fuse box Ram 1500 2019 Owner's Manual

CavityCartridge Fuse Micro Fuse Description
F34 –15 Amp Blue Frt & RR Ventilated Seat Motor
F35 –10 Amp Red Mod Inverter / Mtr Sunshade Sunroof / Mtr
Dual Sunroof
F36 40 Amp Green –Mod CBC 2 Exterior Light 1
F37 –– Spare
F38 –– Spare
F39 –– Spare
F40 –– Spare
F41 A&B –15 Amp Blue Lumbar Support & Pass SW / Mod Cluster
CCN
F42 –10 Amp Red Mod Transfer Case Switch Module (TCSM) /
SBW / Electric Park Brake SW / Overhead
Console (OHC) SW / E-Call / Bank 3 SW / Seat LT & RT Vent
F43 –10 Amp Red Port Diagnostics / Mod CD / Front & Rear
USB
F44 –20 Amp Yellow Radio / DCSD / Telematics Box Mod
F45 30 Amp Pink –Mod Door MUX Driver
F46 30 Amp Pink –Mod Door MUX Passenger
F47 –– Spare
456 IN CASE OF EMERGENCY

New Vehicle Break-In Period..................299
Occupant Restraints ........................ .231
Octane Rating, Gasoline (Fuel) ..............558, 559
Off-Pavement Driving (Off-Road) ...............431
Off-Road Driving (Off-Pavement) ...............431
Oil, Engine ........................... .499, 564
Capacity .............................. .563
Change Interval ........................ .499
Dipstick .............................. .497
Disposal .............................. .500
Filter ............................. .501, 564
Filter Disposal .......................... .500
Identification Logo ...................... .499
Materials Added To ...................... .500
Pressure Warning Light ....................181
Recommendation .....................499, 563
Synthetic ............................. .500
Viscosity ....................... .499, 500, 563
Oil Filter, Change ......................... .501
Oil Filter, Selection ......................... .501
Oil Pressure Light ......................... .181
Onboard Diagnostic System ...................194
Operating Precautions ...................... .194Operator Manual
Owner’s Manual .......................5,678
Outside Rearview Mirrors .....................62
Overheating, Engine ....................... .477
Paint Care ............................... .547
Panic Alarm ...............................21
Parking Brake ............................ .300
ParkSense System, Rear ..................... .364
Passive Entry ..............................38
Pedals, Adjustable ...........................60
Personalized Main Menu .....................569
Pets ................................... .284
Pickup Box ........................... .134, 135
Placard, Tire And Loading Information ...........528
Power Distribution

Center (Fuses) ..............450, 454
Door Locks ..............................37
Mirrors ................................63
Outlet (Auxiliary Electrical Outlet) .........127, 130
Seats ..................................46
Side Steps ..............................37
Sliding Rear Window ......................98
Steering ............................ .63, 336
Sunroof ............................ .99, 102
688 INDEX
