3. Turn the desired bulb socket ¼ turn and remove thesocket and bulb from housing. 4. Pull the desired bulb straight from the socket.
CHMSL Connector Location
CHMSL Bulb And Socket
7
MAINTAINING YOUR VEHICLE 859

CAUTION!
Do not contaminate the bulb glass by touching it
with your fingers or by allowing it to contact other
oily surfaces. Shortened bulb life will result.• Outside Bulbs: Cargo Lamps
• Inside Bulb: Center High-Mounted Stop Lamp
5. Reverse the procedure for installation of bulbs and housing.
Cab Top Clearance Lamps — If Equipped
1. Remove the two screws from the top of the lamp.
Removing Rear Screw From Clearance Lamp
860 MAINTAINING YOUR VEHICLE

2. Rotate the bulb socket ¼ turn and pull it from the lampassembly. 3. Pull the bulb straight from it’s socket and replace.
Removing Bulb Socket From Clearance Lamp
Removing The Bulb From The Bulb Socket
7
MAINTAINING YOUR VEHICLE 861

Rear Lamp Bar ID Marker (Dual Rear Wheels) — If
Equipped
1. Loosen the two screws and the housing to gain accessto the bulb sockets. 2. Turn the socket ¼ turn counterclockwise to access the
bulb.
3. Pull the bulb straight out from the socket.
4. Reverse the procedure for installation of the bulbs and housing.
Screw Locations
862 MAINTAINING YOUR VEHICLE

Side Marker Lamps (Dual Rear Wheels) — If
Equipped1. Push rearward on the side marker lamp assembly.
2. Pull the entire assembly from the fender.
3. Turn the socket ¼ turn counterclockwise and removefrom assembly to access the bulb.
4. Pull the bulb straight out from socket.
5. Reverse the procedure for installation of the bulbs and housing.
Side Marker Lamp Locations
7
MAINTAINING YOUR VEHICLE 863

FLUID CAPACITIES
U.S.Metric
Fuel (Approximate)
1500 Regular Cab Shortbed/Crew Quad Cab Models 26 Gallons98 Liters
1500 Regular Cab Longbed/Crew Quad Cab Models (Optional) 32 Gallons 121 Liters
2500/3500 Shortbed Models 31 Gallons117 Liters
2500/3500 Longbed Models 32 Gallons121 Liters
Engine Oil With Filter
3.6L Engine (We recommend you use SAE 5W-20, API Certified) 6 Quarts5.6 Liters
5.7L Engines (We recommend you use SAE 5W-20, API Certified) 7 Quarts 6.6 Liters
5.7L Engine (We recommend you use SAE 5W-30, API Certified),
for 2500/3500 trucks operating under a gross combined weight
rating greater than 14,000 lbs (6 350 kg). 7 Quarts
6.6 Liters
6.4L Engines (We recommend you use SAE 0W-40 engine oil
meeting the requirements of FCA Material Standard MS-12633 for
use in all operating temperatures.) 7 Quarts
6.6 Liters
864 MAINTAINING YOUR VEHICLE

U.S.Metric
Cooling System
3.6L Engine (We recommend you use MOPAR Antifreeze/Coolant
10 Year/150,000 Mile Formula that meets the requirements of FCA
Material Standard MS.90032.) 13.7 Quarts
13 Liters
5.7L Engine – 1500 Models (We recommend you use MOPAR
Antifreeze/Coolant 10 Year/150,000 Mile Formula that meets the
requirements of FCA Material Standard MS.90032.) 18.3 Quarts
17.3 Liters
5.7L Engine – 2500/3500 Models (We recommend you use
MOPAR Antifreeze/Coolant 10 Year/150,000 Mile Formula that
meets the requirements of FCA Material Standard MS.90032.) 18.3 Quarts
17.3 Liters
6.4 Liter Engine – 2500/3500 Models (We recommend you use
MOPAR Antifreeze/Coolant 10 Year/150,000 Mile Formula that
meets the requirements of FCA Material Standard MS.90032.) 16.6 Quarts
15.7 Liters
7
MAINTAINING YOUR VEHICLE 865

FLUIDS, LUBRICANTS, AND GENUINE PARTS
Engine
ComponentFluid, Lubricant, or Genuine Part
Engine Coolant We recommend you use MOPAR Antifreeze/Coolant 10
Year/150,000 Mile Formula OAT (Organic Additive
Technology).
Engine Oil – 3.6L Engine We recommend you use API Certified SAE 5W-20
Engine Oil, meeting the requirements of FCA Material
Standard MS-6395 such as MOPAR, Pennzoil, and Shell
Helix. Refer to your engine oil filler cap for correct SAE
grade.
MOPAR SAE 5W-30 engine oil approved to FCA Mate-
rial Standard MS-6395 may be used when SAE 5W-20
engine oil meeting MS-6395 is not available.
866 MAINTAINING YOUR VEHICLE

ComponentFluid, Lubricant, or Genuine Part
Engine Oil – 5.7L Engine
We recommend you use API Certified SAE 5W-20 Engine
Oil, meeting the requirements of FCA Material Standard
MS-6395 such as MOPAR, Pennzoil, and Shell Helix. Refer
to your engine oil filler cap for correct SAE grade.
Engine Oil – 5.7L Engine 2500/3500 trucks operating
under a gross combined weight rating greaterthan
14,000 lbs/(6,350 kg.) We recommend you use API Certified SAE 5W-30
Engine Oil, meeting the requirements of FCA Material
Standard MS-6395 such as MOPAR, Pennzoil, Shell
Helix or equivalent. Refer to your engine oil filler cap for
correct SAE grade.
Engine Oil – 6.4L For best performance and maximum protection under
all types of operating conditions, the manufacturer only
recommends full synthetic engine oils that meet the
American Petroleum Institute (API) categories of SN.
The manufacturer recommends the use of Pennzoil
Ultra 0W-40 or equivalent MOPAR engine oil meeting
the requirements of FCA Material Standard MS-12633
for use in all operating temperatures.
7
MAINTAINING YOUR VEHICLE 867

ComponentFluid, Lubricant, or Genuine Part
Engine Oil Filter We recommend you use MOPAR brand Engine Oil
Filters.
Spark Plugs We recommend you use MOPAR Spark Plugs.
Fuel Selection – 3.6L Engine 87 Octane, 0-15% Ethanol.
Fuel Selection – 3.6L Flex Fuel (E-85) Engine – If
Equipped 87 Octane, Up To 85% Ethanol.
Fuel Selection – 5.7L/6.4L Engines 89 Octane Recommended - 87 Octane Acceptable, 0-15%
Ethanol.
