1.Motor: The winch motor is powered by the vehicle
charging system and features a thermal protection
switch that automatically stops motor function in the
power-in direction if the motor gets too hot.
2. Remote Socket: The remote socket allows the remote
control to be attached to the control pack to allow the
winch to function.
3. Winch Drum With Integral Brake: The winch drum
allows the wire rope to be stored on the winch and
transmits force to the wire rope. The winch is equipped
with an integral brake that will stop rotation of the
winch drum if the winch motor is stopped.
4. 3-Stage Planetary Gear Set: Provides balance between
speed and pulling power.
5. Wire Rope: The wire rope allows the winch to be
connected to an anchor to provide a pulling force.
6. Clutch Lever: The clutch lever allows the winch drum to
be disconnected from the winch motor to allow the wire
rope to be pulled from the winch by hand. 7.
Remote Control: The remote control provides the inter-
face between the winch operator and the winch. The
remote control provides the ability to power the winch
in, out, and stop the winch. To operate the winch, the
toggle switch is pressed down to power the winch in
and up to power the winch out. The winch will stop if
the switch is left in the neutral (center) position.
CAUTION!
If not installed, the hook strap must be placed on the
hook.
Fairlead: The fairlead acts as a guide for the wire rope and
minimizes damage to the rope.
5
STARTING AND OPERATING 477

Operating Your Winch
WARNING!
Failure to observe any of these warnings regarding
proper winch usage may result in severe injury.
•Always use supplied hook strap to hold the hook
when spooling wire rope in or out.
• Never use as a hoist.
• Never use to move persons.
• Never exceed winch or wire rope rated capacity.
• Always wear heavy leather gloves when handling
the wire rope.
• Never touch wire rope or hook while in tension or
under load.
• Never engage or disengage clutch if winch is under
load, wire rope is in tension, or wire rope drum is
moving.
• Always stand clear of wire rope and load and keep
others away during winching.
• Always keep hands and clothing clear of the wire
rope, hook and fairlead opening during operation
and when spooling.
(Continued)
WARNING! (Continued)
•Never wrap wire rope back onto itself. Always use a
choker chain, wire choker rope or tree trunk protec-
tor on the anchor.
• Never attach a recovery strap to the winch hook to
increase the length of a pull.
• Never attempt to tow a vehicle with the recovery
strap attached directly to the winch hook.
• Never use bungeestraps that develop tremendous
and potentially dangerous amounts of force when
stretched.
• Always disconnect the remote control when not in
use.
• Never winch when there are less than five wraps of
wire rope around the winch drum.
• Always pass remote control through a window to
avoid pinching lead in door, when using remote
inside a vehicle.
• Never leave the remote control plugged into the
winch while free spooling, rigging or sitting idle.
5
STARTING AND OPERATING 479

General Information
Practice using your winch before you get stuck. Some key
points to remember when using your winch are:
•Always take your time to assess the situation and plan
your pull carefully.
• Always take your time when using a winch.
• Use the right equipment for the situation.
• Always wear leather gloves and do not allow the wire
rope to slip through your hands when handling the
rope.
• Only the operator should handle the wire rope and
remote control.
• Think safety at all times.
Vehicle Recovery Using The Winch
CAUTION!
•Always Know Your Winch: Take the time to fully
read and understand the included Installation and
Operations Guide, and Basic Guide to Winching
Techniques, in order to understand your winch and
the winching operation.
• Always inspect winch installation and wire rope
condition before operating the winch. Frayed,
kinked or damaged wire rope must be replaced
immediately. Loose or damaged winch installation
must be corrected immediately.
• Always be sure any element which can interfere with
safe winching operations is removed prior to initiat-
ing winching.
• Always keep remote control lead clear of the drum,
wire rope and rigging.
• Inspect for cracks, pinches, frayed wires, or loose
connections. Replace if damaged.
• Be careful not to pull the Winch Cable Collar
through the rollers. Watch and listen to Winch for
proper snugness.
480 STARTING AND OPERATING

7. Attach the Clevis/D-shackle and Tree Trunk Protector.Attach the shackle to the two ends of the strap or chain
and through the hook loop, being careful not to over
tighten (tighten and back-off 1/2 turn).
8. Lock the clutch. Lock the winch drum by rotating the clutch lever on the winch to engage.
NOTE: Always ensure the clutch is fully engaged or
disengaged. 9. Connect the remote control to the winch control box,
located behind the front bumper. Be careful not to let the
remote control cord dangle in front of the winch. If you
choose to control the winch from inside your vehicle,
always pass the remote through a window to avoid
pinching the cord in the door. Always disconnect the
remote control when not in use.
Clevis/D-Shackles
Winch Box Remote Control Connector
484 STARTING AND OPERATING

10. Put wire rope under tension. Using the remote controlswitch, slowly wind the wire rope until no slack
remains. Once the wire rope is under tension, stand
well clear of it and never step over it.
11. Check your anchor. Make sure all connections are secured and free of debris before continuing with the
winching procedure. 12. Check wire rope. The wire rope should be neatly
wound around the spooling drum. Improper winding
can cause damage to the wire rope.
In certain situations you may
decide to throw a heavy blanket
or similar object over the wire
rope. A heavy blanket can ab-
sorb energy should the wire
rope break. Place it on the wire
rope midway between the
winch and the anchor point. Do
this before the wire rope is put
Pulling Wire Rope Under Tension
Wire Neatly Wound Around The Spooling Drum
5
STARTING AND OPERATING 485

under tension. Do not approach or move the blanket once
tension is applied. Do not allow it to get pulled into the
fairlead. If it is necessary to move or remove the blanket,
slack the tension on the wire rope first.
13.Establish no people zones:Make your intentions
clear. Be sure that everyone in the immediate vicinity
surrounding the winching operation is completely
aware of your intentions before you pull. Declare
where the spectators should not stand - never behind
or in front of the vehicle and never near the wire rope
or snatch block. Your situation may have other no
people zones. 14. Begin winching. With the winching vehicles engine on
and light tension already on the wire rope, begin
winching slowly and steadily. Be sure that the wire
rope is winding evenly and tightly around the spooling
drum. For additional assistance, the winched vehicle
can be slowly driven while being pulled by the winch.
Continue pulling until the vehicle is on stable ground.
If you are able to drive the vehicle, the winching
operation is complete.
No People Zones
Using The Remote Control
486 STARTING AND OPERATING

WARNING!
To prevent serious injury, NEVER put your fingers
inside the hook area as you are powering-in.
NOTE: How to spool under no load: Arrange the remote
control lead so it cannot be caught in the winch. Arrange
the wire rope so it will not kink or tangle when spooled. Be
sure any wire rope already on the spooling drum is wound
tightly and evenly layered. Tighten and straighten the layer
if necessary. Keep the wire rope under light tension and
spool the wire rope back and onto the winch drum in even
layers. Stop frequently to tighten and straighten the layers
as necessary. Repeat this process until the winch hook is the
same distance as the full length of the remote control from
the winch. Pinch the hook between your thumb and
forefinger and attach the hook strap. Hold the hook strap
between the thumb and forefinger to keep tension on the
wire rope. Walk the wire rope towards the fairlead, care-
fully spooling in the remaining wire rope. By pulsing the
remote control switch. 18. Store the hook on the most outboard loop of the tow
hook.
19. Disconnect the remote control. Disconnect the remote control cord from the control box and store in a clean
and dry place. Winching operations are now complete.
Put the cap on the solenoid plug-in.
NOTE: Always store the remote control in a protected,
clean, dry area.
Hook In Stored Position
488 STARTING AND OPERATING

KeyFob................................32
Remote................................32
Remote Keyless Entry ......................32
Door Locks, Automatic .......................34
Door Opener, Garage ....................... .175
Driving Off-Pavement .......................... .457
Off-Road ............................. .457
Through Flowing, Rising, Or Shallow Standing
Water ................................ .472
Dual Rear Wheels ...................... .532, 581
E-85 Fuel ............................... .545
Electrical Power Outlets ..................... .184
Electric Rear Window Defrost ..................200
Electronically Shifted Transfer Case . . . .417, 422, 427, 432
Electronic Brake Control System ................495
Anti-Lock Brake System ....................495
Electronic Roll Mitigation ...................504
Traction Control System ....................500
Electronic Range Select (ERS) ............393, 401, 410
Electronic Speed Control (Cruise Control) .........154
Electronic Stability Control (ESC) ...............500
Electronic Throttle Control Warning Light .........246
Emergency Brake .......................... .492Emergency, In Case Of
Freeing Vehicle When Stuck .................621
Hazard Warning Flasher ...................580
Jump Starting .......................... .618
Tow Hooks ............................ .623
Emission Control System Maintenance ............637
Engine .............................. .634, 635
Air Cleaner ............................ .643
Block Heater ........................... .385
Break-In Recommendations ..................94
Compartment .......................... .633
Compartment Identification ...........633, 634, 635
Coolant (Antifreeze) ..................... .698
Exhaust Gas Caution ...................95, 545
Flooded, Starting ........................ .384
Fuel

Requirements ....................541, 697
Jump Starting .......................... .618
Oil ........................... .640, 697, 698
Oil Filler Cap .......................... .642
Oil Filter .............................. .642
Oil Selection ........................ .641, 697
Oil Synthetic ........................... .642
Overheating ........................... .580
Engine Oil Viscosity .....................641, 642
Engine Oil Viscosity Chart ....................641
10
INDEX 719

Instrument Cluster..................... .244, 263
Instrument Cluster Display Instrument Cluster Display ..................267
Instrument Panel And Controls .................235
Instrument Panel Lens Cleaning ................677
Integrated Trailer Brake Controls ................562
Interior Appearance Care .....................676
Interior Lights ............................ .143
Intermittent Wipers (Delay Wipers) ..............148
Introduction ................................4
Inverter Outlet (115V) ...................... .189
Jack Location ......................... .583, 600
Jump Starting ............................ .618
Key Fob Programming Additional Key Fobs .............18
Key Fob Battery Service (Remote Keyless Entry) .....25
Key Fob Programming (Remote Keyless Entry) ......21
Key Fob, Remote Keyless Entry .................21
Key-In Reminder ............................17
Keyless Enter-N-Go ..................... .36, 382
Lock The Vehicle’s Doors ................295, 315
Passive Entry ............................36
Passive Entry Programming ...........36, 295, 315 Keyless Entry System
........................21
Key, Replacement ...........................18
Keys ....................................11
Key, Sentry (Immobilizer) ......................17
Lane Change And Turn Signals .................146
Lane Change Assist ........................ .147
Latches ..................................98
Lead Free Gasoline ........................ .541
Leaks, Fluid ...............................98
Life Of Tires ............................. .526
Light Bulbs ........................... .98, 688
Lights ............................... .98, 138
AirBag ............................ .96, 241
Automatic Headlights .....................139
Brake Assist Warning ..................... .503
Brake Warning ......................... .242
Bulb Replacement ....................... .690
Cap

Top Clearance ...................... .694
Cargo................................ .146
Center Mounted Stop ..................... .693
Courtesy/Reading .................144, 145, 174
Cruise ......................... .263, 264, 265
Daytime Running ....................... .140
Engine Temperature Warning ................244
722 INDEX

Reformulated Gasoline...................... .542
Refrigerant ........................... .649, 650
Reminder, Seat Belt ..........................43
Remote Control Starting System ...........................29
Remote Keyless Entry ..................... .21, 22
Programming Additional Key Fobs .............18
Remote Sound System (Radio) Controls ...........327
Remote Starting Uconnect Customer Programmable
Features ........................... .297, 317
Uconnect Settings .....................297, 317
Remote Starting System .......................29
Replacement Bulbs ........................ .688
Replacement Keys ...........................18
Replacement Parts ......................... .639
Replacement Tires ......................... .527
Reporting Safety Defects .....................713
Restraint, Head ........................... .129
Restraints, Child ............................69
Rotation, Tires ............................ .530
Safety Checks Inside Vehicle ...................95
Safety Checks Outside Vehicle ..................98
Safety Defects, Reporting .....................713 Safety, Exhaust Gas
..........................95
Safety Information, Tire ..................... .508
Safety Tips ................................94
Schedule, Maintenance ...................... .704
Seat Belt Adjustable Upper Shoulder Belt Anchorage .......48
Automatic Locking Retractor (ALR) ............54
Lap/Shoulder Belt Operation .................47
Lap/Shoulder Belt Untwisting ................48
Pregnant Women .........................53
Seat Belt Extender .........................52
Seat Belt Pretensioner ......................53
Seat Belt Reminder ........................43
Seat Belt Maintenance ...................... .677
Seat Belt Reminder ..........................43
Seat Belts ............................. .43, 95
Adjustable Shoulder Belt ....................48
Adjustable Upper Shoulder Anchorage ..........48
Child Restraint ...........................69
Extender ...............................52
Front Seat ........................... .43,
47
Inspection ..............................95
Operating Instructions ......................47
Pregnant Women .........................53
Pretensioners ............................53
726 INDEX
