headlights Ram 3500 Chassis Cab 2016 Owner's Guide

Auto Comfort Systems — If Equipped
After pressing the “Auto-On Comfort” button on the
touchscreen the following settings will be available:
•Auto-On Driver Heated/Ventilated Seat & Steering
Wheel With Vehicle Start — If Equipped
When this feature is selected the driver’s heated seat and
heated steering wheel will automatically turn ON when
temperatures are below 40° F (4.4° C). When tempera-
tures are above 80° F (26.7° C) the driver vented seat will
turn ON. To make your selection, press the “Auto Heated
Seats” button on the touchscreen, then select either “Off,”
“Remote Start” or “All Starts”.
Engine Off Options
After pressing the “Engine Off Options” button on the
touchscreen the following settings will be available. •
Engine Off Power Delay
When this feature is selected, the power window
switches, radio, Uconnect phone system (if equipped),
DVD video system (if equipped), power sunroof (if
equipped), and power outlets will remain active for up to
10 minutes after the ignition is cycled to OFF. Opening
either front door will cancel this feature. To change the
Engine Off Power Delay status press the “+” or “–”
buttons on the touchscreen to adjust the time delay up or
down.
• Headlight Off Delay
When this feature is selected, the driver can choose to
have the headlights remain on for 0, 30, 60, or 90 seconds
when exiting the vehicle. To make your selection press
the “+” or “–” buttons on the touchscreen to adjust the
seconds up or down.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 335

Cleaning Headlights
Your vehicle is equipped with plastic headlights and fog
lights that are lighter and less susceptible to stone break-
age than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MOPAR Glass Cleaner, or any commercial
household-type glass cleaner. Never use an abrasive typecleaner. Use caution when cleaning the inside rear win-
dow equipped with electric defrosters or windows
equipped with radio antennas. Do not use scrapers or
other sharp instrument that may scratch the elements.
When cleaning the rear view mirror, spray cleaner on the
towel or cloth that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1. Clean with a wet soft cloth. A mild soap solution may
be used, but do not use high alcohol content or
abrasive cleaners. If soap is used, wipe clean with a
clean damp cloth.
2. Dry with a soft cloth.
602 MAINTAINING YOUR VEHICLE

Disposal............................. .587
Anti-Lock Brake System (ABS) ................439
Appearance Care ........................ .597
Ashtray ................................211
Assist, Hill Start ......................... .442
Auto Down Power Windows ..................46
Automatic Door Locks ......................38
Automatic Headlights ..................... .159
Automatic High Beams .....................161
Automatic Temperature Control (ATC) ..........363
Automatic Transmission ....................593
Adding Fluid ......................... .595
Fluid And Filter Changes ..................597
Fluid Level Check ...................... .594
Fluid Type ........................ .593, 624
Shifting ............................. .404
Special Additives ...................... .594
Axle Fluid ....................... .591, 592, 624Axle Lubrication
..................... .591, 592
Back-Up Camera ......................... .201
Battery ............................ .242, 572
Charging System Light ...................242
Keyless Transmitter Replacement (RKE) ........29
Belts, Seat ...............................115
Body Builders Guide ........................6
Body Mechanism Lubrication .................576
B-Pillar Location ......................... .462
Brake Assist System ...................... .442
Brake Control System, Electronic ..............438
Brake Fluid ......................... .590, 624
Brake System ........................ .438, 589
Fluid Check .......................... .590
Master Cylinder ....................... .590
Parking ............................. .435
Warning Light ........................ .238
Brake/Transmission Interlock .................404
10
INDEX 647

GVWR................................ .500
Hazard Driving Through Flowing, Rising, Or Shallow
Standing Water ........................ .432
Hazard Warning Flasher ....................532
Headlights ............................. .615
Automatic ........................... .159
Cleaning ............................ .602
High Beam ........................... .169
High Beam/Low Beam Select Switch .........169
Passing ............................. .169
Switch .............................. .159
Head Restraints ......................... .147
Heated Mirrors ...................... .136, 223
Heater ............................. .345, 350
High Beam/Low Beam Select (Dimmer) Switch . . . .169
Hill Descent Control ...................... .452
Hill Descent Control Indicator ................452Hill Start Assist
.......................... .442
Hitches Trailer Towing ........................ .507
Hoisting ............................... .544
Hood Release ........................... .156
Hub Caps .............................. .541
Ignition .................................16
Key .............................. .12, 16
Ignition Key Removal .......................16
Illuminated Entry ..........................23
Immobilizer (Sentry Key) ....................18
Inflation Pressure Tires .....................480
Information Center, Vehicle ...............266, 285
Inside Rearview Mirror ..................124, 132
Instrument Cluster ...........229, 232, 241, 246, 263
Instrument Panel And Controls ...............228
Instrument Panel Lens Cleaning ...............602
Integrated Trailer Brake Controls ..............513
10
INDEX 653

Interior Appearance Care....................600
Interior Lights .......................... .165
Intermittent Wipers (Delay Wipers) .............171
Introduction ..............................4
Inverter Outlet (115V) ..................... .212
Jack Location ........................... .536
Jump Starting ........................... .544
Key Fob Programming Additional Key Fobs ...........20
Programming Additional Transmitters .........20
Key-In Reminder ..........................18
Keyless Enter-N-Go ........................41
Lock The Vehicle’s Doors ..............315, 332
Passive Entry ...........................41
Passive Entry Programming ..........41, 315, 332
Keyless Entry System .......................24
Key, Replacement ..........................20 Keys
...................................12
Key, Sentry (Immobilizer) ....................18
Lane Change And Turn Signals ...............168
Lane Change Assist ....................... .169
Lap/Shoulder Belts .........................53
Latches ................................117
Lead Free Gasoline ....................... .494
Leaks, Fluid .............................118
Life Of Tires ............................ .477
Light Bulbs ..............................117
Lights ..............................117,157
AirBag ........................78, 115, 237
Automatic Headlights ....................159
Brake Assist Warning ....................449
Brake Warning ........................ .238
Bulb Replacement ....................614, 615
Cap Top Clearance ..................... .619
Cargo .............................. .168
654 INDEX

Center Mounted Stop....................618
Courtesy/Reading ................166, 167, 204
Cruise ........................... .264, 265
Daytime Running ...................... .160
Engine Temperature Warning ...............241
Exterior ..............................117
Fog ......................... .163, 257, 617
Four-Wheel Drive Indicator ................423
Hazard Warning Flasher ..................532
Headlights ........................... .159
High Beam ........................... .169
High Beam/Low Beam Select ...............169
Hill Descent Control Indicator ..............452
Illuminated Entry ........................23
Interior ....................165, 166, 167, 204
Low Fuel ............................ .254
Malfunction Indicator (Check Engine) .........248
Park ............................... .262
Passing ............................. .169Seat Belt Reminder
..................... .236
Security Alarm ........................ .240
Service .......................... .614, 615
Tire Pressure Monitoring (TPMS) .........252, 484
Traction Control ....................... .449
Transfer Case ......................... .423
Turn Signal ..................117, 168, 263, 615
Warning (Instrument Cluster Description) . . .241, 263
Limited-Slip Differential .................430, 592
Loading Vehicle ......................... .500
Tires ............................... .462
Locks ..................................36
Automatic Door .........................38
Child Protection .........................39
Door .................................36
Power Door ............................38
Low Tire Pressure System ...................484
Lubrication, Body ........................ .576
10
INDEX 655
