CAUTION!
Do not contaminate the bulb glass by touching it
with your fingers or by allowing it to contact other
oily surfaces. Shortened bulb life will result.• Outside Bulbs: Cargo Lamps
• Inside Bulb: Center High-Mounted Stop Lamp
5. Reverse the procedure for installation of bulbs and housing.
Cab Top Clearance Lamps — If Equipped
1. Remove the two screws from the top of the lamp.
Removing Rear Screw From Clearance Lamp
738 MAINTAINING YOUR VEHICLE

2. Rotate the bulb socket ¼ turn and pull it from the lampassembly. 3. Pull the bulb straight from it’s socket and replace.
Removing Bulb Socket From Clearance Lamp
Removing The Bulb From The Bulb Socket7
MAINTAINING YOUR VEHICLE 739

Rear Lamp Bar ID Marker (Dual Rear Wheels) — If
Equipped
1. Loosen the two screws and the housing to gain accessto the bulb sockets. 2. Turn the socket ¼ turn counterclockwise to access the
bulb.
3. Pull the bulb straight out from the socket.
4. Reverse the procedure for installation of the bulbs and housing.
Screw Locations
740 MAINTAINING YOUR VEHICLE

Side Marker Lamps (Dual Rear Wheels) — If
Equipped
1. Push rearward on the side marker lamp assembly.2. Pull the entire assembly from the fender.
3. Turn the socket ¼ turn counterclockwise and remove
from assembly to access the bulb.
4. Pull the bulb straight out from socket.
5. Reverse the procedure for installation of the bulbs and housing.
Side Marker Lamp Locations
7
MAINTAINING YOUR VEHICLE 741

Shifting............................. .406
Special Additives ...................... .709
Axle Fluid ............................. .706
Axle Lubrication (Axle Fluid) .................706
Back-Up Camera ......................... .202
Bar, Stabilizer/Sway System ..................464
Battery ................................ .689
Keyless Transmitter Replacement (RKE) ........29
Belts, Seat ...............................53
Body Builders Guide ........................6
Body Mechanism Lubrication .................692
B-Pillar Location ......................... .535
Brake Assist System ...................... .518
Brake Control System, Electronic ..............517
Brake Fluid ............................ .705
Brake System ........................... .515
Anti-Lock (ABS) ....................... .515
Fluid Check .......................... .705
Master Cylinder ....................... .705Parking
............................. .512
Warning Light ........................ .280
Brake/Transmission Interlock .................396
Bulb Replacement ........................ .730
Bulbs, Light .............................119
Cab Top Clearance Lights ...................738
Camera, Rear ........................... .202
Camper ............................... .257
Capacities, Fluid ......................... .742
Caps, Filler Oil (Engine) .......................... .687
Power Steering .........................511
Radiator (Coolant Pressure) ................700
Carbon Monoxide Warning ..................116
Cargo Light ............................ .171
Car Washes ............................ .713
Cellular Phone .......................... .356
Center High Mounted Stop Light ..............736
Center

Seat Storage Compartment .............231
10
INDEX 771

Integrated Trailer Brake Controls..............593
Interior Appearance Care ....................716
Interior Lights .......................... .168
Intermittent Wipers (Delay Wipers) .............174
Introduction ..............................4
Inverter Outlet (115V) ..................... .225
Jack Location ........................... .621
Jump Starting ........................... .659
Key-In Reminder ..........................18
Keyless Enter-N-Go ........................41
Keyless Entry System .......................23
Key, Programming .........................20
Key, Replacement ..........................19
Keys ...................................12
Key, Sentry (Immobilizer) ....................18
Lane Change and Turn Signals ................172
Lane Change Assist ....................... .173
Lap/Shoulder Belts .........................53
Latches ................................119 Lead Free Gasoline
....................... .568
Leaks, Fluid .............................119
Life of Tires ............................ .549
Light Bulbs ..............................119
Lights .................................119
Airbag ................................74
Alarm .............................. .283
Anti-Lock ............................ .278
Anti-Lock Warning ..................... .516
Automatic Headlights ....................163
Brake Assist Warning ....................527
Brake Warning ........................ .280
Bulb Replacement ...................... .732
Cap Top Clearance ..................... .738
Cargo .............................. .171
Center Mounted Stop ....................736
Check Engine (Malfunction Indicator) .........278
Courtesy/Reading ..................... .169
Daytime Running ...................... .164
10
INDEX 777

Radio Operation......................... .356
Rain Sensitive Wiper System .................176
Ramp Travel Index ....................... .466
Rear Axle (Differential) .....................706
Rear Cargo Area Utility Rails .................255
Rear ParkSense System .....................185
Rear Seat, Folding ........................ .151
Rear Window Features .....................236
Rear Window, Sliding ..................... .238
Reclining Rear Seats ...................... .150
Recorder, Event Data .......................81
Recreational Towing ...................... .606
Shifting into Transfer Case Neutral (N) ........609
Shifting out of Transfer Case Neutral (N) ......611
Reformulated Gasoline .....................569
Refrigerant ............................. .691
Reminder, Seat Belt .........................65
Remote Control Starting System .........................33 Remote Keyless Entry (RKE)
..................23
Remote Sound System (Radio) Controls .........353
Remote Starting System ......................33
Replacement Bulbs ....................... .730
Replacement Keys .........................19
Replacement Parts ........................ .683
Replacement Tires ........................ .550
Reporting Safety Defects ....................765
Restraint, Head .......................... .154
Restraints, Child ...........................82
Restraints, Occupant ........................49
Rotation, Tires .......................... .554
Safety Checks Inside Vehicle ..................117
Safety Checks Outside Vehicle ................119
Safety Defects, Reporting ....................765
Safety, Exhaust Gas ........................116
Safety Information, Tire .....................529
Safety Tips ..............................115
Schedule, Maintenance .....................750
10
INDEX 781
