headlamp Ram 2500 2017 Owner's Manual

DRIVER MEMORY SEAT — IF EQUIPPED .....132
▫ Programming The Memory Feature ..........133
▫ Linking And Unlinking The Remote Keyless
Entry Key Fob To Memory ................133
▫ Memory Position Recall ..................134
▫ Easy Entry/Exit Seat ....................135
 TO OPEN AND CLOSE THE HOOD ..........136
 LIGHTS ............................. .138
▫ Headlights .......................... .139
▫ Automatic Headlights — If Equipped ........139
▫ Headlights On With Wipers (Available With
Automatic Headlights Only) ...............140
▫ Daytime Running Lights (DRL) —
If Equipped ......................... .140
▫ Headlight Delay ....................... .140
▫ Automatic High Beam Headlamp Control —
If Equipped ......................... .141
▫ Parking Lights And Panel Lights ............142▫
Fog Lights — If Equipped ................142
▫ Lights-On Reminder .....................143
▫ Battery Saver ......................... .143
▫ Interior Lights ........................ .143
▫ Cargo Light With Bed Lights — If Equipped . . .146
▫ Multifunction Lever ....................146
▫ Turn Signals ......................... .146
▫ Lane Change Assist .....................147
▫ Flash-To-Pass ........................ .147
▫ High/Low Beam Switch .................147
 WINDSHIELD WIPERS AND WASHERS .......148
▫ W

indshield Wipers .....................148
▫ Windshield Wiper Operation ...............148
▫ Intermittent Wiper System ................148
▫ Windshield Washers ....................148
▫ Mist Feature ......................... .149
▫ Rain Sensing Wipers — If Equipped .........149
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Automatic High Beam Headlamp Control —
If Equipped
The Automatic High Beam Headlamp Control system
provides increased forward lighting at night by automat-
ing high beam control through the use of a digital camera
mounted on the inside rearview mirror. This camera de-
tects vehicle specific light and automatically switches from
high beams to low beams until the approaching vehicle is
out of view.
NOTE:
•If your vehicle is equipped with a touchscreen, the
Automatic High Beam Headlamp Control can be turned
on or off using the Uconnect System. Refer to “Uconnect
Settings” in “Understanding Your Instrument Panel” for
further information.
• If your vehicle is not equipped with a touchscreen, the
Automatic High Beam Headlamp Control can be turned
on or off using the instrument cluster display. Refer to
“Instrument Cluster Display” in “Understanding Your
Instrument Panel” for further information.
• Broken, muddy, or obstructed headlights and taillights
of vehicles in the field of view will cause headlights to
remain on longer (closer to the vehicle). Also, dirt, film, and other obstructions on the windshield or camera lens
will cause the system to function improperly.
• To opt out of the Advanced Auto High-Beam Sensitivity
Control (default) and enter Reduced High-Beam Sensi-
tivity Control (not recommended), toggle the high beam
lever six full on/off cycles within 10 seconds of ignition
ON. System will return to default setting upon ignition
off.
If the windshield or Automatic High Beam Headlamp
Control mirror is replaced, the mirror must be re-aimed to
ensure proper performance. See your local authorized
dealer.
To Activate
1. If your vehicle is equipped with a touchscreen, the Automatic High Beams are enabled through the
Uconnect system. Refer to “Uconnect Settings” in “Un-
derstanding Your Instrument Panel” for further infor-
mation.
If your vehicle is not equipped with a touchscreen, the
Automatic High Beams are enabled through the instru-
ment cluster display. Refer to “Instrument Cluster Display”
in “Understanding Your Instrument Panel” for further
information.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141

▫Appearance Care And Protection
From Corrosion ....................... .672
 FUSES ............................... .679
▫ Power Distribution Center ................680
 VEHICLE STORAGE .....................688
 REPLACEMENT BULBS ...................688
 BULB REPLACEMENT ....................690
▫ Base Quad / Premium Bi-Halogen: Low Beam
Headlamp, High Beam Headlamp, Front Park
And Turn — If Equipped .................690
▫ Fog Lamps — If Equipped ................691
▫ Rear Tail/Stop, Turn Signal
And Backup Lamps .....................692 ▫
Center High-Mounted Stoplamp (CHMSL)
With Cargo Lamp ..................... .693
▫ Cab Top Clearance Lamps — If Equipped .....694
▫ Rear Lamp Bar ID Marker
(Dual Rear Wheels) — If Equipped ..........696
▫ Side Marker Lamps (Dual Rear Wheels) —
If Equipped ......................... .696
 FLUID CAPACITIES ..................... .697
 FLUIDS, LUBRICANTS, AND
GENUINE PARTS ...................... .698
▫ Engine ............................. .698
▫ Chassis ............................ .701
632 MAINTAINING YOUR VEHICLE

Exterior Bulbs
Bulb Number
Base Quad Headlamp –
Low Beam H11LL
Base Quad Headlamp –
High Beam 9005LL
Front Turn Signal Lamp
(Base Quad Headlamp) 3157NA
Premium Bi Halogen
Projector Headlamp - Low
Beam 9005Sl+
Premium Bi Halogen
Projector Headlamp -
High Beam 9005LL
Front Turn Signal Lamp
(Premium Headlamp) LED (Serviced at autho-
rized dealer)
Fog Lamp (Horizontal
shape) 9145
Fog Lamp (Vertical shape) 9006
Center High Mounted
Stop Lamp (CHMSL) 921K
Rear Cargo Lamp 921
Bulb Number
LED Center High
Mounted Stop Lamp
(CHMSL)/Cargo Lamp LED (Serviced at autho-
rized dealer)
Cab Roof Marker Lamps 194NA
Base Rear Tail/Turn and
Stop Lamp 3157K
Premium Rear Tail/Turn
and Stop Lamp LED (Serviced at autho-
rized dealer)
Premium Backup Lamp 7440/W21W
Rear Lamp Bar ID Marker
Lamp 194
Side Marker Lamps (Dual
Rear Wheels) 194
Backup Lamp 921
Rear License Plate Lamp 194
7
MAINTAINING YOUR VEHICLE 689

BULB REPLACEMENT
NOTE:Lens fogging can occur under certain atmospheric
conditions. This will usually clear as atmospheric condi-
tions change to allow the condensation to change back into
a vapor. Turning the lamps on will usually accelerate the
clearing process.
Base Quad / Premium Bi-Halogen: Low Beam
Headlamp, High Beam Headlamp, Front Park And
Turn — If Equipped
1. Open the hood.
2. Disconnect and isolate the negative battery cable.
3. Remove the six plastic push-in fasteners that secure the upper radiator seal to the grille support and both fender
ledges.
4. Remove the two plastic push-in rivets that secure the upper radiator seal to the radiator.
5. Remove the upper radiator seal from the vehicle. 6. Remove the two headlamp assembly attachment screws.
7. Reach into the front wheel house ahead of the front
wheel, remove the fastener, and lift the cover over the
access hole in the front of the wheel house splash shield.
Access to the rear of the lamp can be gained through this
access hole.
Headlamp Assembly Attachment Screw Locations
690 MAINTAINING YOUR VEHICLE

8. Reach through the access hole of the wheel house splashshield and lift the slide lock upward far enough to
disengage it from the lock post on the back of the front
lamp unit housing.
9. Remove the headlamp assembly. Grasp the outboard edge of the lamp and pull it straight forward to disen-
gage the ball stud from the plastic grommet.
10. Disconnect the wiring harness connectors from the bulb socket.
11. Replace bulb(s) as necessary.CAUTION!
• Do not contaminate the bulb glass by touching it
with your fingers or by allowing it to contact other
oily surfaces. Shortened bulb life will result.
• Always use the correct bulb size and type for replace-
ment. An incorrect bulb size or type may overheat
and cause damage to the lamp, the bulb socket, or the
lamp wiring.
NOTE: There are access covers over both headlamp bulb
access holes in the quad front lamp unit housing (if
equipped). These covers MUST be reinstalled after the bulb
has been replaced.
Fog Lamps — If Equipped
1. Reach under and behind the front bumper to access the back of the front fog lamp housing.
2. Disconnect the fog lamp wiring harness connector from the fog lamp bulb.
3. Rotate the bulb counterclockwise ¼ turn to unlock the bulb from the housing.
4. Pull the bulb straight out from the housing.Slide Lock
7
MAINTAINING YOUR VEHICLE 691
