winch Ram 2500 2018 Owner's Guide

you to change your pulling direction while still allowing
the wire rope to be at 90° to wind properly onto the
spooling drum.
Increasing Pulling Power
In some cases, you may find yourself needing more pulling
power. The use of snatch blocks increases mechanical
advantage and that increases your pulling power.
Double Line
Because pulling power decreases with the number of layers
of wire rope on the winch drum, you can use a snatch blockto double line out more wire rope. This decreases the
number of layers of wire rope on the drum, and increases
pulling power. Start by feeding out enough wire rope to
free the winch hook. Attach the hook to your vehicle’s
frame/tow hook and run the wire rope through a snatch
block. Disengage the clutch and, using the snatch block,
pull out enough wire to reach your anchor point. Do not
attach the hook to the mounting kit. Secure to the anchor
point with a tree trunk protector or choker chain. Attach
the clevis/shackle. Attach the shackle to the two ends of
the strap/chain, being careful not to over tighten (tighten
and back-off 1/2 turn).
POWER STEERING
Electric Power Steering — 1500 Models
The electric power steering system will give you good
vehicle response and increased ease of maneuverability in
tight spaces. The system will vary its assist to provide light
efforts while parking and good feel while driving. If the
electric steering system experiences a fault that prevents it
from providing assist, you will still have the ability to steer
the vehicle manually.
Wire Rope Routing
392 STARTING AND OPERATING

There are two ways to assemble the tools:
Assembled For Spare Tire Lowering/RaisingCAUTION!
•The lug wrench can only be attached to extension 2.
• When attaching the tool to the winch mechanism be
sure the large flared end opening on extension 4 is
positioned correctly over the winch mechanism ad-
justing nut.
• Damage to the lug wrench, extensions and winch
mechanism may occur from improper tool assembly.
Assembled For Spare Tire Lowering/Raising
1 — Lug Wrench 3 — Extension 3
2 — Extension 2 4 — Extension 4
7
IN CASE OF EMERGENCY 471

Assembled For Jack Operation
WARNING!
After using the jack and tools, always reinstall them in the
original carrier and location. While driving you may expe-
rience abrupt stopping, rapid acceleration or sharp turns. A
loose jack, tools, bracket or other objects in the vehicle may
move around with force, resulting in serious injury.
Removing The Spare Tire
1. Remove the spare tire before attempting to jack up thetruck. Attach the lug wrench to the extension tubes with
the curved angle facing away from the vehicle. Insert the
extension tube through the access hole between the
lower tailgate and the top of the bumper and into the
winch mechanism tube.
Assembled For Jack Operation
1 — Lug Wrench 4 — Extension 4
2 — Extension 2 5 — Extension With Jack Hook
3 — Extension 3
Inserting The Extension Tubes Into The Access Hole
472 IN CASE OF EMERGENCY

4. Lift the spare tire with one hand to give clearance to tiltthe retainer at the end of the cable.
5. Pull the retainer through the center of the wheel. NOTE:
The winch mechanism is designed for use with the
extension tubes only. Use of an air wrench or other power
tools is not recommended and can damage the winch.
Preparations For Jacking
1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas.
Gaining Access To The Retainer
Pulling The Retainer Through The Center Of The Wheel
474 IN CASE OF EMERGENCY

3. Attach the lug wrench to the extension tubes with thecurved angle facing away from the vehicle. Insert the
extension tubes through the access hole between the
lower tailgate and the top of the bumper and into the
winch mechanism tube. 4. Rotate the lug wrench handle clockwise until the wheel
is drawn into place against the underside of the vehicle.
Continue to rotate until you feel the winch mechanism
slip, or click three or four times. It cannot be overtight-
ened. Push against the tire several times to ensure it is
firmly in place.
NOTE: The winch mechanism is designed for use with the
extension tube only. Use of an air wrench or other power
tools is not recommended and can damage the winch.
Lug Wrench And Extension Tubes Assembled And In
Position
Rotating The Lug Wrench Handle
482 IN CASE OF EMERGENCY

There are two ways to assemble the tools:
Assembled For Spare Tire Lowering/Raising
CAUTION!
•The lug wrench can only be attached to extension 2.
• When attaching the tool to the winch mechanism be
sure the large flared end opening on extension 4 is
(Continued)
CAUTION! (Continued)
positioned correctly over the winch mechanism ad-
justing nut.
• Damage to the lug wrench, extensions and winch
mechanism may occur from improper tool assembly.
Assembled For Jack Operation
Assembled For Spare Tire Lowering/Raising
1 — Lug Wrench 3 — Extension 3
2 — Extension 2 4 — Extension 4
Assembled For Jack Operation
1 — Lug Wrench4 — Extension 4
2 — Extension 2 5 — Jack Driver
3 — Extension 3
7
IN CASE OF EMERGENCY 487

WARNING!
After using the jack and tools, always reinstall them in
the original carrier and location. While driving you
may experience abrupt stopping, rapid acceleration or
sharp turns. A loose jack, tools, bracket or other objects
in the vehicle may move around with force, resulting
in serious injury.
Removing The Spare Tire
1. Remove the spare tire before attempting to jack up thetruck. Attach the lug wrench to the extension tubes with
the curved angle facing away from the vehicle. Insert the
extension tube through the access hole between the
lower tailgate and the top of the bumper and into the
winch mechanism tube.
Inserting The Extension Tubes Into The Access Hole
488 IN CASE OF EMERGENCY

4. Lift the spare tire with one hand to give clearance to tiltthe retainer at the end of the cable.
5. Pull the retainer through the center of the wheel. NOTE:
The winch mechanism is designed for use with the
extension tubes only. Use of an air wrench or other power
tools is not recommended and can damage the winch.
Preparations For Jacking
1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas.
Gaining Access To The Retainer
Pulling The Retainer Through The Center Of The Wheel
490 IN CASE OF EMERGENCY

2. Lift the spare tire with one hand to give clearance to tiltthe retainer at the end of the cable and position it
properly across the wheel opening. 3. Attach the lug wrench to the extension tubes with the
curved angle facing away from the vehicle. Insert the
extensions through the access hole between the lower
tailgate and the top of the bumper and into the winch
mechanism tube.
Reinstalling The RetainerPushing The Retainer Through The Center Of The Wheel
And Positioning It
498 IN CASE OF EMERGENCY

4. Rotate the lug wrench handle clockwise until the wheelis drawn into place against the underside of the vehicle.
Continue to rotate until you feel the winch mechanism
slip, or click three or four times. It cannot be overtight-
ened. Push against the tire several times to ensure it is
firmly in place. NOTE:
The winch mechanism is designed for use with the
jack extension tube only. Use of an air wrench or other
power tools is not recommended and can damage the
winch.
Reinstalling The Jack And Tools (2500 And 3500
Series)
1. Tighten the jack all the way down by turning the jack turn-screw counterclockwise until the jack is snug.
2. Position the jack and tools into bracket assembly. Make sure the lug wrench is under the jack near the jack
Lug Wrench And Extension Tubes Assembled And In
PositionRotating The Lug Wrench Handle
7
IN CASE OF EMERGENCY 499
