remote start Ram 5500 Chassis Cab 2011 Owner's Guide

make your selection, press and release the SELECT
button until a check-mark appears next to the feature
showing the system has been activated or the check-mark
is removed, showing the system has been deactivated.
Remote Start Comfort Sys.
When this feature is selected and the remote start is
activated, the heated steering wheel and driver heated
seat features will automatically turn on in cold weather.
In warm weather, the driver vented seat feature will
automatically turn on when the remote start is activated.
These features will stay on through the duration of
remote start or until the key is turned to RUN. To make
your selection, press and release the SELECT button until
a check-mark appears next to the feature showing the
system has been activated or the check-mark is removed,
showing the system has been deactivated.
Compass Variance
Refer to “Compass Display” for more information.
Calibrate Compass
Refer to “Compass Display” for more information.
MEDIA CENTER 730N/430 (RER/RBZ) — AM/FM
STEREO RADIO AND CD/DVD/HDD/NAV — IF
EQUIPPED
NOTE:The sales code is located on the lower right side
of the unit’s faceplate.
The RER and RBZ radios contain a CD/DVD player, USB
port, and a 30-gigabyte hard drive (HDD). Sirius Satellite
Radio is optional. The 6.5 in (16.5 cm) touch screen allows
for easy menu selection.
The RER radio also contains a Global Positioning System
(GPS)-based Navigation system.
Refer to your Uconnect™ Multimedia RER or RBZ user’s
manual for detailed operating instructions.
210 UNDERSTANDING YOUR INSTRUMENT PANEL

Front Blower Control
There are four blower speeds. Use this
control to regulate the amount of air
forced through the system in any
mode you select. The blower speed
increases as you move the control
clockwise from the OFF position.
NOTE: For vehicles equipped with Remote Start, the
climate controls will not function during Remote Start
operation if the blower control is left in the OFF position.
Temperature Control
Use this control to regulate the tem-
perature of the air inside the passenger
compartment. Rotating the knob coun-
terclockwise, from top center into the
blue area of the scale, indicates cooler temperatures. Rotating the knob clockwise, into the red
area, indicates warmer temperatures.
NOTE:
If your air conditioning performance seems
lower than expected, check the front of the A/C con-
denser (located in front of the radiator), for an accumu-
lation of dirt or insects. Clean with a gentle water spray
from behind the radiator and through the condenser.
Fabric front fascia protectors may reduce airflow to the
condenser, reducing air conditioning performance.
Mode Control (Air Direction)
Mode control allows you to choose
from several patterns of air distribu-
tion. You can select either a primary
mode, as identified by the symbols, or
a blend of two of these modes. The
closer the control is to a particular
mode, the more air distribution you
receive from that mode.
250 UNDERSTANDING YOUR INSTRUMENT PANEL

Tire Inflation Pressure – 4500/5500 with Steel
Carcass Ply Tires
This type of tire utilizes steel cords in the sidewall. As
such, they cannot be treated like normal light truck tires.
Adjusting tire pressure must be performed by personnel
trained, supervised and equipped accordingly.Inflation Pressure Adjustment When Mounted to
Vehicle
During procedures when adding tire inflation pressure,
the technician or individual must utilize a remote infla-
tion device, and ensure that all persons are clear of the
trajectory area.
310 STARTING AND OPERATING

When adjusting inflation pressure to a tire and wheel
assembly mounted on a vehicle, use a Remote Mount
Automatic Inflation Kit or see your authorized dealer.
NOTE:Never attempt to re-inflate a tire and wheel
assembly which has been run flat or is extremely under-
inflated without first removing the tire from the wheel
assembly for inspection.
Personnel trained, supervised, and equipped according
to Federal Occupational Safety and Health Administra-
tion (OSHA) should perform this work.
Inflation Pressure Adjustment When Not Mounted to
Vehicle
When adjusting inflation pressure to a tire and wheel
assembly not mounted on a vehicle, use a Remote Mount
Automatic Inflation Kit and a Tire Inflation Cage or see
your authorized dealer.Tire Pressures for High Speed Operation
The manufacturer advocates driving at safe speeds
within posted speed limits. Where speed limits or condi-
tions are such that the vehicle can be driven at high
speeds, maintaining correct tire inflation pressure is very
important. Increased tire pressure and reduced vehicle
loading may be required for high-speed vehicle opera-
tion. Refer to original equipment or an authorized tire
dealer for recommended safe operating speeds, loading
and cold tire inflation pressures.
WARNING!
High speed driving with your vehicle under maxi-
mum load is dangerous. The added strain on your
tires could cause them to fail. You could have a
serious accident resulting in serious injury or death.
Don’t drive a vehicle loaded to the maximum capac-
ity at continuous speeds above 75 mph (120 km/h).
312 STARTING AND OPERATING

Rear Axle (Differential).................404,405
Rear Window Features .................... 170
Rear Window, Sliding ..................... 172
Reclining Front Seats ..................... 123
Recreational Towing ...................... 347
Shifting into Transfer Case Neutral (N) ....348,351
Shifting out of Transfer Case Neutral (N) . . 349,353
Reformulated Gasoline .................... 322
Refrigerant ............................ 391
Reminder, Seat Belt ....................... 48
Remote Control Starting System ........................ 25
Remote Keyless Entry (RKE) ................. 20
Remote Sound System (Radio) Controls ........ 246
Remote Starting System .................... 25
Replacement Keys ........................ 16
Replacement Parts ....................... 384
Replacement Tires ....................... 315
Reporting Safety Defects ................... 452 Resetting Oil Change Indicator
...........185,199
Restraint, Head ......................... 124
Restraints, Child ....................... 61,66
Restraints, Occupant ...................... 37
Rotation, Tires .......................... 319
Safety Checks Inside Vehicle ................. 74
Safety Checks Outside Vehicle ............... 75
Safety Defects, Reporting .................. 452
Safety, Exhaust Gas ....................... 74
Safety Information, Tire ................... 297
Safety Tips ............................. 73
Satellite Radio Antenna ................... 243
Satellite Radio (Uconnect studios)........... 242
Schedule, Maintenance .................... 430
Seat Belt Maintenance .................... 413
Seat Belt Reminder ....................... 48
Seat Belts .......................... 37,38,74
Adjustable Upper Shoulder Anchorage ........ 46
10
INDEX 469

Spark Plugs............................ 427
Speed Control (Cruise Control) .............. 150
Speedometer ........................... 181
Starting ............................. 25,265
Automatic Transmission ................. 265
Engine Fails to Start .................... 266
Remote .............................. 25
Starting Procedures (Gas Engines) ............ 265
Steel Carcass Ply Tires .................... 310
Steering Power ........................... 291,292
Wheel, Heated ........................ 149
Wheel, Tilt ........................... 147
Steering Wheel Mounted Sound
System Controls ......................... 246
Storage Compartment, Center Seat ........... 166
Storage, Vehicle ...................... 259,419
Storing Your Vehicle ...................... 419
Supplemental Tire Pressure Information ........ 317Synthetic Engine Oil
...................... 388
System, Remote Starting .................... 25
Tachometer ............................ 180
Temperature Control, Automatic (ATC) ........ 253
Temperature Gauge, Engine Coolant .......... 180
Tether Anchor, Child Restraint .............64,68
Tilt Steering Column ..................... 147
Tip Start .............................. 266
Tire and Loading Information Placard ......303,317
Tire Identification Number (TIN) ............. 301
Tire Markings .......................... 297
Tire Safety Information .................... 297
Tires ............................ 75,307,454
Aging (Life of Tires) .................... 314
Air Pressure .......................... 307
Chains .............................. 317
Dual ............................ 320,366
General Information .................... 307
10
INDEX 471
