Ram 4500 Chassis Cab 2017 Owner's Manual

Unfolding The Load Floor/Crew Cab
1. Lift the 60/40 seat cushion(s) to the upward position.2. Unfold both the legs using the straps.
Load Floor Legs In Stowed Position
Load Floor Legs In Opened Position
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189

3. Lift the front panel until the load floor unfolds intoposition.
4. Reverse the procedure to store the load floor.
Positioning The Load Floor For Storage Access Under
The Seat
1. Lift the 60/40 seat cushion(s) to the upward position.
2. Unsnap the securing snap located at either side of the load floor. 3. Lift the load floor up to access storage under the load
floor.
WARNING!
Do not drive with the load floor in the up position.
When stopping fast or in an accident, the load floor
could move to the down position causing serious
injury.
Quad Cab — If Equipped
Load Floor In Open Position
Load Floor Securing Straps/Quad Cab
190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Crew Cab — If Equipped
4. Reverse the procedure to put the load floor back in thesecured down position before you operate the vehicle.
Load Floor Securing Straps/Crew Cab
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ...........195
 INSTRUMENT CLUSTER ..................196
 WARNING AND INDICATOR LIGHTS ........200
▫ Red Telltale Indicator Lights ...............201
▫ Yellow Telltale Indicator Lights .............208
▫ Green Telltale Indicator Lights ..............219
▫ Blue Telltale Indicator Lights ...............221
▫ White Telltale Indicator Lights ..............221
 INSTRUMENT CLUSTER DISPLAY ...........222
▫ Instrument Cluster Display Controls .........222
▫ Instrument Cluster Display Screens ..........224
▫ Oil Life Reset ......................... .226
▫ Instrument Cluster Display Selectable Menu
Items .............................. .227▫
Instrument Cluster Display Messages .........234
▫ Battery Saver On/Battery Saver Mode Message —
Electrical Load Reduction Actions —
If Equipped ......................... .236
 CYBERSECURITY ....................... .238
 UCONNECT SETTINGS ...................239
▫ Buttons On The Faceplate .................240
▫ Buttons On The Touchscreen ...............241
▫ Customer Programmable Features —
Uconnect 5.0 Personal Settings ..............241
▫ Customer Programmable Features — Uconnect
8.4/8.4 NAV Personal Settings .............256
 UCONNECT RADIOS — IF EQUIPPED ........273
 IPOD/USB/MP3 CONTROL — IF EQUIPPED . . . .273
 STEERING WHEEL AUDIO CONTROLS — IF
EQUIPPED ........................... .2744

▫Radio Operation ....................... .274
▫ CD Player — If Equipped .................274
 CD/DVD DISC MAINTENANCE ............275
 RADIO OPERATION AND MOBILE DEVICES . . .275
▫ Regulatory And Safety Information ..........275
 CLIMATE CONTROLS ....................277
▫ Manual Climate Controls Without A Touchscreen —
If Equipped ......................... .277
▫ Climate Controls With a Touchscreen .........282
▫ Automatic Temperature Control (ATC) — If
Equipped ........................... .291
▫ Operating Tips ....................... .291
 PERSONALIZED MENU BAR ...............294
 UCONNECT VOICE RECOGNITION .........294
▫ Introducing Uconnect ....................294
▫ Get Started .......................... .295
▫ Basic Voice Commands ...................297
▫ Radio .............................. .298▫
Media .............................. .300
▫ Phone .............................. .302
▫ Voice Text Reply ...................... .303
▫ Climate (8.4/8.4 NAV) ...................305
▫ Navigation (8.4 /8.4 NAV) ................306
▫ Uconnect Access (8.4/8.4 NAV) .............306
▫ Vehicle Health Alert ....................307
▫ Register (8.4/8.4 NAV) ...................308
▫ Mobile App (8.4/8.4 NAV) ................308
▫ Voice Texting (8.4/8.4 NAV) ...............309
▫ Y

elp (8.4/8.4 NAV) ..................... .310
▫ SiriusXM Travel Link (8.4/8.4 NAV) ..........311
▫ Siri Eyes Free — If Equipped ..............312
▫ Do Not Disturb ....................... .314
▫ General Information .....................315
▫ Additional Information ...................316
194 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT PANEL FEATURES
1 — Headlight Switch7 — 115v Power Inverter Outlet13 — Gear Selector/Transfer Case Position
Switch — If Equipped
2 — Instrument Cluster 8 — Power Outlet — If Equipped14 — Ignition Switch
3 — Radio 9 — Lower Switch Bank15 — Hood Release
4 — Hazard Switch 10 — Instrument Panel Drawer16 — Parking Brake Release
5 — Upper Glove Compartment 11 — Climate Controls
6 — Lower Glove Compartment 12 — Power Outlet/Cigar Lighter — If
Equipped
4
UNDERSTANDING YOUR INSTRUMENT PANEL 195

INSTRUMENT CLUSTER
1. Tachometer•Indicates the engine speed in revolutions per minute
(RPM x 1000). 2. Instrument Cluster Display
•When the appropriate conditions exist, this display
shows the Instrument Cluster Display messages. Refer
Base Instrument Clusters
196 UNDERSTANDING YOUR INSTRUMENT PANEL

to “Instrument Cluster Display” in “Understanding
Your Instrument Panel” for further information.
3. Speedometer •Indicates vehicle speed.
4. Fuel Gauge •The pointer shows the level of fuel in the fuel tank
when the ignition is in the ON/RUN position.
•
The fuel pump symbol points to the side of the
vehicle where the fuel door is located.
5. Temperature Gauge
•The temperature gauge shows engine coolant tem-
perature. Any reading within the normal range indi-
cates that the engine cooling system is operating
satisfactorily.
• The gauge pointer will likely indicate a higher tem-
perature when driving in hot weather, up mountain
grades, or when towing a trailer. It should not be
allowed to exceed the upper limits of the normal
operating range.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call an authorized dealer for
service if your vehicle overheats. If you decide to look
under the hood yourself, see “Maintaining Your Ve-
hicle”. Follow the warnings under the Cooling System
Pressure Cap paragraph.
CAUTION!
Driving with a hot engine cooling system could dam-
age your vehicle. If the temperature gauge reads “H”
pull over and stop the vehicle. Idle the vehicle with the
air conditioner turned off until the pointer drops back
into the normal range. If the pointer remains on the
“H”, turn the engine off immediately and call an
authorized dealer for service.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 197

1. Tachometer•Indicates the engine speed in revolutions per minute
(RPM x 1000).
2. Voltmeter •When the engine is running, the gauge indicates the
electrical system voltage. The pointer should stay within the normal range if the battery is charged. If the
pointer moves to either extreme left or right and
remains there during normal driving, the electrical
system should be serviced.
Premium Instrument Clusters
198 UNDERSTANDING YOUR INSTRUMENT PANEL
