tailgate Ram 2500 2018 Owner's Guide

WARNING!
After using the jack and tools, always reinstall them in
the original carrier and location. While driving you
may experience abrupt stopping, rapid acceleration or
sharp turns. A loose jack, tools, bracket or other objects
in the vehicle may move around with force, resulting
in serious injury.
Removing The Spare Tire
1. Remove the spare tire before attempting to jack up thetruck. Attach the lug wrench to the extension tubes with
the curved angle facing away from the vehicle. Insert the
extension tube through the access hole between the
lower tailgate and the top of the bumper and into the
winch mechanism tube.
Inserting The Extension Tubes Into The Access Hole
488 IN CASE OF EMERGENCY

2. Lift the spare tire with one hand to give clearance to tiltthe retainer at the end of the cable and position it
properly across the wheel opening. 3. Attach the lug wrench to the extension tubes with the
curved angle facing away from the vehicle. Insert the
extensions through the access hole between the lower
tailgate and the top of the bumper and into the winch
mechanism tube.
Reinstalling The RetainerPushing The Retainer Through The Center Of The Wheel
And Positioning It
498 IN CASE OF EMERGENCY

Conditions that would require replacement:
•Rib chunking (one or more ribs has separated from belt
body)
• Rib or belt wear
• Longitudinal belt cracking (cracks between two ribs)
• Belt slips
• “Groove jumping (belt does not maintain correct posi-
tion on pulley)
• Belt broken (note: identify and correct problem before
new belt is installed) •
Noise (objectionable squeal, squeak, or rumble is heard
or felt while drive belt is in operation)
Some conditions can be caused by a faulty component such
as a belt pulley. Belt pulleys should be carefully inspected
for damage and proper alignment.
Belt replacement on some models requires the use of
special tools, we recommend having your vehicle serviced
at an authorized dealer.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, door hinge pivot points and rollers, liftgate,
tailgate, decklid, sliding doors and hood hinges, should be
lubricated periodically with a lithium based grease, such as
Mopar Spray White Lube to assure quiet, easy operation
and to protect against rust and wear. Prior to the applica-
tion of any lubricant, the parts concerned should be wiped
clean to remove dust and grit; after lubricating excess oil
and grease should be removed. Particular attention should
also be given to hood latching components to ensure
proper function. When performing other underhood ser-
vices, the hood latch, release mechanism and safety catch
should be cleaned and lubricated.
Accessory Belt (Serpentine Belt)8
SERVICING AND MAINTENANCE 541

Steering Wheel Audio Controls.................653
Steering Wheel Mounted Sound System Controls . . . .653
Storage Compartment, Center Seat ..............123
Storage, Vehicle ........................105, 584
Storing Your Vehicle ........................584
Sun Roof .................................110
Suspension, Air ........................344, 350
Sway Control, Trailer ........................213
Synthetic Engine Oil ........................530
Tailgate .................................153
Telescoping Steering Column ...................61
Temperature Control, Automatic (ATC) ...........104
Tilt Down ...............................47, 49
Up .................................47, 49
Tilt Steering Column .........................61
Tip Start .................................289
Tire And Loading Information Placard ............564
Tire Markings ............................ .558
Tires......................... .281, 568, 575, 583
Aging (Life Of Tires) ..................... .572
Air Pressure ............................568
Chains ............................... .579
Changing ............................. .468Compact Spare
..........................575
Dual ............................. .582, 594
General Information ...................568, 575
High Speed ............................ .570
Inflation Pressures ........................569
Jacking ............................... .468
Life Of Tires ............................572
Load Capacity .......................564, 565
Pressure Monitor System (TPMS) .............216
Pressure Warning Light ....................194
Quality Grading ........................ .583
Radial ............................... .570
Replacement ............................573
Rotation ...............................580
Safety ............................ .558,568
Sizes .................................560
Snow

Tires ............................ .575
Spare Tire ..........................575, 577
Spinning ...............................571
Trailer Towing .......................... .425
Tread Wear Indicators .....................572
Wheel Nut Torque ........................594
Tire Safety Information .......................558
Tongue Weight/Trailer Weight .................423
694 INDEX
