Ram 2500 2018 Owner's Manual

When changing a front wheel, place the scissor jack under the
rear portion of the lower control arm as shown below.
Rear Jacking Location
Operate the jack using the extension with jack hook and the
lug wrench. The extension tubes may be used but is not
required.
When changing a rear wheel, assemble the extension with
jack hook to the jack and connect the extension tubes. Place
the jack under the axle between the wheel and the shock
bracket with the extension with jack hook extending to the
rear.Connect the extension tubes and lug wrench.CAUTION!
Before raising the wheel off the ground, make sure that
the jack will not damage surrounding truck parts and
adjust the jack position as required.
4. By rotating the lug wrench clockwise, raise the vehicle until the wheel just clears the surface.
4X4 Front Jacking Location
Rear Jacking Location
7
IN CASE OF EMERGENCY 479

WARNING!
Raising the vehicle higher than necessary can make the
vehicle less stable. It could slip off the jack and hurt
someone near it. Raise the vehicle only enough to
remove the tire.
5. Remove the lug nuts and pull the wheel off. Install the spare wheel and lug nuts with the cone shaped end of
the lug nuts toward the wheel. Hand tighten the lug
nuts with vehicle lifted. To avoid the risk of forcing the
vehicle off the jack, do not fully tighten the lug nuts until
the vehicle has been lowered.
6. Lower vehicle to ground, finish tightening the lug nuts. Push down on the wrench while at the end of the handle
for increased leverage. Tighten the lug nuts in a star
pattern until each nut has been tightened twice. For the
correct lug nut torque refer to “Torque Specifications” in
“Technical Specifications”. If in doubt about the correct
tightness, have them checked with a torque wrench by
an authorized dealer or service station.
WARNING!
A loose tire or jack thrown forward in a collision or
hard stop, could endanger the occupants of the vehicle.
Always stow the jack parts and the spare tire in the
places provided.
7. Install the wheel center cap and remove the wheel blocks. Do not install chrome or aluminum wheel center
caps on the spare wheel. This may result in cap damage.
8. Lower the jack to its fully closed position. Stow the replaced tire, jack, and tools as previously described.
9. Adjust the tire pressure when possible.
NOTE: Do not oil wheel studs. For chrome wheels, do not
substitute with chrome plated wheel nuts.
To Stow The Flat Or Spare
NOTE: Vehicles equipped with aluminum wheels cannot
be stored under the vehicle because the wheel retainer will
not fit through the wheel pilot hole. Secure the flat tire in
the bed of the truck. Have the flat tire repaired or replaced
immediately.
480 IN CASE OF EMERGENCY

WARNING!
A loose tire or jack thrown forward in a collision or
hard stop could endanger the occupants of the vehicle.
Always stow the jack parts and the spare tire in the
places provided. Have the deflated (flat) tire repaired
or replaced immediately.
1. Turn the wheel so that the valve stem is facing the ground and toward the rear of the vehicle for conve-
nience in checking the spare tire inflation. Slide the
wheel retainer through the center of the wheel. 2. Lift the spare tire with one hand to give clearance to tilt
the retainer at the end of the cable and position it
properly across the wheel opening.
Reinstalling The Retainer
Pushing The Retainer Through The Center Of The Wheel
And Positioning It
7
IN CASE OF EMERGENCY 481

3. Attach the lug wrench to the extension tubes with thecurved angle facing away from the vehicle. Insert the
extension tubes through the access hole between the
lower tailgate and the top of the bumper and into the
winch mechanism tube. 4. Rotate the lug wrench handle clockwise until the wheel
is drawn into place against the underside of the vehicle.
Continue to rotate until you feel the winch mechanism
slip, or click three or four times. It cannot be overtight-
ened. Push against the tire several times to ensure it is
firmly in place.
NOTE: The winch mechanism is designed for use with the
extension tube only. Use of an air wrench or other power
tools is not recommended and can damage the winch.
Lug Wrench And Extension Tubes Assembled And In
Position
Rotating The Lug Wrench Handle
482 IN CASE OF EMERGENCY

Reinstalling The Jack And Tools (1500 Series)
1. Tighten the jack all the way down by turning the jackturn-screw counterclockwise until the jack is snug.
2. Position the jack and tool bag. Make sure the lug wrench is under the jack near the jack turn-screw. 3. Secure the tool bag straps to the jack.
Jack And Tool Bag
Jack And Tools Tied
7
IN CASE OF EMERGENCY 483

4. Place the jack and tools in the storage position holdingthe jack by the jack turn-screw, slip the jack and tools
under the seat so that the bottom slot engages into the
fastener on the floor.
NOTE: Ensure that the jack slides into the front hold down
location.
5. Turn the wing bolt clockwise to secure to the floor pan. Reinstall the plastic cover.
WARNING!
After using the jack and tools, always reinstall them in
the original carrier and location. While driving you
may experience abrupt stopping, rapid acceleration or
sharp turns. A loose jack, tools, bracket or other objects
in the vehicle may move around with force, resulting
in serious injury.
Jack Hold Down Fastener
Jack And Tools (1500 Series)
484 IN CASE OF EMERGENCY

Jacking And Tire Changing 2500 And 3500 Series
Trucks
WARNING!
•Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off
the road to avoid the danger of being hit when
operating the jack or changing the wheel.
• Being under a jacked-up vehicle is dangerous. The
vehicle could slip off the jack and fall on you. You
could be crushed. Never put any part of your body
under a vehicle that is on a jack. If you need to get
under a raised vehicle, take it to a service center
where it can be raised on a lift.
• Never start or run the engine while the vehicle is on
a jack.
• The jack is designed to be used as a tool for changing
tires only. The jack should not be used to lift the
vehicle for service purposes. The vehicle should be
jacked on a firm level surface only. Avoid ice or
slippery areas.
Jack Location
The jack and jack tools are stored under the front passenger
seat.
Removal Of Jack And Tools (2500 And 3500 Series)
To access the jack and jack tools, you must remove the
plastic access cover located on the side of the front passen-
ger ’s seat. To remove the cover, pull the front part of the
cover (closest to the front of the seat) toward you to release
a locking tab. Once the front of the cover is loose, slide the
cover toward the front of the seat until it is free from the
seat frame.
Jack Access Cover
7
IN CASE OF EMERGENCY 485

Remove the jack and tools by turning the wing bolt
counterclockwise, remove the wing bolt and then slide the
assembly out from under the seat.Remove the jack and tools from the bracket assembly. Turn
the jack-turn-screw counterclockwise to release jack from
bracket assembly.
Wing Bolt/Jack And Tools (2500/3500 Series)Jack And Tools Bracket Assembly
486 IN CASE OF EMERGENCY

There are two ways to assemble the tools:
Assembled For Spare Tire Lowering/Raising
CAUTION!
•The lug wrench can only be attached to extension 2.
• When attaching the tool to the winch mechanism be
sure the large flared end opening on extension 4 is
(Continued)
CAUTION! (Continued)
positioned correctly over the winch mechanism ad-
justing nut.
• Damage to the lug wrench, extensions and winch
mechanism may occur from improper tool assembly.
Assembled For Jack Operation
Assembled For Spare Tire Lowering/Raising
1 — Lug Wrench 3 — Extension 3
2 — Extension 2 4 — Extension 4
Assembled For Jack Operation
1 — Lug Wrench4 — Extension 4
2 — Extension 2 5 — Jack Driver
3 — Extension 3
7
IN CASE OF EMERGENCY 487

WARNING!
After using the jack and tools, always reinstall them in
the original carrier and location. While driving you
may experience abrupt stopping, rapid acceleration or
sharp turns. A loose jack, tools, bracket or other objects
in the vehicle may move around with force, resulting
in serious injury.
Removing The Spare Tire
1. Remove the spare tire before attempting to jack up thetruck. Attach the lug wrench to the extension tubes with
the curved angle facing away from the vehicle. Insert the
extension tube through the access hole between the
lower tailgate and the top of the bumper and into the
winch mechanism tube.
Inserting The Extension Tubes Into The Access Hole
488 IN CASE OF EMERGENCY
