Ram 3500 Chassis Cab 2016 Owner's Manual

Pull on the upper handle on the front of the armrest to
raise the cover. The upper storage area contains a USB
power outlet that can be used to power small electrical
devices, refer to “Electrical Power Outlets” for further
information.With the upper lid closed, pull on the lower handle to
open the lower storage bin.
Upper Storage Compartment
Lower Storage Bin
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219

WARNING!
Do not operate this vehicle with a console compart-
ment lid in the open position. Driving with the
console compartment lid open may result in injury in
a collision.
The center console is equipped with a front storage bin
located next to the cupholders. This storage bin may be
equipped with a manual sliding top door.
Front Storage Bin With Door — If Equipped
220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Seatback Storage
Located in the back of both the driver and passenger
front seats are pockets that can be used for storage.
Storage (Regular Cab)
The storage bin is located behind the front seats and runs
the length of the cab.
Drivers Side Seatback StorageStorage Bin
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221

Storage and Seats (Crew Cab)
The Crew Cab models provide additional storage under
the rear seats. Lift the seats to access the storage com-
partment.
To open the storage compartments, lift upward on the
fold flat lid.
Plastic Grocery Bag Retainers (Regular Cab
Models)
Retainer hooks which will hold plastic grocery bag
handles are built into the back panel of the cab, behind
the rear seat.
Crew Cab Storage
Grocery Bag Hooks
222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

REAR WINDOW FEATURES
Rear Window Defroster
The rear window defroster button is located on
the climate control panel. Push this button to turn
on the rear window defroster and the heated outside
mirrors (if equipped). An indicator in the button will
illuminate when the rear window defroster is on. The
rear window defroster automatically turns off after ap-
proximately 10 minutes. For an additional five minutes of
operation, push the button a second time.
NOTE: To prevent excessive battery drain, use the rear
window defroster only when the engine is operating.
CAUTION!
Failure to follow these cautions can cause damage to
the heating elements:
• Use care when washing the inside of the rear
window. Do not use abrasive window cleaners on
the interior surface of the window. Use a soft cloth
and a mild washing solution, wiping parallel to the
heating elements. Labels can be peeled off after
soaking with warm water.
• Do not use scrapers, sharp instruments, or abrasive
window cleaners on the interior surface of the
window.
• Keep all objects a safe distance from the window.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 223

Power Sliding Rear Window — If Equipped
The switch for the power sliding rear window is located
on the overhead console.
Push the switch to the right to open the glass. Pull the
switch to the left to close the glass.
Manual Sliding Rear Window — If Equipped
A locking device in the center of the window helps to
prevent entry from the rear of the vehicle. Squeeze the
lock to release the window.
Rear Window Switch
224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ..........228
 INSTRUMENT CLUSTER — BASE ..........229
 INSTRUMENT CLUSTER — PREMIUM ......232
 WARNING AND INDICATOR LIGHTS .......235
▫ Red Telltale Indicator Lights ..............236
▫ Yellow Telltale Indicator Lights ............248
▫ Green Telltale Indicator Lights ............262
▫ Blue Telltale Indicator Light ..............264
▫ White Telltale Indicator Light .............265
ELECTRONIC VEHICLE INFORMATION CENTER
(EVIC) ............................. .266
▫ Electronic Vehicle Information Center (EVIC)
Displays — 3.5” Display ................268
▫ Oil Life Reset ....................... .270
▫ EVIC Messages ...................... .271
▫ EVIC Selectable Menu Items .............274
 DRIVER INFORMATION DISPLAY (DID) .....285
▫ Driver Information Display (DID) Displays . . .288
▫ Oil Life Reset ....................... .2904

▫DID Messages ....................... .291
▫ DID Selectable Menu Items ..............294
 UCONNECT SETTINGS ..................307
▫ Buttons On The Faceplate ................308
▫ Buttons On The Touchscreen ..............309
▫ Customer Programmable Features — Uconnect
5.0 Personal Settings ...................309
▫ Customer Programmable Features — Uconnect
8.4A/8.4AN Personal Settings ............323
 UCONNECT RADIOS — IF EQUIPPED ......339
 iPod/USB/MP3 CONTROL — IF EQUIPPED . . .340
 STEERING WHEEL AUDIO CONTROLS — IF
EQUIPPED .......................... .341
▫ Radio Operation ..................... .341▫
CD Player — If Equipped ................342
 CD/DVD DISC MAINTENANCE ...........342
 RADIO OPERATION AND MOBILE DEVICES . .343
▫ Regulatory And Safety Information .........343
 CLIMATE CONTROLS ...................344
▫ Manual Climate Controls Without Touchscreen —
If Equipped ........................ .345
▫ Manual Climate Controls With Touchscreen — If
Equipped .......................... .350
▫ Automatic Climate Controls With Touchscreen —
If Equipped ........................ .355
▫ Climate Control Functions ...............361
▫ Automatic Temperature Control (ATC) ......363
▫ Operating Tips ...................... .364
226 UNDERSTANDING YOUR INSTRUMENT PANEL

PERSONALIZED MENU BAR .............368
 UCONNECT VOICE RECOGNITION ........369
▫ Introducing Uconnect ...................369
▫ Get Started ......................... .371
▫ Basic Voice Commands ..................372
▫ Radio ............................. .374
▫ Media ............................. .375
▫ Phone ............................. .377
▫ Voice Text Reply ..................... .378
▫ Climate (8.4A/8.4AN) ..................380
▫ Navigation (8.4A/8.4AN) ................381 ▫
Uconnect Access (8.4A/8.4AN) ............382
▫ Register (8.4A/8.4AN) ..................383
▫ Mobile App (8.4A/8.4AN) ...............384
▫ Voice Texting (8.4A/8.4AN) ..............385
▫ Yelp (8.4A/8.4AN) .....................387
▫ SiriusXM Travel Link (8.4A/8.4AN) .........388
▫ Siri Eyes Free — If Equipped .............389
▫ Do Not Disturb ..................... .389
▫ General Information ...................390
▫ Additional Information .................390
4
UNDERSTANDING YOUR INSTRUMENT PANEL 227

INSTRUMENT PANEL FEATURES
1 — Headlight Switch7 — 115v Power Inverter Outlet 13 — Gear Selector/Transfer Case Position Switch — If Equipped
2 — Instrument Cluster 8 — Power Outlet — If Equipped 14 — Ignition Switch
3 — Radio 9 — Lower Switch Bank 15 — Hood Release
4 — Hazard Switch 10 — Instrument Panel Drawer 16 — Parking Brake Release
5 — Upper Glove Compartment 11 — Climate Controls
6 — Lower Glove Compartment 12 — Power Outlet/Cigar Lighter — If Equipped
228 UNDERSTANDING YOUR INSTRUMENT PANEL
