ENGINE COMPARTMENT — 6.4L
1 — Coolant Pressure Bottle6 — Battery
2 — Transmission Dipstick 7 — Power Distribution Center (Fuses)
3 — Engine Oil Fill 8 — Washer Solvent
4 — Engine Oil Dipstick 9 — Power Steering Fluid Reservoir
5 — Brake Fluid Reservoir 10 — Air Cleaner Filter
680 MAINTAINING YOUR VEHICLE

CAUTION!(Continued)
•Your vehicle has been built with improved fluids
that protect the performance and durability of your
vehicle and also allow extended maintenance inter-
vals. Do not use chemical flushes in these compo-
nents as the chemicals can damage your engine,
transmission, power steering or air conditioning.
Such damage is not covered by the New Vehicle
Limited Warranty. If a flush is needed because of
component malfunction, use only the specified
fluid for the flushing procedure.
Engine Oil
Checking Oil Level
To assure proper lubrication of your vehicle’s engine, the
engine oil must be maintained at the correct level. Check
the oil level at regular intervals, such as every fuel stop. The best time to check the engine oil level is about five
minutes after a fully warmed up engine is shut off.
Checking the oil while the vehicle is on level ground will
improve the accuracy of the oil level readings. Always
maintain the oil level within the SAFE zone on the
dipstick. Adding one quart of oil when the reading is at
the bottom of the SAFE zone will result in a reading at the
top of the safe zone on these engines.
CAUTION!
Overfilling or underfilling the crankcase will cause
oil aeration or loss of oil pressure. This could damage
your engine.
7
MAINTAINING YOUR VEHICLE 685

FUSES
WARNING!
•When replacing a blown fuse, always use an ap-
propriate replacement fuse with the same amp
rating as the original fuse. Never replace a fuse
with another fuse of higher amp rating. Never
replace a blown fuse with metal wires or any other
material. Failure to use proper fuses may result in
serious personal injury, fire and/or property dam-
age.
• Before replacing a fuse, make sure that the ignition
is off and that all the other services are switched off
and/or disengaged.
• If the replaced fuse blows again, contact an autho-
rized dealer.
(Continued)
WARNING! (Continued)
•If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, gearbox system) or steering system
blows, contact an authorized dealer.
720 MAINTAINING YOUR VEHICLE

Cavity Cartridge Fuse Micro FuseDescription
F74 20 Amp Yellow
(Gas Engine &
1500 LD Diesel) / 10 Amp Red
(Cummins Diesel Engine) Brake Vacuum Pump Gas/Diesel – If Equipped
F75 10 Amp RedCoolant Temperature Valve Actuator
F76 10 Amp RedAntilock Brakes/Electronic Stability Control
F77 10 Amp Red Drivetrain Control Module/Front Axle Disconnect
Module
F78 10 Amp Red Engine Control Module / Electric Power Steering
F79 15 Amp Blue Clearance Lights
F80 10 Amp RedUniversal Garage Door Opener / Compass
F81 20 Amp YellowTrailer Tow Right Turn/Stop Lights
F82 10 Amp Red Steering Column Control Module/ Cruise Control
F84 15 Amp BlueSwitch Bank/Instrument Cluster
7
MAINTAINING YOUR VEHICLE 727

Cavity Cartridge Fuse Micro FuseDescription
F85 10 Amp Red Airbag Module
F86 10 Amp Red Airbag Module
F87 10 Amp Red Air Suspension-If Equipped / Trailer Tow / Steering
Column Control Module
F88 15 Amp BlueInstrument Panel Cluster
F90/F91 20 Amp Yellow Power Outlet (Rear seats) Customer Selectable
F93 20 Amp Yellow Cigar Lighter
F94 10 Amp RedShifter / Transfer Case Module
F95 10 Amp RedRear Camera / Park Assist
F96 10 Amp RedRear Seat Heater Switch
F97 25 Amp Natural Rear Heated Seats & Heated Steering Wheel – If
Equipped
F98 25 Amp NaturalFront Heated Seats – If Equipped
F99 10 Amp Red Climate Control
728 MAINTAINING YOUR VEHICLE

ComponentFluid, Lubricant, or Genuine Part
Rear Axle – 1500 Models We recommend you use MOPAR® Synthetic Gear Lubricant SAE 75W-140 (MS- 8985). Limited-Slip Rear Axles require the addition of 5 oz. (148 ml) MOPAR®
Limited Slip Additive (MS-10111).
Front and Rear Axle –
2500/3500 Models We recommend you use Synthetic, GL-5 SAE, 75W-90. Limited slip additive is not
required for Limited-Slip Rear Axles.
Brake Master Cylinder We recommend you use MOPAR® DOT 3. If DOT 3 brake fluid is not available, then DOT 4 is acceptable.
Power Steering Reservoir –
2500/3500 Models We recommend you use MOPAR® Power Steering Fluid +4 or MOPAR® ATF+4®
Automatic Transmission Fluid.
7
MAINTAINING YOUR VEHICLE 747

Severe Duty All Models
•Change Engine Oil at 4000 miles (6,500 km) if the
vehicle is operated in a dusty and off road environ-
ment. This type of vehicle use is considered Severe
Duty
Once A Month Or Before A Long Trip:
• Check engine oil level
• Check windshield washer fluid level •
Check tire pressure and look for unusual wear or dam-
age. Rotate tires at the first sign of irregular wear, even if
it occurs before the oil indicator system turns on.
• Check the fluid levels of the coolant reservoir, brake
master cylinder, power steering (2500/3500 Models
Only) and automatic transmission (six-speed only) as
needed
• Check function of all interior and exterior lights
8
M
A I
N T
E
N
A
N
C E
S
C
H E
D
U L
E
