slide in camper Ram 3500 2015 Owner's Manual

SLIDE-IN CAMPERS ....................264
▫ Camper Applications ...................264
 EASY-OFF TAILGATE ...................265
▫ Disconnecting The Rear Camera Or Remote
Keyless Entry — If Equipped .............265
▫ Removing The Tailgate ..................266 ▫
Locking Tailgate ..................... .267
 TRI-FOLD TONNEAU COVER —
IF EQUIPPED ......................... .268
▫ Tri-Fold Tonneau Cover Removal ..........268
▫ Tri-Fold Tonneau Cover Installation .........272
▫ Tri-Fold Tonneau Cover Cleaning ..........278
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125

To remove the cleats from the utility rail, remove the end
cap screw located in the center of the end cap, using a
#T30 Torx® head driver. Remove the end cap and slide
the cleat off the end of the rail.SLIDE-IN CAMPERS
Camper Applications
Certain truck models are not recommended for slide-in
campers. To determine if your vehicle is excluded, please
refer to the “Consumer Information Truck-Camper Load-
ing” document available from your authorized dealer.
For safety reasons, follow all instructions in this impor-
tant document.
NOTE:When a cap or pickup camper is installed on a
vehicle, an alternate Center High-Mounted Stop Light
(CHMSL) must be provided.
Utility Rail End Cap
264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Raise the tailgate to a 45 degree angle.
4. Raise the right side of the tailgate until the right sidepivot clears the hanger bracket.
5. Slide the entire tailgate to the right to free the left side pivot. 6. Remove the tailgate from the vehicle.
NOTE:
Do not carry the tailgate loose in the truck
pickup box.
WARNING!
To avoid inhaling carbon monoxide, which is deadly,
the exhaust system on vehicles equipped with “Cap
or Slide-In Campers” should extend beyond the
overhanging camper compartment and be free of
leaks.
Locking Tailgate
The lock is located next to the tailgate handle. The
tailgate can be locked using the vehicle key or by locking
the truck with the key-fob if equipped with remote
keyless entry.
Locking Tang
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267
