicians need in
diagnosing/troubleshooting, problem solving, maintain-
ing, servicing, and repairing FCA US LLC vehicles. A
complete working knowledge of the vehicle, system,
and/or components is written in straightforward language
with illustrations, diagrams, and charts.
Diagnostic Procedure Manuals
Diagnostic Procedure Manuals are filled with diagrams,
charts and detailed illustrations. These practical manuals
make it easy for students and technicians to find and fix
problems on computer-controlled vehicle systems and fea-
tures. They show exactly how to find and correct problems
the first time, using step-by-step troubleshooting and driv-
ability procedures, proven diagnostic tests and a complete
list of all tools and equipment.Owner’s Manuals
These Owner’s Manuals have been prepared with the
assistance of service and engineering specialists to acquaint
you with specific FCA US LLC vehicles. Included are
starting, operating, emergency and maintenance proce-
dures as well as specifications, capabilities and safety tips.
Call toll free at:
•
1-800-890-4038 (U.S.)
• 1-800-387-1143 (Canada)
Or
Visit us on the Worldwide Web at:
• www.techauthority.com
680 CUSTOMER ASSISTANCE

Adding Engine Coolant (Antifreeze).............548
Adding Fuel ............................. .413
Additives, Fuel ............................597
Adjust Down ...............................47, 49
Forward ............................ .47, 48
Rearward ............................47, 48
Up .................................47, 49
Adjustable Pedals ...........................62
Air Bag Air Bag Operation ........................240
Air Bag Warning Light .....................237
Enhanced Accident Response .............250, 514
Event Data Recorder (EDR) .................514
If A Deployment Occurs ....................249
Knee Impact Bolsters ..................... .241
Maintaining Your Air Bag System .............251
Transporting Pets ........................278
Air Bag Light .......................189, 237, 279
Air Bag Maintenance ........................251
Air Cleaner, Engine (Engine Air Cleaner Filter) ......531
Air Conditioner Maintenance ..................533
Air Conditioning ............................86
Air Conditioning Filter ...................105, 534
Air Conditioning, Operating Tips ...............104Air Conditioning Refrigerant
...............533, 534
Air Conditioning System ..................104, 533
Air Filter ............................... .531
Air Pressure, Tires ..........................569
Air Suspension ........................ .344, 350
Alarm, Panic ...............................23
Alarm (Security Alarm) ....................35, 191
Alarm System (Security Alarm) .................35
Alterations/Modifications, Vehicle ................7
Antifreeze (Engine Coolant) ................547, 603
Disposal ...............................549
Anti-Lock Brake System (ABS) .................204
Anti-Lock Warning Light .....................196
Ashtray .................................137
Assist, Hill

Start.......................... .206
Audio Systems (Radio) .......................611
Auto Down Power Windows ..................107
Automatic Door Locks ........................42
Automatic Headlights ........................76
Automatic High Beams .......................75
Automatic Temperature Control (ATC) ...........104
Automatic Transmission ..................299, 556
Adding Fluid ........................554, 556
Fluid And Filter Changes ...................556
Fluid Change .......................... .556
682 INDEX

Fluid Level Check.....................553, 554
Fluid Type ..........................553, 607
Shifting ............................306, 315
Special Additives ........................ .553
Automatic Transmission Limp Home Mode ........304
Axle Fluid ............................556, 607
Axle Lubrication .......................... .556
Back-Up .................................410
Back-Up Camera .......................... .410
Bar, Stabilizer/Sway System ...................361
Battery ...............................191, 526
Charging System Light ....................191
Keyless Key Fob Replacement ................24
Belts, Seat ............................... .279
Body Builders Guide ..........................7
Body Mechanism Lubrication ..................541
B-Pillar Location .......................... .564
Brake Assist System ........................ .206
Brake Control System, Electronic ................205
Brake Fluid .......................... .552, 607
Brake System ..........................552, 593
Fluid Check ............................552
Master Cylinder ........................ .552
Parking ...............................295 Warning Light
.......................... .190
Brake/Transmission Interlock ..................299
Bulb Replacement ..........................452
Bulbs, Light .......................... .281, 452
Cab Top Clearance Lights .....................458
Camera .................................410
Camera, Rear ............................ .410
Camper .................................152
Capacities, Fluid .......................... .603
Caps, Filler Oil (Engine) ..................... .523, 529, 530
Power Steering ..........................394
Radiator (Coolant

Pressure).................549
Carbon Monoxide Warning ................279, 600
Cargo Light ...............................79
Car Washes ...............................585
Cellular Phone ............................654
Center High Mounted Stop Light ...............457
Center Seat Storage Compartment ...............123
Changing A Flat Tire ........................468
Chart, Tire Sizing .......................... .560
Check Engine Light (Malfunction Indicator Light). . . .201
Checking Your Vehicle For Safety ...............278
Checks, Safety ............................ .278
12
INDEX 683
