Ram 2500 2013 Owner's Manual

Cavity Car-tridgeFuse Micro
Fuse Description
F33 20 Amp Yellow Diesel Fuel Heater
#1 – If Equipped / Rear Blower – If Equipped
F34 30 Amp Pink Vehicle System In-
terface Module #2 – If Equipped
F35 30 Amp Pink Sunroof – If
Equipped
F36 30 Amp Pink Rear Defroster– If
Equipped
F37 30 Amp Pink Diesel Fuel Heater
#2 if equippedCavity Car- tridgeFuse Micro
Fuse Description
F38 30 Amp Pink Power Inverter
115V AC– IfEquipped
F39 30 Amp Pink Vehicle System In-
terface Module #1– If Equipped
F41 10 Amp
Red Active Grill Shutter
F42 20 Amp
Yellow Horn
F43 10 Amp
Red Snow Plow (Left) –
If Equipped
F44 10 Amp
Red Diagnostic Port
7
MAINTAINING YOUR VEHICLE 679

Cavity Car-tridgeFuse Micro
Fuse Description
F46 10 Amp
Red Tire Pressure Moni-
tor
F47 10 Amp
Red Snow Plow (Right)
– If Equipped
F49 10 Amp
Red Instrument Panel
Cluster
F50 20 Amp
Yellow Air Suspension
Control Module – If Equipped
F51 10 Amp
Red Ignition Node
Module / Keyless Ignition
F52 5 Amp
Ta n Battery SensorCavity Car-
tridgeFuse Micro
Fuse Description
F53 20 Amp
Yellow Trailer Tow – Left
Turn/Stop Lights
F54 20 Amp
Yellow Adjustable Pedals
F55 20 Amp
Yellow E38 Radio – If
Equipped
F56 15 Amp
Blue Additional Diesel
Content – IfEquipped
F57 20 Amp
Yellow Transmission
680 MAINTAINING YOUR VEHICLE

Cavity Car-tridgeFuse Micro
Fuse Description
F58 20 Amp
Yellow (Gas
Engine) /25
Amp
Natural (Diesel
Engine) Engine Cooling
Pump
F60 15 Amp
Blue Underhood Lamp
F61 20 Amp
Yellow Power Take-off
Unit – If Equipped
F62 10 Amp
Red Air Conditioning
ClutchCavity Car- tridgeFuse Micro
Fuse Description
F63 20 Amp
Yellow IgnitionCoils (Gas),
Urea Heater (Die- sel)
F64 25 Amp
Natural Fuel Injectors /
Powertrain
F65 10 Amp
Red USB interface
F66 10 Amp
Red Sunroof / Passen-
ger Window
Switches / Rain Sensor
F67 10 Amp
Red CD / DVD /
Bluetooth Hands- free Module – If Equipped
7
MAINTAINING YOUR VEHICLE 681

Cavity Car-tridgeFuse Micro
Fuse Description
F69 15 Amp
Blue Mod SCR 12V – If
Equipped
F70 30 Amp
Green Fuel Pump Motor
F71 25 Amp
Natural Amplifier
F72 10 Amp
Red Voltage Stabilizer
Modules – IfEquippedCavity Car- tridgeFuse Micro
Fuse Description
F74 20 Amp
Yellow (Gas
Engine) /10
Amp Red
(Diesel
Engine) Brake Vacuum
Pump Gas/Diesel – If Equipped
F75 10 Amp
Red Coolant Tempera-
ture Valve Actuator
F76 10 Amp
Red Antilock Brakes/
Electronic Stability Control
682 MAINTAINING YOUR VEHICLE

Cavity Car-tridgeFuse Micro
Fuse Description
F77 10 Amp
Red Drivetrain Control
Module/Front Axle Disconnect Module
F78 10 Amp
Red Engine Control
Module / Electric Power Steering
F79 15 Amp
Blue Clearance Lights
F80 10 Amp
Red Universal Garage
Door Opener / Compass
F81 20 Amp
Yellow Trailer Tow Right
Turn/Stop LightsCavity Car- tridgeFuse Micro
Fuse Description
F82 10 Amp
Red Steering Column
Control Module/ Cruise Control
F84 15 Amp
Blue Switch Bank/
Instrument Cluster
F85 10 Amp
Red Airbag Module
F86 10 Amp
Red Airbag Module
F87 10 Amp
Red Air Suspension-If
Equipped / Trailer
Tow / Steering Col- umn Control Mod- ule
7
MAINTAINING YOUR VEHICLE 683

Cavity Car-tridgeFuse Micro
Fuse Description
F88 15 Amp
Blue Instrument Panel
Cluster
F90/F91 20 Amp
Yellow Power Outlet (Rear
seats) Customer Selectable
F93 20 Amp
Yellow Cigar Lighter
F94 10 Amp
Red Shifter / Transfer
Case Module
F95 10 Amp
Red Rear Camera /
Park Assist
F96 10 Amp
Red Rear Seat Heater
SwitchCavity Car- tridgeFuse Micro
Fuse Description
F97 25 Amp
Natural Rear Heated Seats
& Heated Steering Wheel – IfEquipped
F98 25 Amp
Natural Front Heated Seats
– If Equipped
F99 10 Amp
Red Climate Control
F101 15 Amp
Blue Electrochromatic
Mirror / Smart
High Beams – If Equipped
F104 20 Amp
Yellow Power Outlets (In-
strument Panel/Center Console)
684 MAINTAINING YOUR VEHICLE

CAUTION!
•When installing the power distribution center
cover, it is important to ensure the cover is properly
positioned and fully latched. Failure to do so may
allow water to get into the power distribution
center and possibly result in an electrical system
failure.
• When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If
a properly rated fuse continues to blow, it indicates
a problem in the circuit that must be corrected.
VEHICLE STORAGE
If you are storing your vehicle for more than 21 days, we
recommend that you take the following steps to mini-
mize the drain on your vehicle’s battery:
• Disconnect the negative cable from battery.
• Any time you store your vehicle or keep it out of
service (i.e., vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
ensure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
7
MAINTAINING YOUR VEHICLE 685

REPLACEMENT BULBS
All of the inside bulbs are brass or glass-wedge base.
Aluminum base bulbs are not approved.
Interior Bulbs
Bulb Number
Overhead Console
Lamps TS 212–9
Dome Lamp 7679
For lighted switches, see your authorized dealer for
replacement instructions.
Exterior Bulbs
Bulb Number
Base Quad Headlamp –
Low Beam H11
Bulb Number
Base Quad Headlamp –
High Beam 9005
Front Turn Signal Lamp
(Base Quad Headlamp) 3157NA
Premium Bi Halogen
Projector Headlamp -
Low Beam HIR2
Premium Bi Halogen
Projector Headlamp -
High Beam 9005
Front Turn Signal Lamp
(Premium Headlamp) LED (Serviced at Autho-
rized Dealer)
Fog Lamp (Horizontal
shape) 9145
Fog Lamp (Vertical
shape) 9006
686 MAINTAINING YOUR VEHICLE

Bulb Number
Center High Mounted
Stop Lamp (CHMSL) 921
Rear Cargo Lamp 921
Cab Roof Marker Lamps 194NA
Base Rear Tail/Turn and
Stop Lamp 3157K
Premium Rear Tail/Turn
and Stop Lamp LED (Serviced at Autho-
rized Dealer)
Premium Backup Lamp T20
Rear Lamp Bar ID
Marker Lamp 194
Side Marker Lamps
(Dual Rear Wheels) 194
Backup Lamp 921
Rear License Plate Lamp 194BULB REPLACEMENT
NOTE:Lens fogging can occur under certain atmo-
spheric conditions. This will usually clear as atmospheric
conditions change to allow the condensation to change
back into a vapor. Turning the lamps on will usually
accelerate the clearing process.
Base Quad / Premium Bi-Halogen: Low Beam
Headlamp, High Beam Headlamp, Front Park And
Turn – If Equipped
1. Open the hood.
2. Disconnect and isolate the negative battery cable.
3. Remove the four plastic push-in fasteners that secure the upper radiator seal to the grille support and both
fender ledges.
4. Remove the two plastic push-in rivets that secure the upper radiator seal to the radiator.7
MAINTAINING YOUR VEHICLE 687

5. Remove the upper radiator seal from the vehicle.
6. Remove the two headlamp assembly attachmentscrews.
7. Reach into the front wheel house ahead of the front wheel, remove the fastener, and lift the cover over the access hole in the front of the wheel house splash
shield. Access to the rear of the lamp can be gained
through this access hole.
8. Reach through the access hole of the wheel house splash shield and lift the slide lock upward far enough
to disengage it from the lock post on the back of the
front lamp unit housing.
688 MAINTAINING YOUR VEHICLE
