General Information
The following regulatory statement applies to all radio
frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, in-cluding interference that may cause undesired opera-
tion.
NOTE: Changes or modifications not expressly approved
by the party responsible for compliance could void the
user ’s authority to operate the equipment.
VEHICLE SECURITY ALARM
The Vehicle Security Alarm monitors the vehicle doors and
ignition for unauthorized operation. When the Vehicle
Security Alarm is activated, interior switches for door locks
are disabled. The system provides both audible and visible
signals for the first three minutes. The horn will sound, the
headlights will turn on, the park lamps and/or turn signals
will flash and Vehicle Security Light will flash repeatedly. For an additional 15 minutes only, the headlights will turn
on, the park lamps and/or turn signals, and Vehicle
Security Light will flash.
Rearming Of The System
The Vehicle Security Alarm will rearm itself after the 15
additional minutes of headlights and Vehicle Security Light
flashing, if the system has not been disabled. If the condi-
tion which initiated the alarm is still present, the system
will ignore that condition and monitor the remaining doors
and ignition.
To Arm The System
Follow these steps to arm the Vehicle Security Alarm:
1. Remove the key from the ignition system (refer to
Starting Procedures inStarting And Operating for
further information).
• For vehicles equipped with Keyless Enter-N-Go —
Ignition, make sure the vehicle ignition system is
OFF.
• For vehicles not equipped with Keyless Enter-N-Go —
Ignition, make sure the vehicle ignition system is
OFF and the key is physically removed from the
ignition.
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
Page 23 of 534
remain armed when the battery is reconnected; the exterior
lights will flash, and the horn will sound. If this occurs,
disarm the Vehicle Security Alarm.
Security System Manual Override
The Vehicle Security Alarm will not arm if you lock the
doors using the manual door lock plunger.
ILLUMINATED APPROACH
The courtesy lights will turn on when you use the key fob
to unlock the doors or open any door.
This feature also turns on the approach lighting in the
outside mirrors (if equipped). Refer to “Mirrors” in “Un-
derstanding The Features Of Your Vehicle” for further
information.
The lights will fade to off after approximately 30 seconds,
or they will immediately fade to off once the ignition
switch is turned to ON/RUN from the OFF position.
The front courtesy overhead console and door courtesy
lights will not turn off if the dimmer control is in the
“Dome ON” position (rotate horizontal thumb wheel on
the bottom of the switch to the far right detent position).The illuminated entry system will not operate if the
dimmer control is in the “Dome OFF” position (rotate
horizontal thumb wheel on the bottom of the switch to the
far left detent position).
NOTE:
If your vehicle is equipped with illuminated ap-
proach lights under the outside mirrors, they can be turned
off by using the Instrument Cluster Display controls (if
NOT equipped with a touchscreen radio) or the Uconnect
radio (if equipped with a touchscreen radio). Refer to
“Instrument Cluster Display” or “Uconnect Settings” in
“Understanding Your Instrument Panel” for further infor-
mation.
REMOTE KEYLESS ENTRY
The Remote Keyless Entry system allows you to lock or
unlock all doors, tailgate, and the RamBox (if equipped) as
well as activate the Panic Alarm from distances up to
approximately 66 ft (20 m) using a hand-held radio key fob
with integrated key. The key fob does not need to be
pointed at the vehicle to activate the system. Push and
release the LOCK button on the key fob to lock all doors,
the tailgate and the RamBox (if equipped). The turn signal
lights will flash and the horn will chirp to acknowledge the
signal.
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21
Page 24 of 534
NOTE:Inserting the key fob into the ignition switch
disables the system from responding to any button pushes
from that key fob. Driving at speeds 5 mph (8 km/h) and
above disables the system from responding to all key fob
buttons for all key fobs.
Remote Unlock The Doors
Push and release the UNLOCKbutton on the key fob
once to unlock the driver ’s door. Push the unlock
button twice within five seconds to unlock all doors,
the tailgate and the RamBox (if equipped). The turn
signal lights will flash to acknowledge the unlock
signal. The illuminated entry system will also turn on.
NOTE: The Instrument Cluster Display or Uconnect Set-
tings are setup for driver door first, otherwise this will
unlock all doors.
Remote Keyless Entry Key Fob (IGNM)
Key Fob Keyless Enter-N-Go
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 25 of 534
Remote Key Unlock, Driver Door/All Doors First
This feature lets you program the system to unlock either
the driver’s door or all doors on the first push of the
UNLOCK button on the key fob. To change the current
setting, proceed as follows:
•For vehicles not equipped with a touchscreen radio,
refer to Customer-Programmable Features” in “Under-
standing Your Instrument Panel” for further informa-
tion.
• For vehicles equipped with a touchscreen radio, refer to
“Uconnect Settings” in “Understanding Your Instrument
Panel” for further information.
NOTE: Pushing the LOCK button on the key fob while you
are inside the vehicle will activate the Vehicle Security
Alarm System. Opening a door with the Vehicle Security
Alarm System activated will cause the alarm to sound.
Push the UNLOCK button to deactivate the Vehicle Secu-
rity Alarm System.
Flash Lamps With Remote Key Lock
This feature will cause the turn signal lights to flash when
the doors are locked or unlocked with the key fob. This
feature can be turned on or turned off. To change the
current setting, proceed as follows: •
For vehicles not equipped with a touchscreen radio,
refer to Settings/Customer-Programmable Features in
“Understanding Your Instrument Panel” for further in-
formation.
• For vehicles equipped with a touchscreen radio, refer to
“Uconnect Settings” in “Understanding Your Instrument
Panel” for further information.
To Lock The Doors
Push and release the LOCKbutton on the key fob to
lock all doors, the tailgate and the RamBox (if
equipped). The turn signal lights will flash and the horn
will chirp to acknowledge the signal.
Sound Horn With Remote Key Lock
This feature will cause the horn to chirp when the doors are
locked with the key fob. This feature can be turned on or
turned off. To change the current setting, proceed as
follows:
• For vehicles not equipped with a touchscreen radio,
refer to Settings/Customer-Programmable Features in
“Understanding Your Instrument Panel” for further in-
formation.
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
Page 26 of 534
•For vehicles equipped with a touchscreen radio, refer to
“Uconnect Settings” in “Understanding Your Instrument
Panel” for further information.
NOTE: Pushing the LOCK
button on the key fob
while you are in the vehicle will activate the Vehicle
Security Alarm System. Opening a door with the Vehicle
Security Alarm System activated will cause the alarm to
sound. Push the UNLOCK
button to deactivate the
Vehicle Security Alarm System.
Using The Panic Alarm
To turn the Panic Alarm feature ON or OFF, push and hold
the
button on the key fob for at least one second and
release. When the Panic Alarm is on, the headlights will
turn on, the park lights will flash, the horn will pulse on
and off, and the turn signal lights will flash.
The Panic Alarm will stay on for three minutes unless you
turn it off by either pushing the
button a second time
or drive the vehicle at a speed of 5 mph (8 km/h) or
greater.
NOTE:
• The interior lights will turn off if you turn the ignition
switch to the ACC or ON/RUN position while the Panic
Alarm is activated. However, the exterior lights and
horn will remain on.
• You may need to be less than 35 ft (11 m) from the
vehicle when using the key fob to turn off the Panic
Alarm due to the radio frequency noises emitted by the
system.
Programming Additional Key Fobs
If you do not have a programmed key fob, contact your
authorized dealer for details.
Key Fob Battery Replacement
The recommended replacement battery is one CR2032
battery.
NOTE:
• Perchlorate Material — special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
• Do not touch the battery terminals that are on the back
housing or the printed circuit board.
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 44 of 534
Enhanced Seat Belt Use Reminder System (BeltAlert)
Driver and Passenger BeltAlert (If Equipped)
BeltAlert is a feature intended to remind the driver
and outboard front seat passenger (if equipped with
outboard front passenger seat BeltAlert) to buckle their
seat belts. The Belt Alert feature is active whenever the
ignition switch is in the START or ON/RUN position.
Initial Indication
If the driver is unbuckled when the ignition switch is first
in the START or ON/RUN position, a chime will signal for
a few seconds. If the driver or outboard front seat passen-
ger (if equipped with outboard front passenger seat
BeltAlert) is unbuckled when the ignition switch is first in
the START or ON/RUN position the Seat Belt Reminder
Light will turn on and remain on until both outboard front
seat belts are buckled. The outboard front passenger seat
BeltAlert is not active when an outboard front passenger
seat is unoccupied.
BeltAlert Warning Sequence
The BeltAlert warning sequence is activated when the
vehicle is moving above a specified vehicle speed range
and the driver or outboard front seat passenger is unbuck-
led (if equipped with outboard front passenger seat BeltAlert) (the outboard front passenger seat BeltAlert is
not active when the outboard front passenger seat is
unoccupied). The BeltAlert warning sequence starts by
blinking the Seat Belt Reminder Light and sounding an
intermittent chime. Once the BeltAlert warning sequence
has completed, the Seat Belt Reminder Light will remain on
until the seat belts are buckled. The BeltAlert warning
sequence may repeat based on vehicle speed until the
driver and occupied outboard front seat passenger seat
belts are buckled. The driver should instruct all occupants
to buckle their seat belts.
Change Of Status
If the driver or outboard front seat passenger (if equipped
with outboard front passenger seat BeltAlert) unbuckles
their seat belt while the vehicle is traveling, the BeltAlert
warning sequence will begin until the seat belts are buck-
led again.
The outboard front passenger seat BeltAlert is not active
when the outboard front passenger seat is unoccupied.
BeltAlert may be triggered when an animal or other items
are placed on the outboard front passenger seat or when
the seat is folded flat (if equipped). It is recommended that
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 100 of 534
WARNING!(Continued)
interference with the accelerator, brake, or clutch
pedals then re-install the floor mats.
• It is recommended to only use mild soap and water
to clean your floor mats. After cleaning, always check
your floor mat has been properly installed and is
secured to your vehicle using the floor mat fasteners
by lightly pulling mat.
Periodic Safety Checks You Should Make Outside
The Vehicle
Tires
Examine tires for excessive tread wear and uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread or sidewall. Inspect the tread for cuts
and cracks. Inspect sidewalls for cuts, cracks, and bulges.
Check the wheel bolts for tightness. Check the tires (includ-
ing spare) for proper cold inflation pressure.
Lights
Have someone observe the operation of brake lights and
exterior lights while you work the controls. Check turn
signal and high beam indicator lights on the instrument
panel.
Door Latches
Check for proper closing, latching, and locking.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
engine coolant, oil, or other fluid leaks. Also, if gasoline
fumes are detected or if fuel, power steering fluid (if
equipped), or brake fluid leaks are suspected. The cause
should be located and corrected immediately.
98 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 102 of 534
LIGHTS ............................. .129
▫ Headlights .......................... .130
▫ Automatic Headlights — If Equipped ........130
▫ Headlights On With Wipers (Available With
Automatic Headlights Only) ...............131
▫
Daytime Running Lights (DRL) — If Equipped . .131
▫ Headlight Delay ....................... .131
▫ Automatic High Beam Headlamp Control — If
Equipped ........................... .132
▫ Parking Lights And Panel Lights ............133
▫ Fog Lights — If Equipped ................133
▫ Lights-On Reminder .....................134
▫ Battery Saver ......................... .134
▫ Interior Lights ........................ .134
▫ Cargo Light ......................... .137
▫ Multifunction Lever ....................137
▫ Turn Signals ......................... .137
▫ Lane Change Assist .....................138 ▫
Flash-To-Pass ........................ .138
▫ High/Low Beam Switch .................138
WINDSHIELD WIPERS AND WASHERS .......138
▫ Windshield Wipers .....................138
▫ Windshield Wiper Operation ...............139
▫ Intermittent Wiper System ................139
▫ Windshield Washers ....................139
▫ Mist Feature ......................... .140
▫ Rain Sensing Wipers — If Equipped .........140
TILT STEERING COLUMN .................142
DRIVER ADJUSTABLE PEDALS —
IF EQUIPPED ......................... .142
HEATED STEERING WHEEL — IF EQUIPPED . .144
ELECTRONIC SPEED CONTROL ............145
▫ To Activate .......................... .146
▫ To Set A Desired Speed ...................146
▫ T
o Deactivate ........................ .146
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 133 of 534
Headlights On With Wipers (Available With
Automatic Headlights Only)
When this feature is active, the headlights will turn on
approximately 10 seconds after the wipers are turned on if
the headlight switch is placed in the AUTO position. In
addition, the headlights will turn off when the wipers are
turned off, if they were turned on by this feature.
NOTE:If your vehicle is equipped with a touchscreen, this
feature can be programmed through the Uconnect system.
Refer to “Uconnect Settings” in “Understanding Your
Instrument Panel” for further information.
If your vehicle is not equipped with a touchscreen, this
feature can be programmed through the instrument cluster
display. Refer to “Instrument Cluster Display” in “Under-
standing Your Instrument Panel” for further information.
Daytime Running Lights (DRL) — If Equipped
The headlights on your vehicle will illuminate when the
engine is started and the transmission is in any gear except
PARK. This provides a constant Lights ONcondition
until the ignition is turned OFF. The lights illuminate at less
than 50% of normal intensity. If the parking brake is
applied, the Daytime Running Lights (DRL) will turn OFF. Also, if a turn signal is activated, the DRL lamp on the
same side of the vehicle may turn off for the duration of the
turn signal activation. Once the turn signal is no longer
active, the DRL lamp will illuminate.
Headlight Delay
To aid in your exit, your vehicle is equipped with a
headlight delay that will leave the headlights on for
approximately up to 90 seconds. This delay is initiated
when the ignition is turned OFF while the headlight switch
is on, and then the headlight switch is cycled off. Headlight
delay can be cancelled by either turning the headlight
switch on then off, or by turning the ignition ON.
NOTE:
If your vehicle is equipped with a touchscreen, this
feature can be programmed through the Uconnect system.
Refer to “Uconnect Settings” in “Understanding Your
Instrument Panel” for further information.
If your vehicle is not equipped with a touchscreen, this
feature can be programmed through the instrument cluster
display. Refer to “Instrument Cluster Display” for further
information.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131
Page 139 of 534
Cargo Light
The cargo light is turned on by pushing on the cargo light
button.
The cargo light will also turn on for approximately 60
seconds when a key fob UNLOCK button is pushed, as
part of the Illuminated Entry feature.
Multifunction Lever
The multifunction lever is located on the left side of the
steering column.
Turn Signals
Move the multifunction lever up or down and the arrows
on each side of the instrument cluster display will flash to
show proper operation of the front and rear turn signal
lights.
NOTE:If either light remains on and does not flash, or
there is a very fast flash rate, check for a defective outside
light bulb. If an indicator fails to light when the lever is
moved, it would suggest that the indicator bulb is defec-
tive.
Cargo Light Button
Turn Signal Lever
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137
