▫Automatic Door Locks — If Equipped ........42
▫ Child-Protection Door Lock ................43
 SEATS ................................44
▫ Manual Front Seat Adjustment ..............44
▫ Manual Rear Seat Adjustment ...............46
▫ Power Driver Seat Adjustment — If Equipped . . .46
▫ Power Passenger Seat Adjustment —
If Equipped ...........................48
▫ Driver Memory Seat — If Equipped ..........49
▫ Heated Seats — If Equipped ...............52
▫ Ventilated Seats — If Equipped ..............54
▫ Manual Folding Rear Seats (Mega Cab Models) . .55
▫ Plastic Grocery Bag Retainers (Regular Cab
Models) ..............................58
 HEAD RESTRAINTS ......................58
▫ Front Head Restraint Adjustment ............58
▫ Rear Head Restraint Adjustment .............59
▫ Front Head Restraint Removal ..............60▫
Rear Head Restraint Removal ...............60
 STEERING WHEEL .......................61
▫ Tilt Steering Column .....................61
▫ Heated Steering Wheel — If Equipped .........61

DRIVER ADJUSTABLE PEDALS — IF EQUIPPED . .62
 MIRRORS ..............................64
▫ Inside Day/Night Mirror — If Equipped ......64
▫ Automatic Dimming Mirror — If Equipped .....64
▫ Automatic Dimming Mirror With Rear View
Camera Display — If Equipped .............65
▫ Outside Mirrors ........................66
▫ Driver’s Outside Automatic Dimming Mirror — If
Equipped .............................66
▫ Power Mirrors — If Equipped ..............67
▫ Power Folding Outside Mirrors For Standard And
Trailer Tow — If Equipped .................68
▫ Trailer Towing Mirrors — If Equipped ........70
▫ Heated Mirrors — If Equipped .............71
16 GETTING TO KNOW YOUR VEHICLE

Adjusting The Seat Up Or Down
The height of the seats can be adjusted up or down. Pull
upward or push downward on the rear of seat switch, the
seat will move in the direction of the switch. Release the
switch when the desired position has been reached.
Tilting The Seat Up Or Down
The angle of the seat cushion can be adjusted in four
directions. Pull upward or push downward on the front or
rear of the seat switch, the front or rear of the seat cushion
will move in the direction of the switch. Release the switch
when the desired position is reached.
Driver Memory Seat — If Equipped
This feature allows the driver to store up to two different
memory profiles for easy recall through a memory switch.
Each memory profile contains desired position settings for
the driver ’s seat, side mirrors, adjustable pedals (if
equipped) and a set of desired radio station presets. Your
remote keyless entry key fob can also be programmed to
recall the same positions when the unlock button is
pushed.
NOTE:Your vehicle is equipped with two key fobs, one
key fob can be linked to memory position 1 and the other
key fob can be linked to memory position 2. The memory seat buttons are located on the outboard side
of the driver ’s seat cushion.
Programming The Memory Feature
To create a new memory profile, perform the following:
1. Cycle the vehicle’s ignition to the ON/RUN position (do
not start the engine).
2. Adjust all memory profile settings to desired prefer- ences (i.e., driver ’s seat, outside mirrors and radio
station presets).
Memory Seat Buttons
3
GETTING TO KNOW YOUR VEHICLE 49

Memory Position Recall
NOTE:
•For vehicles equipped with an automatic transmission,
the vehicle speed must be lower than 5 mph to recall
memory positions. If a recall is attempted when the
vehicle speed is greater than 5 mph, a message will be
displayed in the instrument cluster display.
• For vehicles equipped with a manual transmission, the
vehicle speed must be at 0 mph (0 km/h) to recall
memory positions. If a recall is attempted with the
vehicle speed above 0 mph (0 km/h), a message will
appear in the instrument cluster display.
Driver One Memory Position Recall
• To recall the memory settings for driver one using the
memory switch, push memory button (1) on the
memory switch.
• To recall the memory settings for driver one using the
key fob, push the unlock button on the key fob linked to
memory position 1. Driver Two Memory Position Recall
•
To recall the memory setting for driver two using the
memory switch, push memory button (2) on the
memory switch.
• To recall the memory settings for driver two using the
key fob, push the unlock button on the key fob linked to
memory position 2.
A recall can be cancelled by pushing any of the memory
buttons during a recall (S, 1, or 2). When a recall is
cancelled, the driver’s seat and the power pedals (if
equipped) stop moving. A delay of one second will occur
before another recall can be selected.
Easy Entry/Exit Seat
This feature provides automatic driver ’s seat positioning to
enhance driver mobility when entering and exiting the
vehicle.
The distance the driver ’s seat moves depends on where
you have the driver ’s seat positioned when you remove the
key fob from the ignition (or change the ignition to OFF, for
vehicles equipped with Keyless Enter-N-Go).
• When you remove the key fob from the ignition (or
change the ignition to OFF, for vehicles equipped with
3
GETTING TO KNOW YOUR VEHICLE 51

Keyless Enter-N-Go), the driver ’s seat will move about
2.4 inches (60 mm) rearward if the driver ’s seat position
is greater than or equal to 2.7 inches (67.7 mm) forward
of the rear stop. The seat will return to its previously set
position when you place the ignition into the ACC or
RUN position.
• When you remove the key fob from the ignition (or
change the ignition to OFF, for vehicles equipped with
Keyless Enter-N-Go), the driver ’s seat will move to a
position 0.3 inches (7.7 mm) forward of the rear stop if
the driver ’s seat position is between 0.9 inches and 2.7
inches (22.7 mm and 67.7 mm) forward of the rear stop.
The seat will return to its previously set position when
you place the ignition to the ACC or RUN position.
• The Easy Entry/Easy Exit feature is disabled when the
driver ’s seat position is less than 0.9 inches (22.7 mm)
forward of the rear stop. At this position, there is no
benefit to the driver by moving the seat for Easy Exit or
Easy Entry.
Each stored memory setting will have an associated Easy
Entry and Easy Exit position. NOTE:The Easy Entry/Exit feature is not enabled when the
vehicle is delivered from the factory. The Easy Entry/Exit
feature is enabled (or later disabled) through the program-
mable features in the Uconnect system. Refer to “Uconnect
Settings” in “Multimedia” for further information.
Heated Seats — If Equipped
On some models, the front and rear seats may be equipped
with heaters located in the seat cushions and seat backs.
WARNING!
• Persons who are unable to feel pain to the skin
because of advanced age, chronic illness, diabetes,
spinal cord injury, medication, alcohol use, exhaus-
tion or other physical condition must exercise care
when using the seat heater. It may cause burns even
at low temperatures, especially if used for long
periods of time.
•
Do not place anything on the seat or seatback that
insulates against heat, such as a blanket or cushion.
This may cause the seat heater to overheat. Sitting in a
seat that has been overheated could cause serious burns
due to the increased surface temperature of the seat.
52 GETTING TO KNOW YOUR VEHICLE

•The pedals can be adjusted with the ignition OFF.
• The pedals cannotbe adjusted when the vehicle is in
REVERSE or when the Speed Control System is on. The
following messages will appear on vehicles equipped
with an instrument cluster display if the pedals are
attempted to be adjusted when the system is locked out:
“Adjustable Pedal Disabled — Cruise Control Engaged”
or “Adjustable Pedal Disabled — Vehicle In Reverse”. NOTE:
•
Always adjust the pedals to a position that allows full
pedal travel.
• Further small adjustments may be necessary to find the
best possible seat/pedal position.
• For vehicles equipped with Driver Memory Seat, you
can use your remote keyless entry key fob or the
memory switch on the driver ’s door trim panel to return
the adjustable pedals to pre-programmed positions. Re-
fer to “Driver Memory Seat” in “Getting To Know Your
Vehicle” for further information.WARNING!
Do not adjust the pedals while the vehicle is moving.
You could lose control and have an accident. Always
adjust the pedals while the vehicle is parked.
Adjustable Pedals Switch
3
GETTING TO KNOW YOUR VEHICLE 63

Setting NamesSetting Names
Abbreviated (Left Submenu Layer) Sub-Menus (Right Submenu Layer)
12 Auto Lock Doors Auto Lock Doors On; Off
13 Auto Unlock Doors Auto Unlock Doors On; Off
14 Sound Horn with Remote Start Horn w/ Rmt Start
On; Off
15 Sound Horn with Remote Lock Horn w/ Rmt Lock
Off; 1st Press; 2nd Press
16 Remote Unlock Sequence Remote Unlock
Driver Door; All Doors
17 Key Fob Linked to Memory Key in Memory
On; Off
18 Passive Entry Passive Entry On; Off
19 Remote Start Comfort System Rmt Start Comfort
Off; Remote Start; All starts
20 Easy Exit Seat Easy Exit Seat On; Off
21 Key-off Power Delay Power Off Delay Off; 45 seconds; 5 minutes; 10 minutes
184 GETTING TO KNOW YOUR INSTRUMENT PANEL

Setting NameSelectable Options
Sound Horn With Lock Off1st Press 2nd Press
Remote Door Unlock All Driver
NOTE:
The “Remote Door Unlock” feature will allow you to program your remote door locks to open “All doors” or only
the “Driver door” with the first push of the key fob or grabbing the Passive Entry door handle. Sound Horn With Remote Start On
Off
NOTE:
When the “Sound Horn With Remote Start” feature is selected, the horn will sound when the remote start is acti-
vated. Memory Linked To Fob — If Equipped On
Off
NOTE:
•The “Memory Linked To Fob” feature provides automatic driver seat positioning to enhance driver mobility when
entering and exiting the vehicle.
•The seat will return to the memorized seat location if “Memory Linked To Fob” is set to (On) when the key fob is
used to unlock the door. Passive Entry — If Equipped On Off
622 MULTIMEDIA

Daytime Running.........................74
Engine Temperature Warning ................191
Exterior ...............................281
Fog ............................78, 197, 455
Four-Wheel Drive Indicator .................327
Hazard Warning Flasher ...................447
Headlights ..............................73
High Beam ..............................74
High Beam/Low Beam Select .................74
Hill Descent Control Indicator ...............214
Illuminated Entry .........................83
Interior ............................. .80, 82
Low Fuel ............................. .196
Malfunction Indicator (Check Engine) ..........192
Park ................................. .198
Passing ................................76
Seat Belt Reminder .......................189
Security Alarm ..........................191
Service ............................... .452
Side Marker ............................460
Tire Pressure Monitoring (TPMS) ..........194, 216
Traction Control ........................ .212
Transfer Case .......................... .327
Turn Signal ................78, 198, 281, 454, 456
Warning (Instrument Cluster Description) . . . .191, 198 Limited-Slip Differential
..................375, 557
Loading Vehicle ............................414
Tires................................. .564
Load Shed Battery Saver Mode .......................187
Battery Saver On ........................ .187
Electrical Load Reduction ...................187
Intelligent Battery Sensor ...................187
Locks Automatic Door ..........................42
Child Protection ..........................43
Power Door .............................38
Low Tire Pressure System .....................216
Lubrication, Body ..........................541
Lug Nuts ............................... .594
Maintenance Fr

ee Battery.....................526
Maintenance Schedule .......................517
Malfunction Indicator Light (Check Engine) . . . .192, 201
Manual, Service ............................680
Manual Transmission Fluid Level Check ........................557
Lubricant Selection .......................607
Memory Feature (Memory Seat) .................44
Memory Seat ............................44, 49
12
INDEX 689

Memory Seats And Radio.....................44
Methanol ............................... .598
Mirrors ..................................64
Electric Powered ..........................67
Heated .................................71
Memory ................................49
Outside ................................66
Rearview ........................ .64, 65, 447
Trailer Towing ...........................70
Modifications/Alterations, Vehicle ................7
Monitor, Tire Pressure System ..................216
Mopar Parts ............................. .679
Multi-Function Control Lever ...................74
Navigation System (Uconnect GPS) ..............410
New Vehicle Break-In Period ..................295
Occupant Restraints ........................ .223
Octane Rating, Gasoline (Fuel) .................596
Off-Pavement Driving (Off-Road) ............362, 443
Off-Road Driving (Off-Pavement) ............362, 443
Oil, Engine ............................528, 604
Capacity ...............................603
Change Interval ........................ .528
Dipstick ...............................526 Disposal
...............................530
Filter ............................. .530, 604
Filter Disposal .......................... .530
Identification Logo .......................529
Materials Added To .......................530
Pressure Warning Light ....................191
Recommendation .....................528, 603
Synthetic ............................. .530
Viscosity ........................529, 530, 603
Oil Filter, Change ..........................530
Oil Filter, Selection ..........................530
Oil Pressure Light ..........................191
Onboard Diagnostic System ...................200
Operating Precautions ...................... .200
Operator Manual

(Owner’s Manual) ...............5
Outside Rearview Mirrors .....................66
Overdrive ............................313, 322
Overdrive OFF Switch ....................313, 322
Overheating, Engine ........................505
Owner’s Manual (Operator Manual) ...........5,680
Paint Care ............................... .584
Panic Alarm ...............................23
Parking Brake ............................ .295
ParkSense System, Rear ...................398, 404
690 INDEX

Memory............................ .44, 49
Power .................................46
Rear Folding ........................44, 55, 56
Reclining Rear ...........................46
Seatback Release ..........................44
Tilting .................................44
Vented .................................44
Ventilated ...............................44
Security Alarm ..........................35, 191
Selection Of Coolant (Antifreeze) ...............604
Sentry Key Key Programming .........................34
Sentry Key (Immobilizer) ......................33
Sentry Key Replacement ......................34
Service Assistance ..........................676
Service Contract .......................... .678
Service Manuals .......................... .680
Settings, Personal ..........................182
Shifting .................................297
Automatic Transmission .............299, 306, 315
Transfer Case .......................... .326
Transfer Case, Shifting Into Transfer Case
Neutral (N) ............................ .438
Transfer Case, Shifting Out Of Transfer Case
Neutral (N) ............................ .440Shift Lever Override
........................506
Signals, Turn ........................78, 198, 281
Snow Chains (Tire Chains) ....................579
Snow Plow ...............................433
Snow Tires ...............................575
Spare Tire ............................ .575, 577
Spark Plugs ............................. .604
Speed Control Accel/Decel ............................397
Cancel ............................... .397
Resume ...............................397
Speed Control (Cruise Control) .................395
Stabilizer/Sway Bar System ...................361
Starting ............................. .288, 289
Automatic Transmission ....................288
Cold Weather .......................... .294
Engine Fails

To Start..................... .293
Starting And Operating ..................... .289
Starting Procedures ........................ .289
Starting Procedures (Gas Engines) ...............288
Steering Power ..........................392, 393, 394
Tilt Column .............................61
Wheel, Heated ...........................61
Wheel, Tilt ..............................61
12
INDEX 693
